Notes: This model's CD mechanism changer unit is CRS1. Please refer to the original Service Manual
(Order No. MD0509368C0) for this mechanism.

Specifications

RMS output power
THD 10%, both channels driven
1 kHz
(Low channel)
10 kHz
(High channel)
Total Bi-Amp power
PMPO
n FM/AM TUNER, TERMINALS SECTION
Preset station
Frequency Modulation (FM)
Frequency range
Sensitivity
S/N 26 dB
Antenna terminal(s)
Amplitude Modulation (AM)
Frequency range
Sensitivity
S/N 20 dB (at 1000 kHz)
Audio performance (Amplifier)
112.5 W per channel (3 Ω)
112.5 W per channel (3 Ω)
450 W
4800 W
FM 20 stations
AM 15 stations
87.9 to 107.9 MHz (200 kHz
steps)
87.5 to 108.0 MHz (100 kHz
steps)
4.0 µV (IHF)
2.2 µV
75 Ω (unbalanced)
520 to 1710 kHz (10 kHz step)
560 µV/m
SA-AK350PL
Colour
(S)... Silver Type
Input Sensitivity/ Input Impedance
Aux
Music Port input jack
Terminal
Sensitivity
Phone jack
Terminal
Mic jack
Terminal
Sensitivity
n CASSETTE DECK SECTION
Track system
Heads
Record/playback
Erasure
Motor
Recording system
Erasing system
Tape speed
Overall frequency response (+3, -6 dB) at DECK OUT
NORMAL
S/N ratio
Wow and flutter
© 2007 Matsushita Electric Industrial Co. Ltd.. All
rights
reserved.
distribution is a violation of law.
ORDER NO. MD0704045CE
CD Stereo System
250 mV, 14.7 kΩ
Stereo, 3.5 mm jack
100 mV, 4.7 kΩ
Stereo, 3.5 mm jack
Mono, 3.5 mm jack
0.7 mV, 680 Ω
4 track, 2 channel
Solid permalloy head
Double gap ferrite head
DC servo motor
AC bias 100 kHz
AC erase 100 kHz
35 Hz to 14 kHz
50 dB (A weighted)
0.18 % (WRMS)
Unauthorized
copying
4.8 cm/s
and

Advertisement

Table of Contents
loading

Related Manuals for Panasonic SA-AK350PL

Summary of Contents for Panasonic SA-AK350PL

  • Page 1: Specifications

    ORDER NO. MD0704045CE CD Stereo System SA-AK350PL Colour (S)... Silver Type Notes: This model’s CD mechanism changer unit is CRS1. Please refer to the original Service Manual (Order No. MD0509368C0) for this mechanism. Specifications RMS output power Input Sensitivity/ Input Impedance THD 10%, both channels driven 250 mV, 14.7 kΩ...

  • Page 2: Table Of Contents

    SA-AK350PL Fast forward and rewind time Approx. 120 seconds with Number of channels 2 (Stereo) (FL, FR) C-60 cassette tape n GENERAL n DISC SECTION Power supply AC 120 V, 60Hz Disc played [8 cm or 12 cm] Power consumption...
  • Page 3 SA-AK350PL 13 Procedure for Checking Operation of Individual Parts of Deck 19.3. (C) Panel Circuit Mechanism Unit 19.4. (D) Sub Panel Circuit & (G) Deck Mechanism Circuit 13.1. Operation Check with Cassette Tape 19.5. (E) Power Circuit 13.2. Operation Check without Cassette Tape 19.6.

  • Page 4: Safety Precautions

    SA-AK350PL 1 Safety Precautions 1.1. General Guidelines 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. 2. After servicing, ensure that all the protective devices such as insulation barriers and insulation papers shields are properly installed.

  • Page 5: Protection Circuitry

    SA-AK350PL 1.3. Protection Circuitry The protection circuitry may have operated if either of the following conditions are noticed: · No sound is heard when the power is turned on. · Sound stops during a performance. The function of this circuitry is to prevent circuitry damage if, for example, the positive and negative speaker connection wires are “shorted”, or if speaker systems with an impedance less than the indicated rated impedance of the amplifier are used.
  • Page 6 SA-AK350PL 6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminium foil or comparable conductive material).

  • Page 7: Handling Precautions For Traverse Deck

    SA-AK350PL 3 Handling Precautions For Traverse Deck The laser diode in the traverse deck (optical pickup) may break down due to potential difference caused by the static electricity of clothes or our human body. So, be careful of electrostatic breakdown during repair of the traverse deck (optical pickup).
  • Page 8 SA-AK350PL...

