  • Page 2 1、 CAUTION: Use of controls, adjustments or procedures other than those specified herein may result in hazardous radiation exposure. CA UTION: TO REDUCE THE RISK OF CAUTION ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE RISK RISK OF OF ELECTRI ELECTRIC C PARTS INSIDE.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS CAUTION: Read all of these instructions. Save these instructions for later use. Follow all Warnings and Instructions marked on the audio equipment. 1. Read Instructions- All the safety and operating instructions should be read before the product is operated. 2.
  • Page 4 PROTECTION AND LOCATION OF YOUR SET Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, etc. Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall outlet and refer servicing to qualified service personnel.

  • Page 5: If The Set Does Not Operate Properly

    OPERATION OF YOUR SET 18. This television set should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply at your home, consult your television dealer or local power company. For television sets designed to operate from battery power, refer to the operating instructions.
  • Page 6 TCL-Thomson Electronics R&D Center (Shen’Zhen Lab) Product Functional Specification Chassis Name NX56-LA Serial No. Issued On 2008-5-19 Page 1 of 7 Updated On Version...
  • Page 7 TTE Corporation R&D Center (Shen’Zhen Lab) Disclosure Proprietary Information: These drawings and specifications are the property of TCL-Thomson Electronics and shall not be reproduced or copied or used as the basis for the manufacture or sale of apparatus or devices without the written permission of TCL-Thomson Electronics.
  • Page 8 TTE Corporation R&D Center (Shen’Zhen Lab) Revision History Model No. Status Date Comment V1.0 lipeng 2008.5.19 Prepared by 03-B185SAE-SC31 29185 Checked by Released by: V1.0 lipeng 2008.5.19 Prepared by 03-DM63SAE-SC31S 21M63US Checked by Released by: Revised by Checked by Released by: Revised by Checked by Released by:...
  • Page 9 TTE Corporation R D Center (Shen’Zhen Lab) Model NX56-LA NX56-LA Item 29185 21M5US Master Data -Version -Customer ID -Destination -Brand -BOM NO. 03-B185SAE-SC31 03-DM63SAE-SC31S -Chassis Reception -Tuning [Channels Amt.] -Tuning [Technology] -Tuning [Indication] Channel Channel -Frequency Bands Antenna AND Cable Antenna AND Cable -IF Frequency 45.7MHz...
  • Page 10 TTE Corporation R D Center (Shen’Zhen Lab) Model NX56-LA NX56-LA Item 29185 21F5US -Nicam -America Stereo (MTS,BTSC,MPS) -America SAP -Korea Stereo -Thai Bilingual -Super Woofer -AVL -Sound Control [General] Volume Mute -Sound Control [Special] Treble Bass Balance Equalizer Smart Sound * modes Others -Speakers Quantity User Interface...
  • Page 11 TTE Corporation R D Center (Shen’Zhen Lab) Model NX56-LA NX56-LA Item 29185 21F5US -Front Cabinet Color -Middle Cabinet Color -Rear Cabinet Color -Local Controls Front Mains Switch CH+ CH- VOL+ VOL- TV/AV Menu Auto Search -Local Controls Top CH+ CH- VOL+ VOL- TV/AV Menu Auto Search...
  • Page 12 TTE Corporation R D Center (Shen’Zhen Lab) Model NX56-LA NX56-LA Item 29185 21F5US Guarantee Doc. Warning Label Approbation Label Others -Languages DFU -Indication on BACKOVER Made-in in family sheet FCC/Elect Shock Caution Label CE/Elect Shock Caution Label Warning Label Others Approbation IEC65 IEC65...

  • Page 13: Alignment Procedure

    TCL Multimedia Technology Holding CRT BU R&D Center NX56-AP&NX56B-AP Chassis Alignment Procedure Disclosure Proprietary Information: These drawings and specifications are the NX56-AP&NX56B-AP Chassis Name Serial No. 2008-01-18 Page 1 of 17 Issued on Page 2009-04-24 Updated on Version...
  • Page 14 TCL Multimedia Technology Holding CRT BU R&D Center property of TCL-Thomson Electronics and shall not be reproduced or copied or used as the basis for the manufacture or sale of apparatus or devices without the written permission of TCL-Thomson Electronics.

