Page 2
Easy navigation map updates It is easy to keep the navigation system up to date. Simply download new map data from Clarion’s portal site, store them on a microSD card and insert it into the Clarion NX503E via the front card slot.
3.1.2.6 Tips on entering addresses quickly ................43 3.1.3 Selecting the destination from the Places of Interest ..........43 3.1.3.1 Quick search for a Place of Interest ................43 3.1.3.2 Searching for a Place of Interest using preset categories......... 45 NX503E English 3...
Page 4
5.1.2 Daytime and night colour themes................77 5.1.3 Tunnel view ......................77 5.1.4 Route calculation and recalculation ..............78 5.1.5 Green routing .......................80 5.1.6 Road safety cameras and other proximity alert points........80 5.1.7 Speed limit warning.....................81 5.1.8 Traffic information in route planning..............82 4 NX503E English...
The navigation system helps you find your way to your destination with a connected GPS receiver. Clarion Mobile Map does not transmit your GPS position; others cannot track you. It is important that you look at the display only when it is safe to do so. If you are the driver of the vehicle, we recommend that you operate Clarion Mobile Map before you start your journey.
2. Getting started Clarion Mobile Map is optimised for in-car use. You can use it easily by tapping the screen buttons and the map with your fingertips. When using the navigation software for the first time, an initial setup process starts automatically.
The initial setup is now complete. The Configuration wizard can be restarted later from the Settings menu (page 85). After the initial setup, the Map screen appears and you can start using Clarion Mobile Map. 2.1 Buttons and other controls on the screen When you are using Clarion Mobile Map, you usually tap buttons on the touch screen.
Page 9
Slider When a feature can be set Drag the handle to to different values in a move the slider to range, Clarion Mobile Map its new position. shows an indicator on a Tap the slider gauge that displays and where you want sets the value.
Finalising the keyboard entry (accepting the suggested search result) Finalising the keyboard entry (opening the list of search results) Finalising the keyboard entry (saving your input) Cancelling the keyboard entry (returning to the previous screen) 10 NX503E English...
Depending on the speed of the sliding, the list will scroll fast or slow, only a bit or till the end. Moving the map in map browsing mode: grab the map, and move it in the desired direction. NX503E English 11...
When GPS position is available, the Vehimarker is displayed in full colour, now showing your current position. There are screen buttons and data fields on the screen to help you navigate. During navigation, the screen shows route information. 12 NX503E English...
Page 13
If Clarion NX503E is capable of receiving live traffic information, the calculation takes into account traffic delays affecting your route if they are received. However, this calculation is rarely accurate.
2.2.3 Objects on the map 2.2.3.1 Streets and roads Clarion Mobile Map shows the streets in a way that is similar to how the paper road maps show them. Their width and colours correspond to their importance: you can easily tell a motorway from a small street.
The same symbols are used in both fields: Icon Description Turn left. Turn right. Turn back. Bear right. Turn sharp left. Keep left. Continue straight in the intersection. Go left on the roundabout, 3rd exit (next manoeuvre). Enter roundabout (second next manoeuvre). NX503E English 15...
When navigating on multi-lane roads, it is important to take the appropriate lane in order to follow the recommended route. If lane information is available in the map data, Clarion Mobile Map displays the lanes and their directions using small arrows at the bottom of the map.
Tap any of them to display it on the map and add it as a waypoint to your route if needed. If you want to display other types of Places for the exits, you can change the icons in Visual Guidance settings (page 95). NX503E English 17...
3D buildings 3D block representation of full city building data containing actual building size and position on the map. 2.2.3.7 Elements of the active route Clarion Mobile Map shows the route in the following way: Symbol Name Description Current GPS position and Your current position displayed on the map.
Note! If there are traffic events on the recommended route that the application has not bypassed, the icon will open the list of significant traffic events to let you quickly check them. NX503E English 19...
Zooming in and out Changes how much of the map is displayed on the screen. Clarion Mobile Map uses high-quality vector maps that let you examine the map at various zoom levels, always with optimised content. It always displays street names and other text...
