Yaesu VX-8DR Operating Manual
  1. Manuals
  2. Brands
  3. Yaesu Manuals
  4. Transceiver
  5. VX-8DR
  6. Operating manual

Yaesu VX-8DR Operating Manual

50/144/430 mhz triple-band heavy duty submersible transceiver
Hide thumbs Also See for VX-8DR:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Manual
50/144/430 MHz
TRIPLE-BAND HEAVY DUTY
SUBMERSIBLE TRANSCEIVER
VX-8DR/DE
O
M
PERATING
ANUAL
YAESU MUSEN CO., LTD.
Tennozu Parkside Building
2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan
YAESU USA
6125 Phyllis Drive, Cypress, CA 90630, U.S.A.
YAESU UK LTD.
Unit 12, Sun Valley Business Park, Winnall Close
Winchester, Hampshire, SO23 0LB, U.K.
YAESU HK LTD.
Unit 1306-1308, 13F., Millennium City 2, 378 Kwun Tong Road,
Kwun Tong, Kowloon, Hong Kong

Advertisement

Table of Contents
loading

Related Manuals for Yaesu VX-8DR

Summary of Contents for Yaesu VX-8DR

  • Page 1 50/144/430 MHz TRIPLE-BAND HEAVY DUTY SUBMERSIBLE TRANSCEIVER VX-8DR/DE PERATING ANUAL YAESU MUSEN CO., LTD. Tennozu Parkside Building 2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan YAESU USA 6125 Phyllis Drive, Cypress, CA 90630, U.S.A. YAESU UK LTD. Unit 12, Sun Valley Business Park, Winnall Close Winchester, Hampshire, SO23 0LB, U.K.

  • Page 2: Table Of Contents

    Automatic Lamp Illumination on Scan Stop ......71 Accessories & Option ..............6 Band Edge Beeper ..............71 ® Accessories Supplied with the VX-8DR/DE ......6 Bluetooth Operation ............. 72 Available Options for your VX-8DR/DE ......... 7 Pairing ..................72 Installation of Accessories ............

  • Page 3: Introduction

    NTRODUCTION The Ultra Compact VX-8DR/DE ( 2.4” W x 3.7” H x 0.9” D ( 60 W x 95 H x 24.2 D )) is thinner than the previous advanced model - It is packed with advanced technology and features, de- signed for outdoor operation.

  • Page 4: Controls &Connections

    The functions of the keys are described Some stereo earphone plugs may not fit in details on pages this jack, depending on the shape of the 4 and 5. connection plug. VX-8DR/DE O PERATING ANUAL...

  • Page 5: Display Icons & Indicators

    Active Bell Alarm Active : Key Lock Active : Receiving an FM Stereo Signal Mute Feature Active PERATING : VOX Feature Active NFM: FM : Battery Saver Active WFM: Wide FM : Battery Indicator AM: AM VX-8DR/DE O PERATING ANUAL...

  • Page 6: Keypad Functions

    Activates the AF Dual Activates the Spectrum ECONDARY UNCTION Selects the desired transmit function while receiving the Analyzer (Spectra-Scope power output level. RESS Broadcast Stations. feature. HIRD UNCTION No Action. No Action No Action RESS AND VX-8DR/DE O PERATING ANUAL...
  • Page 7 Enters the Broadcast ECONDARY UNCTION key to switch the mode. Reception mode. RESS frequency display be- tween the “Double-size Character” and “Small HIRD UNCTION No Action No Action Character” mode while RESS AND Mono band operation. VX-8DR/DE O PERATING ANUAL...

  • Page 8: Accessories & Option

    PA-44U (230 VAC, Type-BF plug: AAG85X004) Connector Unit 1 pc (CB4392001) Belt Clip 1 pc (RA1053600) Screws 2 pcs (M3x10SUS: U24310020) Plastic Cap 1 pc (RA1054200) Sheet 2 pcs (RA1066900) Operating Manual 1 pc Warranty Card 1 pc VX-8DR/DE O PERATING ANUAL...

  • Page 9: Available Options For Your Vx-8Dr/De

    Availability of accessories may vary. Some accessories are supplied as standard per local requirements, while others may be unavailable in some regions. Consult your Yaesu Dealer for details regarding these and any newly-available options. Connection of any non-Yaesu ap- proved accessory, should it cause damage, may void the Limited War- ranty on this apparatus.

  • Page 10: Installation Of Accessories

    Do not over-tighten by use of extreme force. When operating the VX-8DR/DE on the 50 MHz band and lower frequencies, disconnect the antenna cap from the base antenna, then screw the Extender Element onto the Antenna Base.

  • Page 11: Installation Of Fnb-101Li Battery Pack

    Pack from the transceiver. NSTALL ATTERY ELEASE 1) The VX-8DR/DE battery must be correctly in- stalled, to maintain the waterproof integrity. 2) Always use the FNB-101LI or optional FNB- 102LI Lithium-Ion Battery Pack. 3) Battery Pack shall not be exposed to excessive heat such as sunshine, fire, or the like.

  • Page 12: Battery Life Information

    2) Perform the battery charging where the ambient temperature range +41 °F to +95 °F (+5 °C to +35 °C). Charge out of this range could cause damege to the battery pack. 3) Use only the Yaesu Musen Co., Ltd. model PA-44B/C/U Battery Charger. ATTERY NFORMATION When the battery charge is almost depleted, a “Low Voltage”...

  • Page 13: Installation Of Fba-39 Alkaline Battery Case

    The FBA-39 is designed for use only with AA-type Alkaline cells. If you do not use the VX-8DR/DE for a long time, remove the Alkaline batteries from the FBA-39, as battery leakage could cause damage to the FBA-39 and/or the trans- ceiver.

  • Page 14: Interface Of Packet Tncs

    The input level to the VX-8DR/DE from the TNC should be adjusted at the TNC side; the optimum input volt- age is approximately 5 mV at 2000 Ohms. Be sure to turn the transceiver and TNC off before connecting the cables, to prevent volt- age spikes from damaging your transceiver.

  • Page 15: Operation

    Hi! I’m R. F. Radio, and I’ll be helping you along as you learn the many features of the VX-8DR/DE. I know you’re anxious to get on the air, but I encourage you to read the “Operation” section of this manual as thoroughly as possible, so you’ll get the most out of this fantastic new transceiver.

  • Page 16: Squelch Adjustment

    HOUR LOCK The VX-8DR/DE has a 24-hour clock with a calendar which covers all dates from January 1, 2000 through December 31, 2099. Set the clock according to the “Clock Set” column on page 120.

  • Page 17: Selecting The Operating Band

    PERATION ELECTING THE PERATING In the factory default configuration, the VX-8DR/DE operates in the “Dual Receive” mode. During Dual Receive operation, the “A-Band” frequency will be displayed on the upper part of the LCD, and the “B-Band” frequency will be displayed on the lower part. The “Operating”...

  • Page 18: Selecting The Frequency Band

    PERATION ELECTING THE REQUENCY The VX-8DR/DE covers an incredibly wide frequency range, over which a number of different operating modes are used. Therefore, the VX-8DR/DE’s frequency coverage has been divided into different PERATING REQUENCY ANGE “VFO-A” “VFO-B” UMBER operating bands. Each...

