Page 1: Table Of Contents
Cutting off the water and electricity supplies Cleaning the washing machine Cleaning the detergent dispenser drawer Caring for the door and drum of your appliance Cleaning the pump Checking the water inlet hose Troubleshooting 14 Service 15 Warranty, 16-17 Splendide ®...
Page 2: Na Important Safety Instructions
Important safety instructions GROUNDING INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS WARNING - To reduce the risk of fire, electrical shock, or This appliance must be grounded. In the event of mal- injury to persons when using your appliance, follow basic function or breakdown, grounding will reduce the risk of precautions, including the following: electric shock by providing a path of least resistence for electric current.
Page 3: Safety
Safety CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: To reduce the risk of electric shock, DO NOT remove cover (or back)/no user servicable parts inside. Refer for servicing to qualified services personnel. The model number of this product may be found on the back of the unit; the serial number of the label affixed inside the door and to the back of the unit.
Page 4: Installation Instructions
Installation instructions Levelling the machine correctly will provide it with stability, This instruction manual should be kept in a safe place help to avoid vibrations and excessive noise and prevent it for future reference. If the washer is sold, transferred or from shifting while it is operating.
Page 5: Connecting Water Inlet
Connecting Water Inlet Floor Standpipe Wall Standpipe If the water pipes you will be connecting to are new or unused, run the water until clear to remove any debris that could clog the water valve screens or valves before con- necting the machine.
Page 6: Electrical
Electrical • Insert the outlet end of the drain hose into the standpipe, wall or floor drain (Fig. 6). NOTE: The outlet end of the • Machine Voltage/Amperage - 120V, 60 Hz, 4 Amp. drain hose MUST be at least 20” (50 cm) above the base •...
Page 7: Description Of The Washing Machine And Starting A Wash Cycle
Description of the washing machine and starting a wash cycle Control panel WASH CYCLE PROGRESS indicator lights DISPLAY DOOR ON/OFF TEMPERATURE LOCKED button with indicator button light indicator light START/PAUSE Detergent dispenser drawer button with indicator SPIN SPEED FUNCTION light button buttons with indicator lights...
Page 8: Indicator Lights
Indicator lights Temperature indicator light When a temperature value is selected, the corresponding indicator light will illuminate. The indicator lights provide important information. This is what they can tell you: Wash cycle phase indicator lights As the WASH CYCLE knob is rotated, the indicator lights illuminate, indicating the stages which will be performed by Spin indicator light the machine in accordance with the selected wash cycle.
Page 9: Wash Cycles
Wash cycles Table of wash cycles Detergents Max. Max. Max load Cycle Description of the wash cycle temp. speed (lb) duration Fabric (°C) (rpm) Bleach Wash softener Essentials cycles 1 Cottons Regular: Heavily soiled whites and resistant colours.   2 Cottons Colored: Lightly soiled whites and delicate colours.
Page 10: Personalisation
Personalisation Setting the temperature By pressing the TEMPERATURE button to set the wash temperature. (See Table of wash cycles) Wash temperature can be set selecting , “Cold”, “Warm”, “Hot” or 2 in-between positions which correspond to intermediate levels of water tempe- rature (example: the position between “cold”...
Page 11 Reduced Wrinkles By selecting this function, the wash and spin cycles will be modified in order to reduce the formation of creases. At the end of the cycle the washing machine will perform slow rotations of the drum; the REDUCED WRINKLES indicator light will switch on and the START/PAUSE indicator light will flash in an orange colour and the phase END will remain lit in a fixed manner.
Page 12: Detergents And Laundry
- the type of fabric/the symbol on the label. - the colours: separate coloured garments from whites We recommend using Splendide All-Natural • Empty all garment pockets and check the buttons. Premium HE Laundry Powder (Part No. 1005). It softens fabrics naturally and does not require the •...
Page 13: Care And Maintenance Instructions
Care and maintenance instructions Cutting off the water and electricity Cleaning the pump supplies The washing machine is fitted with a self-cleaning pump • Turn off the water tap after every wash cycle. This will which requires little maintenance. Sometimes, limit wear on the hydraulic system inside the washing small items (such as coins or buttons) may fall into the pre- machine and help to prevent leaks.
Page 14: Troubleshooting
Troubleshooting Your washing machine could fail to work. Before contacting the Technical Assistance Centre (see “Assistance”), make sure that the problem cannot be not solved easily using the following list. Problem: Possible causes / Solutions: The washing machine does not •...
Page 15: Service
Siphon break kit (sold at most har- dware stores) “Y” connector (sold at most hardware Disposer drain stores) Splendide SecureFit™ instal- Shifting Concerns (RV and Marine lation Brackets, Part No. MK01. Installations) Keeps washer in place during travel to prevent: • Kinked inlet hoses • Disconnected dryer vent hoses • Crushed dryer vent hose • Blocked dispenser drawer • Knobs rubbing against closed doors • Scuffed cabinet woodwork All Splendide parts are available direct from Westland Sales: 1-800-356-0766...
Page 16: Warranty
Warranty ARISTON ONE-YEAR LIMITED WARRANTY (USA & CANADA ONLY) WHO IS COVERED BY THIS WARRANTY 5. Replacement of house fuses or correction of the plumbing or electric wiring in your home. This limited one-year warranty (“Warranty”) is given only 6. Damage caused by neglect, accident, fire, floods or acts to the original end-use/retail purchaser (the “First Using of God.
Page 17 WHAT YOU SHOULD DO TO OBTAIN WARRANTY SERVICE All repairs or warranty service must by provided by Ariston or an Authorized Ariston Service Center. To schedule warranty service please call 1-800-356-0766, email service@westlandsales.com. Please remember to provide us with your Ariston Product’s model number and serial number.
Page 19 This manual has been provided courtesy of My RV Works, Inc. www.myrvworks.com You can find more RV service manuals here: www.myrvworks.com/manuals Over the years of running a mobile RV repair service, having a dedicated place to access service manuals for all the different appliances and components found on RVs was something that I always had a desire to create.