  • Page 15: Revision History

    TCL Multimedia Technology Holding CRT BU R&D Center Revision History Model No. Status Date Comment Prepared by Luo MJ 2008-01-18 Ver0.1 29A41/NX56 Checked by 03-BA41UAE-TH32（29A41/NX56） Released by Ver1.0 Prepared by Luo MJ 2008-01-18 1. Updated the B+ specs accord All NX56-AP with 21”...
  • Page 16 TCL Multimedia Technology Holding CRT BU R&D Center 1.1. The way to enter P-Mode a) Method one Switch on the TV set. Press the “MENU” key on RC to show the “PICTURE” OSD menu. Move the cursor to “Contrast” item then press the “9”, “7”, “3”, “5” key continuously on RC within 3 seconds then enter P-Mode.
  • Page 17 TCL Multimedia Technology Holding CRT BU R&D Center 1.4. The adjustment page list an RC key function on P-Mode: RC key Item Description Screen voltage adjustment Adjust the VG2 voltage page Vertical geometry Vertical geometry page Horizontal geometry Horizontal geometry...
  • Page 18 TCL Multimedia Technology Holding CRT BU R&D Center Flowchart of alignment procedure B+ adjustment Electrical RF AGC properties adjustment checking for chassis Parameter setup White balance Aging Adjustment of Adjustment of Adjustment focus voltage screen voltaget PAL geometry NTSC Set shopping...
  • Page 19 TCL Multimedia Technology Holding CRT BU R&D Center 3. Adjustment description Note: Alignment should be done after 3 minutes warm up of TV. 3.1 B+ Voltages 1. All relevant connectors and modules must be connected and inserted. 2. Main voltage is at 220VAC, 50Hz.（voltage range:110VAC~240VAC,50Hz）...
  • Page 20 TCL Multimedia Technology Holding CRT BU R&D Center 3.2 RF AGC alignment 3.2.1 Method 1 A. Connect the detector as shown below (Picture 3.2) to collector of Q101. B. Receive a grey scale signal with 70dBμV amplitude. C. Enter P-Mode, press “6” key on RC to select “AGCT”.
  • Page 21 TCL Multimedia Technology Holding CRT BU R&D Center 3.4 White Balance Adjustment 1. Input a black and white pattern to RF input. 2. Enter P-Mode, press key “3” to select white balance adjustment menu. 3. Use the color analyzer to measure the black side of the screen. Adjust the value of “RC”,”GC”...
  • Page 22 TCL Multimedia Technology Holding CRT BU R&D Center 3.5 Sub brightness adjustment 1. Input eight steps gray signal. 2. Press key “3” to enter sub-brightness adjustment. 3. At dynamic state, adjust “BRTC” until the secondary gray bar just to be seen. (like picture 3.5.)
  • Page 23 TCL Multimedia Technology Holding CRT BU R&D Center 3. On producing, please use the “AUTO OFFSET” (On page “2”) function to easy the geometry adjustment of NTSC signal. When finished the PAL signal geometry adjustment, press “2” key to enter page “2” to select “AUTO OFFSET” item, press “►” key to active the automatic offset function.
  • Page 24 TCL Multimedia Technology Holding CRT BU R&D Center 1. Enter P-Mode, press key “4” to select page “4”.Set the corresponding item to require value. See below table 3.7.1 for detailed description. Table 3.7.1: Producing parameter setup and option page “4”...
  • Page 25 TCL Multimedia Technology Holding CRT BU R&D Center B. Picture set to “Standard” status. (Brightness=50, Contrast=50, Colour=50, White tone =Normal.) C. Sound set normal.(Volume=30,Balance=50.) 2). Set the user picture and sound curve value A. Brightness curve: OSD menu Default Value...
  • Page 26 TCL Multimedia Technology Holding CRT BU R&D Center 2. Enter P-Mode, press key “5” to select page “5”. Set the corresponding item to require value. See below table 3.7.2 for detailed description. Table 3.7.2: Producing parameter setup and option page “5”...
  • Page 27 TCL Multimedia Technology Holding CRT BU R&D Center 38.90 IF frequency Select the IF frequency AGCS AGC speed Don’t adjust, use default AGNE Audio gain Don’t adjust, use default 4. Enter P-Mode, press key “7” to select page “7”. Set the corresponding item to require value.
  • Page 28 TCL Multimedia Technology Holding CRT BU R&D Center RUSSIAN* Russian enable FRENCH* French enable FARSI* Farsi enable 0=ALPS tuner TUNER TYPE* Select tuner type 1=TCL tuner AV no signal within 10 minutes 0=Disable AV STANDB automatic standby 1=Enable 0=Follow TV...
  • Page 29 TCL Multimedia Technology Holding CRT BU R&D Center value. See below table 3.7.7 for detailed description. Table 3.7.7: Producing parameter setup and option page “9” OSD menu Default Value Description Remark 0=Disable Black stretch enable 1=Enable 0=15IRE Black Stretch depth...
  • Page 30 RF Section Tuner Tu101 receive the radio frequency signal, after inside circuit to do signal receiving, and signal amplifying. The amplified high frequency signal accompany with the high frequency oscillation voltage oscillated by set oscillator input to the mixer. The IF picture signal and sound signal formed in mixer and output from mixer, then send to picture IF processing circuit.
  • Page 31 Small Signal Processing Section Small signal processing section is the IF (intermediate frequency) signal across saw filter send in the pin12 and pin13 of IC201. The VIFIN signal through built-in PLL DEMOD, sound trap, video amplifier and synchronous detector processing, get the color video broadcast signal and 2 sound IF signal.
  • Page 32 (Fig3. Block Diagram of IC201.) Horizontal Scanning Section The horizontal drive signal send out from pin 56 of IC201, Q401 is horizontal driving transistor, coupled by horizontal driving transformer T402 , to control the horizontal output transistor working in switch on and off situation, get good linearly and enough amplitude of saw-tooth wave current to drive horizontal deflection yoke scanning.
  • Page 33 Vertical Scanning Section Vertical scanning section adopted STV8172A vertical deflection booster, we use as differential-output driver. The vertical raw-tooth wave signal sends out from pin14/15 of IC201 VDA/VDB. The two differential signal input pin 1 and 7 of STV8172A IC301. Pin2(+14v) and Pin7(-14v) of IC301 is power supply which come from the main power transformer.
  • Page 34 Audio Power Amplifying Section Power Supply Section AC supply 220V/110v through filtering network and rectifying circuit and get 300Vdc voltage. LF801/LF801A and CX802 makes up a differential mode rejection, LF802 and CY801,CY802 makes up a common mode rejection network. D801-D804 is rectifying network. 300Vdc voltage supply pin3 of T801, also through R804 send to pin8 of IC801 NCP1337.