  • Page 19: Frequency Navigation

    PERATION REQUENCY AVIGATION The VX-8DR/DE will initially be operating in the “VFO” mode, as just described. This is a frequency step system which allows free tuning throughout the currently-selected operating band. Three basic frequency navigation methods are available on the VX-8DR/DE:...

  • Page 20: Scanning

    DIAL knob one click in the counter-clockwise direction while the VX-8DR/DE is scanning. The scanning direction will be reversed. To revert to scanning toward a higher frequency once more, rotate the DIAL knob one click clock- wise.

  • Page 21: Transmission

    Once you have set up an appropriate frequency inside one of the three (or four) Amateur bands on which the VX-8DR/DE can transmit (50 MHz, 144 MHz, or 430 MHz, plus 222 MHz on the USA version), you’re ready to transmit. These are the most basic steps; more advanced aspects of transmitter operation will be discussed later.

  • Page 22: Vox Operation

    PERATION RANSMISSION 1 ) The VX-8DR/DE is smart! You can set up Low power on one band (like UHF), while leaving VHF on High power, and the radio will remember the different settings on each band. And when you store memories, you can store High and Low power settings separately in each memory, so you don’t waste battery...
  • Page 23 4. Rotate the DIAL knob to select the desired delay time (“0.5sec”, “1.0sec”, “1.5sec”, “2.0sec”, “2.5sec”, or “3.0sec”). 5. When you have made your choice, press the PTT switch to save the new setting and return to normal operation. VX-8DR/DE O PERATING ANUAL...

  • Page 24: Am And Fm Broadcast Reception

    FM B ROADCAST ECEPTION The VX-8DR/DE includes provision for reception of AM and FM broadcasts. FM broad- cast reception, utilizes a wide-bandwidth filter and stereo decoder which provides excel- lent fidelity. The AM and FM Broadcast reception is only possible on “VFO-A”.
  • Page 25 5. When you finish the selection, press the PTT switch to exit from the Menu mode and return to the Broadcast Reception mode. If you wish to output the audio of the FM Broadcast station to the VX-8DR/DE internal speaker while using the earphone antenna, select Set Mode Item 90: SPEAKER OUT to “SPEAKER”.

  • Page 26: Af-Dual Operation

    The “Main” band is selected by pressing the key as usual. 1. Set the VX-8DR/DE to the desired amateur band frequencies by the VFO or Memory channel selections on both “A-Band” and “B-Band”. 2. Select the “Main” Band you wish to use for transmit by pressing the key.
  • Page 27 AF-D ETTING THE ESUME The VX-8DR/DE allows you to select the resume mode of the AF-Dual Opera- tion when a signal is received in the amateur band. 1. Press and hold the key for one second to enter the Set Mode.

  • Page 28: Advanced Operation

    DVANCED PERATION Now that you mastered the basics of VX-8DR/DE operation, let’s learn more about some of the really neat features. EYBOARD OCKING In order to prevent accidental frequency change or inadvertent transmission, various keys and switches may be locked out. The possible lockout combinations are:...

  • Page 29: Adjusting The Keypad Beeper Volume Level

    LCD to “toggle” between display of double-size characters and large characters. However, this feature does not work during Dual Receive operation, as two frequencies are displayed in that instance. OUBLE SIZE HARACTERS ARGE HARACTERS VX-8DR/DE O PERATING ANUAL...

  • Page 30: Audio Muting

    EYPAD LLUMINATION Your VX-8DR/DE includes a reddish illumination lamp which aids in nighttime opera- tion. The red illumination yields clear viewing of the display in a dark environment, with minimal degradation of your night vision. Three options for activating the lamp are pro-...

  • Page 31: Changing The Channel Steps

    The VX-8DR/DE’s frequency synthesizer provides the option of utilizing tuning steps of 5, 6.25, 8.33, 9, 10, 12.5, 15, 20, 25, 50, 100, and 200 kHz per step. The VX-8DR/DE is set up at the factory with different default steps for each operating band which are probably satis- factory for most operation.

  • Page 32: Sql S-Meter

    Full Scale on the S-meter, the squelch will only open on signals which are Full Scale on the S-meter. In this case, the Noise Squelch overrides the action of the S-meter Squelch. VX-8DR/DE O PERATING ANUAL...

  • Page 33: Repeater Operation

    EPEATER HIFTS Your VX-8DR/DE has been configured, at the factory, for the repeater shifts customary in your country. For the 50 MHz band, this usually will be 1 MHz, while the 144 MHz shift will be 600 kHz; on 70 cm, the shift may be 1.6 MHz, 7.6 MHz, or 5 MHz (USA version).

  • Page 34: Manual Repeater Shift Activation

    5. Press the PTT switch to save the new setting and return to normal operation. If you just have one “odd” split that you need to program, don’t change the default repeater shift! Enter the transmit and receive frequencies separately, as shown on page 48. VX-8DR/DE O PERATING ANUAL...

  • Page 35: Tone Calling (1750 Hz)

    PTT switch for activating the transmitter thereafter. If you need to access the repeaters which requires a 1750-Hz burst tone for access by the VX-8DR (USA/EXP versions), you can set the key to serve as a “Tone Call” switch instead.

  • Page 36: Ctcss/Dcs/Epcs Operation

    DIAL knob in step 3 above. When the Reverse Tone Squelch system is ac- tive, the VX-8DR/DE’s receiver is muted when it receives a call from a radio sending a matching CTCSS tone. The “RTN” icon will appear on the display when the Reverse Tone Squelch system is activated.
  • Page 37 250.3 254.1 – – – – received. 2) During CTCSS operation, you may set up the VX-8DR/DE so a ringing “bell” sound alerts you to an incoming call. See page 42 for details. VX-8DR/DE O PERATING ANUAL...

  • Page 38: Dcs Operation

    CTCSS. The DCS Encoder/Decoder is built into your VX-8DR/DE, and operation is very similar to that just described for CTCSS. Your repeater system may be configured for DCS.

  • Page 39: Dcs Code Inversion

    Receive the Inverted DCS Tone and transmit the Normal DCS Tone. RX-BOTH, TX-NORMAL: Receive both Normal and Inverted DCS Tones and transmit the Normal DCS Tone. RX-NORMAL, TX-INVERT: Receive the Normal DCS Tone and transmit the Inverted DCS Tone. VX-8DR/DE O PERATING ANUAL...
  • Page 40 This is different from the usual method of restoring normal operation, and it applies only to the configuration of the CTCSS/DCS frequencies. Remember to restore the default setting “R-N.T-N” (Receive and transmit the Normal DCS Tone) when done. VX-8DR/DE O PERATING ANUAL...

  • Page 41: Tone Search Scanning

    Tone Scanning to listen to the (muted) signal from the other station. When you release the key, Tone Scanning will resume after about a second. Tone Scanning works either in the VFO or Memory modes. VX-8DR/DE O PERATING ANUAL...

