- Page 1 FP715 Electronic 2-channel full programmer for heating & hot water Installation & User Instructions...
-
Page 2: Table Of Contents
Index Installation Product specifi cation Installation Wiring DIL switch settings Wiring Conversion 6-13 User Your programmer Preset programmes Resetting the unit 24hr or AM/PM display Setting the Time and Day 15-16 Accepting the preset programmes Changing the preset programmes Programming heating - 5/2 day 18-19 Programming heating - 7 day 20-21... -
Page 3: Product Specifi Cation
Installation Instructions Please Note: This product should only be installed by a qualifi ed electrician or competent heating installer, and should be in accordance with the current edition of the IEEE wiring regulations. Product specifi cation Specifi cation Power supply 230 Vac, ±10%, 50/60 Hz Switching action 2 x SPDT internally linked, Type 1B... - Page 4 For wiring connections refer to diagram on page 5. FP715 models are double insulated and do not require an earth connection, however a parking terminal is provided on the wallplate. This is clearly marked with an Earth symbol.
-
Page 5: Dil Switch Settings
Wiring Always switch off mains fi rst and never fi t programmer to a live wallplate. For Wiring Conversion tables see - pages 6-13 DIL Switch Settings Before mounting the unit, ensure the 4 DIL switches on the rear of the unit have been moved to the required settings Remember to tick the... - Page 6 WIRING CONVERSIONS Wiring conversions can be used when replacing the following programmers with the FP715. Some time controls are connected differently depending on the type of system they are controlling. Consult the column headed “NOTE Table A MAINS DANFOSS RANDALL...
- Page 7 This conversion ...” to determine whether Table A (pages 6-9) or Table B (pages 10-13) should be used. If in any doubt, contact our Technical Services Department before proceeding with the replacement. *Any wires connected to switch COMMONS which are linked LIVE on existing wallplates must be transferred to the LIVE terminal on the new wallplate.
- Page 8 Table A cont.. MAINS DANFOSS RANDALL FP715, CP715 (PUMPED) SANGAMO S409/3 SATCHWELL LIBRA & DHP 2201 SATCHWELL ET 1401 & 1451 SMITHS IND. CENTROLLER 90 SMITHS IND. CENTROLLER 1000 SWITCHMASTER 800 & 805 SWITCHMASTER 900 & 9000 SWITCHMASTER SONATA VENNER CHC/W2 (WITH STAT)
- Page 9 An additional terminal Wires other block may be required than links in NOTE where these discon- these terms This conversion applies nected leads (or pairs) got to LIVE only if..should be terminated Programme selectors UNLINKED Programme selectors UNLINKED Used in a system having independent control of water and heating...
- Page 10 HORSTMANN 425 DIADEM HORSTMANN 525 & 527 HONEYWELL ST669 POTTERTON EP2000, EP3000 RANDALL TSR2P RANDALL MKII R6 DANFOSS RANDALL 3060 & 3020P RANDALL 701 DANFOSS RANDALL SET 2 SANGAMO M5 410 FORM 4 SANGAMO S409 FORMS 1 & 4 N,1,3...
- Page 11 An additional terminal Wires other block may be required than links in NOTE where these discon- these terms This conversion nected leads (or pairs) got to LIVE applies only if..should be terminated Programmed selectors UNLINKED BOILER STAT Programme selectors UNLINKED Programme selectors UNLINKED ...set for gravity HW...
- Page 12 Table B cont... MAINS DANFOSS RANDALL FP715, CP715 (PUMPED) SMITHS IND. CENTROLLER 1000 SMITHS IND. CENTROLLER 60 SMITHS IND. CENTROLLER 10 SMITHS IND. CENTROLLER 70 SMITHS IND. CENTROLLER 1000 SWITCHMASTER 320 & 350 SWITCHMASTER 400 SWITCHMASTER 600 SWITCHMASTER 900 & 9000...