  • Page 9: Precaution Of Laser Diode

    SA-AK350PL 4 Precaution of laser diode CAUTION: This unit utilizes a class 1 laser diode in the optical pickup unit . Invisible laser radiation is emitted from the optical pickup lens. Wavelength: 780nm When the unit is turned on: 1. Do not look directly into the optical pickup lens.

  • Page 10: About Lead Free Solder (Pbf)

    SA-AK350PL 5 About Lead Free Solder (PbF) 5.1. Service caution based on legal restrictions 5.1.1. General description about Lead Free Solder (PbF) The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this equipment in considering the globally environmental conservation.

  • Page 11: Accessories

    SA-AK350PL 6 Accessories Remote Control FM Antenna Wire AC Cord AM Loop Antenna...

  • Page 12: Operating Procedures

    SA-AK350PL 7 Operating Procedures 7.1. Main Unit Key Buttons Operations...

  • Page 13: Remote Control Key Buttons Operations

    SA-AK350PL 7.2. Remote Control Key Buttons Operations...

  • Page 14: New Features

    SA-AK350PL 8 New Features 8.1. Using the Music Port This feature enables you to enjoy music from a portable audio equipment.
  • Page 15 SA-AK350PL With reference to page 15 of the operating instruction manual.

  • Page 16: Self Diagnosis And Special Mode Setting

    SA-AK350PL 9 Self diagnosis and special mode setting This unit is equipped with functions for checking and inspecting namely: Self-Diagnostic and Test Mode. 9.1. Service Mode Summary Table The service modes can be activated by pressing various button combination on the main unit and remote control unit. Below is the...
  • Page 17 SA-AK350PL...
  • Page 18 SA-AK350PL 9.2.1. EEPROM Checksum (ROM Correction) Purpose: To check for microprocessor firmware version and EEPROM checksum (ROM correction).

  • Page 19: Reliability Test Mode (Crs1 Mechanism)

    SA-AK350PL Below are the procedures for this mode. Step 1: Enter into Doctor mode (for more information, refer to section 9.2 on the key operation to enter into this mode. Step 2: Check for firmware version and EEPROM checksum (By pressing STOP button on main unit followed by “4” and “7” on remote control).
  • Page 20 SA-AK350PL...

  • Page 21: Error Code Table Display

    SA-AK350PL 9.4. Error code Table Display Self-Diagnosis Function (refer Section 9.2) provides information on any problems occuring for the unit and its respective components by displaying the error codes. These error code such as U**, H** and F** are stored in memory and held unless it is cleared.
  • Page 22 SA-AK350PL 9.4.2. Error Code Table For CD Changer Block...
  • Page 23 SA-AK350PL...
  • Page 24 SA-AK350PL...
  • Page 25 SA-AK350PL 9.4.3. Error Code Table For Power Supply 9.4.4. CRS1 Error Code display CRS1 Error Code display 1. The errors that occured in CRS1 Mechanism can be recalled and displayed, in the order of the occurence under self-diagnostic for procedures to enter this mode.

  • Page 26: Assembling And Disassembling

    SA-AK350PL 10 Assembling and Disassembling 10.1. Caution Special Note: This model uses a new CD changer unit CRS1. In this following section does not contain the necessary disassembly & assembly information for the CD changer unit (CRS1) except the disasembly & assembly of traverse unit. Kindly refer to the original service manual for the CD changer unit.

  • Page 27: Disassembly Flow Chart

    SA-AK350PL 10.2. Disassembly flow chart The following chart is the procedure for disassembling the casing and inside parts for internal inspection when carrying out the servicing. To assemble the unit, reverse the steps shown in the chart as below.

  • Page 28: Main Parts Location

    SA-AK350PL 10.3. Main Parts Location...

  • Page 29: Disassembly Of Top Cabinet

    SA-AK350PL 10.4. Disassembly of Top Cabinet Step 1 Remove 3 screws on both sides on top cabinet. Step 2 Remove 5 screws at the rear. Step 3 Lift the sides of top cabinet outwards. Step 4 Push the top cabinet backwards to release catches.