  • Page 42: Epcs (Enhanced Paging & Code Squelch)

    AGING QUELCH The VX-8DR/DE includes an Enhanced CTCSS tone encoder/decoder and a dedicated microprocessor providing paging and selective calling features. This allows you to place a call to a specific station (Paging), and to receive calls of your choice directed only to you (Code Squelch).

  • Page 43: Activating The Enhanced Paging & Code Squelch System

    AGING NSWER When you press the PTT switch to respond to a page call, the VX-8DR/DE transmits the same CTCSS tone pair. This tone pair will open the Code Squelch of the calling station. If you prefer, you can have the VX-8DR/DE respond to page calls automatically (“transpond”).

  • Page 44: Ctcss/Dcs/Epcs Bell Operation

    PERATION CTCSS/DCS/EPCS B PERATION During CTCSS Decode, DCS, or EPCS operation, you may set up the VX-8DR/DE so that a ringing “bell” sound alerts you that a call is coming in. Here is the procedure for activating the CTCSS/DCS/EPCS Bell: 1.

  • Page 45: Programming The User Melody

    “SELECT” notation in the “Operation Mode” slot turns into “DELETE”. Now, press and hold in the key for one second to delete that beep tone. VX-8DR/DE O PERATING ANUAL...

  • Page 46: Split Tone Operation

    PLIT PERATION The VX-8DR/DE can be operated in a Split Tone configuration via the Set mode. 1. Press and hold the key for one second to enter the Set Mode. 2. Rotate the DIAL knob to select Set Mode Item 94: SQL SPLIT.
  • Page 47 VX-8DR/DE O PERATING ANUAL...

  • Page 48: Memory Mode (Regular Memory Channel Operation)

    EMORY The VX-8DR/DE provides a wide variety of memory system resources. These include: “Regular” Memory Channels, which include: 900 “Standard” memory channels, numbered “1” through “900.” 99 “Frequency Skip Memories,” numbered “901” through “999.” 11 “Home” channels, providing storage and quick recall of one prime frequency on each operating band.

  • Page 49: Memory Storage

    On rare occasions the memorized data may become corrupted by miss operation, or static electricity. When repairs are made the memory data may be lost. Please write down or record the memorized information so you will be able to restore it if needed. VX-8DR/DE O PERATING ANUAL...

  • Page 50: Memory Recall

    For example, to recall memory channel #14, press 2) You may change the step of the fast channel selection mode ( key + DIAL knob ) via Set Mode Item 52: MEMORY FAST STEP. See page 151 for details. VX-8DR/DE O PERATING ANUAL...

  • Page 51: Home Channel Memory

    470.000 MHz [ 9 ] Information Band 2 860.000 MHz 860.000 MHz AM Broadcast Band [ A ] 0.540 MHz 0.540 MHz FM Broadcast Band [ F ] 76.000 MHz EXP: 76.000 MHz EU: 88.000 MHz VX-8DR/DE O PERATING ANUAL...

  • Page 52: Labeling Memories

    During Memory Recall (“MR”) with Mono Band operation, the alphanumeric Tag will appear below the frequency display. The alphanumeric Tag does not appear if you activate the Dual Receive Operation. VX-8DR/DE O PERATING ANUAL...

  • Page 53: Memory Offset Tuning

    Once you have recalled a particular memory channel, you may easily tune off that chan- nel, as though you were in the “VFO” mode. 1. With the VX-8DR/DE in the Memory Recall (“MR”) mode, select the desired memory channel. 2. Now press the key, then press key.

  • Page 54: Masking Memories

    Watch out! You can manually store data over a “Masked” memory, deleting previous data, if you’re not careful. Use the “next available memory” stor- age technique to avoid over-writing a masked memory. VX-8DR/DE O PERATING ANUAL...

  • Page 55: Memory Bank Operation

    EMORY PERATION The large number of memories available in the VX-8DR/DE could be difficult to utilize without some means of organizing them. Fortunately, the VX-8DR/DE includes provi- sion for dividing the memories into as many as 24 Memory Banks, so you can categorize the memories in a manner convenient to you.
  • Page 56 A total of 16 characters may be used in the creation of a label. 9. Press and hold the key for two seconds to delete all data after the cursor that may have been previously stored. VX-8DR/DE O PERATING ANUAL...

  • Page 57: Moving Memory Data To The Vfo

    To place the radio into the Memory Only mode, turn the radio off. Now press and hold in key while turning the radio on. To return to normal operation, repeat the above power-on procedure. VX-8DR/DE O PERATING ANUAL...

  • Page 58: Memory Mode (Special Memory Channel Operation)

    PECIAL EMORY HANNEL PERATION The VX-8DR/DE provides Special Memory Channels, which are made up of: 10 Weather Broadcast Channels. 57 VHF Marine Channels 89 popular Short-wave Broadcast Station Memory Channels. 1) The Special Memory Channels are only recalled on the “A-Band”...

  • Page 59: Vhf Marine Memory Channels

    156.450 157.200 161.800 156.425 157.175 161.775 156.500 157.250 161.850 156.475 157.225 161.825 156.550 157.300 161.900 156.525 157.275 161.875 156.600 157.350 161.950 156.575 157.325 161.925 156.650 157.400 162.000 156.625 157.375 161.975 156.700 156.675 157.425 162.025 156.750 156.725 VX-8DR/DE O PERATING ANUAL...

  • Page 60: Short-Wave Broadcast Station Memory Channels

    9.780 PORTUGAL Radio Portugal 11.860 JAPAN Radio Japan 11.630 PORTUGAL Radio Portugal 5.995 AUSTRALIA Radio Australia 15.550 PORTUGAL Radio Portugal 9.580 AUSTRALIA Radio Australia 21.655 PORTUGAL Radio Portugal 9.660 AUSTRALIA Radio Australia 12.080 AUSTRALIA Radio Australia VX-8DR/DE O PERATING ANUAL...
  • Page 61 VX-8DR/DE O PERATING ANUAL...

  • Page 62: Scanning

    CANNING ENERAL The VX-8DR/DE allows you to scan just the memory channels, the entire operating band, or a portion of that band. It will halt on signals encountered, so you can talk to the station(s) on that frequency, if you like.
  • Page 63 Delay Time. Available selections are 0.1sec - 0.9sec (0.1sec/step) and 1.0sec - 10.0sec (0.5sec/step). 5. Press the PTT switch to save the new setting and exit to normal operation. The default condition for this Set Mode Item is “2.0sec”. VX-8DR/DE O PERATING ANUAL...

  • Page 64: Vfo Scanning

    3) You may change the scanner’s method of operation so the VFO frequency will jump to the low band edge of the next band when the VFO frequency reaches the high edge of the current band (or vice versa). See page 160 regarding Set Mode Item 105: VFO MODE. VX-8DR/DE O PERATING ANUAL...

  • Page 65: How To Skip (Omit) A Frequency During Vfo Scan

    The VX-8DR/DE has 100 VFO Frequency Skip Memory Channels. ETTING THE QUELCH EVEL DURING ACTIVE CANNING OPERATION The VX-8DR/DE allows adjustment of the Squelch level “on the fly” while you are scanning. 1. While the scanner is engaged, press the key, then press the key (the current squelch level will appear below the frequency display).

