Page 1 Liquid Crystal Projector ED-S3170A/ED-X3270A USER'S MANUAL Vol.1 Basic Please read this user's manual thoroughly to ensure correct usage through understanding. BEDIENUNGSANLEITUNG Teil 1 Grundlagen Bitte lessen Sie diese Benutzerhandbuch zugunsten der korrekten Bedienung aufmerksam. MANUEL D'UTILISATION Vol.1 Fondements Nous vous recommandons de lire attentivement ce manuel pour bien assimiler le fonctionnement de l'appareil.
Page 2: Table Of Contents
LCD Projector ED-S3170A/ED-X3270A USER'S MANUAL USER'S MANUAL Vol.1 (Basic) Thank you for purchasing this projector. WARNING • Please read the accompanying manual “SAFETY INSTRUCTIONS” and this “USER'S MANUAL” thoroughly to ensure correct usage through understanding. After reading, store this instruction manual in a safe place for future reference.
Page 3: Projector Features
Projector (with Lens Cap) Video/Audio cable RGB cable Liquid Crystal Projector ED-S3170A/ED-X3270A USER'S MANUAL Vol.1 Basic Please read this user's manual thoroughly to ensure correct usage through understanding. BEDIENUNGSANLEITUNG Teil 1 Grundlagen Bitte lessen Sie diese Benutzerhandbuch zugunsten der korrekten Bedienung aufmerksam.
Page 4 WARNING Precautions to observe in regards to the power cord: Please use extra caution when connecting the projector's power cord as incorrect or faulty connections may result in FIRE AND/OR ELECTRICAL SHOCK. Please adhere to the following safety guidelines to insure safe operation of the projector: •...
Page 5: Part Names
THE PROJECTOR PART NAMES Indicates the corresponding reference page MENU button RESET button POWER indicator KEYSTONE button TEMP indicator INPUT button LAMP indicator STANDBY/ON button Zoom ring Focus ring Air filter Elevator button Remote sensor Lens cap S-VIDEO IN port AUDIO IN R and L ports RGB IN 1 and 2 ports VIDEO IN port...
Page 6: The Remote Control
THE REMOTE CONTROL SEARCH button STANDBY/ON button RGB button STANDBY/ON VIDEO SEARCH VIDEO button AUTO button ASPECT AUTO BLANK BLANK button ASPECT button MAGNIFY HOME PAGE UP VOLUME VOLUME button MAGNIFY buttons PAGE DOWN MUTE MUTE button FREEZE KEYSTONE FREEZE button KEYSTONE button KEYBOARD buttons POSITION...
Page 7: Setting Up The Projector
SETTING UP THE PROJECTOR CAUTION • Install the projector in a suitable environment according to instructions of the accompanying manual “SAFETY INSTRUCTIONS” and this manual. • If you press the elevator buttons without holding the projector, the projector might crash down, overturn, smash your fingers and possibly result in malfunction. To prevent damaging the projector and injuring yourself, ALWAYS HOLD THE PROJECTOR whenever using the elevator buttons to adjust the elevator feet.
Page 8: Adjusting The Screen Size And Projection Distance
The values shown in the table are calculated for a full size screen (ED-S3170A: 800x600 pixels/ED-X3270A: 1024x768 pixels). a:Distance from the projector to the screen (±10%) b:Distance from the lens center to the bottom of the screen (±10%) c:Distance from the lens center to the top of the screen (±10%)
Page 9: Connecting Your Devices
CONNECTING YOUR DEVICES Devices You Can Connect to the Projector (Refer to this section for planning your device configuration to use for your presentation.) CAUTION • Incorrect connecting could result in fire or electrical shock. Please read this manual and the separate “SAFETY INSTRUCTIONS”. ATTENTION Precautions to observe when connecting other devices to the projector •...
Page 10: Ports And Cables
Ports and Cables Refer to the table below to find out which projector port and cable to use for connecting a given device. Use this table for determining which cables to prepare. Function Projector Port Connection Cables RGB IN 1 Accessory RGB cable or optional RGB RGB input RGB IN 2...
Page 11: Connecting To A Computer
CONNECTING YOUR DEVICES (continued) Connecting to a Computer ATTENTION Whenever attempting to connect a laptop computer to the projector, be sure to activate the laptop's RGB external image output (set the laptop to CRT display or to simultaneous LCD and CRT display). For details on how this is done, please refer to the instruction manual of the corresponding laptop computer.
Page 12: Connecting To A Dvd Player
Connecting to a DVD Player RGB IN AUDIO IN S-VIDEO IN L / (MONO) VIDEO IN RGB OUT CONTROL AUDIO IN AUDIO OUT S-VIDEO cable If using a S-video connection DVD player Connecting to a VCR RGB IN AUDIO IN S-VIDEO IN L / (MONO) VIDEO IN RGB OUT...
Page 13 CONNECTING YOUR DEVICES (continued) Connecting to a Display Monitor RGB IN AUDIO IN S-VIDEO IN L / (MONO) VIDEO IN RGB OUT CONTROL AUDIO IN AUDIO OUT Display monitor http://www.pureglare.com.au...