  • Page 42: General Description

    UOC-TOP-64 N1 series Versatile signal processor for CRT TV applications Rev. 0.11 — 25 January 2007 Product data sheet 1. General description The UOC-TOP-64 series is a very flexible concept which offers attractive solutions for 1f TV receivers with CRTs. This new concept offers a complete range of products with the right price level to cover TV receivers from basic mono 14 inch sets up to the best featured large and/or wide screen AV-stereo TV sets.
  • Page 43 UOC-TOP-64 N1 series NXP Semiconductors Signal processor for CRT TV 2. Features 2.1 Analog Video Processing 2.1.1 Overview of available features (AV-110/90 and Mono-110 concept) Multi-standard vision IF circuit with alignment-free PLL demodulator Internal (switchable) time-constant for the IF-AGC circuit Switchable group delay correction and sound trap (with switchable centre frequency) for the demodulated CVBS signal Separate Second Sound IF output or FM demodulator output without de-emphasis...
  • Page 44 UOC-TOP-64 N1 series NXP Semiconductors Signal processor for CRT TV Picture improvement features with peaking (with switchable centre frequency, depeaking, variable positive/negative peak ratio, variable pre-/overshoot ratio and video dependent coring), dynamic skin tone control, gamma control and blue- and black stretching.
  • Page 45 UOC-TOP-64 N1 series NXP Semiconductors Signal processor for CRT TV 2.2 Micro-Controller 80C51 m-controller core standard instruction set and timing 0.9766 ms machine cycle maximum of 80 k x 8-bit late programmed ROM maximum of 3 k x 8-bit Auxiliary RAM C byte level bus interface.
  • Page 46 UOC-TOP-64 N1 series NXP Semiconductors Signal processor for CRT TV 2.4 Display 2.4.1 Features of the OSD-only devices Up to 4 character sets with 256 characters each (size 16 pixels x 18 lines) Enhanced OSD modes 50Hz/60Hz display timing modes Serial and Parallel Display Attributes Single/Double Width and Height for characters Scrolling of display region...
  • Page 47 UOC-TOP-64 N1 series NXP Semiconductors Signal processor for CRT TV 3. Quick reference data Table 1: Quick reference data SYMBOL PARAMETER MIN. TYP. MAX. UNIT Supply analogue supply voltage VSP − − supply current (5.0 V) digital supply VSP / analogue supply periphery −...