  • Page 30: Disassembly Of Rear Panel

    SA-AK350PL · Disassembly of Mecha Chassis Step 5 Remove 2 screws. Step 6 Remove the Mecha Chassis. Note: For disassembly & assembly of traverse unit, please refer to section 10.15 of this service manual. Please refer to original Service Manual for the Disassembly and Assembly of the CD Changer Unit (CRS1).

  • Page 31: Disassembly Of Main P.c.b

    SA-AK350PL 10.7. Disassembly of Main P.C.B. · Follow the (Step 1) - (Step 5) of Item 10.4 · Follow the (Step 1) - (Step 4) of Item 10.5 · Follow the (Step 1) - (Step 4) of Item 10.6 Step 1 Detach FFC cables at connectors (CN2803 & CN2806) on Main P.C.B..

  • Page 32: Disassembly Of Power P.c.b

    SA-AK350PL 10.9. Disassembly of Power P.C.B. · Follow the (Step 1) - (Step 5) of Item 10.4 · Follow the (Step 1) - (Step 4) of Item 10.5 · Follow the (Step 1) - (Step 4) of Item 10.6 · Follow the (Step 1) - (Step 3) of Item 10.7 Step 1 Remove the 4 screws on Power P.C.B..

  • Page 33: Disassembly Of Front Panel Unit

    SA-AK350PL Step 3 Remove up the heat sink sub assembly (with IC5501). Step 4 Remove screw and IC clip. Step 5 Remove IC5501 from the sub assembly. Caution: During assembly of the heat sink sub assembly (with IC5501) all soldering points is touch-up to avoid dry- joints.

  • Page 34: Disassembly For Panel P.c.b

    SA-AK350PL 10.11. Disassembly for Panel P.C.B. · Follow the (Step 1) - (Step 5) of Item 10.4 · Follow the (Step 1) - (Step 4) of Item 10.5 · Follow the (Step 1) - (Step 5) of Item 10.10 Step 1 Remove the volume knob.

  • Page 35: Disassembly Of Deck Mechanism Unit

    SA-AK350PL 10.13. Disassembly of Deck mechanism unit · Follow the (Step 1) - (Step 5) of Item 10.4 · Follow the (Step 1) - (Step 4) of Item 10.5 · Follow the (Step 1) - (Step 5) of Item 10.10 Step 1 Remove the 4 screws.
  • Page 36 SA-AK350PL Step 3: Remove the traverse unit as arrow shown. · Assembly of Traverse Unit Step 1: Press and hold the plunger lever and rotate the gear as arrows shown until it stop. Step 1: Turn over the unit and install the traverse unit.

  • Page 37: Disassembly For Deck Mechanism

    SA-AK350PL Step 2: Push the traverse slide plate as arrow shown to lock the traverse unit. 10.16. Disassembly for Deck Mechanism · Follow the (Step 1) - (Step 4) of Item 10.4 · Follow the (Step 1) - (Step 4) of Item 10.5 ·...
  • Page 38 SA-AK350PL 10.16.2. Replacement of Motor, Capstan Belt A, Capstan Belt B, and Winding Belt...

  • Page 39: Disassembly Of Deck Mechanism P.c.b

    SA-AK350PL 10.17. Disassembly of Deck Mechanism P.C.B. · Follow the (Step 1) - (Step 4) of Item 10.4 · Follow the (Step 1) - (Step 4) of Item 10.5 · Follow the (Step 1) - (Step 5) of Item 10.10...

  • Page 40: Disassembly Of Cassette Lid

    SA-AK350PL · Follow the (Step 1) - (Step 3) of Item 10.14 Step 1 Remove 1 screw. Step 2 Desolder plunger terminals. Step 3 Release catches. Step 4 Remove Deck Mechanism P.C.B.. 10.18. Disassembly of cassette lid · Follow the (Step 1) - (Step 4) of Item 10.4 ·...
  • Page 41 SA-AK350PL Step 2 Push the lever upward and open the cassette lid. Remove the cassette tape. Note: Follow 10.18 Disassembly of cassette lid (Step1) to (Step 3). Remove the cassette tape.

  • Page 42: Service Fixture And Tools

    SA-AK350PL 11 Service Fixture and Tools Service Tools Extension FFC (A) Deck P.C.B. - Main P.C.B. REEX0485 (14 Pins) 12 Service Positions Note: For description of the disassembly procedures, see the Section 10. 12.1. Checking and Repairing of Main P.C.B.

