- Page 1 INSTALLATION INSTRUCTIONS ActiveSmart™ Slide-in refrigerator RS90A and RS90AU models NZ AU GB IE EU AE HK SG IN www.fisherpaykel.com 839137 A 02.15...
-
Page 3: Safety And Warnings
SAfEty ANd wArNINGS BEforE INStAllAtIoN Please follow the installation steps below to ensure your appliance is installed and operates correctly. this refrigerator contains flammable Power refrigerant isobutane (r600a). The appliance must be installed so the plug is accessible. r600a ● ● To ensure that the appliance is not accidently switched off, connect your refrigerator to its ●... -
Page 4: Components List
ComPoNENtS lISt door panel fittings kit – Included with standard appliance. French door Drawer hanging Side bracket Side strap Side screw Screw washer 4 x 14 hanging bracket bracket (10) (10) (10) (34) Top stud Screw handle M8 washer M8 nut Top cover Side cover (12) (10) - Page 5 ComPoNENtS lISt Anti-tip bracket kit – Included with standard appliance. Anti-tip bracket Phillips screw Masonry plug Product kit - Included with standard appliance. Wood screw Kickstrip filter Kickstrip grille Power cord clip Ice & water kit – Included with standard Ice & Water models only. Collet locking key Water filter cartridge (1) Filter cartridge tool...
- Page 6 ProdUCt ANd CAvIty dImENSIoNS wItH StANdArd door PANElS rS90A rS90AU CAvIty dImENSIoNS Overall height of cavity 1800 Overall width of cavity when adjoining cabinetry can share 4 mm door gap when adjoining cabinetry cannot share 4 mm door gap Overall depth of cavity Total front panel width with required gaps at sides = 904 mm ( product width + 2 x cabinetry gaps).
- Page 7 ProdUCt ANd CAvIty dImENSIoNS wItH StANdArd door PANElS Wall Wall 115° door oPENING 90° door oPENING (fUll rotAtIoN) 115° DOOR OPENING 90° DOOR OPENING [FULL ROTATION] rS90A rS90AU door ClEArANCE dImENSIoNS Depth of door (widest opening) measured from front of door Depth of drawer (open) measured from front of drawer, including handle Depth of drawer (open) measured from front of drawer, excluding handle Minimum door clearance to adjacent wall*...
- Page 8 ProdUCt ANd CAvIty dImENSIoNS wItHoUt door PANElS Shown with custom attached to fridge rS90A CAvIty dImENSIoNS Overall height of cavity 1800 Overall width of cavity when adjoining cabinetry can share 4 mm door gap when adjoining cabinetry cannot share 4 mm door gap Overall depth of cavity Total front panel width with required gaps at sides = 904 mm ( product width + 2 x...
- Page 9 ProdUCt ANd CAvIty dImENSIoNS wItHoUt door PANElS Wall Wall 115° door oPENING 90° door oPENING (fUll rotAtIoN) 115° DOOR OPENING 90° DOOR OPENING [FULL ROTATION] rS90A door ClEArANCE dImENSIoNS Depth of door (widest opening) measured from front of cabinetry Depth of drawer (open) measured from front of cabinetry* Minimum door clearance** to adjacent wall (115°...
