Cordless Recipro Saw
MODEL 4390D
I N S T R U C T I O N
M A N U A L
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
w w w . m a k i t a t o o l s . c o m

Advertisement

Table of Contents
loading

Related Manuals for Makita 4390D

Summary of Contents for Makita 4390D

  • Page 1 Cordless Recipro Saw MODEL 4390D I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. w w w . m a k i t a t o o l s . c o m...

  • Page 2: Specifications

    (Outer dia. x Thickness) Battery Charger DC9700A Input A. C. only 50 Hz - 60 Hz 2. Do not operate power tools in explosive 4390D 15 mm (9/16”) 24 mm (15/16”) 12 mm (1/2”) 40 mm x 2 mm (1-5/8” x 5/64”) 2,700/min.
  • Page 3 3. Keep bystanders, children, and visitors away while operating a power tool. Distrac- tions can cause you to lose control. Electrical Safety 4. A battery operated tool with integral bat- teries or a separate battery pack must be recharged only with the specified charger for the battery.

  • Page 4: Specific Safety Rules

    SERVICE 21. Tool service must be performed only by qualified repair personnel. Service or main- tenance performed by unqualified personnel may result in a risk of injury. SPECIFIC SAFETY RULES DO NOT let comfort or familiarity with product (gained from repeated use) replace strict adherence to cordless recipro saw safety rules.
  • Page 5 (1) battery charger, (2) battery, and (3) product using battery. 3. CAUTION - To reduce risk of injury, charge only MAKITA rechargeable marked on the charger label. Other types of batteries may burst causing personal injury and damage.
  • Page 6 12. To reduce risk of electric shock, unplug charger from outlet before attempting any maintenance or cleaning. Turning off con- trols will not reduce this risk. 13. The battery charger is not intended for use by young children or infirm persons without supervision.

  • Page 7: Functional Description

    5. After charging, unplug the charger from the power source. NOTE: • The battery charger is for charging Makita battery cartridge. Never use it for other purposes or for other manufacturer’s batteries.
  • Page 8 002490 1. Lock-off lever 2. Switch trigger • If you try to charge a battery cartridge from a just operated tool, sometimes the charging light will not come on. If this occurs, let the cartridge cool off for a while. Then re-insert it and try to charge it once more. •...
  • Page 9 ASSEMBLY 002498 1. Roller 2. Blade clamp 3. Blade installing position 002499 1. Blade clamp 2. Slider 3. Spring pin 4. Pin 5. Blade shank 6. Hole 002500 1. Slider 2. Hex wrench 3. Roller 4. Blade 5. Blade clamp 6.

  • Page 10: Operation

    Always be sure that the tool is switched off and the battery cartridge is removed before attempting to perform inspection or maintenance. To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts.

  • Page 11: Recycling The Battery

    Ni-Cd ACCESSORIES Recycling the Battery The only way to dispose of a Makita battery is to recycle it. The law prohibits any other method of disposal. To recycle the battery: 1. Remove the battery from the tool. 2. a) Take the battery to your nearest Makita Factory Ser-...
  • Page 12 Memo...
  • Page 13 First-Class Postage Required Post Office will not deliver without proper postage. Makita U.S.A., Inc. 14930 Northam Street La Mirada, CA 90638-5753 Fold...
  • Page 14 Paste 3. How did you learn about this product: Magazine From Dealer Newspaper Store Display Catalog 4. Most favored points are: Design Features Size Price Makita Brand MODEL NO. YEAR SERIAL NO. PHONE 20-29 30-39 40-49 Paste Paste Radio Exhibition...

  • Page 15: Factory Service Centers

    Date Purchased When you need service: Send complete tool (prepaid) to one Dealer’s Name & Address of the Makita Factory Service Centers listed, or to an Authorized Makita Service Center. Be sure to attach a letter to the outside of Model No.

  • Page 16: Warranty Policy

    MAKITA LIMITED ONE YEAR WARRANTY Warranty Policy Every Makita tool is thoroughly inspected and tested before leaving the factory. It is warranted to be free of defects from workmanship and materials for the period of ONE YEAR from the date of original purchase.