  • Page 66: Memory Scanning

    Memory Scan mode, the “MS ERR” notation will appear on the display. 5. To cancel scanning, press the PTT switch or key. You may initiate the scanning in the previously selected Memory Scan Mode by pressing and holding either key for one second. VX-8DR/DE O PERATING ANUAL...

  • Page 67: How To Skip (Omit) A Channel During Memory Scan

    5 above (the “Skipped” channel will, of course, still be accessible via manual channel selection methods using the DIAL knob in the Memory Recall (“MR”) mode, whether or not it is locked out of the scanning loop). VX-8DR/DE O PERATING ANUAL...

  • Page 68: Preferential Memory Scan

    REFERENTIAL EMORY The VX-8DR/DE also allows you to set up a “Preferential Scan List” of channels which you can “flag” within the memory system. These channels are designated by a blinking “ ” icon when you have selected them, one by one, for the Preferential Scan List. When you initiate memory scanning on a channel with the blinking “...

  • Page 69: Memory Bank Scan

    Bank scan, the Memory Bank number (“B x”) in- dication turns into “bx” (capital “B” turns into small “b”). “E ” EMORY NABLED 2) You may enable/disable the Memory Bank scan via Set Mode Item 7: BANK LINK. “D ” EMORY ISABLED VX-8DR/DE O PERATING ANUAL...

  • Page 70: Programmable (Band Limit) Memory Scan (Pms)

    6. 50 pairs of Band Limit memories, labeled L1/U1 through L50/U50 are available. You therefore can set upper and lower operation limits on a number of bands, if you like. 7. To exit to normal operation, press the key. VX-8DR/DE O PERATING ANUAL...

  • Page 71: Priority Channel" Scanning (Dual Watch)

    CANNING ATCH The VX-8DR/DE’s scanning features include a two-channel scanning capability which allows you to operate on a VFO or Memory channel, while periodically checking a user- defined Memory Channel for activity. If a station is received on the Memory Channel which is strong enough to open the Squelch, the scanner will pause on that station in accordance with the Scan-Resume mode set via Menu Item 83: SCAN RESUME.

  • Page 72: Priority Revert Mode

    Mode Item. 4. Rotate the DIAL knob to select “ON”. 5. Press the PTT switch briefly to save the new setting and exit to normal operation. To disable Priority Revert operation, select “OFF” in step 4 above. VX-8DR/DE O PERATING ANUAL...

  • Page 73: Automatic Lamp Illumination On Scan Stop

    EEPER The VX-8DR/DE will automatically “beep” when a band edge is encountered during scanning (either in standard VFO scanning or during PMS operation). You may enable this feature (band edge beeper) when the frequency reaches the band edge while selecting the VFO frequency by the DIAL knob.

  • Page 74: Bluetooth ® Operation

    7. Bring the BH-1A ( or BH-2A ) close to the VX-8DR/DE, then press and hold in the POWER switch of the BH-1A ( or BH-2A ) until the LED indicator blinks red/blue alternately (approximately five seconds).

  • Page 75: Activation

    BH-1A ( or BH-2A ) will turn off automatically. SAVE: OFF: Disable the Battery Saver in the BH-1A ( or BH-2A ) . ® 7. If you wish to turn the Bluetooth unit off to conserve transceiver battery power VX-8DR/DE O PERATING ANUAL...

  • Page 76: Operation

    Press the key, then rotate the DIAL knob to select the “POWR” parameter to “OFF”. 8. Press the PTT switch of the VX-8DR/DE to save the new setting and return to normal operation. PERATION 1. When the BH-1A ( or BH-2A ) is correctly recognized by the VX-8DR, “...
  • Page 77 VX-8DR/DE O PERATING ANUAL...

  • Page 78: Gps Operation

    This is normal, as the GPS unit is downloading “almanac” information from the GPS satellites. 2) While the VX-8DR/DE searches for a GPS signal, the compass icon does not appear on the display and the position information (Longitude/Latitude) blinks on the display.
  • Page 79 5. Align the mounting guide to the transceiver’s depression, then affix the Mount- ing Plate to the CT-136 using the supplied screw. 6. Connect the antenna to the antenna jack. 7. The installation is now complete. Align the mounting guide to the depression. VX-8DR/DE O PERATING ANUAL...

  • Page 80: Setting The Time Zone (Time Offset)

    See illustration below to find your offset time from UTC. If “UTC +0:00” is assigned, the time is the same as UTC. 6. Press the PTT switch briefly to save the new setting and exit from the APRS/GPS Set Mode. VX-8DR/DE O PERATING ANUAL...

  • Page 81: Selecting The Display Units Of The Gps Screen

    6. Press the PTT switch briefly to save the new setting and exit from the APRS/GPS Set Mode. Do not change the Map Datum while the GPS/APRS (described next chapter) in in operation. The position indication will be incorrect. VX-8DR/DE O PERATING ANUAL...

  • Page 82: Aprs Operation

    ® APRS PERATION The VX-8DR/DE is equipped with a 1200/9600bps AX.25 Data Modem to enable APRS ® (Automatic Packet Reporting System) operation. The Automatic Packet Reporting Sys- ® tem (APRS ) is a software program and registered trademark of Bob Bruninga, WB4APR.
  • Page 83 Digipeater Digipeater HF to VHF Gateway IGate (not Home Station) Operation via Satellite Hand-held Transceiver, such as VX-8DR/DE Maritime Mobile MobileTransceiver, such as FTM-350R/E Operation via Internet APRS touch-tone User (and the Occasional Balloons) Portable Units, such as Laptops, Camp Sites etc.
  • Page 84 You may memorize your current position as plotted by the GPS (up to ten points can be saved). See page 166 for details. The VX-8DR/DE provides many convenient functions for the APRS operation. Refer to the “APRS/GPS Set Mode” chapter beginning with page 162 for details.

  • Page 85: Receiving An Aprs Beacon

    The AX.25 modem cannot be activated in the “A-Band”. 2. Disable the Receiver Battery Saver via the Set Mode Item 79: SAVE RX. When the Receiver Battery Saver is turned on, the VX-8DR/DE can not reliably receive an APRS Beacon.
  • Page 86 6. Repeat above steps and select “OFF” to any other filters you wish to exclude. 7. When you have completed your selection, press the PTT switch to save the new setting and exit to the STATION LIST screen. VX-8DR/DE O PERATING ANUAL...

  • Page 87: Transmit An Aprs Beacon

    1) You may toggle the APRS Beacon mode between “MANUAL”, “AUTO”, and “SMART” by pressing the key. 2) When the APRS frequency is busy (Squelch is opened), the VX-8DR/DE will not transmit an APRS Beacon in manual or automatic modes. Insure that the squelch is closed.
  • Page 88 Note: Some transceivers cannot receive the full 60-character message. We recom- mend that you make the message as short as possible. 12. When you have completed your entry, press the PTT switch to save the new setting and exit to the STATION LIST screen. VX-8DR/DE O PERATING ANUAL...
  • Page 89 IGIPEATER ETTING The VX-8DR/DE allows you to set up to eight digipeaters for the APRS Packet Path. The VX-8DR/DE is preset to “WIDE1-1” and “WIDE1-1, WIDE2-1” digi-path to insure that your transmitted APRS Beacon is repeated by the new-N paradigm digipeaters. We recommend that you use this setting by default (P3: WIDE1-1, WIDE2-1).

