Summary of Contents for Leupold Tactical
- Page 1 Tactical Binocular USER GUIDE...
- Page 2 Using Your Leupold ® Tactical Binocular Using your Leupold Tactical binocular is very simple. However, you must set them to match your eyesight before use. This is done by adjusting the interpupillary distance and focusing the binoculars to your own visual acuity.
- Page 3 SETTING THE DIOPTER ADJUSTMENT Setting the diopter adjustment of your binocular properly is very important, as properly adjusted binoculars will prevent eye strain and provide you with a crisp, sharp image. TO SET THE DIOPTER ADJUSTMENT ON RIGHT EYEPIECE DIOPTER ADJUSTMENT MODELS: 1.
- Page 4 3. Cover the left objective lens with your hand. 4. Adjust the center focus wheel (located between the two barrels) until the image presented to your right eye is clear and sharp. 5. Cover the right objective lens with your hand. 6.
- Page 5 To range with the Mil-L reticle, follow the instructions for the Leupold Mil Dot and TMR reticles listed in the Tactical Milling Reticle instruction manual. CLEANING You can clean the fully armored body by simply wiping off any accumulated dirt or dust.
- Page 6 Leupold’s plant in Oregon. The goal is to provide you with reliable performance at a reasonable price. If your Leupold Tactical binocular fails to perform in any way, you may return it directly to the factory for service. We recommend contacting Leupold Technical Service at 1-800-Leupold (538-7653), and following these shipping instructions: 1.
- Page 7 Germany: Harold Ros, Coburger Strasse 71, 98673 Eisfeld, Germany Sweden: HDF Gyttorp Jakt AB, Svarvaregatan 5, S-302 50 Halmstad, Sweden Our Product Service telephone numbers are (503) 526-1400 or (800) LEUPOLD (538-7653), fax is (503) 352-7621. They can also be contacted through our...
- Page 8 Leupold Tactical Products Warranty Warranties on Leupold Tactical optical products may vary depending on use and other factors.
- Page 9 Leupold & Stevens, Inc. All marks, including corporate logos and emblems, are subject to Leupold’s rights and may not be used in connection with any product or service that is not Leupold’s, or in any manner that disparages or discredits Leupold, or in a manner likely to cause confusion.
- Page 10 Notes...
- Page 11 Notes...
