Page 1: Replacement Parts List
PARTS & SERVICE DEPARTMENT Nashville, Tennessee 615-889-8900 • Fax: 615-547-1000 www.Lochinvar.com Replacement Parts List Power-Fin Heating Boilers & Hot Water Supply Boilers PB/PF 502 thru 1302 PB1-PF1-RP-04 ®... - Page 2 CONTROL PANEL ASSEMBLY GAS TRAIN ASSEMBLIES PB1-PF1-RP-04 2 of 4 HEAT EXCHANGER ASSEMBLY...
- Page 3 ITEM PART RLY2114 CONNECTION BOARD RLY2210 BOARD, CONTROL ,USER INTERFACE RLY2100 BOARD, CONTROL, MAIN RLY2706 PUMP RELAY FAN3727 FAN, COMBUSTION AIR SWT2006 ON / OFF SWITCH TST2032 THERMOSTAT SENSOR GTP2900 GAUGE, TEMP AND PRESSURE HLC2510 THERMOSTAT, HI LIMIT 200 DEGREE 10 HLC2701 THERMOSTAT, HI LIMIT W/ AUTO RESET 11 PLT3400...
- Page 4 ITEM PART 23 HEX3228 HEAT EXCHANGER (HLW) 23 HEX3236 HEAT EXCHANGER (H) 23 HEX3229 HEAT EXCHANGER (HLW) 23 HEX3237 HEAT EXCHANGER (H) 23 HEX3230 HEAT EXCHANGER (HLW) 23 HEX3238 HEAT EXCHANGER (H) 23 HEX3231 HEAT EXCHANGER (HLW) 23 HEX3239 HEAT EXCHANGER (H) 24 JKH2016 V BAFFLE (20 REQ.) 24 JKH2017...
