Summary of Contents for Haier HBR-1301AA

  • Page 1 HBR-1301AA Built under larder fridge...
  • Page 2 USER MANUAL FOR YOUR HAIER HBR-1301AA Built under larder fridge NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference. for you or any person not familiar with the operation of the appliance.

  • Page 3: Table Of Contents

    Contents Environmental note Important safety information 5 – 6 Specifications of your larder fridge Description of the appliance Description of the product features 9 - 10 Using your Baumatic larder fridge 10 - 12 Before switching on During first use 10 - 11 Switching on the appliance and setting the thermostat 11 - 12...

  • Page 4: Environmental Note

    Environmental note Note : Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person. Disable the door lock to make sure that children cannot get stuck inside the appliance.

  • Page 5: Important Safety Information

    Important safety information Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Baumatic Advice Line.
  • Page 6 Child safety o Packaging material should be kept away from children. o Children should not be allowed to touch the controls or play with the appliance. General safety o Do not pull on the power supply cable to remove the plug from your mains supply socket.

  • Page 7: Specifications Of Your Larder Fridge

    Specifications of your larder fridge Dimensions of appliance Dimensions of aperture* Height: 818 - 868 mm Height: 820 – 870 mm Width: 596 mm Width: 600 mm Depth: 550 mm Depth: 560 mm (min) o Automatic fridge defrost o Adjustable thermostat o 3 Safety glass shelves o 2 Salad crispers o Bottle rack...

  • Page 8: Description Of The Appliance

    * Please refer to the installation instructions for more specific information on the size of aperture that you will require. IMPORTANT: When you install your appliance it is important to bear in mind its climatic rating. In order to find out the climatic rating of your appliance, you should check the rating plate.

  • Page 9: Description Of The Product Features

    Description of the product features (Please note that this drawing is for illustrative purposes only and does not accurately show the interior of the appliance). 1) Shelves o The shelves may be placed in any of the guide slots within the interior of the appliance.

  • Page 10: Using Your Baumatic Larder Fridge

    IMPORTANT: IT IS IMPORTANT THAT NONE OF THE SHELVES THAT SIT IN THE DOOR ARE OVERLOADED, AS THIS WILL DRASTICALLY REDUCE THEIR WORKING LIFE. Using your Haier larder fridge Before switching on o Make sure that it has been installed by a suitably qualified person, as per the information contained in Baumatic’s...

  • Page 11: Switching On The Appliance And Setting The Thermostat

    o If the unit is switched off or unplugged, you must allow at least 5 minutes before restarting the appliance on the thermostat or connecting it to your mains supply. Switching on the appliance and setting the thermostat You switch on your appliance by connecting it to your mains supply and setting the thermostat.

  • Page 12: Arranging And Storing Food In Your Refrigerator

    o IMPORTANT: Do not run the appliance with the thermostat above number 5 in normal usage otherwise the defrost drain hole will freeze. Arranging and storing food in your refrigerator o Warm food or evaporating liquids should not be stored in your refrigerator, as this will increase the humidity inside of the appliance.

  • Page 13: Cleaning And Maintenance

    o Milk bottles should have a cap on them and be stored on the bottle shelf that sits in the door. o Garlic, potatoes, onions and bananas should only be stored in a refrigerator IF they are stored in airtight containers.

  • Page 14: The Defrost Drain Hole

    The defrost drain hole o Defrosting occurs automatically in the refrigerator compartment during operation. The defrost water is collected by the evaporating tray and evaporates automatically. o The drain hole should be cleaned periodically with the drain hole cleaner. This will prevent water from collecting in the bottom of the refrigerator, instead of flowing down the defrost drainage channel and drain hole.

  • Page 15: Replacing The Light Bulb

    Replacing the light bulb WARNING: PLEASE ENSURE THAT YOUR APPLIANCE IS DISCONNECTED FROM YOUR MAINS SUPPLY BEFORE ATTEMPTING TO REPLACE THE LIGHT BULB. o Press the rear end of the bulb cover until the sides release and then lift the bulb cover clear of the bulb. o Change the present light bulb with a new one.

  • Page 16: Electrical Connection

    Electrical connection YOUR REFRIGERATOR IS INTENDED FOR FITTED AND PERMANENT INSTALLATION. We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. and who will comply with the I.E.E. and local regulations. o Your refrigerator comes supplied with a 13 amp plug fitted. If in future you need to change the fuse in this plug, then a 13 amp ASTA approved (BS 1362) fuse must be used.

  • Page 17: Positioning

    The green and yellow wire must be connected to the terminal marked “E” (earth), or by the earth symbol, or coloured green and yellow. o When the connection is completed, no stray strands or cut wire should be present. The cord clamp must be secured over the outer sheath.
  • Page 18 o Slacken the retaining screws (1) on the appliance and then carefully remove the appliance door. o Place the appliance door on a cushioned surface, so that damage does not occur to it. o Lever off the cover caps (3). o Insert the retaining screws (1) into the opposite side of the appliance from their original position.
  • Page 19 o Reattach the appliance door and then fully re-tighten the retaining screws (1) and the door retaining screws (2). o Insert the cover caps (3) into the holes that are now exposed on the right hand side of the cabinet. IMPORTANT: Check that the door opens and shuts correctly, without fouling, after you have completed the door reversal process.

  • Page 20: Aperture Dimensions

    Aperture dimensions a) The diagram opposite shows the aperture size that you will need to be able to install your appliance. o The appliance must be stood on a level floor. You can use the levelling feet to take into account any minor unevenness in the floor.

  • Page 21: Fitting The Furniture Door To The Appliance

    o Use a spanner to adjust the height of the adjustable feet. o If your aperture has a height of 820 mm, then the adjustable feet should be set at a height of 30 mm. o If your aperture has a height of 870 mm, then the adjustable feet should be set at a height of 50 mm.
  • Page 22 a) Undo the screws from the two adjusting bolts that are located on the top of the appliance door and then remove the mounting bracket (1). b) Measure the width of the furniture door, at the halfway point mark a line vertically down the inner surface of the furniture door.
  • Page 23 c) Hang the furniture door onto the appliance door, making sure that the brackets on the mounting bracket locate over the adjusting bolts. c) Use a screwdriver to adjust the gap on the lower section of the adjusting bolts. The gap should be set to approximately 9 mm (as shown in the above drawing).
  • Page 24 d) Fix the lower bracket to the bottom of the furniture door and the underneath of the appliance door (as shown in the drawing on the previous page). o It is possible to make minor adjustments to the position of the furniture door using the screws on the top and the bottom of the appliance door.

  • Page 25: Troubleshooting

    Troubleshooting IMPORTANT: If your refrigerator appears not to be operating properly, before contacting the Customer Care Department, please refer to the checklist below. My fridge does not appear to be working/there is no power to my appliance. o Check that the plug is fully inserted into the power socket. o Check that there is power to your mains supply (e.g.
  • Page 26 Ice has formed on the inner back wall of my fridge o Check that food has not been pushed too far back inside the appliance, so that it is in contact with the inner back wall. o IMPORTANT: It is normal to get some ice droplets forming on the back wall of the appliance.