  • Page 43: Checking And Repairing Of Transformer P.c.b

    SA-AK350PL 12.2. Checking and Repairing of Transformer P.C.B. 12.3. Checking and Repairing of Panel, Deck & Deck Mechanism P.C.B.

  • Page 44: Checking And Repairing Of Power P.c.b

    SA-AK350PL 12.4. Checking and Repairing of Power P.C.B.

  • Page 45: Procedure For Checking Operation Of Individual Parts Of Deck Mechanism Unit

    SA-AK350PL 13 Procedure for Checking Operation of Individual Parts of Deck Mechanism Unit 13.1. Operation Check with Cassette Tape 1. Pull up the EJECT lever using a rubber band. (Fig. 6) 2. Supply DC5V to MOTOR. (→ MOTOR rotates.) (Fig. 5) 3.
  • Page 46 SA-AK350PL...

  • Page 47: Measurement And Adjustments

    SA-AK350PL 14 Measurement And Adjustments 14.1. Cassette Deck Section 14.1.1. Requirements · Test tape (QZZCFM) (QZZCWAT) · Normal blank cassette tape (QZZCRA) · Digital frequency counter · Oscilloscope · Electrical voltmeter · Headphone jack output jig (Fig 8) 14.1.2. Setting of Unit ·...
  • Page 48 SA-AK350PL Fig. 10 Fig. 11 14.1.5. Bias Voltage Check 1. Connect an electrical voltmeter. (Fig 12) (Fig 9 for location of test point) 2. Set the function to “TAPE” position. 3. Insert a normal blank cassette tape (QZZCRA). 4. While pressing and holding down [REC( )] button, press [TAPE( )] button to pause the recording mode.

  • Page 49: Voltage And Waveform Chart

    SA-AK350PL 15 Voltage and Waveform Chart Note: Circuit voltage and waveform described herein shall be regarded as reference information when probing defect point, because it may differ from an actual measuring value due to difference of Measuring instrument and its measuring condition and product itself.

  • Page 50: Main P.c.b

    SA-AK350PL 15.3. Main P.C.B. 15.4. Panel P.C.B.

  • Page 51: Power P.c.b. & Transformer P.c.b

    SA-AK350PL 15.5. Power P.C.B. & Transformer P.C.B.

  • Page 52: Waveform Chart

    SA-AK350PL 15.6. Waveform Chart...

  • Page 53: Wiring Connection Diagram

    SA-AK350PL 16 Wiring Connection Diagram JK2803 9 ..1 CN3601 H5104 CN2810 TUNER PACK MOTOR CN2809 POWER P.C.B. SOLDER SIDE CN2801 MAIN P.C.B. SOLDER SIDE LEFT SPEAKERS TO CRS1 JK5101 (CN1) RIGHT SPEAKERS CN2808 CN2805 CN5103 1 .
  • Page 54 SA-AK350PL...

  • Page 55: Block Diagram

    SWITCH PROCESSOR/ TO MAIN CN7002 CN2801 (1/2) DIGITAL FILTER 3.3V 3.3V 3.3V 3.3V D/A CONVERTER MUTE PC1 4 CN7002 CN2801 [CH1] LCH OUT 3.3V TO MAIN CN7002 CN2801 (2/2) RCH OUT MUTE PC2 2 [CH2] SA-AK350PL CD SERVO BLOCK DIAGRAM...

  • Page 56: Deck/ Deck Mechanism Diagram

    : AM SIGNAL LINE : FM/AM SIGNAL LINE : USB SIGNAL LINE : FM SIGNAL LINE : AUX SIGNAL LINE : TAPE PLAYBACK SIGNAL : TAPE RECORD SIGNAL LINE ( ) Indicates the Pin No. of Right Channel. SA-AK350PL DECK/DECK MECHANISM BLOCK DIAGRAM...

  • Page 57: Main Diagram

    SWITCH DRIVER FROM DECK Q2501 D2503 LM.1 LEVEL METER CONTROL SWITCH ASPDA ASPCLK IDCDET Q2942 FAN MOTOR ON/OFF SWITCH TO FAN Q2943 FAN SUPPLY FROM POWER CONTROL SWITCH Q2949 Q2948 D2946 DC DETECT DC DETECT SWITCH SWITCH SA-AK350PL MAIN 1/2 DIAGRAM...
  • Page 58 ASPCLK LM.1 Q2937 Q2936 VREF CD SUPPLY CHANGER PLUNGER ON/OFF SWITCH CONTROLSWITCH QR3105 QR3106 Q2803 SWITCH SWITCH IC4000 C0DBZGC00067 RESET (MICRO-P) 3.3V REGULATOR SWITCH Q3601 STBY SWITCH D2936 IC2872 C0CBAHG00011 VOLTAGE REGULATOR 3.3V D2811 D2813 D3400 SA-AK350PL MAIN 2/2 DIAGRAM...