  • Page 90: Receiving An Aprs Message

    The AX.25 modem is not activated in the “A-Band”. 2. Disable the Receiver Battery Saver from Set Mode Item 79: SAVE RX. When the Receiver Battery Saver is turned on, the VX-8DR cannot reliably receive APRS Messages. 3. Press the key several times until the APRS MESSAGE screen appears on the display.
  • Page 91 (G1 ALL , G2 CQ , G3 , or G4 YAESU Note: “ ” is a wild card indicating any received character will be accepted in that slot. 6. If you add a new message group code and/or bulletin group code, select “G5” (for message group code) or “B1”...

  • Page 92: Transmit An Aprs Message

    (“ack”) even if the APRS message transmits five times, the “ ” (pe- riod) icon (on the APRS MES- SAGE screen) or “TXOUT” notation (on the Detailed Message screen) will appear on VX-8DR/DE O PERATING ANUAL...
  • Page 93 TORE THE IXED ESSAGE The VX-8DR/DE allows you to store five fixed form messages (up to 16 characters for each message). 1. Press the key several times until the APRS MESSAGE screen appears on the display.

  • Page 94: Arts Tm (Automatic Range Transponder System)

    ARTS in order to resume normal operation. This is a safety feature designed to prevent accidental loss of contact due to channel change, etc. VX-8DR/DE O PERATING ANUAL...

  • Page 95: Basic Arts Tm Setup And Operation

    Set Mode Item. 4. Rotate the DIAL knob to select the desired polling interval (25sec or 15sec). 5. Press the PTT switch briefly to save the new setting and exit to normal operation. VX-8DR/DE O PERATING ANUAL...

  • Page 96: Arts Tm Alert Beep Options

    Set Mode Item. 4. Rotate the DIAL knob to select the desired ARTS Beep mode (see above). 5. Press the PTT switch briefly to save the new setting and exit to normal operation. VX-8DR/DE O PERATING ANUAL...

  • Page 97: Cw Identifier Setup

    1 - 3 above, then press the key. 2) You may adjust the monitoring tone (CW sidetone pitch) via Set Mode Item 23: CW PITCH. Available selections are 400 - 1000 Hz (50 Hz/step). VX-8DR/DE O PERATING ANUAL...

  • Page 98: Spectrum Analyzer Operation

    4. To turn the Spectrum Analyzer off and operate on the center (displayed) channel, press the key to stop the sweep, if needed, then press the key followed by key. VX-8DR/DE O PERATING ANUAL...
  • Page 99 VX-8DR/DE O PERATING ANUAL...

  • Page 100: Channel Counter Operation

    The frequency can be measured by bringing the VX- 8DR/DE close to the transceiver which is transmitting. The VX-8DR/DE performs a high-speed search within a ±5 MHz range from the fre- quency displayed on the LCD. When the strongest signal in that range is identified, the VX-8DR/DE displays the frequency of that (strongest) signal, and writes it into the spe- cial “Channel Counter”...
  • Page 101 Set Mode Item. 4. Rotate the DIAL knob to select the desired bandwidth (see above). 5. Press the PTT switch briefly to save the new setting and exit to normal operation. VX-8DR/DE O PERATING ANUAL...

  • Page 102: Smart Search Operation

    One-Shot searching; if all 31 channels are not filled after the first sweep, however, the radio will continue sweeping until they are all filled. The Smart Search feature can only be activated while the VX-8DR/DE is oper- ating in the Mono band mode.
  • Page 103 Smart Search is a great tool when visiting a city for the first time. You don’t need to spend hours looking up repeater frequencies from a reference guidebook…just ask your VX-8DR/DE where the action is! VX-8DR/DE O PERATING ANUAL...

  • Page 104: Message Feature

    EATURE ENERAL The VX-8DR/DE provides a message feature, which sends a message (up to 16 charac- ters) instead of sending a voice. 20 different messages can be programmed, any one of them can be selected and transmitted with your ID.

  • Page 105: Programming A Member List

    ID. 6. Press and hold in the key for two seconds to clear the previously stored personal ID, if desired. 7. Rotate the DIAL knob or press the keyboard to set the first VX-8DR/DE O PERATING ANUAL...

  • Page 106: Set Your Personal Id

    Mode Item. 4. Rotate the DIAL knob to select the member box (1 ~ 20) where your ID is stored. 5. Press the PTT switch briefly to save the new setting and exit to normal operation. VX-8DR/DE O PERATING ANUAL...

  • Page 107: Sending A Message

    “MSG” notation will appear on the display. 10. Press the PTT switch again (without speaking into the mi- crophone) to transmit the selected message on the coordina- tion frequency. It takes approximately 6 seconds to transmit the message. VX-8DR/DE O PERATING ANUAL...

  • Page 108: Receiving A Message

    To disable the Message feature, repeat the above procedure, rotating the DIAL knob to select “OFF” in step 3 above. If you enable the CTCSS/DCS/EPCS Bell feature (described previously), you can tell that you are receiving a message by the ringing “bell” sound alert. VX-8DR/DE O PERATING ANUAL...

  • Page 109: Emergency Feature

    MERGENCY HANNEL PERATION The VX-8DR/DE includes an “Emergency” feature, which may be useful if you have someone monitoring on the same frequency as your transceiver’s UHF “Home” channel. See page 49 for details on setting the Home channel. The “Emergency” feature is activated by pressing and holding in the key for one second.

  • Page 110: Emergency Automatic Id (Eai) Feature

    3) Set the operating band to “A-Band”. 4) Activate the EAI function “Set Mode Item 32: EAI” to “ON”. The VX-8DR/DE radio may now be used normally. The EIA function will monitor the EIA memory channel in the background, and it will be activated when the Pager Memory Tone Pair is received on the EIA memory channel.

  • Page 111: Selecting The Eai Mode And Its Transmit Time

    To disable the EAI feature, just repeat the above procedure, ro- tating the DIAL knob to select “OFF” in step “5” above. The VX-8DR/DE will ignore the EAI feature when (1) the squelch is open, (2) there is an incoming signal on the operating frequency, (3) the operating frequency is the same as the frequency which is stored in the Memory Chan- nel “EAI,”...

  • Page 112: To Locate An Unresponsive Operator

    3. Press and hold in the PTT switch for five seconds. If the EAI signal is received by a VX-8DR transceiver programmed with matching CTCSS Receiving Pager Code, the EAI feature will activate. The lost operator’s radio will transmit in accordance with the setting of Set Mode item 33: EAI TIME (For example, in the Interval mode, the radio will transmit a loud (0.5 second) beep every 2.5 seconds until the EAI timer...

