Table of Contents

Advertisement

Quick Links

Download this manual
Large Underwater Pool Lights
Sta-Rite Pool/Spa Group
293 Wright Street, Delavan, WI 53115
North America: 800-752-0183, FAX 800-582-2217
International: 414-728-5551, FAX: 414-728-4461, TELEX: ITT 4970245
Union City, TN • Delavan, WI • Mississauga, Ont. • Murrieta, CA
© 1999, Sta-Rite Industries, Inc.
Sunsaver™ and Sunbrite™
O
W
N
E
INSTALLATION, OPERATION & PARTS
R ' S
M
A N
Printed in U.S.A.
U
A L
This manual should be furnished to
the end user of this light; its use will
reduce service calls and chance of
injury and will lengthen light life.
S473 (1/12/99)

Advertisement

Table of Contents
loading

Related Manuals for STA-RITE Sunsaver

Summary of Contents for STA-RITE Sunsaver

  • Page 1 293 Wright Street, Delavan, WI 53115 North America: 800-752-0183, FAX 800-582-2217 International: 414-728-5551, FAX: 414-728-4461, TELEX: ITT 4970245 Union City, TN • Delavan, WI • Mississauga, Ont. • Murrieta, CA S473 (1/12/99) © 1999, Sta-Rite Industries, Inc. Printed in U.S.A.

  • Page 2: General Safety

    READ AND Installation and maintenance of this circuit, and the light, light niche, and any other accessories attached to the cir- FOLLOW SAFETY cuit, must be performed by a qualified, licensed electri- INSTRUCTIONS! cian. This is the safety alert symbol. When you see this The complete electrical system must be installed, tested, symbol in this manual, look for one of the follow- and approved by a qualified, licensed electrician before...

  • Page 3: Installation

    3. Make connections in the junction box (be sure to fol- INSTALLATION low code requirements). Connect the supply circuit Sunsaver™ Lamp Housing Installation grounding wire (green, green and yellow, or bare cop- per) to the green ground conductor from the light fix- (Refer to Figure 2 and the Exploded View on Page 6).

  • Page 4: Specifications

    SPECIFICATIONS Sunsaver™ Large Underwater Pool Lights (U.S.) Sunbrite™ Large Underwater Lights U.S. Canada Cord Length Stainless Steel Thermoplastic Cord Length Model Model in Feet (m) Models Models in Feet (m) 12 Volts - 12 Volts - 100 Watts 100 Watts...

  • Page 5: Maintenance

    3. Tilt the fixture out of the niche, remove from the water SPECIFICATIONS and place face down on the pool deck. Sunsaver™ Large Underwater Pool Lights (Canada) 4. Place the head of a flat head screw driver into the “V” shaped space (located on the face ring), Key No. 2,...
  • Page 6 12 Volt Lamp 120 Volt Lamp Figure - 2 Sunsaver™ Lamp Exploded View REPAIR PARTS LIST – SUNSAVER™ LAMPS 05102-1402 – 1406, 05102-1422 – 1426, 05101-1382 – 2250 1800 and 2246 1534 and 1575 05101-1362 – 2248 05101-2275 – 2281 05102-2254 –...
  • Page 7 120 Volt Lamp 12 Volt Lamp Figure 3 - Replacement Parts Sunbrite™ Lamps Exploded View REPAIR PARTS LIST – SUNBRITE™ LAMPS 05501-2204 – 2210 05501-2211 – 2217 05502-1990 – 1996 05502-1997 – 2203 05501-2232 – 2238 05501-2239 – 2245 05502-2218 – 2224 05502-2225 – 2231 Part Description Qty.

  • Page 8: Warranty Registration Card

    Retain Warranty Certificate (upper portion) in a safe and convenient location for your records. DETACH HERE: Fill out bottom portion completely and mail within 10 days of purchase/installation to: Sta-Rite, Attn: Warranty Dept., 293 Wright St., Delavan, WI 53115 Warranty Registration Card...