- Page 13 An additional terminal Wires other block may be required than links in NOTE where these discon- these terms This conversion nected leads (or pairs) got to LIVE applies only if..should be terminated Programme selectors UNLINKED L & 4 are LINKED Programme selectors UNLINKED Used in a system...
-
Page 14: Your Programmer
User Instructions Your programmer The FP715 allows you to switch your heating and hot water on and off at times that suit you. You can programme up to 3 ON/OFF times per day for the heating and the hot water and the two systems can be operated independently. -
Page 15: Before You Start
Before you start Open the fl ap on the front of the clock. Press the RESET button using a non-metallic object (e.g. pencil/matchstick) until you hear a click and the 2 red lights on the front of the unit fl ash once. This will reinstate the preset programmes and set the time to 12.00pm on Monday (MO) -
Page 16: Accepting The Preset Programmes
SETTING THE DAY Press DAY repeatedly until the correct day of the week is displayed. MO is Monday, TU is Tuesday etc. Accepting the preset programmes If you are happy to use the preset programmes on page 14, you don’t need to do anything else. - Page 17 Before you change the preset programmes Your installer will have set your unit to operate in one of the following modes: ● 5/2 day - one set of programmes for weekdays and another for weekends (page 18-19) ● 7 day - different settings for each day of the week (page 20-21) ●...
- Page 18 Programming the heating in 5/2 day mode 1. Press PROG until SET CH ON TIME appears at the top of the display and MOTUWETHFR appears at the bottom of the display. Use the + and - buttons to set the time you would like your heating to fi...
- Page 19 4. Press the DAY button once and SASU will appear at the bottom of the display. You can press COPY to keep the same settings for Saturday and Sunday as you have programmed for Monday to Friday. Alternatively, programme new ON/OFF times by pressing the NEXT ON/OFF button to move to the next setting and...
- Page 20 Programming the heating in 7 day mode 1. Press PROG until SET CH ON TIME appears at the top of the display and MO appears at the bottom of the display. Use the + and - buttons to set the time you want your heating to fi...
- Page 21 Continue programming the rest of the week by pressing: a) NEXT ON/OFF button to move to the next setting, b) + and - buttons to amend the time c) DAY to advance to the next day. Alternatively press COPY to keep the same settings as the day before 4.
- Page 22 Programming the heating in 24 hour mode 1. Press PROG until SET CH ON TIME appears at the top of the display. Use the + and - buttons to set the time you want your heating to fi rst come on in the morning (Event 1).
- Page 23 Programming the hot water To set the hot water programme press the PROG button until SET HW ON TIME appears on the display. Set the hot water programme in the same way as the heating programme, using: a) + and - buttons to alter the time b) pressing the NEXT ON/OFF button to move to the next...
- Page 24 Running your Programme To run the central heating programme: press the SELECT button next to the radiator symbol. To run the hot water programme: press the SELECT button next to the tap symbol. As you press the SELECT button the display will change between ON, OFF, ALLDAY and AUTO.
-
Page 25: Temporary Overrides
Temporary override buttons Sometimes you may need to change the way you use your heating temporarily, i.e. due to unusually cold weather. The FP715 has two convenient overrides which can be selected without affecting the set programme. +1HR +1HR +1HR... - Page 26 Changing clocks forward & back Open the fl ap on the front of the unit to reveal the programming buttons. To change from Summer to Winter (clocks back) - press and hold - button To change from Winter to Summer (clocks forward) - press and hold + button NOTE: After the fi...
-
Page 27: Hot Water
Fault Check List o Hot Water heck FP715 programmer. Turn the heating selector to OFF and the water selector to ON. Is the red light by the water switch on? heck fuse in fused spur heck cylinder thermostat Is the stat set to a temperature of 60° ? Turn knob to 60°... - Page 28 Call our technical department 0845 121 7505 (8.45-5.15 Mon-Thurs, 8.45-4.45 Fri) For a large print version of these instructions please contact the Marketing Services Department on 0845 121 7400. Danfoss Randall Ltd Ampthill Road Bedford MK42 9ER Tel: 01234 364621 Fax: 01234 219705...
