Miele HS15 Operating Instructions Manual

Hide thumbs Also See for HS15:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Instructions, Operating Instructions Manual

Operating instructions

Vacuum cleaner

To avoid the risk of accidents or damage to the
vacuum cleaner, it is essential to read these
instructions before using it for the first time.
en - AU, NZ
These operating instructions apply to
HS15
standard models SGJE0 as well as
to special edition models which are
distinguished by names rather than numbers.
M.-Nr. 10 039 290

Advertisement

Table of Contents
loading

Related Manuals for Miele HS15

Summary of Contents for Miele HS15

  • Page 1: Operating Instructions

    - AU, NZ These operating instructions apply to HS15 standard models SGJE0 as well as to special edition models which are distinguished by names rather than numbers.

  • Page 2: Table Of Contents

    Contents Caring for the environment ......... . 3 Description of the vacuum cleaner .

  • Page 3: Caring For The Environment

    Caring for the environment Disposal of packing material Disposing of your old vacuum cleaner The packing material protects the vacuum cleaner from transport Before disposing of your old vacuum damage. The transport and protective cleaner, remove the dustbag and filters packing has been selected from and dispose of them with the normal materials which are environmentally...

  • Page 4: Description Of The Vacuum Cleaner

    Description of the vacuum cleaner...
  • Page 5 HEPA AirClean 50 filter k Illuminated ParkSystem for storage (on either side of vacuum cleaner) l Dust compartment filter (for motor protection) m ElectroBrush socket cover holder n Original Miele dustbag o Carrying handle p AllTeQ or AirTeQ floorhead q Release button...

  • Page 6: Warning And Safety Instructions

    Warning and Safety instructions This vacuum cleaner complies with statutory safety requirements. Improper use can, however, lead to personal injury and damage to property. To avoid the risk of accidents and damage to the vacuum cleaner, please read these instructions carefully before using it for the first time.
  • Page 7 The wall socket must be protected against short circuit by a delay fuse 16 A or 10 A. While the vacuum cleaner is under warranty, repairs should only be undertaken by a Miele authorised service technician. Otherwise the warranty will be invalidated.
  • Page 8 Do not use the vacuum cleaner if the cable is damaged. If the cable is damaged it must be replaced together with a complete cable rewind. For safety reasons this work must be done by a Miele authorised service technician.
  • Page 9 Do not dispose of them with the normal household waste. Accessories To avoid the risk of injury when vacuuming with a Miele Turbobrush, do not touch the rotating roller brush. It is not advisable to vacuum directly with the handle, i.e. without an accessory attached as the rim could get damaged and you could hurt yourself on sharp edges.
  • Page 10 "Original Miele" logo on them. Otherwise the manufacturer cannot guarantee the safety of the product and the manufacturer's warranty will be invalidated. Miele cannot be held liable for damage caused by incorrect use or operation or by non-compliance with these Warning and Safety instructions.

  • Page 11: Preparing For Use

    Preparing for use Attaching the suction hose ^ Insert the hose connector into the suction socket until it clicks into position. To do this, line up the guides on the two pieces. Removing the suction hose ^ Press the release buttons at the side of the hose connector, and lift the hose from the socket.

  • Page 12: Adjusting The Telescopic Wand

    Preparing for use Connecting the handle to the suction tube ^ Insert the handle into the suction tube until it clicks into position. To do this, line up the guides on the two pieces. ^ Press the release button (arrow) if you want to separate the parts and pull the handle out of the suction tube with a slight twist.
  • Page 13 Adjusting the standard floorhead This floorhead can be used for all normal cleaning of carpets, rugs and robust hard flooring. Miele offer a range of other floorheads, brushes and accessories for other types of flooring and special requirements (see "Optional accessories").

  • Page 14: Activating The Exhaust Filter Change Indicator

    Preparing for use Inserting batteries into the LED handle a Undo the screws on the cover of the battery compartment. b Press down on both sides of the cover and lift off. c Take out the battery holder and insert the three batteries supplied, making sure the polarity is correct.
  • Page 15 Preparing for use ^ Remove the information strip. ^ Press the reset button ~ for the exhaust filter change indicator. ^ A narrow red strip will appear on the left edge of the display field after 10 - 15 seconds. ^ Close the dust compartment lid securely, making sure it clicks into position.

  • Page 16: Using The Accessories Supplied

    Using the accessories supplied a Crevice nozzle For cleaning in folds, crevices and corners. b Dusting brush For cleaning skirting boards, ornate, carved or delicate articles, etc. The head of the dusting brush can be swivelled to attain the best cleaning position.

  • Page 17: Use

    Mains connection cable Unwinding the cable ^ Pull out the connection cable to the required length (max. cable length approx. 7.5 m). ^ Plug the connection cable into a wall socket and switch on at the wall. The ParkSystem lighting on either side of the vacuum cleaner will switch on.

  • Page 18: Selecting The Suction Power

    Selecting the suction power The suction power can be regulated to suit the type of flooring. Reducing the suction power reduces the amount of effort required to manoeuvre the floorhead. The symbols on the controls indicate the type of use the settings are suitable for.

