Summary of Contents for Laney IRT-Studio IronHeart
- Page 2 WARNING: When using electrical products, basic cautions should always be followed, including the following: 1. Read these instructions. 2. Keep these instructions safe. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7.
- Page 3 ATTENTION: L’utilisation de tout appareil électrique doit être soumise aux precautions d’usage incluant: 1. Lire ces instructions 2. Gardez ce manuel pour de futures références. 3. Prétez attention aux messages de précautions de ce manuel. 4. Suivez ces instructions. 5. N’utilisez pas cette unité proche de plans d’eau. 6.
- Page 4 ACHTUNG: Beim Einsatz von Elektrogeräten müssen u.a. grundlegende Vorsichtsmaßnahmen befolgt werden: 1. Lesen Sie sich diese Anweisungen durch. 2. Bewahren Sie diese Anweisungen auf. 3. Beachten Sie alle Warnungen. 4. Befolgen Sie alle Anweisungen. 5. Setzen Sie dieses Gerät nicht in der Nähe von Wasser ein. 6.
- Page 5 CUIDADO: Cuando use productos electrónicos, debe tomar precauciones básicas, incluyendo las siguientes: 1. Lea estas instrucciones. 2. Guarde estas instrucciones. 3. Haga caso de todos los consejos. 4. Siga todas las instrucciones. 5. No usar este aparato cerca del agua. 6.
- Page 7 1) This device may not cause harmful interference 2) This device must accept any interference received, that may cause undesired operation. Warning: Changes or modification to the equipment not approved by Laney can void the user's authority to use the equipment.
- Page 9 UK - where the sound of metal guitar was born, comes the IRONHEART. With molten metal flowing through its circuits, IRONHEART continues the legacy passed on by previous Laney amps such as KLIPP and AOR, and hits you hard between the eyes like a power hammer from hell.
- Page 10 FRONT PANEL CONTROLS 15W INPUT: Mono jack socket. Connect your guitar here to get full volume output. Use only high quality guitar cable. <1W INPUT: Mono jack socket. Connecting your guitar here switches the output stage to under 1W. This allows you to drive the output stage hard at bedroom volume levels.
- Page 11 Midway (0) is a good starting point. REVERB: Controls the level of the built in Laney-designed digital reverb. POWER SWITCH: Main power switch for the unit.Tube amplifiers take between 30 seconds to 2 minutes to warm up and be ready to play after switching on, this is normal.To turn on, flip the switch to 1 (up).
- Page 12 REAR PANEL CONTROLS L Z B 1 2 3 4 Spare fuse located in the fuse drawer. MAINS INLET SOCKET - MAINS FUSE: Make sure the voltage indicated on the rear panel is correct for your country! This drawer contains the main safety fuse for the unit. The fuse protects the amplifier from damage in the event of fault by disconnecting the mains power supply.
- Page 13 REAR PANEL CONTROLS USB: Record replay connector, (Dry on left channel, processed on right channel). USB2.0 is compatible with Windows XP & operating system Windows 7 operating system & Windows 8 operating system Also compatible with Ma iPad ® ® ®...
- Page 14 Equalisation Per chan nel: Passive Bass, Middle Treble with switchable Deep, Mid Shift & Treble Shift Master section: Dynamics & Ton e Footswitch Laney FS4-IRT (included): Chan nel, Clean, Reverb , Boost Loudspeaker Outputs 8-16 Ohms (switchable) Input Impedance 1M Ohm/47pF...
- Page 15 QUICK START SETTINGS Set To Preference CLEAN RHYTHM ROCK LEAD RHYTHM METAL LEAD RHYTHM DETUNED METAL LEAD...
- Page 16 TUBE AMP TIPS Tube amplifiers generally sound much warmer/sweeter than solid state transistor amplifiers but they also need a little more respect due to the fragile glass tubes. The IRT-Studio uses three 12AX7 preamp tubes, and 2 EL84 output tubes which should give you years of trouble free service, however like all tube amps;...
- Page 17 SAMPLE SETUP Mixer Desk Powered Cab L Z B 1 2 3 4 iPad or iPad mini ® FX Unit FS4-IRT IRT-212...
- Page 18 SIGNAL PATH BLOCK DIAGRAM Aux/CD/MP3 Input Send Return Guitar Input Tube Pre-Amplifier FX Loop Tube Power Amplifier Speaker Load Reverb Cabinet Emulation User External Emulation FX Processors Switch Balanced To PA/Desk Signal Gain Unbalanced Send Return Phones Stereo Jack Line Out Monitor 12dB - 0 - +12dB Switch...
- Page 19 USB INTERFACE FOR PC, MAC & IPAD USB Interface options: USB2.0 Bidirectional to PC/Mac/iPad etc. ■ Record output of amplifier with or without a speaker load connected ■ Simultaneously record dry guitar signal for later processing or Re-Amping. ■ Re-Amp guitar track changing the settings as required ■...
- Page 20 USB INTERFACE FOR PC, MAC & IPAD IRT Studio USB Recording: iPad/MAC/PC Optional Speaker Load Recording Device IRT-Studio Guitar Input Connect your USB recording device (PC/MAC or iPad) via an appropriate USB cable. Your amplifier will send two audio tracks to your recording device: (1) On the Left channel the direct unaffected guitar signal.
- Page 21 USB INTERFACE FOR PC, MAC & IPAD IRT Studio USB “Re-Amping”: Optional Speaker Load iPad/MAC/PC Recording Device IRT-Studio Connect USB cable as for recording. Then connect a good quality screened guitar cable from the rear panel “Re-Amp” output jack and loop round the front panel to guitar input jack.
- Page 22 USB INTERFACE FOR PC, MAC & IPAD IRT Studio USB “Re-Amping” Optional Speaker Load with added Stomp box Effects: iPad/MAC/PC Proceed as for normal “Re-Amping” except in this case Recording Device insert your FX box/s into the Guitar lead from the Re- Amp out jack to the Guitar amplifier input.
- Page 23 RACK MOUNTING Ventilation: Ensure the amplifier is well ventilated and that the ventilation slots in the top, bottom & sides are not obstructed in any way. Avoid dropping anything in through the vents especially liquids of any kind. If this should happen turn off the product and disconnect from the power supply immediately and leave to dry out for at least 24hrs.
