Splendide QR-S125 Quick Operation Manual

Before setting the washer
controls, make sure...
LAUNDRY AIDS
Slide open the dispenser
AW125 Washer
drawer and add laundry aids
to the correct compartments.
When fi nished, close the
drawer.
4
1
2
3
1. Detergent* for prewash.
2. Detergent* for the wash
cycle (1-2 Tbsp)
3. Fabric Softener (1-2 Tbsp)
4. Bleach (fill to Max. Line)
IMPORTANT
NEVER EXCEED THE
RECOMMENDED AMOUNTS
SHOWN ABOVE.
*AMOUNTS ABOVE ARE FOR
POWDER DETERGENT ONLY.
IF USING LIQUID DETERGENT,
USE NO MORE THAN 1/4 TO 1/2
TBSP PER LOAD.
QUICK OPERATION GUIDE
•
•
•
•
Detergent Dispenser SPIN SPEED
Drawer
WASH
Select a wash cycle using Select a wash temperature
the Program knob. and spin speed using the
Temperature and Spin Speed
• TIP Refer to the Cycle Key knobs, then press START.
printed on the dispenser
drawer to help choose a
• TIP The door lock will engage
cycle. Pick a cycle that best
once the cycle begins. The
describes both the type of
'Status LED's' will let you
fabric (Cotton, Permanent
know the progress of your
Press, or Wool) and degree
cycle.
of soil for the load.
• TIP For faster drying, make
• TIP Select Wool Dry ONLY
sure the Spin Speed knob is
when drying 100% wool
set to the maximum spin.
fabrics.
• TIP To further customize the
cycle, press one or more of
the option buttons.
• TIP Rinse temperatures are
ALWAYS COLD.
• TIP Not all options or
combinations of options
available in all cycles.
IMPORTANT
ALWAYS USE A HIGH EFFICIENCY (HE) DETERGENT. FAILURE TO DO SO COULD RESULT IN REDUCED WASHING AND
You'll reduce your carbon footprint and get outstanding results in your Splendide,
when you use our specially formulated, all-natural HE laundry powder (Splendide Premium Laundry Powder,
#1005). Available direct from Splendide at 1-800-356-0766.
the drum is loaded correctly (see 'Load Sizes' on this page) and the door is CLOSED,
laundry aids have been added to the dispenser drawer (see 'Laundry Aids' on this page),
the ON/OFF button has been pressed in, so power is ON,
and the DOOR LOCK LED is FLASHING SLOWLY - if it isn't press and HOLD the Start button
to RESET controls.
ON/OFF
ON/OFF / DOOR LOCK
INDICATOR AS66VX Dryer
START/
PROGRAM
CANCEL
KNOB
TEMPERATURE
DRYING PERFORMANCE AND DAMAGE TO YOUR APPLIANCE.
AW125 Washer and AS66VX Dryer (Multifamily)
TEMPERTURE
BUTTON
High Heat = OUT
Low Heat = IN
DRY
After loading the dryer drum,
select the length of drying
time by rotating the Program
knob clockwise. Press the START button.
•
• TIP For faster drying, make
sure the Temperature button
is in the OUT position.
• TIP For the Auto cycle to
work, the Temperature button
must be in the High Heat,
OUT position.
IMPORTANT
THE WASHER DOOR WILL STAY LOCKED FOR THE DURATION OF
THE WASH CYCLE. TO OPEN THE DOOR DURING A CYCLE, SEE
'CANCEL A CYCLE' INSTRUCTIONS ON NEXT PAGE.
QR-S125
START
BUTTON
PROGRAM
KNOB
TIP Always clean the lint
fi lter before starting a new
dry load.