It can be opened directly from the Map screen by tapping The menu will close after a few seconds of inactivity or if you tap Most of these functions are shortcuts. They are accessible from the menu system. NX503E English 21...
Page 22
This button skips the next waypoint from the route. My Route / Overview This button opens a 2D map scaled and positioned to (page 62) show the entire route. More / Settings / This button opens the Visual Guidance settings screen. Visual Guidance (page 95) 22 NX503E English...
Page 23
GPS reception This button offers your Home location as a destination. More / Settings / This button opens the parameters of the selected Vehicle Route (page 89) profile. NX503E English 23...
You can also perform some actions on this screen: to save the current position as a Favourite destination. You can also search for assistance near your current position. Tap open a new screen for the Quick search: 24 NX503E English...
: Petrol stations Tap any of the buttons, select a Place from the list, and navigate to it. 2.3 Navigation Menu You can reach all parts of Clarion Mobile Map from the Navigation Menu. You have the following options: ...
Page 26
The button itself is a miniature live map that shows your current position, the recommended route and the surrounding map area. Tap the button to enlarge the map to the full screen. to open the Traffic Summary screen. 26 NX503E English...
3 On-road navigation When first started, Clarion Mobile Map calculates routes using the road network of the high quality vector maps provided with the product. You can set up your route in different ways: If you need a route for immediate navigation, you can select the destination and start navigating to it right away (normal navigation).
The background search is carried out while you enter letters so this number may keep on increasing if you wait a few seconds. Keep on entering new letters while this number is high. 28 NX503E English...
Page 29
Tip! Favourites first: tap then give a name for the new Favourite, and tap to save the location. The map with the destination returns automatically. Now you can start your journey. NX503E English 29...
The list is now filtered. What you see is the list of your Favourite destinations with a matching name. Scroll down the list if necessary and then select one of the destinations from the list. 30 NX503E English...
After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated. Tap to modify route parameters, or tap and start your journey. NX503E English 31...
After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated. Tap to modify route parameters, or tap and start your journey. 32 NX503E English...
Once the destination is selected, a full screen map appears with the selected point in the middle. If necessary, tap the map somewhere else to modify the destination. The Cursor ( ) appears at the new location. Tap to confirm the destination, or tap to select a different destination. NX503E English 33...
Navigation Menu. In the Navigation Menu, tap the following buttons: By default, Clarion Mobile Map proposes the country and city/town where you are. If needed, tap , enter the first few letters of the country name on the keyboard, and select one country from the list of results.
Page 35
If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of results before it appears automatically, tap ). Select the street from the list. NX503E English 35...
Page 36
Favourites first: tap then , give a name for the new Favourite, and tap to save the location. The map with the destination returns automatically. Now you can start your journey. 36 NX503E English...
A full screen map appears with the selected point in the middle. If necessary, tap the map somewhere else to modify the destination. The Cursor ( ) appears at the new location. Tap to confirm the destination, or tap to select a different destination. NX503E English 37...
(to open the list of results before it appears automatically, tap ). Select the street from the list. Enter the intersecting street name: If only a few intersecting streets exist, their list appears immediately. 38 NX503E English...
In the Navigation Menu, tap the following buttons: If necessary, modify the country as described earlier (page 34). Select the destination city/town: Start entering the name of the city/town on the keyboard. Find the city/town you need: NX503E English 39...
Page 40
After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated. Tap to modify route parameters, or tap and start your journey. 40 NX503E English...
If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of results before it appears automatically, tap ). Select the street from the list. NX503E English 41...
Page 42
After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated. Tap to modify route parameters, or tap and start your journey. 42 NX503E English...
3.1.3 Selecting the destination from the Places of Interest You can select your destination from the Places of Interest included with Clarion Mobile Map. Using the same screen, you can find a Place in different ways: ...
Page 44
After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated. Tap to modify route parameters, or tap and start your journey. 44 NX503E English...
If an active route exists, restaurants are searched along the route. If there is no active route (destination is not selected), they are searched around the current position. NX503E English 45...
Page 46
After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated. Tap to modify route parameters, or tap and start your journey. 46 NX503E English...
