Summary of Contents for Carrier 42 VKG
- Page 1 42 VKG Console ISO 9001 OWNER’S MANUAL...
-
Page 2: Table Of Contents
“Room Controller” “Group Controller” “Zone Manager” The unit can be used with infrared Remote Control, with the Carrier “Room Controller” or “Group Controller” remote control. Business versions can also be used with the Carrier “Zone Manager” remote control. Infrared control instructions are contained in the present manual. -
Page 3: General Information
42 VKG General information Unit operation and maintenance • Inspect equipment for damage due to improper transportation or handling: in case of damage file an immediate claim with the shipping company. Read this instruction manual thoroughly before using the unit. -
Page 4: System Description
42 VKG System description E N G L I S H A. Outdoor unit 1. Receiver of signals from remote 4. Air return 7. Characteristics nameplate B. Indoor unit controller 5. Air filters 8. Interconnecting tubing 2. Indicators of unit operating status 6. -
Page 5: Infrared Remote Controller
42 VKG Infrared remote controller Insert batteries paying attention to the correct polarity indicated in Fix the remote control holder to the wall using the screw. the battery compartment; replace cover. The remote controller operates with two 1.5 V non re-chargeable batteries, type IEC LR03. -
Page 6: Display Of Selected Functions
42 VKG Display of selected functions E N G L I S H 1. Symbol of signal transmission 2. Operating mode display M O D E 3. Dehumidification only 4. Cooling and dehumidification 5. Automatic 6. Heating T E M P E R A T E M P E R A T U R E 7. -
Page 7: Unit Warning Lights And Controls
42 VKG Unit warning lights and controls T = Test M = Manual A = Remote control P Q R N Signal receiver from remote controller. Notes: • When indicator R flashes, there is a unit malfunction. P RED indicator: •... -
Page 8: Use Of The Remote Controller
42 VKG Use of the remote controller E N G L I S H Start/stop Setting desired temperature (button B) When the air conditioner is not in operation, the controller readout (button E) will display the time of day only (in case other symbols are lit, turn... - Page 9 42 VKG Use of the remote controller Set combined program Night stop The combined program (a selection of a sequence of start and (button K) stop times) will start and stop the air conditioner daily at the programmed time without any action from the user.
-
Page 10: Practical Advice
42 VKG Practical advice E N G L I S H Optimum comfort and lowest consumption Clean indoor and outdoor units. Keep room temperature to comfort levels. Do not open doors and windows more frequently than necessary. Indoor unit cleaning Turn the unit off and switch the mains supply off. -
Page 11: Maintenance
42 VKG Practical advice, maintenance and guidelines for the owner Filters cleaning Photocatalytic filters A. Photocatalytic filters B. Acrylic-fibre filters • Clean these filters every three months. Wash them with water, The standard filters supplied are high-efficiency washable and and leave them for 2/3 hours to dry in sunlight. -
Page 12: Troubleshooting
42 VKG Troubleshooting E N G L I S H After batteries have been placed into the controller, the When pressing any button display will not change: display is not lit: • The triangle symbol 1 is on, as another signal is being •... - Page 13 L010124H60 - 0201 Via R. Sanzio, 9 - 20058 Villasanta (MI) Italy - Tel. 039/3636.1 The manufacturer reserves the right to change any product specifications without notice. Order No. 14278-74, February 2001. Supersedes Order No. 14278-74, January 2001. Printed in Italy...