  • Page 113: Internet Connection Feature

    EATURE ENERAL The VX-8DR/DE can be used to access a “node” (repeater or base station) which is tied into the Vertex Standard WIRES™ (Wide-Coverage Internet Repeater Enhancement Sys- tem) network, operating in the “SRG” (Sister Radio Group) mode. Details may be found at the WIRES-II Web site: http://www.vxstd.com/en/wiresinfo-en/.

  • Page 114: Frg ("Friendly Radio Group") Mode

    DTMF string. 14. If you make a mistake, press the key to backspace the cursor, then re-enter the correct letter or number. 15. Repeat steps 12 through 14 until you have completed the access code (“#1101D”). VX-8DR/DE O PERATING ANUAL...
  • Page 115 DTMF string (to establish the link to the desired Internet-link node). 9. To return to the WIRES™ SRG mode, repeat steps 1 - 5 above, selecting “SRG” in step 4. VX-8DR/DE O PERATING ANUAL...

  • Page 116: Dtmf Operation

    DTMF O PERATION The VX-8DR/DE’s keypad allows easy DTMF dialing for Autopatch, repeater control, or Internet-link access purposes. Besides numerical digits [ 0 ] through [ 9 ] , the keypad in- cludes the [ ] and [ # ] digits, plus the [ A ] , [ B ] , [ C ] , and [ D ] tones often used for repeater control.
  • Page 117 Item 31: DTMF SPEED, see page 146 for details. 2) You can also set a longer delay between the time your transmitter is keyed and the first DTMF digit is sent, using Set Mode Item 28: DTMF DELAY, see page 146 for details. VX-8DR/DE O PERATING ANUAL...

  • Page 118: Cw Learning Feature

    CW L EARNING EATURE The VX-8DR/DE provides a CW learning feature, which sends the designated Morse Code via the sidetone (heard in the speaker) to help your CW learning. 1. Press and hold the key for one second to enter the Set Mode.
  • Page 119 CW L EARNING EATURE The “CPM” selection is based on the international “PARIS” standard, which stipulates five characters per word. VX-8DR/DE O PERATING ANUAL...

  • Page 120: Cw Training Feature

    CW T RAINING EATURE The VX-8DR/DE provides another CW learning feature; call it a CW Training feature, which sends random Morse Code via the sidetone (heard in the speaker), so you can improve your CW proficiency. 1. Press and hold the key for one second to enter the Set Mode.

  • Page 121: Sensor Mode

    ENSOR The VX-8DR/DE always displays the “Battery Voltage” and “Current Time” while the VX-8DR/DE is operating in the “Mono” band mode with the Large characters, the VX- 8DR/DE can display various information provided by internal sensors. Available selections are “Battery Voltage”, “Tempera- ture”, “Audio Wave-form”, “Current Barometric Pressure”,...

  • Page 122: Sensor Mode Options

    ENSOR ENSOR PTIONS LOCK The VX-8DR/DE has a 24-hour clock with a calendar which covers all dates from Janu- ary 1, 2000 through December 31, 2099 (accuracy: ±30 sec/month). To set the clock: 1. Press and hold the key for one second to enter the Set Mode.

  • Page 123: Selecting The Measurement Units Of The Sensor Unit

    3. Press the key briefly to enable adjustment of this Set Mode Item. 4. Rotate the DIAL knob to adjust the VX-8DR display to the calibrated barometer value. Note: The offset value appears in an “OFST” row. 5. Press the key to change the cursor to “ALTI”, then ro-...

  • Page 124: Miscellaneous Setting

    2) If you forget the password number, you may turn on the transceiver by performing the “Microprocessor Resetting” procedure (see page 134). However, the VX-8DR/DE will clear the password, as well as all memories, and will restore all other settings to factory defaults.

  • Page 125: Programming The [ Internet ( Txpo )] Key

    5. Press the PTT switch briefly to save the new setting and exit to normal op- eration. Now, briefly pressing of the key will immediately recall the selected Menu Item. You must press the key again to exit to normal operation. VX-8DR/DE O PERATING ANUAL...

  • Page 126: Att (Front End Attenuator)

    1) When the attenuator is activated, the “ ” icon will appear on the display. 2) The attenuator does not activate on the AM/FM Broadcast Bands. 3) The attenuator can be set independently on each operating band of the “A-Band” and “B-Band”. VX-8DR/DE O PERATING ANUAL...

  • Page 127: Receive Battery Saver Setup

    AVER ETUP An important feature of the VX-8DR/DE is its Receive Battery Saver, which “puts the radio to sleep” for a time interval, periodically “waking it up” to check for activity. If somebody is talking on the channel, the VX-8DR/DE will remain in the “active” mode, then resume its “sleep”...

  • Page 128: Disabling The Busy Indicator

    ( PWR ) switch for 2 seconds to turn the transceiver back on Just press and hold in the after an APO shutdown, as usual. To disable the APO, just repeat the above procedure, rotating the DIAL knob to select “OFF” in step 4 above. VX-8DR/DE O PERATING ANUAL...

  • Page 129: Transmitter Time-Out Timer (Tot)

    Alert bell will provide an audible warning from the speaker. 2) Since brief transmissions are the mark of a good operator, try setting up your radio’s TOT feature for a maximum transmission time of 1 minute. This will sig- nificantly improve battery life, too! VX-8DR/DE O PERATING ANUAL...

  • Page 130: On/Off Preset Timer

    ISCELLANEOUS ETTING ON/OFF P RESET IMER The VX-8DR/DE includes the capability to turn itself on/off at preset time. If you use these features, you must first set the VX-8DR/DE’s clock, as described previously (page 120). ON T IMER 1. Press and hold the key for one second to enter the Set Mode.

  • Page 131: Busy Channel Lock-Out (Bclo)

    In such operating environments, it is often required that operators use reduced deviation levels, to reduce the potential for interference to users on adjacent chan- nels. The VX-8DR/DE includes a simple method of accomplishing this: 1. Press and hold the key for one second to enter the Set Mode.

  • Page 132: Changing The Microphone Gain

    OWER ETER YMBOLS The VX-8DR/DE has four types of S- (Signal Strength) and TX Power Meter symbol formats available. You may change the default setting to any of the available symbols. 1. Press and hold the key for one second to enter the Set Mode.

  • Page 133: Display Contrast

    The available selections are LEVEL 1 - LEVEL 4 (factory default: LEVEL 4). 5. When you have completed your selection, press the PTT switch to save the new setting and exit to normal operation. VX-8DR/DE O PERATING ANUAL...

  • Page 134: My Bands Operation

    SW and Air bands, you may skip (omit) these bands from the band selec- tion loop. My Bands Setup 1. Set the VX-8DR/DE to the VFO mode. 2. Press and hold the key for one second to enter the Set Mode.

  • Page 135: Changing The Status Of The [ Vol ] Key

    AUTO BACK: The key keeps its status for approxi- mately three seconds after pressing the key. 5. When you have completed your selection, press the PTT switch to save the new setting and exit to normal operation. VX-8DR/DE O PERATING ANUAL...

