SERVICE MANUAL
Ver 1.0 2004. 05
• The tuner and CD sections have no adjustments.
CD player section
Signal-to-noise ratio
120 dB
Frequency response
10 – 20,000 Hz
Wow and flutter
Below measurable limit
Tuner section
FM
Tuning range
FM tuning interval:
50 kHz/200 kHz switchable
87.5 – 108.0 MHz (at 50 kHz step)
87.5 – 107.9 MHz (at 200 kHz step)
Antenna terminal
External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Usable sensitivity
9 dBf
Selectivity
75 dB at 400 kHz
Signal-to-noise ratio
67 dB (stereo),
69 dB (mono)
Harmonic distortion at 1 kHz
0.5% (stereo),
0.3% (mono)
Separation
35 dB at 1 kHz
Frequency response
30 – 15,000 Hz
AM
Tuning range
AM tuning interval:
9 kHz/10 kHz switchable
531 – 1,602 kHz (at 9 kHz step)
530 – 1,710 kHz (at 10 kHz step)
Antenna terminal
External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
AM: 30 µV
Sensitivity
Sony Corporation
9-877-870-01
2004E04-1
e Vehicle Company
© 2004. 05
Published by Sony Engineering Corporation
CDX-F5500M
Model Name Using Similar Mechanism
CD Drive Mechanism Type
Optical Pick-up Name
SPECIFICATIONS
Power amplifier section
Outputs
Speaker impedance
Maximum power output 52 W × 4 (at 4 ohms)
General
Outputs
Inputs
Tone controls
Power requirements
Dimensions
Mounting dimensions
Mass
Supplied accessories
Design and specifications are subject to change without
notice.
FM/AM COMPACT DISC PLAYER
E Model
CDX-F5500
MG-611MA-186//Q
KSS1000E
Speaker outputs
(sure seal connectors)
4 – 8 ohms
Audio outputs terminal
(front, rear/sub switchable)
Power antenna/aerial relay control terminal
Power amplifier control terminal
Telephone ATT control terminal
Remote controller input terminal
BUS control input terminal
BUS audio input terminal
Antenna/aerial input terminal
Low: ±10 dB at 60 Hz (XPLOD)
Mid: ±10 dB at 1 kHz (XPLOD)
High: ±10 dB at 10 kHz (XPLOD)
12 V DC car battery
(negative ground)
Approx. 178 × 50 × 181 mm
(w/h/d)
Approx. 182 × 53 × 161 mm
(w/h/d)
Approx. 1.2 kg
Card remote commander RM-X115
Parts for installation and connections (1 set)
Front panel case (1)
1
Advertisement
Table of Contents
Related Manuals for Sony CDX-F5500M
Summary of Contents for Sony CDX-F5500M
-
Page 1: Specifications
External antenna connector Intermediate frequency 10.7 MHz/450 kHz Design and specifications are subject to change without AM: 30 µV Sensitivity notice. FM/AM COMPACT DISC PLAYER Sony Corporation 9-877-870-01 2004E04-1 e Vehicle Company © 2004. 05 Published by Sony Engineering Corporation... - Page 2 COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
- Page 3 CDX-F5500M Notes on CD-Rs (recordable CDs)/CD-RWs (rewritable UNLEADED SOLDER CDs) Boards requiring use of unleaded solder are printed with the lead This unit can play the following discs: free mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size.)
