Allpro ScanX Quantum Quick Start Instructions

Tha n k Yo u and Con g rat ul a t io ns on your purchase of the ScanX Quantum Digital Imaging System, a rugged portable
imaging system manufactured by Air Techniques, Inc. for ALLPRO Imaging. Each system has been designed and manufactured
using state-of-the-art technology to produce the lightest, most rugged and dependable digital imaging system available for
the demanding conditions encountered in portable radiography applications.
This document provides abbreviated instructions to setup and operate the ScanX. Refer to the Operator's Manual (P/N D5471)
included as a PDF file on the Drivers and Utilities Disk (P/N D5475) for complete instructions to ensure that your ScanX gives
the highest level of service.
Although each ScanX has been designed to minimize exposure of personnel to hazards, users must exercise every precaution to
ensure personnel safety, and be familiar with the warnings and cautions presented below and throughout the supplied Operator's
Manual.
Use of Accessory Equipment.
The use of ACCESSORY equipment not complying with the equivalent safety requirements of this equipment may lead to a
reduced level of safety of the resulting system. Use of ACCESSORIES or cables other than those specified or provided by the
manufacturer may result in increased EMISSIONS or decreased IMMUNITY of the EQUIPMENT.
Electrical Safety Notes.
• The main power switch is the main power disconnect device.
• Use only the line cord provided with the unit.
• Use only grounded electrical connections.
• Check the device cables for possible damage before switching on. Damaged cables, plugs and sockets must be replaced
before use.
• Do not locate unit where it could be sprayed with water, or in a damp environment.
Do Not Attempt Internal Service.
The interior of each component of the ScanX is only accessible by removing hardware with tools and should only be opened
and serviced by an authorized dealer service technician. Contact your ALLPRO Imaging authorized dealer for service. Failure to
heed this directive may result in equipment damage and voiding the warranty.
Laser Class Warning.
The ScanX is a Class 1 Laser Product [Class 1 Laser Product (IEC 60825)]
The warning label shown on the right identifies the ScanX as such a product and describes the
potential danger to humans in the event the product is opened during service. There is no laser radiation
from this product when operated and maintained as instructed.
The Laser Product Accession Number is 0212282-00
Customer-Supplied Computer and Imaging Software
To operate the ScanX, it must be connected to a compliant Computer System, and the computer must be loaded with an authorized
Imaging Software. See the Operator's Manual for the minimum computer system requirements necessary to operate the ScanX.
Contact your dealer for available Computer System and Software options.
In addition to imaging software authorized for the ScanX, USB device drivers must also be installed on the computer in order
to operate the associated ScanX. The USB device drivers are provided on the Drivers and Utilities Disk (P/N D5475) included
with each unit. Also refer to the SYSTEM SETUP section of the Operator's Manual included on the Drivers and Utilities Disk for
installation information for device drivers.
ScanX Quantum is a registered trademarks of ALLPRO Imaging.
Q u i c k S t a r t I n s t r u c t i o n s
D i g i t a l I m a g i n g S y s t e m
© Copyright ALLPRO Imaging, 2009
CAUTION
CLASS 1 LASER PRODUCT
CLASS 3B LASER
RADIATION WHEN OPEN
AVOID EXPOSURE TO BEAM
DANGER
LASER RADIATION WHEN OPEN
AVOID DIRECT
EXPOSURE TO BEAM
COVER REMOVED MAKES
THIS DEVICE A
CLASS IIIb LASER PRODUCT
•
P/N D5471Q Rev. F - November 2013
