- Page 1 HS-TS300 YL,YH,YJ SERVICE MANUAL STEREO RADIO BASIC TAPE MECHANISM : 4ZM-2 P13NC CASSETTE PLAYER • This Service Manual is the "Revision Publishing" and replaces "Simple Manual" (S/M Code No. 09-001-427-5T1). S/M Code No. 09-005-427-5R1...
-
Page 2: Specifications
Power source : DC 3V using two R6 (size AA) batteries AC house current using the optional AC adaptor Aiwa AC-D302 Speaker : Diameter 50 mm (2 inches), 8 ohm Maximum dimensions : 116.4 (W) x 92 (H) x 42 (D) mm in.) -
Page 3: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C601 87-012-141-080 CAP,CHIP S 0.22-16F C602 87-010-184-080 CAP,CHIP S 3300P(K) 87-A21-387-040 C-IC,TA2145F C603 87-010-197-080 CAP,CHIP S 0.01 DM 87-A20-851-040 C-IC,TA2111F C604 87-010-197-080 CAP,CHIP S 0.01 DM 87-002-232-080 C-IC,NJM2073M(T1) C605... -
Page 4: Transistor Illustration
CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure Resistor Code Value of resistor Chip resistor Dimensions (mm) Wattage Type Tolerance Symbol Resistor Code Form 1/16W 1005 0.35 1/16W 1608 0.45 1/10W 2125 1.25 0.45 1/8W 3216 0.55 TRANSISTOR ILLUSTRATION RN1411 RN1404 RN1407... - Page 5 WIRING - 5 -...
- Page 6 SCHEMATIC DIAGRAM - 6 -...
- Page 7 ADJUSTMENT A MAIN C.B VOLUME L104 PVC101 PVC1 L102 TC101 TC104 TC102 L103 SFR51 TC103 SFR 1 L105 PHONES P HEAD L101 (BAR ANT) BAR ANT <TUNER SECTION> <TAPE PLAYER SECTION> 1. AM IF Adjustment 6. Tape Speed Adjustment L105 ..............455 kHz Settings : •...
-
Page 8: Mechanical Exploded View