-
Page 4: Table Of Contents
CDX-F5500M TABLE OF CONTENTS 1. GENERAL Location of controls ..............5 Card remote commander RM-X115 ........5 Connections ................6 2. DISASSEMBLY 2-1. Sub Panel Assy ..............7 2-2. CD Mechanism Block ............8 2-3. Main Board ................. 8 2-4. Chassis (T) Sub Assy ............9 2-5. -
Page 5: General
CDX-F5500M SECTION 1 GENERAL This section is extracted from instruction manual. -
Page 6: Connections
CDX-F5500M Connections... -
Page 7: Disassembly
CDX-F5500M SECTION 2 DISASSEMBLY Note : This set can be disassemble according to the following sequence. 2-1. SUB PANEL ASSY (Page 7) 2-2. CD MECHANISM BLOCK (Page 8) 2-10. SERVO BOARD 2-3. MAIN BOARD 2-4. CHASSIS (T) SUB ASSY (Page 12) -
Page 8: Cd Mechanism Block
CDX-F5500M 2-2. CD MECHANISM BLOCK 7 bracket (CD) 5 CD mechanism block 6 two screws (+PTT 2.6 x 4) 2 screw (+PTT 2.6 x 6) 1 screw (+PTT 2.6 x 6) 4 CN350 2-3. MAIN BOARD 1 three ground point screws (+PTT 2.6 x 6) -
Page 9: Chassis (T) Sub Assy
CDX-F5500M 2-4. CHASSIS (T) SUB ASSY 4 claw 2 two screws (+P 1.7 x 2.2) 1 two screws (+P 1.7 x 2.2) 6 chassis (T) sub assy 5 SENSOR board 3 claw 2-5. ROLLER ARM ASSY 3 washer 5 roller arm assy... -
Page 10: Chassis (Op) Assy
CDX-F5500M 2-6. CHASSIS (OP) ASSY qa chassis (OP) assy 0 coil spring (damper) lever (D) 4 washer 1 CN1 9 two coil springs (damper) 5 gear (LE1) slider (R) 3 tension coil spring (KF) 2 Remove the six solderings. 2-7. OPTICAL PICK-UP... -
Page 11: Sl Motor Assy (M902)
CDX-F5500M 2-8. SL MOTOR ASSY (M902) 1 screw (+P 1.4 x 1.8) 2 SL motor assy (M902) 2-9. LE MOTOR ASSY (M903) 8 screw 0 woam (LEB) assy (+M 1.7 x 2.5) 9 bearing (LEB) 2 washer qa screw (+M 1.7 x 2.5) -
Page 12: Servo Board
CDX-F5500M 2-10. SERVO BOARD 6 SERVO board 1 Remove the eight solderings. 2 Remove the three solderings. 4 toothed lock screw (M 1.7) 5 claw 3 CN1... -
Page 13: Diagrams
CDX-F5500M SECTION 3 DIAGRAMS 3-1. IC PIN DESCRIPTIONS • IC3 CXD3059BR (DIGITAL SERVO/DIGITAL SIGNAL PROCESSOR) (SERVO BOARD (1/2)) Pin No. Pin Name Pin Description MIRR Mirror signal input/output (Not used in this set) DFCT Defect signal input/output (Not used in this set) Focus OK signal input/output —... - Page 14 CDX-F5500M Pin No. Pin Name Pin Description FILI Filter signal input Charge pump output AVDD5 — Analog power supply pin (+3.3 V) DDVROUT DC/DC converter output DDVRSEN DC/DC converter output voltage monitor signal input AVSS5 — Analog ground DDCR Reset signal input —...
- Page 15 CDX-F5500M Pin No. Pin Name Pin Description SENS SENS signal output SCLK Clock signal input ATSK Input/output for anti-shock. (Fixed at L in this set) WFCK WFCK signal output (Not used in this set) XUGF XUGF signal output (Not used in this set)
- Page 16 DAVDD — D/A converter power supply (+) pin (+3.3 V) Not used. (Open) DAVSS — D/A converter power supply (–) pin UNISO SONY-BUS data output UNISI SONY-BUS data input UNICKO SONY-BUS clock output RETRA_SW Not used. (Open) 8, 9 Not used. (Open) VDD1 —...
- Page 17 CDX-F5500M Pin No. Pin Name Pin Description E2P_SIO Serial data input/output with EEPROM communication. DOORIND Door indicator detection output AMPSTB Not used. (Open) Not used. (Open) FLS.SO/LCDSO Serial data output to LCD driver IC. FLS.SI/LCDCE Chip enable output to LCD driver IC.
