Peavey DM 115 Operating Manual

Hide thumbs Also See for DM 115:

Advertisement

Table of Contents

DM
115
™
Powered Speaker System
Operating
Manual
www.peavey.com

Advertisement

Table of Contents
loading

Related Manuals for Peavey DM 115

Summary of Contents for Peavey DM 115

  • Page 1 ™ Powered Speaker System Operating Manual www.peavey.com...
  • Page 2 FCC/ICES Compliancy Statement  This device complies with Part 15 of the FCC rules and Industry Canada license‐exempt RSS Standard(s).  Operation is  subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must  accept any interference received, that may cause undesired operation.  Le présent appareil est conforme aux CNR d’lndustrie Canada applicables aux appareils radio exempts de  licence.  L’exploitation est autorisée aux deux conditions suivantes: (1) I’appareil ne doit pas produire de  brouillage, et (2) I’utilisateur de I’appareil doit accepter tout brouillage radioélectrique subi, même si le  brouillage est susceptible d’en compromettre le fonctionnement.  Warning: Changes or modifications to the equipment not approved by Peavey Electronics Corp. can void the  user’s authority to use the equipment.  Note – This equipment has been tested and found to comply with the limits for a Class B digital device,  pursuant to Part 15 of the FCC Rules.  These limits are designed to provide reasonable protection against  harmful interference in a residential installation.  This equipment generates, uses, and can radiate radio  frequency energy and, if not installed and used in accordance with the instructions, may cause harmful  interference to radio communications.  However, there is no guarantee that interference will not occur in a  particular installation.  If this equipment does cause harmful interference to radio or television reception,  which can be determined by turning the equipment off and on, the user is encouraged to try and correct the  interference by one or more of the following measures.  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is ...
  • Page 3 ENGLISH Introduction Thank you for purchasing the powered Peavey® DM™ 115 powered speaker system. The DM™ 115 features a reliable bi-amped power section that provides a total of 660 Watts of peak available dynamic power with signal compression to prevent audible overload. The analog power amplifiers and linear power supply are coupled with a DSP based crossover and EQ.
  • Page 4 A typical signal source for the line-level inputs of the Peavey DM™115 would be a sound reinforcement mixing console (mixer) or the output from a CD player, MP3 player or tape deck. A dynamic microphone can be con-...

  • Page 5: On/Off Switch

    LOWER REAR PANEL BOTTOM OF REAR PANEL ON-OFF SWITCH (1) FUSE (1) This rocker switch supplies AC power to the DM 115 when switched to the ON position. The ON position is ™ with the left side of the switch pushed “in” or nearly flush with the rear panel. The unit is AC power line fuse protected from overloads and fault conditions with a slow-blow 5 x 20mm 250V fuse.

  • Page 6: Voltage Selector Switch

    ground pin, a suitable grounding adapter should be used and the third wire should be grounded properly. To prevent the risk of shock or fire hazard, always be sure that the mixer and all other associated equipment are properly grounded. VOLTAGE SELECTOR SWITCH (4) The DM™115 has a voltage selector switch to allow switching between an input power voltage of 120VAC to a range from 220VAC to 240VAC, all at either 50 or 60 cycles per second (Hz).

  • Page 7: Mic/Line Switch

    UPPER REAR PANEL INPUT (5) The line-level input is of the medium impedance balanced type. The jack is a combo female XLR and 1/4" TRS connector. Sensitivity of this input is 0.39 volts for full output, when the MIC/LINE switch (7) is in the LINE position GAIN (6) Controls the gain or output level of the input signal.
  • Page 8 UPPER REAR PANEL Push-To-Select button (12) Rotary knob that allow the user to select and choose menu options on the LCD display screen (11). Pushing the button in till it detents makes a menu choice. OPERATING INSTRUCTIONS Cautions The unit must be disconnected from the AC power source before any work is done on it. Refer all servicing to qualified service personnel.
  • Page 9 Use of the DM™115 with a Speaker Stand The DM™115 has a stand mount cup molded-in so that the system can be stand mounted on a standard 1 3/8” (36mm) diameter stand pole. When using stands or poles, be sure to follow these precautions: Check the stand or pole specs to make sure that it can support the weight of the DM™115 (42 lbs./19.1 kg), and observe all safety precautions stated by the stand manufacturer, including the maximum height the stand is rated for.
  • Page 10 With the Level control adjusted fully clockwise, gain is at maximum and the input sensitivity is 0.39 V RMS for full-rated output with the line level position of the Mic-Line Switch (7). When driving the DM™115 from a mix- er, it may be advantageous to reduce the input sensitivity by turning the Level control to the halfway point. The DM™115 will now more closely match a typical power amp.
  • Page 11 Once the desired menu choice is displayed, push in the "Push-to-Select" knob. If the default LCD message display is present (e.g. DM 115 and 01: EDM ), then push in the "Push-to-Select" knob to bring up the menu, which will display the first choice of " Recall preset ".

  • Page 12: Troubleshooting

    If the DM™115 has been subjected to direct sunlight or excessive heat, the built-in thermal protection may have been triggered. If so, turn off the DM™115 and let it cool for a sufficient amount of time. If there is still no output, contact your authorized Peavey dealer or the Peavey International Service Center. Hum or Buzz...
  • Page 13 If, after checking all the things listed to check and anything else you can think of to check safely, and the system still exhibits problems, carefully note all conditions and check with your Peavey dealer for advice. Care and Maintenance Your DM™115 is a sturdy and durable product and will provide years of reliable use if properly cared for.
  • Page 14 124 dB with music as a source, when measured at a distance of 1M and driven to full output capacity. The system shall utilize a 15” heavy-duty woofer and a Peavey® DX™14 1.4” titanium dia- phragm dynamic compression driver. The nominal radiation pattern shall be 110° in the horizontal plane, and 80°...

  • Page 15: Specifications

    SPECIFICATIONS Frequency Response: 62 Hz to 19 kHz, +/- 6 dB, anechoic environment Usable Low Frequency limit (-10 dB point anechoic): 52 Hz Nominal sensitivity (1W @1M, swept sine input in anechoic environment): 96 dB (average) Maximum Sound Pressure Level (1 meter): 124 dB SPL peak with music Radiation Angle measured at -6 dB point of polar response: Nominal: 110 degrees horizontal X 80 degrees vertical...
  • Page 16 Nominal Amplifier Frequency Response: +1, -3 dB from 20 Hz to 20 kHz Hum and Noise: Greater than 90 dB below rated power THD and IM: Typically less than 0.7 % Power requirements of Peavey DM™115 System: Nominal 170 Watts, 120 VAC 60 Hz Fuse Type For 120 VAC USE: International fuse classification T4AH 250V.
  • Page 18 What Peavey Will Do We will repair or replace (at Peavey’s discretion) products covered by Warranty at no charge for labor or materials. If the product or component must be shipped to Peavey for Warranty service, the consumer must pay initial shipping charges. If the repairs are covered by Warranty, Peavey will pay the return shipping charges.
  • Page 19 U.S. customer warranty registration. Logo referenced in Directive 2002/96/EC Annex IV (OJ(L)37/38,13.02.03 and defined in EN 50419: 2005 The bar is the symbol for marking of new waste and is applied only to equipment manufactured after 13 August 2005...