  • Page 59: Panel Diagram

    VR6511 VOLUME TO MAIN (1/2) JK6751 MUSIC PORT S6201-S6207 TO MAIN (2/2) JK6551 HEADPHONE TO MAIN (1/2) SUB PANEL CIRCUIT S6301-S6309 VR6491 +VREF MIC VOLUME +VREF TO MAIN (2/2) S6106-S6108 S6101-S6105 QR6457 MOT10V DRIVE SUB PANEL P.C.B SA-AK350PL PANEL DIAGRAM...

  • Page 60: Power Diagram

    FAN ON/OFF SWITCH SWITCH D5126 TO MAIN (1/2) Q5111 Q5101,Q5110 +15V REGULATOR Q5102 Q5108,Q5109 CURRENT CONTROL SWITCH TO TRANSFORMER Q5112,Q5114 Q5113 CURRENT STABLISER CURRENT LMIITER 11V REGULATOR SWITCH IC5101 TO MAIN C0DAZYY00005 (2/2) REGULATOR IC D5130 5.6V 3.3V SA-AK350PL POWER DIAGRAM CTRL...

  • Page 61: Transformer Diagram

    SA-AK350PL 17.6. Transformer Diagram T5950 D5950-D5953 TO POWER FP5950 D5954-D5957 Q5951 VOLTAGE REGULATOR Q5953 RL5950 PCONT SWITCH TO PANEL Q5952 T5951 SYNCHRONISATION SWITCH JK5950 D5966 AC INLET L5950 Z5950 D5951, Q5950 D5952 D5963 VOLTAGE REGULATOR SA-AK350PL TRANSFORMER DIAGRAM...
  • Page 62 SA-AK350PL...

  • Page 63: Notes Of Schematic Diagram

    SA-AK350PL 18 Notes Of Schematic Diagram (All schematic diagrams may be modified at any time with : Main Signal line the development of new technology) : FM/AM Signal line Notes: S971: Mode switch. : Tape Record Signal line S972: Half switch.
  • Page 64 SA-AK350PL...

  • Page 65: Schematic Diagram

    12 11 R7220 R7330 W7002 W7004 5.6K C7335 IC7002 X7201 C7315 H2B169500005 0.47 BA5948FPE2 C7334 4 CH DRIVE IC C7338 10V220 0.056 R7331 R7323 3.3k R7315 R7325 3.3k R7332 R7335 M7301 M7302 TRAVERSE MOTOR SPINDLE MOTOR SA-AK350PL CD SERVO CIRCUIT...

  • Page 66: B) Main Circuit

    SA-AK350PL 19.2. (B) Main Circuit SCHEMATIC DIAGRAM - 2 MAIN CIRCUIT : TAPE PLAYBACK SIGNAL LINE : FM/AM SIGNAL LINE : MAIN SIGNAL LINE : AUX SIGNAL LINE : MIC SIGNAL LINE : +B SIGNAL LINE : CD SIGNAL : TAPE RECORD SIGNAL LINE...
  • Page 67 C3709 W586 K3705 R2456 R3711 180k +15V R2417 C3707 R2423 C3712 C2423 R2428 C3710 R2418 8.2k 0.015 R2429 R2426 100k R3709 3.3K Q2417 R2416 W654 R3712 2.2k C2421 R2421 C2425 16V10 C2943 50V2.2 TO MAIN SECTION (4/4) SA-AK350PL MAIN CIRCUIT...
  • Page 68 SA-AK350PL SCHEMATIC DIAGRAM - 4 MAIN CIRCUIT : +B SIGNAL LINE : CD SIGNAL LINE : FM/AM SIGNAL LINE : MAIN SIGNAL LINE : AUX SIGNAL LINE R2284 W658 R2285 D2811 B0ADCJ000020 R2894 R2121 3.3k TO MAIN SECTION (1/4) R2122 C2121 +3.3V...
  • Page 69 W615 Q2937 Q2936 28 27 25 24 21 20 12 11 11 12 13 14 B1ACKD000006 CD SUPPLY CONTROL SWITCH Q2937 B1GBCFJJ0051 CHANGER PLUNGER CN2806 CN2805 ON/OFF SWITCH TO CRSI (CN1) PANEL CIRCUIT (CN6601) IN SCHEMATIC DIAGRAM-6 SA-AK350PL MAIN CIRCUIT...