- Page 18 CDX-F5500M • Waveforms THIS NOTE IS COMMON FOR PRINTED WIRING — Servo Board — BOARDS AND SCHEMATIC DIAGRAMS. (In addition to this, the necessary note is (MODE: CD PLAY) printed in each block.) for schematic diagram: • All capacitors are in µF unless otherwise noted. (p: pF) Approx.
-
Page 19: Block Diagram -Cd Section
CDX-F5500M 3-2. BLOCK DIAGRAM — CD SECTION — • Signal path : CD • R-ch is omitted due to same as L-ch. DETECTOR MAIN RFACO 42 RFACI ASYO 45 ASYI CD-L AOUT1 SECTION (Page 20) AOUT2 R-CH RF AMP,DIGITAL SERVO,... -
Page 20: Block Diagram -Main Section
CDX-F5500M 3-3. BLOCK DIAGRAM — MAIN SECTION — J400 BUS AUDIO IN R-CH AUDIO OUT REAR R-CH SOUND CONTROL ELECTRONIC VOLUME IC400 AUDIO OUT FRONT R-CH BUS-LCH POWER AMP IC300 (1/2) CN700 OUTF2 EFFECT CD-L MUTE Q440 TUNER UNIT OUTR2... -
Page 21: Block Diagram -Display Section
CDX-F5500M 3-4. BLOCK DIAGRAM — DISPLAY SECTION — 3-5. CIRCUIT BOARDS LOCATION SERVO board SYSTEM CONTROL LCD DRIVER IC500 (3/3) IC901 SENSOR board KEY MATRIX KEYIN0 S801 LCDSO DATA S901-907, LCDCKO 910-923 SEG7-14 7-14 KEYIN1 LCDCE SEG16-31 16-31 SEG33-64 33-64... -
Page 22: Printed Wiring Boards -Cd Mechanism Section
CDX-F5500M 3-6. PRINTED WIRING BOARDS — CD MECHANISM SECTION — • Refer to page 18 for Common Note for Printed Wiring Boards. : Uses unleaded solder. R139 R116 R149 R109 C110 R108 R144 R111 C115 R143 C107 R141 R119 M901... -
Page 23: Schematic Diagram -Cd Mechanism Section (1/2)
CDX-F5500M 3-7. SCHEMATIC DIAGRAM — CD MECHANISM SECTION (1/2) — • Refer to page 18 for Common Note on Schematic Diagram and Waveforms. TP59 TP60 TP57 TP61 TP180 TP181 TP129 TP72 TP123 TP128 TP139 TP53 TP56 TP140 TP55 TP167 TP54... -
Page 24: Schematic Diagram -Cd Mechanism Section (2/2)
CDX-F5500M 3-8. SCHEMATIC DIAGRAM — CD MECHANISM SECTION (2/2) — • Refer to page 18 for Common Note on Schematic Diagram and Waveforms. • Refer to page 31 for IC Block Diagrams. (Page 23) R136 R146 R117 IC B/D TP11... -
Page 25: Printed Wiring Board -Main Section
CDX-F5500M 3-9. PRINTED WIRING BOARD — MAIN SECTION — • Refer to page 18 for Common Note on Printed Wiring Boards. : Uses unleaded solder. J400 J561 CN600 CN700 R482 R472 R442 R422 JW126 C414 C452 C432 F901 C304 C442... -
Page 26: Schematic Diagram -Main Section (1/2)
