Flueing options and suitability
1
Direct
flueing:
inside of an external wall with a maximum thickness of 430 mm (EF models) and 485 mm (XR/HD
internal models.
Horizontal extension flueing: The same as direct flueing with additional pipe required due to the
longer horizontal distance.
Vertical straight flueing: Installations where the internal unit is flued vertically through the roof.
Combination vertical and horizontal flueing: A combination of all the above.
Description
The flueing for internal
water heaters is a coaxial
design. It has a stainless
steel inner pipe to discharge
products of combustion and
a thermoplastic outer pipe for
air supply to the appliance.
The Rinnai INFINITY® internal
gas hot water heaters are room
sealed appliances—sealed
from the room as it takes
air for combustion from the
outside, and expels products
of combustion outside. No
ventilation in the space where
the water heater is installed is
required.
Each Rinnai INFINITY® water
heater is flued individually.
4 | Continuous flow internal flueing guide: 11748-D 04-13
2
For installations where
the internal continuous flow unit is mounted directly on the
Suitability
The flueing components
outlined in this guide are
suitable for the following
Rinnai INFINITY® models
EFi250
HDi200
HDi200
HD200i
HD200ia REU-VRM2632FFUC
XR26i
XR26ia
4
3
REU-KM3237FFUD
REU-VR2632FFUG
REU-VRM2632FFUG
REU-VRM2632FFUG
REU-VR2632FFUG
REU-VR2632FFUG
Female flue spigot (4913)
All of the 'suitable' models
have a female flue spigot at the
top of the unit.