  • Page 48: Block Diagram

    UOC-TOP-64 N1 series NXP Semiconductors Signal processor for CRT TV 5. Block diagram µ-PROCESSOR / TELETEXT DECODER / OSD BCLIN BLKIN/ SVM/ VGUARD **) The mono-110 version has only volume control and no tone control functions Fig 1. Block diagram of the “AV-110/90” and “MONO-110” TV processor <Document ID>...
  • Page 49 UOC-TOP-64 N1 series NXP Semiconductors Signal processor for CRT TV µ-PROCESSOR / TELETEXT DECODER / OSD BCLIN BLKIN/VGUARD Fig 2. Block diagram of the “MONO-90” TV processor <Document ID> © NXP B.V. 2007. All rights reserved. Product data sheet Rev. 0.11 — 25 January 2007 10 of 230...
  • Page 50 UOC-TOP-64 N1 series NXP Semiconductors Signal processor for CRT TV 6. Pinning information Table 6: Pinning information SYMBOL DESCRIPTION SDIP64 AV-110 AV-90 Mono-90 Mono-110 − IFVO/SVO/PIP IF video output / selected CVBS output / PIP output − − IFVO/SVO IF video output / selected CVBS output supply voltage TV processor (+5 V) VCC8V 8 Volt supply for audio switches...
  • Page 51 UOC-TOP-64 N1 series NXP Semiconductors Signal processor for CRT TV Table 6: Pinning information SYMBOL SDIP64 DESCRIPTION AV-110 AV-90 Mono-90 Mono-110 GND5 ground OTP Programming Voltage VDDA1(3.3V) supply voltage − BO/PBOUT Blue output / P output − − Blue output −...

  • Page 52: Main Features

    STV8172A ® Vertical Deflection Booster for 3-A TV/Monitor Applications with 75-V Flyback Generator PRODUCT PREVIEW Main Features Power Amplifier HEPTAWATT (Plastic Package) Flyback Generator ORDER CODE: STV8172A Stand-by Control Output Current up to 3 App Thermal Protection Description Input (Non Inverting) The STV8172A is a vertical deflection booster Output Stage Supply Output...
  • Page 53 Absolute Maximum Ratings STV8172A Absolute Maximum Ratings Symbol Parameter Value Unit Voltage Supply Voltage (pin 2) - Note 1 Note 2 Flyback Peak Voltage - Note 2 Voltage at Pin 3 - Note Note 3 Note 6 -0.4 to (V + 3) Amplifier Input Voltage - Note...

  • Page 54: Electrical Characteristics

    STV8172A Electrical Characteristics Electrical Characteristics = 34 V, T = 25°C, unless otherwise specified) Symbol Parameter Test Conditions Min. Typ. Max. Unit Fig. Supply Operating Supply Voltage Range (V Note 8 Pin 2 Quiescent Current = 0, I Pin 6 Quiescent Current = 0, I = 0, V =35v...
  • Page 55 Electrical Characteristics STV8172A Figure 1: Measurement of I and I 2.2V 39kW STV8172A 5.6kW (a): I2 and I6 measurement (b): I1 measurement Figure 2: Measurement of V 2.2V STV8172A - I5 Figure 3: Measurement of V and V I3 or I5 STV8172A 2.2V (a): V...
  • Page 56 STV8172A Application Hints Application Hints The yoke can be coupled either in AC or DC. DC-coupled Application When DC coupled (see Figure 4), the display vertical position can be adjusted with input bias. On the other hand, 2 supply sources (V and -V ) are required.
  • Page 57 Application Hints STV8172A 4.1.1.1 Centering Display will be centered (null mean current in yoke) when voltage on pin 7 is (R is negligible): æ ö ´ ------------------------ ç --------------------- - ÷ è ø 4.1.1.2 Peak Current – V M V m ´...
  • Page 58 STV8172A Application Hints AC-Coupled Applications In AC-coupled applications (See Figure 6), only one supply (V ) is needed. The vertical position of the scanning cannot be adjusted with input bias (for that purpose, usually some current is injected or sunk with a resistor in the low side of the yoke). Figure 6: AC-coupled Application Output (47 to 100µF)
  • Page 59 Application Hints STV8172A performs an integration of the parabolic signal on C , therefore the amount of S correction is set by the combination of C and C Application with Differential-output Drivers Certain driver ICs provide the ramp signal in differential form, as two current sources i and i with opposite variations.