CDX-F5500M 3-10. SCHEMATIC DIAGRAM — MAIN SECTION (1/2) — • Refer to page 18 for Common Note on Schematic Diagram and Waveforms. • Refer to page 32 for IC Block Diagrams. C303 C802 R443 JC301 C800 R423 JC423 Q420 R422... -
Page 27: Schematic Diagram -Main Section (2/2)
CDX-F5500M 3-11. SCHEMATIC DIAGRAM — MAIN SECTION (2/2) — • Refer to page 18 for Common Note on Schematic Diagram and Waveforms. (Page 26) TH600 R610 IC502 Q601 Q600 C513 R522 R531 JC605 S501 R607 R518 JC504 JC508 R608 Q501... -
Page 28: Printed Wiring Board -Sub Section
CDX-F5500M 3-12. PRINTED WIRING BOARD — SUB SECTION — • Refer to page 18 for Common Note on Printed Wiring Boards. : Uses unleaded solder. (Page 29) LED802 S801 CN801 D801 LED801 (Page 25) CN802 3-13. SCHEMATIC DIAGRAM — SUB SECTION — • Refer to page 18 for Common Note on Schematic Diagram. -
Page 29: Printed Wiring Board -Key Section
CDX-F5500M 3-14. PRINTED WIRING BOARD — KEY SECTION — • Refer to page 18 for Common Note on Printed Wiring Boards. : Uses unleaded solder. S906 S912 S905 LED912 LED906 R906 LED923 LED911 S923 S911 LED961 LED962 LCD901 LED907 LED910... -
Page 30: Schematic Diagram -Key Section
CDX-F5500M 3-15. SCHEMATIC DIAGRAM — KEY SECTION — • Refer to page 18 for Common Note on Schematic Diagram. R981 R982 R983 R996 R972 IC971 LED923 LED907 LED922 LED919 LED916 LED913 LED912 LED961 R995 R927 R933 LED914 LED901 LED920 LED917... -
Page 31: Ic Block Diagrams
CDX-F5500M 3-16. IC BLOCK DIAGRAMS IC1 LA6560-TE-L-E 36 S-GND THERMAL SHUTDOWN INPUT 35 VCONT VCC2 BTL-AMP MUTE 34 MUTE OUTPUT OUTPUT ON/OFF VLO- CONTROL 33 VIN4 VLO+ 32 VIN4- LEVEL VO4+ 31 VIN4+ SHIFT VO4- 30 VREF-IN LEVEL VIN1/VREF-SW VO3+... - Page 32 CDX-F5500M IC7 R1114N151D-TR-FA 5 VOUT CURRENT VREF LIMIT IC300 TDA8588BJ/N2 OUT-FL- C BUS OUT-FL+ OUT-RL- PGND3 OUT-RL+ IN-RL IN-FL S-GND PROTECTION/ DIAGNOSTIC IN-FR IN-RR BEEP OUT-RR+ PGND2 OUT-RR- OUT-FR+ STANDBY/ MUTE OUT-FR- CHIP DETECT/ PGND1 DIAGNOSTIC BATTERY TEMPERATURE DIAG DETECTION...
- Page 33 CDX-F5500M IC400 BD3808FS-FE2 FADER FADER FADER FADER (0~-58, (0~-58, (0~-58, (0~-58, C BUS -∞dB) -∞dB) -∞dB) -∞dB) GAIN+ATT LOGIC (+10~-29, -∞dB) 2ND ORDER LPF EFFECT (0dB~ EFFECT (0dB~ +20dB,2dB STEP) +20dB,2dB STEP) fc:OFF,80,120,160Hz 2ND ORDER Q: 0.707 BASS fo:60,70,80,100,120,140,160,200Hz TONE TONE Q:0.5,0.75,1,1.25...
