Mantis Swift Split Owner's Manual And Safety Instructions page 20

O. Parts List
ITEM NO. PART NO. DESCRIPTION
1 520100 CART BOTTOM ASSEMBLY
WELDED AND PAINTED
2 520500 M10, CARRIAGE BOLT, SQ NECK,
60MM LG
3 520101 KNOB
4 520102 WHEEL 10 INCH DIA
5 520103 HANDLE UPPER SUB-ASSEMBLY
PAINTED
6 520104 STABILIZING BAR/PIVOTING SUPPORT 1
7 520105 CONNECTING LINK
8 520501 BOLT HEX M6 X 40MM
9 520502 NUT LOCK M6, NYLON INSERT
10 520106 SOLENOID PROTECTION BRACE
11 520503 WASHER #6
12 520504 BOLT HEX M6 X 15MM
13 520107 END CAP
14 520505 BOLT HEX M6 X 30MM
15 520108 PROTECTIVE BRACE
16 520506 WASHER 4MM DIA
17 520507 SCREW M4 X 35MM
18 520508 NUT M4
19 520109 SWITCH BOX ASSEMBLY 110V
WITH STRAIN RELIEF OPENING
20 520509 NUT M16 (THIN)
21 520110 MOTOR ASSEMBLY 110V
22 520111 HYDRAULIC ASSEMBLY
23 510601 WARNING LABEL
24 520112 DIP STICK
25 520113 DIP STICK SEAL
26 520114 AIR BLEED SCREW
27 520115 DRAIN PLUG SEAL
28 520116 WHEEL SHAFT
29 520510 M14 WHEEL NUT
30 520134 SWITCH BOX ASSEMBLY 110V
WITHOUT STRAIN REL OPENING
31 520117 CABLE TIE 152MM (6") LONG
19
QTY ITEM NO. PART NO. DESCRIPTION
32 510600
1
33 520118
41 520200
2
61 520220
2
111 520516
2
520109
1
34 520119
35 520120
2
36 520121
2
37 520122
6
38 520511
1
520134
4
2
114 520135
2
2 35 520120
1 36 520121
4 38 520511
2
2 97 520110
98 520123
1
99 520124
2
100 520514
1
37 520122
1
102 520126
1
37 520122
1
104 520128
1
105 520129
1
107 520130
1
108 520131
2
109 520132
2
38 520511
113 520133
1
1
SWIFT SPLIT LOGO LABEL
SWITCH PROTECTIVE COVER
BLEED SCREW SEAL
DRAIN PLUG, M10 X 8MM THREAD
ALLEN WRENCH #8 (DRAIN PLUG)
SWITCH BOX ASSEMBLY WITH
STRAIN RELIEF OPENING
SWITCH BOX
SWITCH BOX COVER
SWITCH 110V
STRAIN RELIEF (SWITCH BOX)
SCREW SELF TAPPING 3.2X16 LONG 4
SWITCH BOX ASSEMBLY WITHOUT
STRAIN RELIEF OPENING
SWITCH BOX WITHOUT STRAIN
REL OPENING
SWITCH BOX COVER
SWITCH 110V
SCREW SELF TAPPING 3.2X16 LONG 4
MOTOR ASSEMBLY
MOTOR, 110V
WIRE CLAMP
15 AMP CIRCUIT BREAKER
C/B NUT
STRAIN RELIEF (SWITCH BOX)
CORD (OUTDOOR USE)
STRAIN RELIEF (SWITCH BOX)
RUBBER FEET COVER
CAPACITOR 300VAC
GASKET (MOTOR JUNCTION BOX)
MOTOR JUNCTION BOX
LID
SCREW SELF TAPPING 3.2X16 LONG 8
STRAIN RELIEF
QTY
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