  • Page 70: C) Panel Circuit

    C6502 R6753 W901 Q6501 L6501 C6510 C6504 R6751 3.3K 3.3K MUSIC PORT L6502 C6509 R6509 W910 C6753 C6751 C6503 0.01 0.01 R6503 0.047 C6506 C6505 0.01 R6506 W1004 0.22 2.2K W1000 JK6501 JK6751 VR6511 EVUF2AF15B14 MIC VOLUME SA-AK350PL PANEL CIRCUIT...

  • Page 71: D) Sub Panel Circuit & (G) Deck Mechanism Circuit

    S6305 R6306 2.2K R6491 R6107 S6306 R6307 2.7K S6108 2.7K M.EQ+ C6492 C6491 100P 100P HARD R6108 BASS S6307 4.7K R6308 R6310 MANUAL 4.7K S6308 COM B R6309 6.8K M.EQ- S6309 VR6491 EVEKE2F3024B VOLUME JOG SA-AK350PL SUB PANEL/DECK MECHANISM CIRCUIT...

  • Page 72: E) Power Circuit

    C5202 100P IC5201 Q5202 100P Q5201 Q5103,Q5104 X5202 B1ADCF000063 B1ABCF000176 FREQUENCY HOPPING R5207 FAN ON/OFF SWITCH SWITCH 6.8K Q5104 Q5202 Q5103 X5201 H2A415300001 R5209 C5204 100P AGND C5205 C5208 X5202 6.3V220 H2A375300003 AGND D5126 R5150 B0ACCK000005 220K SA-AK350PL POWER CIRCUIT...
  • Page 73 R5105 IN SCHEMATIC R5110 MUTE_F 2.2K mUTE-F_HOP C5133 DIAGRAM-5 MOTOR12V 6.3V100 D5103 C5113 MOTOR 12V B0BA5R000004 D5109 50V33 XM5.3V R5132 XM5.3V B0BA01100004 -9V AGND AGND Q5109 Q5114 +3.3V 2SB0709AHL CN5103 B1ABCF000176 VOLTAGE REGULATOR 11V REGULATOR E5103 K9ZZ00001279 SA-AK350PL POWER CIRCUIT...

  • Page 74: F) Deck Circuit

    R1337 R1332 B0ACCK000005 MOTOR_GND MOTOR_H C1311 C1320 16V47 50V1 R1331 DECK MECHANISM (CS971) Q1315 CN1305 7.5K ON SCHEMATIC DIAGRAM-7 Q1314 R1344 R1342 R1341 R1374 R1343 3.3K Q1316 WR1903 R1345 2SD09650RA SWITCH Q1314 Q1315 B1GDCFGH0002 B1ACKD000006 SWITCH SWITCH SA-AK350PL DECK CIRCUIT...

  • Page 75: H) Transformer Circuit

    Q5953 SUB TRANSFORMER B1AACF000064 PCONT SWITCH L5950 ELF15N035AN C5951 JK5950 0.01u C5953 AC IN 0.01u 120V 60Hz R5952 Z5950 125V T4AL 4.7K ERZV10V511CS R5958 C5963 R5953 Q5952 B1GACFJJ0018 C5962 C5952 SYNCHRONISATION SWITCH 10V220 C5954 R5957 10V47 0.01 SA-AK350PL TRANSFORMER CIRCUIT...
  • Page 76 SA-AK350PL...

  • Page 77: Printed Circuit Board

    SA-AK350PL 20 Printed Circuit Board Note: Circuit board diagrams may be modified at any time with the development of new technology.

  • Page 78: A) Cd Servo P.c.b., (F) Deck P.c.b. & (G) Deck Mechanism P.c.b

    SA-AK350PL 20.1. (A) CD Servo P.C.B., (F) Deck P.C.B. & (G) Deck Mechanism P.C.B. CD SERVO P.C.B (REPV0111A) DECK P.C.B (REPV0134B) (RF) TP51 C7227 W1930 W7014 Q1309 CN1305 Q1310 C7204 W7015 W1909 W1935 C7226 R7212 TP18 TP50 C7228 C1317 TP17...