-
Page 34: Exploded Views
CDX-F5500M SECTION 4 EXPLODED VIEWS NOTE: • The mechanical parts with no reference • Color Indication of Appearance Parts The components identified by mark 0 or dotted line with mark number in the exploded views are not supplied. Example : 0 are critical for safety. -
Page 35: Front Panel Section
CDX-F5500M 4-2. FRONT PANEL SECTION not supplied (KEY board) not supplied LCD901 not supplied not supplied not supplied not supplied supplied supplied not supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-1067-239-A PANEL COMPLETE ASSY, FRONT... -
Page 36: Cd Mechanism Section (1)
CDX-F5500M 4-3. CD MECHANISM SECTION (1) (MG-611MA-186//Q) not supplied (SENSOR board) not supplied not supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-3372-444-A CHASSIS (T) SUB ASSY 3-352-758-31 SCREW (M1.7), TOOTHED LOCK 3-253-729-11 SPRING (LTR), TENSION COIL... -
Page 37: Cd Mechanism Section (2)
CDX-F5500M 4-4. CD MECHANISM SECTION (2) (MG-611MA-186//Q) (including M901) M902 not supplied not supplied not supplied not supplied The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. -
Page 38: Cd Mechanism Section (3)
CDX-F5500M 4-5. CD MECHANISM SECTION (3) (MG-611MA-186//Q) M903 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 3-348-993-01 WASHER 3-259-467-12 BRACKET (LEM) 3-259-024-01 WHEEL (RA), WORM 3-345-648-91 SCREW (M1.4), TOOTHED LOCK A-3372-441-A ARM ASSY, ROLLER A-3372-450-A WORM (LEB) ASSY... -
Page 39: Cd Mechanism Section (4)
CDX-F5500M 4-6. CD MECHANISM SECTION (4) (MG-611MA-186//Q) Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 3-259-429-11 WHEEL (LE), WORM 3-899-829-01 WASHER (SLIT) 3-344-223-01 WASHER 3-259-032-01 GEAR (LE2) 3-259-470-11 GEAR (LE1) A-3337-998-A CHASSIS (M) BLOCK ASSY 3-253-755-12 LEVER (D) -
Page 40: Electrical Parts List
CDX-F5500M SECTION 5 ELECTRICAL PARTS LIST NOTE: • Due to standardization, replacements in • Items marked “*” are not stocked since The components identified by mark 0 or dotted line with mark the parts list may be different from the they are seldom required for routine service. - Page 41 CDX-F5500M MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R929 1-216-809-11 METAL CHIP 1/10W S919 1-771-884-31 SWITCH, TACTILE (4/SHUF) R933 1-216-809-11 METAL CHIP 1/10W S920 1-771-884-31 SWITCH, TACTILE (3/REP) R934 1-216-809-11 METAL CHIP 1/10W S921...
- Page 42 CDX-F5500M MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C431 1-126-964-11 ELECT 10uF D110 8-719-056-93 DIODE UDZ-TE-17-18B C432 1-163-251-11 CERAMIC CHIP 100PF D301 8-719-200-82 DIODE 11ES2 C441 1-126-964-11 ELECT 10uF D302 8-719-200-82 DIODE 11ES2 C442...
- Page 43 CDX-F5500M MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark JC503 1-216-864-11 SHORT CHIP R105 1-216-809-11 METAL CHIP 1/10W JC504 1-216-296-11 SHORT CHIP R106 1-216-809-11 METAL CHIP 1/10W JC505 1-216-296-11 SHORT CHIP R107 1-216-809-11 METAL CHIP...
- Page 44 CDX-F5500M MAIN SENSOR SERVO Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R518 1-216-845-11 METAL CHIP 100K 1/10W A-3283-357-A SERVO BOARD, COMPLETE R522 1-216-845-11 METAL CHIP 100K 1/10W ********************** R523 1-216-845-11 METAL CHIP 100K 1/10W R524...
- Page 45 CDX-F5500M SERVO Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1-100-381-11 ELECT CHIP 10uF 1-218-990-11 SHORT CHIP 1-162-970-11 CERAMIC CHIP 0.01uF 1-218-990-11 SHORT CHIP 1-107-826-11 CERAMIC CHIP 0.1uF 1-218-965-11 RES-CHIP 1/16W 1-126-208-21 ELECT CHIP 47uF 1-218-965-11 RES-CHIP...
- Page 46 CDX-F5500M SERVO Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1-220-200-81 RES-CHIP 1/16W < RESISTOR > 1-218-971-11 RES-CHIP 1/16W 1-218-941-81 RES-CHIP 1/16W R801 1-216-817-11 METAL CHIP 1/10W 1-218-941-81 RES-CHIP 1/16W 1-218-965-11 RES-CHIP 1/16W < SWITCH >...
- Page 47 CDX-F5500M MEMO...
- Page 48 CDX-F5500M REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 2004. 05...
