Streaming Music to the W Studio Micro

Your Home Network
The Wireless Collection uses your home 's Wi-Fi network to connect streaming
devices and speakers, and uses the Definitive Technology App to control
the audio streamed to each DTS Play-Fi-enabled speaker or device.
System Requirements for Basic
Streaming Connections
It all begins by building a wireless home network, preferably one with a
high-speed Internet connection. Here's what you'll need to connect your
W Studio Micro to your network:
• A high-speed Internet connection.
• A wireless router rated 802.11n or better.
• An Android device with version 2.2 operating system or newer
OR an iOS device with version 6.0 operating system or newer.
• Your wireless network password (if required).
For the Best DTS Play-Fi Experience
• For the fastest streaming performance, especially when streaming to
multiple speakers simultaneously, an 802.11ac router is recommended.
• DTS Play-Fi uses Windows 7, 8,8.1 & 10. DTS Play-Fi is not available
for XP or Vista at this time. DTS Play-Fi is not available for MAC OS X at
this time.
• Ensure your DTS Play-Fi-enabled device is within wireless reach of your
router, or that the signal is not hindered by concrete, brick, or other
dense walls. Check the quality of your connection by looking at the
Wireless Strength icon on the Definitive Technology App.
Your Wi-Fi Connection
To ensure the easiest setup during this procedure, consider placing your
W Studio Micro sound bar close to your Internet-connected wireless router.
When the setup is completed, you will be able to move your
W Studio Micro sound bar to its permanent location.
1. Use the included power cable to connect the W Studio Micro sound bar
to a nearby power outlet.
www.definitivetech.com
2. Turn the unit ON using the Power button on the front panel of the sound
bar, or on the Remote Control.
3. The rightmost White LED on the front panel will blink QUICKLY for
about 15 seconds, after which it will begin to pulse SLOWLY.
4. The slowly pulsing light means your device is ready to connect to your
Wi-Fi network.
5. If the Wi-Fi LED is not pulsing slowly, press and hold the Wi-Fi setup
button (located on the rear panel of the unit) for eight seconds, until you
hear the second tone. Your W Studio Micro sound bar is now ready to
be connected to your network.
6. Now download the Definitive Technology App from the Apple App
Store or Google Play Store.
Launch the App and follow the instructions. (See instructions on next page.)
Need Help? Get In Touch With Us!
If you have any questions, please contact us directly through our Definitive
Technology Aficionado hotline at 1-800-223-5246 or email info@
DefinitiveTech.com.
Download Our FREE Apps
Download the Definitive Technology App from the Apple App Store or
Google Play Store.
How to Set Up the
W Studio Micro on Your
Wi-Fi Network
iOS Device Instructions
1. Launch the Definitive Technology app.
2. Go to Setup > Add Play-Fi Device Click on the device and hit next
within the app to take you to setup instruction screens.
3. Exit the Definitive Technology app and go to your Settings on your
iOS device.
4. Select Wi-Fi. Ensure that Wi-Fi is enabled. Once enabled,
choose the device listed with "PlayFi2Device," followed by six
alphanumeric characters.
5. Once selected, exit the Settings menu and return to the Definitive
Technology App to select your wireless network. (If password
protected, enter your password.)
6. When your sound bar is connected to the network, the Wi-Fi light on
the front of the sound bar will change from blinking to a solid white.
7. You're connected! From here, feel free to rename your device with
one of the preset names, create your own custom name.