  • Page 79: B) Main P.c.b

    SA-AK350PL 20.2. (B) Main P.C.B. MAIN P.C.B (REPV0130J) JK2803 J2996 R2447 C2705 R2702 R2941 W566 R2446 C2941 C2312 C2240 Q2441 R2145 R2705 R2703 W277 R2241 C2983 W569 R2944 C2981 R2315 C2703 C2944 C2441 Q2943 C2314 C2313 C2341 Q2142 R2353 R2344 R2347...

  • Page 80: C) Panel P.c.b

    SA-AK350PL 20.3. (C) Panel P.C.B. PANEL P.C.B (REPV0131F) S6201 S6103 (CD1) (OPEN/CLOSE) S6202 S6102 (CD2) (MULTI CHANGE) W805 R6632 S6203 R6105 (CD3) J6553 J6551 S6104 (SINGLE CHANGE) S6204 R6458 (CD4) W840 R6199 J6552 R6209 W1017 J6753 R6208 S6206 R6206 (/FF/)

  • Page 81: D) Sub Panel P.c.b

    SA-AK350PL 20.4. (D) Sub Panel P.C.B. SUB PANEL P.C.B (REPV0131F) JW6001 D6462 S6304 (VOL. LED) S6305 (TUNER/ R6302 R6303 FM/AM) (EXT_IN) R6457 VR6491 R6304 S6302 S6303 (CD) (TAPE) W960 W968 R6305 W751 C6491 C6492 QR6457 W971 D6457 (VOL. LED) W756...

  • Page 82: E) Power P.c.b

    SA-AK350PL 20.5. (E) Power P.C.B. POWER P.C.B (REPV0133C) H5104 W701 C5171 W602 W714 C5102 C5103 C5172 R5203 W662 W697 R5201 W698 R5202 Q5202 C5204 W700 C5203 W691 C5202 W737 W638 R5207 Q5201 C5301 C5302 R5522 C5332 C5330 R5206 W639 R5302...

  • Page 83: H) Transformer P.c.b

    SA-AK350PL 20.6. (H) Transformer P.C.B. TRANSFORMER P.C.B (REPV0132F) T5951 125V 4A (SUB TRANSFORMER) L5950 C5953 Q5950 J5955 R5952 Z5950 C5951 C5952 D5952 RL5950 C5954 JK5950 Q5952 W5914 Q5953 W5915 CN5951 R5958 AC IN ~ W5905 R5951 R5960 120V 60HZ R5961...
  • Page 84 SA-AK350PL...

  • Page 85: Illustration Of Ics, Transistors And Diodes

    SA-AK350PL 21 Illustration of ICs, Transistors and Diodes C0AABB000125 C0ABBB000244 (8P) C0CBAHG00011 C1AA00000612 C1BB00001121 (100P) MN6627954MA (100P) C0HBB0000057 (44P) C2CBYY000482 (100P) CNB13030R2AU C0DAZYY00005 C0JBAB000011(14P) AN7326K (26P) C0DBZGC00067 BA5948FPE2 C1BA00000487 (24P) 2SB0709AHL B1ADCF000001 B1AAKD000014 2SD09650RA B1GACFJJ0018 B1DEGM000026 B1ABCF000176 B1GDCFJJ0047 B1ACKD000006 B1ABGC000005...

  • Page 86: Terminal Function Of Ic's

    SA-AK350PL 22 Terminal Function of IC's 22.1. IC7001 (MN6627954MA) Servo Processor,Digital Signal Processor/Digital filter and D/A Converter Pin No. Mark Function Pin No. Mark Function DRAM address signal O/P 11 IREF Reference I/P DRAM address signal O/P 9 PLLF PLL Loop Filter Terminal...

  • Page 87: Ic7002 (Ba5948Fpe2) Ic 4Ch Drive

    SA-AK350PL 22.2. IC7002 (BA5948FPE2) IC 4CH Drive Pin No. Mark Function Pin No. Mark Function Motor Driver 92 Input Motor Drive (3) reverse - action output Turntable Motor Drive Signal (“L”:ON) Motor Drive (3) forward - action Motor Drive (1) Input...
  • Page 88 SA-AK350PL Pin No. Mark Function MDATA_OUT CD Command Data Output MCLK CD Command Clock Output /RESET_SW CD Limit Switch Input for the most Inner Point (Active Low) HOME_SW Home Switch for CRS1 CD_RST CD Reset output CLOSE_SW CLOSE switch for CRS1...

