HP ProLiant DL100 Storage Server
Rack Installation Instructions
Second Edition (September 2004)
Part Number: 372017-002
Rack
Installation
Instructions
372017- 002
This document is for the person who installs, administers, and
troubleshoots servers and storage systems. HP assumes you are
qualified in the servicing computer equipment and trained in
recognizing hazards in products with hazardous energy levels.
Operating system
The HP ProLiant DL100 Storage Server is preloaded with the
Windows ® Storage Server 2003 operating system. Prior to power
up, deployment instructions found in the "Installation Guide"
should be followed to enable the successful configuration of the
storage server in addition to the guidelines found below.
Required Items:
Installation Guide
Administration Guide
To begin the first-time startup procedure:
Be sure that the server is safely installed in an adequate
environment.
Be sure that the power cables and peripheral devices are
plugged in and AC power is supplied to the server.
Refer to the Installation Guide prior to powering up the server.
Front and rear views
UID
UID
1
Reserved
1
Hard drive status/activity
2
Power button
3
UID button
4
1 2 3 4
13 12
Power connector
1
Mouse (green)
2
Keyboard (purple)
3
Serial (teal)
4
Video (blue)
5
NIC 1 (Eth0)
6
1 3 4 6
UID
2 5
2 1 2 1
Power LED
5
UID LED
6
NIC 1 activity LED
7
NIC 2 acitivity LED
8
5 6 7 8
11 10 9
78 HP SCSI Ultra 160 Dual Port
Adaptec 2410SA HW RAID 4 Port
9
SATA controller (internal)
NIC 2 (Eth1)
-
UID light and button
q
we USB
8
UID
7
2
