Congratulations! We welcome you to the exciting world of motor home travel and camping. You will
find it convenient and enjoyable to have all the comforts of home and still enjoy the great outdoors
wherever you choose to go.
Your motor home has been carefully designed, engineered and manufactured to provide dependability
as well as safety. Before sliding into the driver's seat, take a few minutes to become familiar with opera-
tions and features. This manual was prepared to aid you in the proper care and operation of the vehicle and
equipment. We urge you to read it completely. In addition, spend some time with the dealer when you take
delivery, you will want to learn all you can about your new motor home.
Your new motor home is covered by a factory warranty against defects in material and workmanship.
This warranty should be validated at once and returned to the factory by your dealer.
Read and understand all instructions and precautions in this manual before operating your new motor
home.
About Safety Messages Used in This Manual
Throughout this manual, certain items are labeled Note, Caution, Warning or Danger. These terms alert
you to precautions that may involved damage to your vehicle or a risk to your personal safety. Read and
follow them carefully.
This SAFETY ALERT SYMBOL is used to draw your attention to issues which could
involved potential personal injury. This symbol is used throughout this manual and/or on labels
affixed on or near various equipment in this motor home.
DANGER
DANGER indicates a directly hazard-
ous situation which, if not avoided,
will result in death or serious personal
injury.
.
WARNING
WARNING indicates a potentially
hazardous situation which, if not
avoided, could result in death or seri-
ous personal injury.
April 2003
TO THE OWNER
132000-03-004
