Detailed Specifications

Operating Environment

Operating
Environment
Required Temperature
Range
Required Relative Humidity
Altitude (above sea level)
Sound Power Levels
(Base Configuration)
Sound Pressure Levels
(Base Configuration)

Electrical Requirements

Electrical
North America Voltage : 110-127 VAC +/- 10%
Frequency: 50/60 Hz +/- 3%, 20 A
Europe / Asia / Voltage : 220-240 VAC +/- 10%
South America / Frequency: 50/60 Hz +/- 3%, 10 A
Africa
NA Specific Power Requirements:
C60/C70
Line Option
Voltage
Amperage
Cycles
Xerox Receptacle Part Number
Receptacle NEMA Part Number
Power Cord Length
Receptacle Diagram
The Xerox Color C60/C70
requires the use of a 20-ampere
outlet, which is standard in most
modern office buildings. Consult
the diagram (right side) to
confirm the existence of this
outlet in the proposed
installation space.
EU Specific Power Requirements:
C60/C70
Line Option
Voltage
Amperage
Cycles
Receptacle
Customer Expectation and Installation Guide
C60/C70
50° to 82° F (10° to 28° C)
15% to 85% RH
Max of 8,200 (2,500 meters)
Operating: 7.55 LwAd(B)
Standby: 5.17 LwAd(B)
Operating: 57.4 LpAd(dBA)
Standby: 34.7 LpAd(dBA)
C60/C70
Sole Use (not required but
recommended)
110-127
20
60 Hz, Single Phase
600S3703
5-20R
8.5ft.
120 V 20A
NEMA 5-20R
Sole Use (not required but
recommended)
220-240
10
50 Hz, Single Phase
The Xerox Color C60/C70 requires
the use of a 10-ampere outlet,
which is standard in most modern
office buildings. Consult with local
service to determine the country
specific receptacle and confirm the
existence of this outlet in the
proposed installation space.
Power Cord Length
Accessories Requiring External Power Source
Conv. Stapler
Print Server
Monitor
OHCF (1- or 2- tray)
IFM
Standard Finisher
Booklet Maker Finisher
GBC Advanced Punch
Square-Fold Trimmer
C/Z Folder
Spectrophotometer powered
through USB port

Feature Specifications

Print
3
First Print Out Time
Resolution
Registration
Max Printable Area
Print Features
®
Xerox Color C60/C70
8.5ft.
(120V 15 A) / (220V 10 A
(120V 15 A) / (220V 10 A
(120V 15 A) / (220V 10 A
(120V 15 A) / (220V 10 A)
(120V 15 A) / (220V 10 A
(120V 15 A) / (220V 10 A)
(120V 15 A) / (220V 10 A)
(120V 15 A) / (220V 10 A)
(120V 15 A) / (220V 10 A)
(120V 15 A) / (220V 10 A)
C60/C70
A4 LEF Simplex Color 10.4 seconds /
Black-and-white 8.5 seconds
Up to 2400 x 2400 dpi, 256 shades of gray
Printing registration specifications for 8.5 x
11" (A4):
 ±0.7 mm (side 1-2), along the lead edge
from Trays 1-4
 ±1.2mm (side 1-2) along the side edge
from Trays 1-4
 Skew along Lead Edge from Bypass
tray skew is ±1.5mm.
The Xerox® Color C60/C70 will reproduce
11" x 17" full bleed when printing on 12" x
18" or 13" x 19" paper and A3 full bleed
when printing on SRA3 paper. The
maximum length images (480mm) are
only produced on media 19" long. On all
media there is a Lead Edge deletion of
4mm and a Trail Edge deletion of 4mm.
Side edge deletion is 3mm except for 13"
x 19" media. On 13" x 19" media the side
deletion is 3.5mm.
Copy
Max Image Area
11.69" x 17"
297mm x 432mm
Guaranteed Image Quality Area:
11.69" x 17"
297mm x 432mm
Print
Max Image Area
12.72" x 18.90"
323mm x 480mm
Guaranteed Image Quality Area:
317mm x 480mm 12.48" x 18.90"
Optional:
PostScript Kit
Adobe PostScript printing (includes a
small plug-in card)
Standard:
 Print from USB
 Booklet Creation
 Store and Recall Driver Settings
