S15L7, S12L7, S10L7, S8L7
Congratulations! You have just purchased one of the most advanced
subwoofers in the history of car audio. Your KICKER Solo-Baric is the latest in
KICKER's trend-setting Solo-Baric line, designed and engineered to deliver the
ultimate in low bass performance and unmatched durability when installed
in a properly designed system. Thanks for buying KICKER. Enjoy.
Cast Aluminum Basket (patent pending) for strength and to reject stray
magnetic fields
Perimeter Venting in basket for continuous voice coil cooling and highly
linear response
Highly Rigid Cone (patent pending) with high internal damping and excellent
resistance to sunlight, pollution, and moisture
Inverted Structural Dome™ further increases cone's resistance to flex
under pressure
Stitched Surround (patent pending) prevents cone/surround separation at
high excursions
Blackened Motor Parts for superior heat dissipation and long life
Dual Ultra-Length Voice Coils for high excursion and flexible wiring options
High-Temp Kapton Voice Coil Former prevents cone meltdown to minimize
warping and rubbing
One piece UniPlate™ pole piece and back plate:
Blackened Pole Piece provides effective heat transfer and cool operation for
maximum power handling
One-Piece Hyper-Extended Pole reduces non-linear magnetic fields around
the voice coil gap for even more heat sinking and excellent cone motion control
Vented Pole Piece releases pressure under dustcap for freer cone motion and
enhanced low bass
Sleeved High-Power Tinsel Lead Wires to resist lead breakage and
power-robbing resistance losses
Spring-Loaded Nickel Plated Terminals for solid connections with large gauge
speaker wire
Rubatex front and rear gaskets for airtight seal
Solo-Baric Features
Advertisement
Related Manuals for Kicker Solo-Baric S15L7
Summary of Contents for Kicker Solo-Baric S15L7
- Page 1 S15L7, S12L7, S10L7, S8L7 Congratulations! You have just purchased one of the most advanced subwoofers in the history of car audio. Your KICKER Solo-Baric is the latest in KICKER’s trend-setting Solo-Baric line, designed and engineered to deliver the ultimate in low bass performance and unmatched durability when installed in a properly designed system.
-
Page 2: Recommended Enclosures
RECOMMENDED ENCLOSURES Your Solo-Baric subwoofers are designed for massive sub-bass performance when installed in a simple sealed enclosure. Sealed boxes are known for extended low frequency capability with a smooth gradual roll off characteristic - elaborate hard-to-build boxes aren’t needed to get the best bass response. Because of the Solo-Baric's high moving mass, it is essential that the enclosure size recommendations be followed exactly. - Page 3 The following shows examples of the minimum enclosure sizes for each of the Solo-Baric L7s. Panel dimensions assume 3/4" wood thickness. Panel dimensions for minimum recommended enclosures: Model Volume (cu.ft.) Panel A Panel B Panel C S8L7 0.33 10"x10" 10"x8" 8"X8.5"...
- Page 4 BUILDING YOUR ENCLOSURE The actual construction of the enclosure is fairly simple, but some rules must be fol- lowed to make sure your cabinet is solid and airtight: Use very sturdy wood, such as 3/4" MDF (medium density fiberboard) or multi-ply marine plywood.
- Page 5 WIRING Solo-Baric L7 woofers are available with dual 2 Ohm and dual 4 Ohm voice coils. Both coils should always be hooked up. The dual 2 Ohm woofer will give you a 1 Ohm or a 4 Ohm load depending on if the coils are wired in parallel or in series.
- Page 7 NOTES...
-
Page 8: What Is Not Covered
(1) year previous to the date item is sent in. Freight must be prepaid; items received freight collect will be refused. Failure to follow these steps may void your warranty. Any questions can be directed to the Kicker Customer Service Department at (405)624-8510.