-
Page 10: Custom Door Panel Dimensions
CUStom door PANEl dImENSIoNS When integrating your non-Ice & Water refrigerator with custom door panels, please follow the installation instructions provided with the integrating parts. ProfIlE vIEw rS90A CUStom door PANEl dImENSIoNS ISO VIEW PROFILE VIEW Height of top door panel 1096 Width of top door panel Gap between top door panels... -
Page 11: Custom Panel Preparation
CUStom door PANEl PrEPArAtIoNS CUSTOM PANEL PREPARATION The following drawings apply to non-Ice & Water models only. Dimensions are shown in Handle details Metric (mm) and apply for the preparation and installation of custom door panels. For Dwg and Dxf files of the below panel preparation download the folder on Top Panel –... -
Page 12: Cavity Preparation
CAvIty PrEPArAtIoN Alternative area above Left side cavity for connections of cavity optional electrical and water connection location* Floor REAR VIEW OF CAVITY rEAr vIEw of CAvIty Electrical REAR VIEW OF CAVITY Plumbing rS90A rS90AU Electrical ElECtrICAl SPECIfICAtIoNS Plumbing Supply 230 VAC, 50 Hz 230 VAC, 50 Hz Service... - Page 13 mAxImUm dIStANCE of HoSES ANd Cord Water inlet hose* – 2250 mm Power cord (excl.plug) – 800 mm lEft HANd SIdE rIGHt HANd SIdE Water inlet hose* – 3180 mm Water inlet hose* – 3930 mm Power cord (excl.plug) – 2050 mm Power cord (excl.plug) – 2050 mm * Applies to Ice &...
-
Page 14: Anti-Tip Bracket Installation
ANtI-tIP BrACKEt INStAllAtIoN Safety requires refrigerators be stable when doors and/or drawer, are open. Depending on your installation enclosure, an anti-tip bracket may need to be fitted if the ceiling/cabinetry above the enclosure is not secured to the wall (to withstand a 100 kg load). This will prevent the possibility of the appliance tipping forward, when doors and/or drawer, are open. ImpORTANT! when fastening with masonry plugs and/or screws: Ensure the screws avoid electrical, gas and water conduits. -
Page 15: Installing Your Appliance
CoNNECtING wAtEr SUPPly (ICE & wAtEr modElS oNly) ImpORTANT! the water connection to your Ice & water refrigerator must be installed by an authorized plumber or fisher & Paykel Authorised repairer. ● ● the water connection instructions below are intended only for the professional installer. ●... - Page 16 rEmovING HINGE ENd CAPS Carefully open the French doors and remove hinge end caps. Left hinge end cap Hold onto the corner of the end cap, firmly push to the right to disengage securing hook and pull down. Right hinge end cap Press on the centre of the end cap and push towards the right hinge to remove.
- Page 17 ASSEmBlING All door PANElS Ensure door panel dimensions are correct for your appliance. ● ● The assembly of standard Fisher & Paykel kits (EZKleen stainless steel door panels) and custom door panels are outlined below. For standard Fisher & Paykel kits, only remove the protective film ●...
- Page 18 HANGING door PANElS Secure top studs into the Secure side screws mid-way into Hang door panel onto the top refrigerator doors, ensure the the refrigerator doors x4 for each studs and align the side bracket open end faces the top. French door and x2 drawer.
- Page 19 HANGING door PANElS (ICE & wAtEr modElS oNly) Remove the external display module from inside the product. Thread the display harness through the door panel cavity. Ensure the grommet is engaged. Remove water tube from holder on the refrigerator door. Angle top display tabs into the door panel.
- Page 20 fIxING BrACKEtS ANd rEPlACING ENd HINGE CAPS Left hinge end cap Align hinge cap to the product. Press and firmly slide the cap to the right. Right hinge end cap Secure fixing bracket hole to Hold onto the corner the ceiling of the enclosure of the end cap, firmly Align hinge cap to with wood screw x1.
- Page 21 froNt fEEt, fIttING KICKStrIPS ANd CovErS To stabilise the product, lower the front Conceal the outer top studs using top feet. Turn clockwise to lower feet. covers. Firmly push top cover over top door studs. Repeat on the opposite side. Repeat x1 each French door and x2 Drawer Kickstrip filter...
-
Page 22: Final Checklist
fINAl CHECKlISt to BE ComPlEtEd By tHE INStAllEr Ice & water models only Ensure change filter icon is enabled. This will remind you when the filter next needs All models replacing. Press and hold for 4 seconds on the internal control panel. Check all parts are installed. - Page 24 www.fisherpaykel.com Copyright © Fisher & Paykel 2015. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available.