(The result list will be ordered by the length of the necessary detour.) (optional) If you have selected , select the city/town to search in. Select one of the main Place categories (e.g. Accommodation) or tap to list all Places around the selected location or along the route. NX503E English 47...
Page 48
The name and address of the Place is displayed at the top of the screen. 12. (optional) Tap to see the details of the selected Place. Tap to return to the map. 48 NX503E English...
to search for a place around the destination of the active route. (The result list will be ordered by the distance from the destination.) NX503E English 49...
Page 50
Select one of the main Place categories (e.g. Accommodation) to search in or tap to search among all Places. Select one of the Place subcategories (e.g. Hotel or Motel) to search in or tap to search in the selected Place category. 50 NX503E English...
Page 51
14. If necessary, tap the map somewhere else to modify the destination. The Cursor ) appears at the new location. Tap to confirm the destination, or tap to select a different destination. NX503E English 51...
The name and address of the Place is displayed at the top of the screen. (optional) Tap to see the details of the selected Place. Tap to return to the map. 52 NX503E English...
Preset search categories appear, all for searching around the current position (or around the last known position if the current position is not available): : Car repair and roadside assistance services : Medical and emergency services NX503E English 53...
Page 54
After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated. Tap to modify route parameters, or tap and start your journey. 54 NX503E English...
Adding a location to the list of Favourite destinations is described on page 71. Access the list of Favourites: If you are on the Map screen, tap to open the Quick menu. If you are in the Navigation Menu, tap NX503E English 55...
Now that the Home location is set, you can quickly navigate to it: To select the Home location, do one of the following: If you are on the Map screen, tap and then tap (this button can be added to the Quick menu in Settings - page 88). 56 NX503E English...
The destinations that you have set earlier appear in the History. Access the History: If you are on the Map screen, tap and then tap If you are in the Navigation Menu, tap and then tap NX503E English 57...
You can also select a destination by entering its coordinate. Do as follows: If you are on the Map screen, tap to return to the Navigation Menu. In the Navigation Menu, tap Open the menu and tap 58 NX503E English...
Page 59
After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated. Tap to modify route parameters, or tap and start your journey. NX503E English 59...
Other picture files do not appear in the list. Files must be located on an inserted SD card or USB pendrive, either in the root folder or in a "pictures" folder. 60 NX503E English...
When the new destination is selected, the list returns. To add more destinations, tap where you want to insert the new route point in the list, and repeat the above procedure. NX503E English 61...
3.3 Checking route parameters and accessing route related functions You can check different parameters of the route recommended by Clarion Mobile Map. If you are on the Map screen, tap to return to the Navigation Menu.
(intermediate destination) to the route or append the newly selected destination at the end of the current route. to plan a new route to the newly selected location. The previous destination and waypoint(s) are deleted. NX503E English 63...
GPS position. If you are on the Map screen, tap to return to the Navigation Menu. In the Navigation Menu, tap If you already have a route, tap . If you are starting a new route, 64 NX503E English...
You can edit the route by modifying the list of destinations. You can add or remove destinations, modify the start position or reorder the list. If you are on the Map screen, tap to return to the Navigation Menu. In the Navigation Menu, tap NX503E English 65...
3.4.4 Pausing the active route You do not need to pause the active route: when you start driving again, Clarion Mobile Map restarts the voice instructions from your position. 3.4.5 Cancelling the active route To cancel the navigated route, do one of the following: ...
Select one of the route alternatives and tap to return to the previous screen. Clarion Mobile Map recalculates the route. The orange line now shows the new recommended route. NX503E English 67...
You see the basic details of three route alternatives with the selected route planning method. Tap any of them to see it on the map. Or if you cannot find a good alternative, tap and scroll down for routes with different routing methods. 68 NX503E English...
Select one of the route alternatives then tap and hold for a few seconds to return to the Map screen. Clarion Mobile Map recalculates the route. The orange line now shows the new recommended route. 3.4.8 Changing the vehicle used in route planning To recalculate the active route for a different vehicle, do as follows.