  • Page 89: Exploded Views

    SA-AK350PL 23 Exploded Views 23.1. Cabinet Parts Location...
  • Page 90 SA-AK350PL...

  • Page 91: Deck Mechanism Parts Location (Raa4403-S)

    SA-AK350PL 23.2. Deck Mechanism Parts Location (RAA4403-S)

  • Page 92: Packaging

    SA-AK350PL 23.3. Packaging...

  • Page 93: Replacement Parts List

    SA-AK350PL 24 Replacement Parts List Notes: · Important safety notice: Components identified by mark have special characteristics important for safety. Furthermore, special parts which have purposes of fire-retardent (resistors), high-quality sound (capacitors), low noise (resistors), etc are used. When replacing any of these components, be sure to use only manufacturer’s specified parts shown in the parts list.
  • Page 94 SA-AK350PL Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks RXL0126 WINDING ARM ASS’Y Q2501 B1ABCF000176 TRANSISTOR RXQ0412-3 HEAD PANEL ASS’Y Q2511 B1GDCFJJ0047 TRANSISTOR 133-1 RMB0405-1 FR ROD SPRING Q2803 B1GBCFJJ0051...
  • Page 95 SA-AK350PL Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks D5154 B0JAME000119 DIODE CN2809 K1KB12B00037 12P CONNECTOR D5155 B0JAME000119 DIODE CN2810 K1KA02AA0186 FAN CONNECTOR D5156 B0JAME000119 DIODE CN3601 K1KA10AA0031 10P CONNECTOR...
  • Page 96 SA-AK350PL Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks EYF52BCY FUSE CLIP W621 ERJ3GEY0R00V CHIP JUMPER EYF52BCY FUSE CLIP W622 ERJ3GEY0R00V CHIP JUMPER W623 ERJ3GEY0R00V CHIP JUMPER FSUE PROTECTORS W624...
  • Page 97 SA-AK350PL Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks W905 ERJ6GEY0R00V CHIP JUMPER RESISTORS W906 ERJ6GEY0R00V CHIP JUMPER W907 ERJ6GEY0R00V CHIP JUMPER D0AE102JA048 1K 1/4W W908 ERJ6GEY0R00V CHIP JUMPER D0AE101JA048...
  • Page 98 SA-AK350PL Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks R2161 D0GB153JA008 15K 1/16W R2423 D0GB822JA008 8.2K 1/16W R2163 D0GB563JA007 56K 1/16W R2426 D0GB103JA008 10K 1/16W R2172 D0GB472JA008 4.7K 1/16W R2428...
  • Page 99 SA-AK350PL Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks R2843 D0GB101JA007 100 1/16W R5135 D0AE2R2JA048 2.2 1/4W R2844 D0GB222JA041 2.2K 1/16W R5136 D0AE2R2JA048 2.2 1/4W R2845 D0GB101JA007 100 1/16W R5137 D0AE2R2JA048 2.2 1/4W...
  • Page 100 SA-AK350PL Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks R6203 D0GB102JA008 1K 1/16W CAPACITORS R6204 D0GB122JA008 1.2K 1/16W R6205 D0GB182JA008 1.8K 1/16W F2A1C101A147 100P 16V R6206 D0GB222JA041 2.2K 1/16W C1101...
  • Page 101 SA-AK350PL Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks C2212 ECJ1VB1C105K 1 16V C2802 F2A1H3R3A234 3.3 50V C2213 F1H1H682A219 6800P 50V C2803 F1H1A105A025 1 10V C2221 F1H1H332A013 3300P 50V C2805...
  • Page 102 SA-AK350PL Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks C5171 ECA1JM102E 1000 63V C5427 ECQV1H474JL3 0.47 50V C5172 ECA1JM102E 1000 63V C5428 ECJ1VB1H104K 0.1 50V C5186 ECJ1VB1H104K 0.1 50V C5429...
  • Page 103 SA-AK350PL Ref. No. Part No. Part Name & Description Remarks C7225 F1H1H102A219 1000P 50V C7226 F1H1H102A219 1000P 50V C7227 ECA1HAK010XI 1 50V C7228 ECA1HAK010XI 1 50V C7230 ECJ1VB1C104K 0.1 16V C7231 F2A0J221A200 220 6.3V C7232 F2A0J221A200 220 6.3V C7233 F1H1C104A008 0.1 16V...