  • Page 63: Colour Television

    Colour Television Chassis: NX56 Figure 1 Fuse Blown Fuse Blown Check IC801 and Is the drain of D801~D804 peripheral Q801 shorted components. to earth? Replace Cheek D809~D812 Replace Q801 Figure2 No Raster Abnormal +B raster abnormal + B Check Q402 collector C resistance to earth Replace Q402 resistance to earth ok?
  • Page 64 Colour Television Chassis: NX56 Figure3 No Raster, +B OK No raster Replace IC201 Replace Q402 B Voltage OK Yes Check the waveform H-out Is the voltage waveform at PIN static working Pin8 56 of IC201 OK? point of Q402. IC202 5v Is the resistance Replace to earth of pin8...
  • Page 65 Colour Television Chassis: NX56 Figure 5 No Vertical Scanning Is both +14V and -14V ok? Is the signal at P1 of Check/Replace IC301 ok? , D410, D411 Check/Replace IC301 Check signal at P14/P15 of IC201 Check circuit Check/Replace IC201 between IC301 IC201 Figure 6 No Picture...
  • Page 66 21M63S/NX56E-AP/ P/S BG & DK & I 03-DM63NAK-SY12S PART NO. SEPC LOCATION 03-DM63NAK-SY12S T6-NR0002-AAN0X STARWAYASY V8-NX56AP2- 03-DM63NAK-SY12S SOFTWARE SOFTWARE CODE IC201(CP) TM3V616 T8-21APAK-MA1 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) D454;D404;D401;D301 D406;D601;D316;D315;D204;D210 T8-21APAK-MA1 10-1N4148-ABX DIODE 1N4148 (SWITCHING) ;D313 T8-21APAK-MA1 10-79C33V-DBX DIODE ZENER 33V 1/2W 5% D101 T8-21APAK-MA1 10-79C4V7-DBX...
  • Page 67 T8-21APAK-MA1 18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% R904;R278;R901;R269 T8-21APAK-MA1 18-CD0100-JNX RES. C.F. 10 OHM 1/4W +/-5% J410 T8-21APAK-MA1 18-CD0121-JNX RES. C.F. 120 OHM 1/4W +/-5% R403 T8-21APAK-MA1 18-CD0189-JNX RES. C.F 1.8 OHM 1/4W +/-5% R305 T8-21APAK-MA1 18-FG0180-JSX RMOF 18OHM +/-5% 2W R=Y R262;R261 T8-21APAK-MA1 25-BCB101-M1X...
  • Page 68 T8-21APAK-MA1 41-WJ0090-B00 WIREBAREJUMPER9MM J234;J221 T8-21APAK-MA1 41-WJ0095-B00 WIREBAREJUMPER9.5MM J403 R004;J220;J607;J606;J230;J237 T8-21APAK-MA1 41-WJ0100-B00 WIREBAREJUMPER10MM ;J201;J110 J101;J601;J238;J308;J109;J205 T8-21APAK-MA1 41-WJ0100-B00 WIREBAREJUMPER10MM ;J206;J225 J248;J247;J001;J207;J108;J246 T8-21APAK-MA1 41-WJ0100-B00 WIREBAREJUMPER10MM ;J911;J226 T8-21APAK-MA1 41-WJ0100-B00 WIREBAREJUMPER10MM J002 T8-21APAK-MA1 41-WJ0105-B00 WIREBAREJUMPER10.5MM J413 T8-21APAK-MA1 41-WJ0110-B00 WIREBAREJUMPER11MM J908;J407 T8-21APAK-MA1 41-WJ0115-B00 WIREBAREJUMPER11.5MM J916;J215;J219;J218;J217;J216 T8-21APAK-MA1 41-WJ0120-B00 WIREBAREJUMPER12MM J917...