Clarion Mobile Map plans the best toll-free route. - Clarion Mobile Map includes ferries in a planned route by default. However, a map does not necessarily contain information about the accessibility of temporary ferries. You might also need to pay a fare on ferries.
When the full screen map appears with the selected location in the middle, tap (optional) Using the keyboard, you can change the name offered for the Favourite. Tap to enter numbers or symbols. to save the location as a new Favourite destination. NX503E English 71...
On the newly opened screen, select the type of the alert point, the direction from which you expect the alert, and (if applicable) the speed limit for this alert point. to save the location as a new alert point. 72 NX503E English...
On the newly opened screen, modify the type of the alert point, the direction from which you expect the alert, or (if applicable) the speed limit for this alert point. to save the changes to the alert point. NX503E English 73...
: Jump to the next route event (manoeuvre). : Pause the simulation. : Jump to the previous route event (manoeuvre). 74 NX503E English...
Page 75
: Tap to increase the speed of the simulation to 4, 8 or 16 times faster. Now tap again to return to the normal speed. to stop the simulation. NX503E English 75...
4 Off-road navigation When first started, Clarion Mobile Map calculates routes using the road network of the high quality vector maps provided with the product. You can switch the application to off-road mode in Navigation settings in one of the following ways: ...
While driving without an active route: Smart Zoom will zoom in if you drive slowly and zoom out when you drive at high speed. 5.1.2 Daytime and night colour themes Clarion Mobile Map uses different colour themes during the day and during the night for both the map and the menu screens. ...
: Results in a route with fewer turns and no difficult manoeuvres. With this option, you can make Clarion Mobile Map to take, for example, the motorway instead of a series of smaller roads or streets. Vehicle types: When creating a new vehicle profile, select one of the below vehicle types.
Page 79
Real-time Traffic events are also taken into account and sometimes greatly modify the route. Clarion Mobile Map automatically recalculates the route if you deviate from the proposed itinerary or if a newly received Traffic event concerns a part of the recommended route.
There is a special proximity warning for road safety cameras (like speed or red light cameras) and other proximity alert points (like schools or railroad crossings). These alert points are preloaded in Clarion Mobile Map. You can download more from www.clarion.naviextras.com or you can upload points in a specific text file if needed.
(ask your local dealer), or may not be fully correct for all roads in the map. The maximum speed set in the vehicle profile is also used for this warning. Clarion Mobile Map alerts you if you exceed the preset value even if the legal speed limit is higher.
Clarion NX503E contains the TMC receiver that is needed to receive Traffic events. If public Traffic data is broadcast at your location, Clarion Mobile Map automatically takes into account the traffic events received. You do not need to set anything in the program. The receiver will automatically search the FM radio stations for TMC data, and the decoded information will immediately be used in route planning.
Page 83
Note! If there are traffic events on the recommended route that the application has not bypassed, the icon will open the list of significant traffic events to let you quickly check them. NX503E English 83...
Button Description You can configure the program settings, and modify the behaviour of Clarion Mobile Map. Fine-tune route planning options, change the look of the Map screen, turn on or off warnings, or restart the Configuration wizard, etc. See the next chapter for details.
You can also access program usage statistics. 5.3 Settings menu You can configure the program settings, and modify the behaviour of Clarion Mobile Map. Tap the following buttons: The Settings menu has several options. Tap or scroll with your finger to see the full list.
Natural Voice: These prerecorded sounds can only tell you basic information about turns and distances. TTS Voice: These computed voices can tell you complex instructions, they can tell you the street names or read out the system messages for you. 86 NX503E English...
Page 87
Maps may contain information about the speed limits of the road segments. Clarion Mobile Map is able to warn you if you exceed the current limit. This information may not be available for your region (ask your local dealer), or may not be fully correct for all roads in the map.
Use this switch to enable or disable the TMC receiver that can receive real-time traffic information. The rest of the buttons below are all related to the TMC function and are available only if the receiver is enabled. 88 NX503E English...
When calculating a new route, or when recalculation becomes necessary based on the received Traffic events, Clarion Mobile Map avoids traffic events if it makes sense. You can also set the minimum delay that triggers route recalculation, and you can instruct the application if you want to confirm every recalculation.
