Preface Thank you for using the 6030/6050 Wide Format AutoCAD ADI Driver (hereinafter known as Plotter Driver). This User Guide describes the procedures and precautions involved in installing and setting up Plotter Driver. Refer to the user manuals supplied with the Xerox 6030/6050 Wide Format Copier/Printer for details on relevant operations.
Using This Guide Organization This guide consists of the following chapters. Chapter 1. Installing Plotter Driver Explains how to install Plotter Driver into your computer. Using This Guide...
Page 5
Conventions This User Guide uses the following symbols and conventions: < > key Indicates the keys on the keyboard. Press the <Enter> key. Indicates the menus and display items on the screens. Select either the [On] or [Off] buttons to display [Job Name], [Owner], and [Reason] in that order.
Preface Using This Guide Table of Contents Chapter 1 Installing Plotter Driver ADI Installation Copy the Driver Installing and Setting up the Driver HDI Installation Copy the Driver Installing and Setting up the Driver for Local Plotter .Installing and Setting up the Driver for Network Plotter Driver Operation Reference Change Driver Setup Check Driver Setup...
ADI Installation The following example is based on the assumption that AutoCAD is install in drive C: and the floppy drive is A:. AutoCAD is installed by the attached installer and has the standard directory configuration. Copy the Driver Using Windows Explorer, go to the floppy disk and select the driver “plpxc_e.dll”.
Page 11
Click the [Printer] tab to bring it to the foreground. Click the [New...] button to display the “Add a Printer” dialog box. Then Select “Xerox DW series...”. The “Device Setup” dialog box opens. 1.1 ADI Installation...
Page 12
Optional functions unique to the printer model can be set by clicking [Options...] button. These settings can be changed later by selecting [Device and Default Selection] from the “Print/Plot Configuration” dialog box. Setting items Select paper type: Select type of paper to be used from Bond, Film, or Vellum paper.
Page 13
Click the [Options...] button to open the dialog box. Several functions are not supported by some plotter models (grayed out options are not supported). Folder Options Program: Select Folder Bypass or Programs 1 through 20. Margin: Select Use program setting or Always off. Output Bin: Select Don’t care, Fanfold output, or Bin 1 through Bin 13.
Page 14
The current print settings are displayed. At the prompt “Do you want to change anything?”, enter N for No. Control returns to the “Preferences” dialog box. This completes the driver installation and setup. Chapter 1 Installing Plotter Driver...
HDI Installation The following example is to configure a local non-system plotter and network non- system plotter. Copy the Driver Un zip the driver file. This will create subdirectories for 2000, 2000i, 2002 and 2004. Installing and Setting up the Driver for Local Plotter Open the AutoDesk Plotter Manager.
On the Add Plotter - Plotter Name page, enter a name to identify the currently configured plotter. Choose Next. When you reach the Add Plotter - Finish page, you can choose Finish to exit the Add-a-Plotter wizard. A PC3 file for the newly configured plotter appears in the Plotters window, and the plotter is available for plotting in the list of devices.
Page 17
On the Add Plotter - Plotter Model page, select a manufacturer and model. Choose Next. • (Optional) The Import PCP or PC2 screen enables you to use configuration information from a PCP or PC2 file created with an earlier version of AutoCAD.
Driver Operation Reference The driver setup information set in the “Preferences” box at driver installation can also be changed when the PLOT command is executed. Change Driver Setup Execute the PLOT command to open the “Print/Plot Configuration” dialog. Click the “Device and Default Selection” button. Select the 6030/6050 printer.
Page 19
Paper size: Select paper size. For this driver, paper size must be selected here, not at “Paper Size and Orientation” in the “Print/Plot Configuration” dialog box. Length: When “Custom size” is selected at “Paper Size”, set its length can be set in integral value in 1mm increments.
Margin: Select Use program setting or Always off. Output Bin: Select Don’t care, Fanfold output, or Bin 1 through Bin 13. Manual output: Select Yes or No to use or not to use the function. Click [Image Correction] button to open the dialog box. A correction graph indicates how an output picture image is corrected.