Page 14: Using The Remote Control
USING THE REMOTE CONTROL Putting batteries into the remote control unit CAUTION Precautions to observe in regards to the batteries Always handle the batteries with care and use them only as directed. Improper use may result in battery cracking or leakage, which could result in fire, injury and/or pollution of the surrounding environment. •...
Page 15: Turning On The Power
TURNING ON THE POWER Precautions Connect all devices to be used to the projector prior to turning on the power. WARNING When the power is ON, a strong light is emitted. Do not look into the lens. Make sure that the power cord is firmly and correctly connected to the projector and outlet STANDBY/ON VIDEO...
Page 16: Selecting An Input Signal
Selecting an Input Signal Using the remote control Using the projector's control panel If selecting RGB input Press the INPUT button As illustrated below, each time you Press the RGB button press the INPUT button, the projector Press this button to toggle between the switches between its input signal devices connected to RGB IN 1 and 2.
Page 17: Turning Off The Power
TURNING OFF THE POWER Press the STANDBY/ON button (control panel or remote control) The message "Power off?" will appear on the screen for approximately 5 seconds. STANDBY/ON STANDBY/ON VIDEO SEARCH ASPECT AUTO BLANK MAGNIFY HOME PAGE UP VOLUME PAGE DOWN MUTE Press the STANDBY/ON button again FREEZE...
Page 18: Adjusting The Volume
ADJUSTING THE VOLUME Press the VOLUME button VOLUME As illustrated on the right, a dialog will STANDBY/ON appear on the screen to aid you in adjusting VIDEO SEARCH the volume. ASPECT AUTO BLANK VOLUME VOLUME MAGNIFY HOME PAGE UP VOLUME PAGE DOWN MUTE FREEZE...
Page 19: Adjusting The Position
ADJUSTING THE POSITION Press the POSITION button As illustrated on the right, a dialog will appear on the screen to aid you in adjusting the position. STANDBY/ON VIDEO SEARCH ASPECT AUTO BLANK HOME PAGE UP VOLUME MAGNIFY PAGE DOWN MUTE POSITION FREEZE KEYSTONE...
Page 20: Using The Automatic Adjustment Feature
USING THE AUTOMATIC ADJUSTMENT FEATURE Press the AUTO button AUTO STANDBY/ON VIDEO SEARCH ASPECT AUTO BLANK Automatic Adjustment for RGB Input MAGNIFY HOME PAGE UP VOLUME Horizontal position (H. POSIT), vertical position (V. PAGE DOWN MUTE POSIT), clock phase (H. PHASE) and horizontal size (H. FREEZE KEYSTONE SIZE) are automatically adjusted.
Page 21: Correcting Keystone Distortions
CORRECTING KEYSTONE DISTORTIONS Press the KEYSTONE button KEYSTONE As illustrated on the right, a dialog will appear STANDBY/ON on the screen to aid you in correcting the VIDEO SEARCH distortion. ASPECT AUTO BLANK KEYSTONE MAGNIFY HOME PAGE UP VOLUME PAGE DOWN MUTE FREEZE KEYSTONE...
Page 22: Using The Magnify Feature
USING THE MAGNIFY FEATURE Press the MAGNIFY (ON) button MAGNIFY MAGNIFY The projector enters MAGNIFY mode. STANDBY/ON VIDEO SEARCH ASPECT AUTO BLANK Press the POSITION button, then use the MAGNIFY HOME PAGE UP VOLUME buttons to select the area to enlarge and then PAGE DOWN MUTE press the POSITION button again to confirm your...
Page 23: Signal Searching
SIGNAL SEARCHING Press the SEARCH button When you press the SEARCH button, the projector begins STANDBY/ON searching for input signals. If it detects an input signal, the VIDEO SEARCH search will cease and the projector will project the detected ASPECT AUTO BLANK signal.
Page 24: Using The Menu Functions
USING THE MENU FUNCTIONS Press the MENU button MENU The menu display appears on the screen. The STANDBY/ON projector has the following menus: MAIN, VIDEO SEARCH PICTURE-1, PICTURE-2, INPUT, SCREEN, and ASPECT AUTO BLANK OPTION. Select a menu using the buttons.
Page 25: Operating The Pc Screen
OPERATING THE PC SCREEN You can use the remote control as a simplified mouse or keyboard. CAUTION Caution: Mistaken use of the mouse/keyboard control could damage your equipment. • Only connect to a PC. • Before connecting, read the manuals of the device you will connect. •...
Page 26: The Lamp
Before replacing the lamp, check the serial number of the replacement lamp bulb (sold separately: DT00511 for ED-S3170A/DT00521 for ED-X3270A), then contact your local dealer. Before replacing the lamp, turn off the power, and unplug the power cord, then wait at least 45 minutes, in order to ensure that the lamp is properly cooled.
Page 27: Replacing The Lamp
• Also steadily push the opposite side of the screwed side of the new lamp (sold separately: DT00511 for lamp into the unit. ED-S3170A/DT00521 for ED-X3270A) After making sure that the projector has cooled adequately, slowly flip over the projector, so that the bottom is facing up...