  • Page 69 T8-21APAK-MA1 67-M40068-2E4 TV RAW SUPPORT -- -- 00 00 00 R=N Y301 T8-21APAK-MA1 71-AV0000-V00 SOFT LABEL PAPER WHITE T8-21APAK-PW1 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) D813;D811;D810;D804 D-PIN 1.3V 1_A 1000VV 500NS /W T8-21APAK-PW1 10-0FR107-FBX D809 DO-15 FR1 D-PIN 1.1V 2_A 800V / /W DO-15 T8-21APAK-PW1 10-0RL255-EBX DB804;DB803;DB802;DB801...
  • Page 70 CAP.ELE 5MM 47UF 100V 10*16 85 T8-21APAK-PW1 25-BHB470-M1X C846 B41827系 T8-21APAK-PW1 26-AIC221-KBX CAP.CER 220P0F 500VV - C820;C819;C822 T8-21APAK-PW1 26-AKC152-KRX CAP. CER 1500 pF 1KV +/-10% C811A T8-21APAK-PW1 26-AKC331-KBX CAP.CER 330P0F 1K0V - C817 T8-21APAK-PW1 26-AKC471-KRX CAP.CER 470P0F 1KVV - C805 T8-21APAK-PW1 26-AKC472-MEX CAP.
  • Page 71 T8-21APAK-PW1 64-P30080-104G M/C SCREW P 3 X 8 FOR Q801 T8-21APAK-PW1 66-20517X-0B7 FUSE HOLDER FOR F801 T8-21APAK-PW1 67-H38013-2A0 RAW HEATSINK -- 02 00 R=Y Y801 T8-21APAK-PW1 71-DYP000-WX1 LABEL FOR Y801 T8-21M62AK-KE1 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% R1005 T8-21M62AK-KE1 18-CB0222-JNX RES.
  • Page 72 PRI LABEL ---- WHITE & BLACK R=Y 21091000001起 TV PRI LABEL SCREEN LABEL WHITE & T8-21M63AK-PA10 71-STARWS-SCR9C BLACK T8-21M63AK-PA10 72-BASEIS-E009A IB BASE INSTRUCTION TCL CHS R=Y T8-21M63AK-PA10 72-DM63AE-A129A IB -- -- ARA R=Y T8-21M63AK-PA10 72-DM63AE-E129J IB -- -- ENG R=Y...
  • Page 73 TCL18-CE0221-JNX= RES. C.F. 220 T8-21RFLM-MHF4AK 18-CE0221-JNX R306 OHM 1/2W T8-21RFLM-MHF4AK 18-DB0512-FNX RES. M.F. 5.1K OHM 1/6W +/-1% R833 T8-21RFLM-MHF4AK 18-FF0109-JSX RMOF 1OHM +/-5% 1W R=Y R320;R319 T8-21RFLM-MHF4AK 18-FF0122-JSX RMOF 1W +-5% 1.2KΩ R455A T8-21RFLM-MHF4AK 18-FF0220-JSX RES.M.O.F 22 OHM 1W +/-5% R402 T8-21RFLM-MHF4AK 18-FG0109-JSX...
  • Page 74 T8-NX56AK-CR1 18-FG0153-JSX RMOF 15KOHM +/-5% 2W R=Y R535A;R525A;R515A T8-NX56AK-CR1 26-EBP391-JCS CAP. CER 390PF 50V +/-5% C521;C511;C531 T8-NX56AK-CR1 26-EBP561-JCS CAP. CEP 560PF 50V +/-5% C541 T8-NX56AK-CR1 34-A470K0-1IX COIL CHOKE 47 UH +/-10% L501 T8-NX56AK-CR1 40-0NX56B-CRD1XG TV PCB CR BD R=Y TCL41-WJ0050-B00= WIRE BARE T8-NX56AK-CR1 41-WJ0050-B00 JP501;J505;JP502;JP503...