  • Page 136: Reset Procedures

    68: PAGER CODE-TX, 75: RPT SHIFT, 76: RPT SHIFT FREQ, 95: SQL TYPE, 99: TONE FREQUENCY, ® APRS /GPS Set Mode 6: APRS MSG FLASH, 15: DIGI PASS, 19: MSG FILTER, 20: MY CALLSIGN, 21: MY POSITION, 22: MY SYMBOL VX-8DR/DE O PERATING ANUAL...

  • Page 137: Cloning

    LONING The VX-8DR/DE includes a convenient “Clone” feature, which allows the memory and configuration data from one transceiver to be transferred to another VX-8DR/DE. This can be particularly useful when configuring a number of transceivers for a public service operation. Here is the procedure for Cloning one radio’s data to another: 1.

  • Page 138: Set Mode

    ENERAL The VX-8DR/DE Set Mode, already described in parts of many previous chapters, is easy to activate and set. It may be used for configuration of a wide variety of transceiver pa- rameters, some of which have not been detailed previously. Use the following procedure to activate the Set Mode: 1.
  • Page 139 ENERAL HANGING THE URSOR The VX-8DR/DE has nine types of cursor symbol formats for the Set Mode operation. You may change the default setting to any of the available symbols. 1. Press and hold the key for one second to enter the Set Mode.
  • Page 140 Selects the channel step for the fast channel selection mode while in the Memory Recall 10CH / 20CH / 50CH / 100CH mode. 53: MEMORY NAME Stores “Alpha-Numeric” tags for the Memory channels. 54: MEMORY PROTECT Enables/Disables the Memory Write Protector. ON / OFF VX-8DR/DE O PERATING ANUAL...
  • Page 141 Selects the Wave-Form display while indicating the Wave-Form via Set Mode Item 84: SEN- ALL / RX SIGNAL / TX MODULATION SOR DISPLAY. 111: WX ALERT Enables/Disables the Weather Alert Feature ON / OFF 1: Depends on the transceiver version. 2: Depends on the operating band and transceiver version. VX-8DR/DE O PERATING ANUAL...
  • Page 142 Pin Code. BLUETOOTH P-CODE 0000 - 9999 (6111) ® Select the operating mode of the optional BH-1A/BH-2A Bluetooth Headset. BLUETOOTH SET VOX: PTT / VOX HIGH / VOX LOW, MODE: MONO / STEREO, SAVE: ON / OFF VX-8DR/DE O PERATING ANUAL...
  • Page 143 Selects the VOX delay (“hang”) time. 109: VOX DELAY 0.5sec / 1.0sec / 2.0sec Enables/Disables the Weather Alert Feature 111: WX ALERT ON / OFF 1: Depends on the operating band and transceiver version. 2: Depends on the transceiver version. VX-8DR/DE O PERATING ANUAL...
  • Page 144 Use both the internal Bar Antenna and the Rubber Flex Antenna. BAR ANTENNA: Use the internal Bar Antenna only. Note: The Bar Antenna is directional; rotate the VX-8DR/DE for best reception. 2: ANTENNA FM Function: Select the antenna to be used for the FM Broadcast listening.
  • Page 145 Available Values: KEY & SCAN / KEY / OFF Default: KEY & SCAN KEY & SCAN: The beeper sounds when you press a key or when the scanner stops. KEY: The beeper sounds when you press a key. OFF: The beeper is disabled. VX-8DR/DE O PERATING ANUAL...
  • Page 146 Headset. If there has been no signal or key activity for 20 seconds, the ® Battery Saver automatically puts the BH-1A/BH-2A Bluetooth Headset to “sleep”, to conserve life. When signal is received or the PTT switch is ® pressed, the BH-1A/BH-2A Bluetooth Headset will be active again. VX-8DR/DE O PERATING ANUAL...
  • Page 147 Function: Select the CW tone pitch for the CW Learning, CW Training, and CW Identi- fier functions. Available Values: 400 ~ 1000 Hz (50 Hz/step) Default: 700Hz 24: CW TRAINING Function: Enables/Disables the CW Training feature. See page 118 for details. 25: DC VOLTAGE Function: Indicates the DC Supply Voltage. VX-8DR/DE O PERATING ANUAL...
  • Page 148 Available Values: MANUAL / AUTO Default: MANUAL 30: DTMF SELECT Function: Programming of the DTMF Autodialer. See page 114 for details. 31: DTMF SPEED Function: Selects the DTMF Autodialer Sending Speed. Available Values: 50mS / 100mS Default: 50mS VX-8DR/DE O PERATING ANUAL...
  • Page 149 Emergency message. Here’s how to program the Emergency Message: 1. Press the key to display any previously-stored emergency message. 2. Press and hold the key for two seconds to clear any previous emergency mes- sage, if desired. VX-8DR/DE O PERATING ANUAL...
  • Page 150 Function: Reducing the Deviation level by 50 %. Available Values: ON/OFF Default: OFF 38: HOME VFO Function: Enables/Disables the function of the VFO DIAL knob, while in the Home Chan- nel mode. Available Values: DISABLE / ENABLE Default: ENABLE VX-8DR/DE O PERATING ANUAL...
  • Page 151 Internet Access Number (SRG) or Access String (FRG). (SRG) or (FRG) is determined via Set Mode Item 49: INTERNET MODE. SET MODE: key is the Short-cut path to recall one of the Set Mode Items. See page 123 for programming. VX-8DR/DE O PERATING ANUAL...
  • Page 152 49: LCD DIMMER Function: Setting of the Display brightness level. Available Values: LEVEL 1 ~ LEVEL 4 Default: LEVEL 4 50: LED LIGHT Function: Illuminates the white LED light continuously (useful as emergency flashlight at night). VX-8DR/DE O PERATING ANUAL...
  • Page 153 Stores the data into the memory channel, which is next highest from the last- stored memory channel. LOWER: Stores the data into the next-available “free” channel. 57: MESSAGE LIST Function: Programming a Member List for the Message feature. See page 103 for details. VX-8DR/DE O PERATING ANUAL...
  • Page 154 The OFF Timer turns the radio off at the programmed time. See page 128 for details. 64: ON TIMER Function: Set the ON Timer time. The ON Timer turns the radio on at the programmed time. See page 128 for details. VX-8DR/DE O PERATING ANUAL...
  • Page 155 Function: Sets the Receiver Pager Code for the Enhanced CTCSS Paging & Code Squelch. See page 40 for details. 68: PAGER CODE-TX Function: Sets the Transmitting Pager Code for the Enhanced CTCSS Paging & Code Squelch. See page 40 for details. VX-8DR/DE O PERATING ANUAL...
  • Page 156 Available Values: SIMPLEX / –RPT / +RPT Default: SIMPLEX 76: RPT SHIFT FREQ Function: Sets the magnitude of the Repeater Shift. Available Values: 0.000MHz ~ 150.000MHz (50 kHz/step) Default: Depends on the operating band and transceiver version. VX-8DR/DE O PERATING ANUAL...
  • Page 157 Function: Enables/Disables the Scan Lamp (while scanner is paused). Available Values: ON / OFF Default: ON 82: SCAN RE-START Function: Selects the Scan Re-start Delay time. Available Values: 0.1sec ~ 0.9sec (0.1sec/step) or 1.0sec ~ 10.0sec (0.5sec/step) Default: 2.0sec VX-8DR/DE O PERATING ANUAL...
  • Page 158 86: SET MODE CSR Function: Selects the Set Mode Cursor. Available Values: nine patterns ( Default: 87: SET MODE FORMAT Function: Selects the display format of the Set Mode operation. Available Values: LIST / ITEM Default: LIST VX-8DR/DE O PERATING ANUAL...
  • Page 159 CONTINUOUS: The receiver sweeps the current band repeatedly until the Spectrum Ana- lyzer is turned off. Full Time: This mode is activated similar to a “Continuous” mode. However, the transceiver outputs audio on the center frequency ( ) through the speaker when Spectrum Analyzer is activated. VX-8DR/DE O PERATING ANUAL...
  • Page 160 (the “T-D” icon will appear during operation) D CD-TONE SQL: Encodes a DCS code and Decodes a CTCSS Tone (the “D-T” icon will appear during operation) Select the desired operating mode from the selections shown above. VX-8DR/DE O PERATING ANUAL...
  • Page 161 5) 5.0 kHz steps are not available for use on 250 - 300 MHz, nor above 580 MHz. 97: STEREO Function: Enables/Disables the stereo output while receiving the FM Broadcast band. Available Values: STEREO / MONO Default: STEREO 98: TIME SET Function: Sets the Clock time. See page 120 for details. VX-8DR/DE O PERATING ANUAL...
  • Page 162 (or vice versa). BAND: When the VFO frequency reaches the high band edge of the current band, the VFO frequency will jump to the low band edge of the current band (or vice versa). VX-8DR/DE O PERATING ANUAL...
  • Page 163 Displays the RX Audio wave form and TX Audio modulation wave form. RX SIGNAL: Displays the RX Audio wave form. TX MODULATION: Displays the TX Audio modulation wave form. 111: WX ALERT Function: Enables/disables the Weather Alert Feature Available Values: ON/OFF Default: OFF VX-8DR/DE O PERATING ANUAL...

