Shipping contents The PointWrite is a built in Interactive Whiteboard on the projector. To use the PointWrite correctly, please find the standard accessories below and follow the instructions in this manual. PointWrite Installation CD Quick manual Two PointWrite pens Mini USB cable...
Attaching the PointWrite to the projector Attach the PointWrite to the projector as illustrated and tighten the screw to secure the PointWrite. Attach the PointWrite to the projector as illustrated. Tighten the screw to secure the PointWrite. Attaching the PointWrite to the projector...
Connecting the PointWrite to PC Use the USB cable to connect the PointWrite to PC. Plug the USB mini-B end into the PointWrite and plug the USB type-A end into PC. Pen action The PointWrite Pen provides the following 4 actions: Click: Touch an icon or a menu on the screen.
Driver Installation Insert the PointWrite CD into your CD/DVD-ROM driver. The Installation assistant will run automatically. Follow the instructions on the screen. If the assistant does not run automatically, double click on the “setup.exe” under CD/DVD-ROM directory and the Installation assistant will display.
Page 7
, the PointWrite icon appears on the system tray area. • Click on the PointWrite icon on system tray area and a popup menu will appear. When using the PointWrite for the first time, the configuration window will appear on the desktop to help you configure the PointWrite.
Configuration setting The PointWrite configuration To use the PointWrite, the proper setting of the PointWrite configuration is needed. The Configuration setting window will help you to set up PointWrite correctly. PointWrite configuration: Adjust the setting according to your projector. PointWrite Language: The default language is the same as the language for your operating system.
Alignment View The PointWrite Alignment function is to set the orientation of the PointWrite to the screen. Alignment View: When clicking on the “Alignment View”, the screen image is displayed on the alignment view box (central black box). If the screen image is not in the center, the calibration will fail. Please make sure the PointWrite module is attached to the projector properly.
PointWrite Calibration PointWrite provides two kinds of calibration methods: auto calibration and manual calibration. Auto calibration : click on and the calibration process will run automatically. When you choose this method, white image is shown on the screen and the pattern image is displayed.
Page 11
Click on and the calibration window will be projected on the screen. Use the PointWrite pen to click on the center of calibration cursor immediately after it appears. Then the next cursor will display. Repeat this process until the last calibration cursor disappears.
PointWrite icon will be created on the system tray area. Right click on the PointWrite icon on the system tray area and a pull-up menu appears. Configuration: Choose this when you want to change the installation position of the projector.
Windows: WinXP, Vista, 7, 8 OS Supported Mac: Snow Leopard or later Storage Temperature -20°C ~ 60°C Operating Temperature 5°C ~ 40°C PointWrite Pen e t i The accuracy of auto calibration will be impacted depending on your environment. Speci cations...