  • Page 19: Illuminating The Working Area

    ^ Press the + control to select a higher setting. ^ Press the - control to select a lower setting. After that, the vacuum cleaner will switch on at the setting which was used previously. Vacuuming ^ When vacuuming, pull the cleaner behind you on its wheels.

  • Page 20: Setting Down, Transportation And Storage

    Setting down, transportation and storage ParkSystem for pauses in vacuuming A parking system has been designed for conveniently parking the vacuum cleaner during pauses. ^ Slot the floorhead into the parking attachment at the back of the vacuum cleaner. If the vacuum cleaner is parked on a sloped surface, e.g.

  • Page 21: Parksystem For Storage

    Setting down, transportation and storage ParkSystem for storage It is important to switch off the vacuum cleaner after each use. Switch off at the wall socket and remove the plug. After approx. 30 seconds, the ParkSystem lighting switches off automatically. ^ Stand the vacuum cleaner upright when it is not being used and during storage.

  • Page 22: Maintenance And Care

    Switch off at the wall socket and www.miele-shop.com (depending on remove the plug. country), from Miele (see back cover for contact details) or from your Miele The Miele filter system consists of three Vacuum Cleaner Specialist.

  • Page 23: When To Change The Dustbag

    (see possible reasons for this below). Miele dustbags are disposable. Dispose of full dustbags. Do not continue to use them once they are full as blocked pores reduce the efficiency of the vacuum cleaner.

  • Page 24: Replacing The Dustbag

    Maintenance and care Replacing the dustbag ^ Press the release button for the dust compartment lid and raise the lid as far as it will go. The dustbag has a closing flap which closes automatically when the dust compartment lid is raised to prevent any dust escaping.

  • Page 25: When To Change The Dust Compartment Filter (For Motor Protection)

    Replace this filter every time you start a new packet of dustbags. A dust compartment filter is supplied with every packet of Miele dustbags. Correctly changing the dust compartment filter ^ Open the dust compartment lid. ^ Pull the dustbag out by the grip next to the self-closing flap on the collar.

  • Page 26: When To Replace The Hepa Airclean 50 Exhaust Filter

    You can replace the HEPA AirClean 50 exhaust filter fitted in the vacuum cleaner with one of the other Miele exhaust filters if you wish (see "Replacing one type of exhaust filter with another").
  • Page 27 Maintenance and care ^ Insert a new exhaust filter making sure it goes in properly, then push it down into position. ^ Press the exhaust filter change indicator ~. ^ After approx. 10 - 15 seconds a thin red stripe will appear in the left-hand side of the display.

  • Page 28: Replacing One Type Of Exhaust Filter With Another

    Do not use more than one exhaust filter at a time. You can replace the HEPA AirClean 50 exhaust filter fitted in the vacuum cleaner with one of the other Miele exhaust filters if you wish. a AirClean b Active AirClean 50...

  • Page 29: Changing The Battery In The Led Handle

    Correctly replacing the thread lifters ^ Use a suitable screwdriver to remove the thread lifters from the slots. ^ Fit new thread lifters. Spare parts are available from Miele (see back cover for contact details).

  • Page 30: Cleaning And Care

    Cleaning and care Always disconnect the vacuum cleaner from the electricity supply for maintenance work and for cleaning. Switch off at the wall socket and remove the plug. Vacuum cleaner and accessories Plastic components of the vacuum cleaner and its accessories can be cleaned with a dry or a slightly damp cloth, or with a proprietary cleaner suitable for plastic.

  • Page 31: Problem Solving Guide

    Problem solving guide The vacuum cleaner switches off automatically, and the overheating warning light § comes on. A temperature limiter switch switches the vacuum cleaner off automatically if it gets too hot. The overheating warning light § will then come on to indicate that it has overheated.

  • Page 32: After Sales Service / Warranty / Electrical Connection

    All work should be carried out by a easily remedy, please contact Miele. suitably qualified and competent person in strict accordance with See back cover for Miele's contact national and local safety regulations. details. The voltage and rated load are given...

  • Page 33: Optional Accessories

    (depending on country): Other accessories MicroSet (SMC 20) This set is specially designed for They can also be purchased from Miele. cleaning small objects and difficult to ElectroBrushes reach areas (such as PC keyboards, stereo equipment, intricately carved...
  • Page 34 Optional accessories Flexible crevice nozzle, 30 cm (SFD 10) For cleaning in folds, crevices or corners. Flexible crevice nozzle, 56 cm (SFD 20) For cleaning difficult to access areas. Upholstery nozzle, 19 cm (SPD 10) Extra wide nozzle for vacuuming upholstery, mattresses and cushions.
  • Page 36 Miele Australia Pty. Ltd. ACN 005 635 398 ABN 96 005 635 398 Miele Center and Head Office Melbourne: 1 Gilbert Park Drive Knoxfield, VIC 3180 Miele Center and Office Melbourne: 206-210 Coventry Street South Melbourne, VIC 3205 Miele Center and Office Sydney:...