  • Page 164: Aprs/Gps Set Mode

    OFF / TYPE1 / TYPE2 / TYPE3 25: TIME ZONE Set the time offset between the local time and UTC. UTC -13:00H ~ UTC +13:00H (0.5H / step) (UTC + 0:00H) : Depends on the transceiver version. VX-8DR/DE O PERATING ANUAL...
  • Page 165 When this item is set to “ON”, the transceiver shows the stations that send a packet signal other than the APRS beacon. APRS/GPS Set Mode Item 4: APRS MODEM Function: Enables/Disables the APRS modem (AX.25 Data modem) and its Baud Rate. Available Values: OFF/1200bps/9600bps Default: OFF VX-8DR/DE O PERATING ANUAL...
  • Page 166 Function: Enables/Disables the alert ringer when the APRS message is received. Available Values: ON/OFF Default: ON APRS/GPS Set Mode Item 9: APRS RINGER BCON Function: Enables/Disables the alert ringer when the APRS beacon is received. Available Values: ON/OFF Default: ON VX-8DR/DE O PERATING ANUAL...
  • Page 167 Function: Enables/Disables the automatic transmission of the APRS Beacon. Available Values: MANUAL/ AUTO/ SMART Default: MANUAL MANUAL: The VX-8DR/DE does not transmit the APRS beacon automatically. To trans- mit the APRS beacon, just press the key. AUTO: The VX-8DR/DE transmits the APRS beacon automatically at the time inter- val which is set in Set Mode Item 12: BEACON INTERVAL.
  • Page 168 Note: The “Position” item selects the coordinate system. When the “Position” item is set to “.MMM’”, the VX-8DR/DE displays the location (Lat/Lon) in “ddd° mm. mmm” (Deci- mal system). When the “Position” item is set to “‘SS””, the VX-8DR/DE displays the location (Lat/Lon) in “ddd° mm ss” (Sexagesimal System). The position information used during APRS operation is used to display the location (Lat/Lon) in Sexagesimal System, regardless of this Set Mode setting.
  • Page 169 B2: BLN B3: BLN Note: “ ” is a wild card indicating any received character will be accepted in that slot. APRS/GPS Set Mode Item 20: MY CALLSIGN Function: Program your callsign. See page 80 for details. VX-8DR/DE O PERATING ANUAL...
  • Page 170 Note: Remember to return this Set Mode Item to “Auto” after you have finished entering your position data into memory. If not then the VX-8DR/DE always transmits the position data stored in memory and not your true GPS position data.
  • Page 171 When STATUS is set to “OFF”, the SmartBeaconing function is dis- abled. LOW SPD: This item designates the lower speed threshold. The VX-8DR/DE trans- mits an APRS beacon when your movement speed becomes lower than VX-8DR/DE O PERATING ANUAL...
  • Page 172 TURN TIME: This item designates the minimum delay time between each APRS bea- con. The VX-8DR/DE does not transmit an APRS beacon until this set- ting time has elapsed since the previous APRS beacon transmission, pre- venting too frequent beacon transmissions.
  • Page 173 APRS/GPS S VX-8DR/DE O PERATING ANUAL...

  • Page 174: Specifications

    Specifications are subject to change without notice, and are guaranteed within the 50/144/222/ 430 MHz amateur bands only. Cellular Blocked per FCC rule Part 15.121, may not receive 900 MHz Amateur band. The frequency ranges are different according to a transceiver version. VX-8DR/DE O PERATING ANUAL...
  • Page 175 12 kHz/35 kHz (–6dB/–60dB: NFM, AM) 200 kHz/300 kHz (–6dB/–20dB: WFM) AF Output: 200 mW @ 8 Ohms for 10 % THD (@ 7.4 V DC) 400 mW @ 8 Ohms for 10 % THD (@ 13.8 V DC) VX-8DR/DE O PERATING ANUAL...

  • Page 176: Installation Of The Bu-2 (Option)

    BU-2 with the connector of the Connector Unit and gently press the BU-2 into place (Figure 2). 5. Affix the new (supplied) Caution Seal, and replace the battery pack. 6. Installation is now complete. BU-2 Connector Unit Figure 1 Figure 2 VX-8DR/DE O PERATING ANUAL...
  • Page 177 VX-8DR/DE O PERATING ANUAL...
  • Page 178 FCC N OTICE 1. Changes or modifications to this device not expressly approved by YAESU MUSEN could void the user’s authorization to operate this device. 2. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions;...

  • Page 179: Declaration Of Conformity

    Declaration of Conformity We, Yaesu UK Ltd. declare under our sole responsibility that the following equipment com- plies with the essential requirements of the Directive 1999/5/EC. Type of Equipment: Type of Equipment: Triple Band Transceiver Brand Name: YAESU Model Number:...
  • Page 180 Copyright 2012 Printed in Japan YAESU MUSEN CO., LTD. All rights reserved. No portion of this manual may be reproduced without the permission of 1210R-FY YAESU MUSEN CO., LTD.

This manual is also suitable for:

Vx-8de

Table of Contents
