- Page 1 CADNAV2 Cadillac...
-
Page 3: Installation Tools
Components： Video Output Flash GPS Antenna HDMI Cable Cadillac T-Harnesses VHB Tape Video Input Cable Interface Module Installation Tools: Towel Screw Driver Components Pry Tool... - Page 4 Pr y the cover of shift lever. Pull the right side Pr y the right cover of shift and side cover of screws of trim. shift lever.
- Page 5 Remove the right side cover of shift Pr y the trim of shift lever. lever. Remove the right Pr y the right front front cover and cover of shift lever. unfasten the screws.
- Page 6 Unfasten 6 screws from glove box. Take out the glove box.
- Page 7 Remove the screws holding the Radio module in place. Remove the Radio Module...
- Page 8 Attach to the interface module radio module as shown with VHB tape supplied. Video output flash cable OEM video cabal Video output flash cable Place as Connect all shown cables...
-
Page 10: Wiring Diagram
Wiring diagram: HDMI Rear View Camera NOT USED Interface Module Audio USB Connector Power Connector Connector Fuse To Vehicle Central Left Front GPS Antenna Speaker To HMI To Radio Black Gray 16 Pins 20 Pins Connector Connector To HMI Blue LVDS Connector... -
Page 11: Gps Antenna Installation
Wiring diagram Antenna Install antenna in car GPS antenna installation Clean adhesion area with oil-soluble detergent, and fix GPS antenna with adhesive tape tight. . Remove the right cover of storage box, thread the cable from storage box to center console and tie up with OEM cable together. - Page 12 Video output flash cable OEM 20 Pin male OEM 16 Pin male connector connector Video input flash cable Main power cable 16 Pin female connector Main power cable 20 Video input flash cable Pin female connector Video output flash cable Plug all cables as shown.
- Page 13 Pry the cover of Remove the cover of central speaker. central speaker. Unfasten 2 screws from Unplug the cable central speaker. of speaker.
- Page 14 Speaker flash cable Prepare a steer wire and make it goes through from the hole of central speaker Tape the speaker flash to glove box. cable on steer wire. OEM central speaker cable Central speaker flash cable Take back the steer Connect speaker flash wire with speaker cable with OEM central...
- Page 15 Fasten the both side screws of central speaker. Speaker flash cable Plug speaker flash cable Fix back the cover in central speaker. of central speaker. Fix the bracket on the place as shown.
- Page 16 Fix back the glove box. Turn on, enjoy it.
