- Page 1 ELAR EXTQW FLOOD HP™ user manual ...
- Page 2 Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040 323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com Elation Professional B.V.
-
Page 3: Table Of Contents
C O N T E N T S General Information Warranty Safety Instructions General Guidelines Fixture Installation Understanding DMX Fixture Control DMX Channel Functions And Values Cleaning and Maintenance Technical Specifications Optional Accessories ELAR EXTQW FLOOD HP™ User Manual ver 2... -
Page 4: General Information
O P T I O N A L C O R R O S I O N - R E S I S T A N T C O A T I N G Optional Corrosion-Resistant Coatings may be available for this fixture. Please consult your Elation Professional sales representative for details. ELAR EXTQW FLOOD HP™ User Manual ver 2... - Page 5 You may also visit us on the web at www.elationlighting.com any comments or suggestions. For service related issue please contact Elation Professional®. ELATION SERVICE USA - Monday - Friday 8:00am to 5:00pm PST...
- Page 6 ELAR EXTQW FLOOD HP™ User Manual ver 2...
-
Page 7: Warranty
No accessories should be shipped with the product. If any accessories are shipped with the product, Elation Professional® shall have no liability what so ever for loss and/or or damage to any such accessories, nor for the safe return thereof. -
Page 8: Safety Instructions
Do not operate this fixture if the power cord has become frayed, crimped and/or damaged. If • the power cord is damaged, replace it immediately with a new one of similar power rating. ELAR EXTQW FLOOD HP™ User Manual ver 2... -
Page 9: General Guidelines
• Use the original packaging and materials to transport the fixture in for service. DO NOT TOUCH the housing bare-hand during its operation. Turn OFF the power • and allow approximately 15 minutes for the fixture to cool down before replacing or serving. ELAR EXTQW FLOOD HP™ User Manual ver 2... -
Page 10: Fixture Installation
Yoke. When mounting this fixture to truss be sure to secure an appropriately rated clamp using an M10 screw fitted through the center hole of the mounting Yoke. ELAR EXTQW FLOOD HP™ User Manual ver 2... - Page 11 S A F E T Y C A B L E Always use a Safety Cable whenever installing this fixture in a suspended environment to ensure the fixture will not drop if the clamp fails. ELAR EXTQW FLOOD HP™ User Manual ver 2...
- Page 12 . e l a t i o n l i g h t i n g . c o m SECURING ™ Regardless of the rigging option you choose for your ELAR EXTQW FLOOD HP always be sure to secure your fixture with a safety cable.
-
Page 13: Understanding Dmx
1 to that fixture no matter where it is ™ located in the DMX chain. The ELAR EXTQW FLOOD HP can be controlled via DMX-512 protocol and the DMX address is set via the control menu. - Page 14 Connect the provided XLR cable to the female XLR output of your controller and the ™ other side to the male XLR input of the ELAR EXTQW FLOOD HP . The diagram below illustrates a typical DMX-512 connection when the fixture is in the 8 Channel Mode.
- Page 15 ™ In the case of the ELAR EXTQW FLOOD HP , when in the 12 Channel Mode you should set the starting DMX address of the first unit to 1, the second unit to 9 (1 + 8), the third unit to 17 (9 + 8), and so on.
-
Page 16: Fixture Control
F I X T U R E C O N T R O L ON-BOARD SYSTEM MENU The ELAR EXTQW FLOOD HP™ requires the ELAR WR II™ Infrared Wireless Remote Controller (pictured below) to make any menu/mode changes to the fixture. This remote is an optional accessory and is INCLUDED. - Page 17 AUTO RUN MODE. You can also press the SPEED button to enter SPEED SET MODE and press the “+”and “-” buttons or press two numbers 01-16 to adjust the auto run speed: SPEED, 01 = SLOWEST SPEED, 16 = FASTEST SPEED. ELAR EXTQW FLOOD HP™ User Manual ver 2...
- Page 18 LED color. You can also press the FLASH button to turn ON flash and press the “+”and “-” buttons or press two numbers 00-15 to adjust the flash speed: 00 = OFF, 01= SLOWEST SPEED, 15 = FASTEST SPEED. ELAR EXTQW FLOOD HP™ User Manual ver 2...
- Page 19 If the DMX address was entered incorrectly, the LEDs will glow and a new DMX address must be entered. BLACK OUT MODE Press the “BLACK OUT” button to turn all the LEDs ON/OFF, like a shutter. ELAR EXTQW FLOOD HP™ User Manual ver 2...
-
Page 20: Dmx Channel Functions And Values
STROBING SLOW - FAST DMX Mode 4: 4 Channel Mode Channel Value Function 0-255 RED 0% - 100% 0-255 GREEN 0% - 100% 0-255 BLUE 0% - 100% 0-255 WHITE 0% - 100% ELAR EXTQW FLOOD HP™ User Manual ver 2... - Page 21 MASTER DIMMER 0% - 100% 0-15 STROBING OFF 16-255 STROBING SLOW - FAST STATIC COLOR MACROS (See DMX Mode 1) Note: Channel 1, 2 and 3 will not work, when Channel 7 is being used. ELAR EXTQW FLOOD HP™ User Manual ver 2...
- Page 22 When Channel 7 fader level is between the values of (192 and 255), Channel 8 fader will select one of the 16 COLOR FADE MODES, and Channel 6 will control COLOR FADE speed. ELAR EXTQW FLOOD HP™ User Manual ver 2...
-
Page 23: Cleaning And Maintenance
Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized Elation service technician. Should you need any spare parts, please order genuine parts from your local Elation dealer. -
Page 24: Technical Specifications
CE | IP65** **Optional Corrosion-Resistant Coating may be available for this fixture. Please consult an Elation sales representative for details. Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. -
Page 25: Photometric Data
. e l a t i o n l i g h t i n g . c o m PHOTOMETRIC DATA DIMENSIONAL DRAWINGS Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. ELAR EXTQW FLOOD HP™ User Manual ver 2... -
Page 26: Optional Accessories
3m (4pin) Power Ext/Link Cable ELAR 3C-1M 1m (3pin) Signal Ext Cable ELAR 3C-5M 5m (3pin) Signal Ext Cable Infrared Wireless Remote Controller Required To Program Fixture ELAR WR II *Not Included Purchased Separately ELAR EXTQW FLOOD HP™ User Manual ver 2...
