Summary of Contents for Makita HP2070
- Page 1 INSTRUCTION MANUAL 2-Speed Hammer Drill HP2070 HP2070F HP2071 HP2071F 004284 DOUBLE INSULATION IMPORTANT: Read Before Using.
-
Page 2: Specifications
ENGLISH (Original instructions) SPECIFICATIONS Model HP2070/HP2070F HP2071/HP2071F Speed High High Concrete 20 mm ----- 20 mm ----- Capacities Steel 8 mm 16 mm 8 mm 16 mm Wood 25 mm 40 mm 25 mm 40 mm No load speed (min... -
Page 3: General Power Tool Safety Warnings
Electrical safety Makita Corporation responsible Power tool plugs must match the outlet. Never manufacturer declare that the following Makita modify the plug in any way. Do not use any machine(s): adapter plugs with earthed (grounded) power Designation of Machine: tools. Unmodified plugs and matching outlets will 2-Speed Hammer Drill reduce risk of electric shock. -
Page 4: Hammer Drill Safety Warnings
14. Remove any adjusting key or wrench before Service turning the power tool on. A wrench or a key left 25. Have your power tool serviced by a qualified attached to a rotating part of the power tool may repair person using only identical replacement result in personal injury. -
Page 5: Functional Description
Lighting up the lamps FUNCTIONAL DESCRIPTION For Model HP2070F, HP2071F CAUTION: 1. Lamp Always be sure that the tool is switched off and • unplugged before adjusting or checking function on the tool. Switch action 1. Lock button 2. Switch trigger 004287 CAUTION: Do not look in the light or see the source of light... -
Page 6: Speed Change
Always set the speed change knob to the correct • Installing or removing drill bit position. If you operate the tool with the speed For Model HP2070, HP2070F change knob positioned halfway between the "I" and "II" position, the tool may be damaged. 1. Chuck key Selecting the action mode 1. -
Page 7: Depth Gauge
Hold the ring and turn the sleeve counterclockwise to OPERATION open the chuck jaws. Place the bit in the chuck as far as it will go. Hold the ring firmly and turn the sleeve clockwise Hammer drilling operation to tighten the chuck. To remove the bit, hold the ring and turn the sleeve CAUTION: counterclockwise. -
Page 8: Maintenance
These accessories or attachments are recommended • lamp (red) for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. - Page 12 Makita Corporation Anjo, Aichi, Japan www.makita.com 884501F220...