Page 90
They can be enabled or disabled separately from toll roads. Clarion Mobile Map includes toll roads (pay roads where there is a per-use charge) in the routes by default. If you disable toll roads, Clarion Mobile Map plans the best toll-free route.
Page 91
Manoeuvre restrictions and directional constraints are taken into account when planning a route. Roads are used only if access for cars is allowed. Private roads and resident-only roads are used only they are inevitable to reach the destination. Walkways are excluded from routes. NX503E English 91...
Page 92
Usually the best selection for fast and normal cars. Gives a short route to minimise the distance to travel. It can be practical for slow vehicles. Searching for a short route regardless of the speed, this route type is rarely practical for normal vehicles. 92 NX503E English...
5.3.5 User profiles If more drivers use Clarion Mobile Map for navigating, their settings can be remembered by using one of the user profiles. Rename the profiles after tapping the edit button on the right so that all users know which profile to use and switch between profiles by tapping its name.
Page 94
Tap the name of the Place category to open the list of its subcategories. to save the current Place visibility set or to load a previously saved one. Here you can also revert to the default visibility settings. 94 NX503E English...
When you slow down while driving on a motorway, there is a chance that you are in a traffic jam so Clarion Mobile Map offers you a detour using the next exit. The message shows you distance of the exit and the difference in distance and estimated time compared to the original route.
Also, if there are avoidable parts of the original route ahead (like a tunnel, a toll road or a ferry), you will find them in the list in case you want to bypass them with the help of Clarion Mobile Map.
Track logs, the sequence of the positions given by the GPS receiver, can be saved together with trip logs. They can later be displayed on the map. You can let the application save the track log whenever it saves a trip. NX503E English 97...
Colour theme Clarion Mobile Map comes with different colour themes for daytime or night use of the map and menu screens. Themes are custom graphic settings and they can have different colours for streets, blocks or surface waters in 2D and 3D modes, and they display shades or shadows in different ways in 3D mode.
Page 99
Road Safety Camera Special alert points for speed, red light or bus lane cameras. Different data sources are available. You can configure Clarion Mobile Map to warn you when you approach one of these cameras. Detecting the location of Road Safety Cameras is prohibited in certain countries. It is the sole responsibility of the driver to check whether this feature can be used during the trip.
4.4 Error corrections, additions, updates or upgrades to the Software Product or the Databases used by the User following the conclusion of this Agreement shall also be deemed parts of the Software Product and Used in accordance with this Agreement. 100 NX503E English...
Page 101
Software Product (including translation (compilation) to other programming languages); 7.1.4 to decompile, disassemble, or reverse engineer the Software Product; 7.1.5 to evade the protection of the Software Product or to modify, circumvent or obviate such protection through technological or by any other means; NX503E English 101...
Page 102
NOTWITHSTANDING ANYTHING TO THE CONTRARY CONTAINED HEREIN, THIRD PARTY SUPPLIERS (E.G. DATABASE OWNERS, MAP PROVIDERS) OR AGENTS OF LICENSOR SHALL HAVE NO MONETARY LIABILITY TO THE USER FOR ANY CAUSE (REGARDLESS OF THE FORM OF ACTION) UNDER OR RELATING TO THIS AGREEMENT. 102 NX503E English...
Page 103
User is obliged to use the services in line with the terms and conditions thereof. 9.5 Purchase and acquisition of activation license for the use of certain functions, Databases, content or services may require Internet connection with no alternative way of acquisition offered by Licensor. 10 Anonymous data collection NX503E English 103...
Page 104
Applicable third party terms shall be referred in the "About" section of the Software Product or as part of this Agreement. When first using / enabling Online Content, User accepts compliance with those third party terms and conditions. 104 NX503E English...
Page 105
User accepts that the Google Local Search is declared "deprecated" and is not commercially supported by Google, Inc. and also it may be made unavailable without notice by Google in accordance with relevant terms service http://code.google.com/intl/hu- HU/apis/websearch/terms.html . NX503E English 105...