Page 28: The Air Filter
THE AIR FILTER Caring for the air filter The air filter should be cleaned about every 100 hours. If the LAMP indicator and TEMP indicator blink red simultaneously, or a message prompts you to clean the air filter when you turn on the unit, the filter needs to be cleaned. (See "Related Messages"...
Page 29: Replacing The Air Filter
THE AIR FILTER (continued) Replacing the air filter If the soiling will not come off the air filter, or it becomes damaged, then it needs to be replaced. Please contact your local dealer, after confirming the model of your separately sold replacement air filter. (See "Optional Parts" on Vol.2 Turn off the projector, and unplug the power cord.
Page 30: Other Care
OTHER CARE Caring for the inside of the projector : In order to ensure the safe use of your projector, please have it cleaned and inspected by your local dealer about once every 2 years. Never try to care for the inside of the unit yourself.
Page 31 LCD Projector ED-S3170A/ED-X3270A USER'S MANUAL USER'S MANUAL Vol.2 (Extended) Thank you for purchasing this projector. WARNING • Please read the accompanying manual “SAFETY INSTRUCTIONS” and this “USER'S MANUAL” thoroughly to ensure correct usage through understanding. After reading, store this instruction manual in a safe place for future reference.
Page 32: Multifunctional Settings
MULTIFUNCTIONAL SETTINGS This device has 6 separate menus: MAIN, PICTURE 1, PICTURE 2, INPUT, SCREEN, OPTION. Each of these menus is operated using the same methods. The basic operations of these menus are as follows. Menu screen display : Press the MENU button. Menu selection : Choose a menu name using the button, and press the...
Page 33: Picture1 Menu
MENU PICTURE 1 Menu MAIN COLOR BAL R PICTURE-1 COLOR BAL B PICTURE-2 SHARPNESS INPUT COLOR With the PICTURE 1 menu, the five items shown in the Table SCREEN TINT OPTION below can be performed. Perform each operation in accordance with the instructions in the : SELECT Example : PICTURE1 Menu Table.
Page 34: Input Menu
MULTIFUNCTIONAL SETTINGS (continued) MENU INPUT Menu MAIN AUTO EXECUTE PICTURE-1 VIDEO PICTURE-2 SYNC ON G INPUT With the INPUT menu, the four items shown in the Table below can be SCREEN OPTION performed. With inputting of RGB IN 1 and RGB IN 2 signals, the horizontal and vertical frequencies of the signals will be displayed on the : SELECT Example : INPUT Menu...
Page 35 MENU SCREEN Menu MAIN BLANK MyScreen PICTURE-1 START UP ORIGNAL PICTURE-2 MyScreen INPUT MyScreen Size With the SCREEN menu, the five items shown in the Table below can be performed. SCREEN MyScreen Lock OPTION Please perform each operation in accordance with the instructions in the Table. : SELECT Example : SCREEN Menu SCREEN Menu...
Page 36: Option Menu
MULTIFUNCTIONAL SETTINGS (continued) MENU OPTION Menu MAIN VOLUME PICTURE-1 AUTO OFF PICTURE-2 WHISPER INPUT LAMP TIME With the OPTION menu, the five items shown in the Table below SCREEN FILTER TIME OPTION can be performed. Please perform each operation in accordance with the instructions : SELECT Example : OPTION Menu in the Table.
Page 37: What To Do When You Think A Machine Defect Has Occurred
WHAT TO DO WHEN YOU THINK A MACHINE DEFECT HAS OCCURRED Related Messages When the unit's power is ON, messages such as those shown below may be displayed. When any such message is displayed on the screen, please respond as described below. Message Description CHANGE THE LAMP...
Page 38: Regarding The Indicator Lamps
Regarding the Indicator Lamps Lighting and flashing of the POWER indicator, the LAMP indicator, and the TEMP indicator have the meanings as described in the Table below. Please respond in accordance with the instructions within the Table. POWER LAMP TEMP Description indicator indicator...
Page 39: Phenomena That May Easily Be Mistaken For Machine Defects
WHAT TO DO WHEN YOU THINK A MACHINE DEFECT HAS OCCURRED (continued) Phenomena That May Easily Be Mistaken for Machine Defects Before requesting repair, check in accordance with the following chart. If the situation cannot be corrected, then contact your dealer. Reference Phenomenon Cases not involving a machine defect...
Page 40: Specifications
Panel size 1.8 cm (0.7 type) Liquid Drive system TFT active matrix crystal ED-S3170A 480,000 pixels (800 horizontal x600 vertical) panel Pixels ED-X3270A 786,432 pixels (1024 horizontal x 768 vertical) Lens Zoom lens F=1.7 ~ 1.9 f=21.7 ~ 26.1 mm...
Page 41: Warranty And After-Service
WARRANTY AND AFTER-SERVICE If a problem occurs with the equipment, first refer to the “WHAT TO DO WHEN YOU THINK A MACHINE DEFECT HAS OCCURRED” section and run through the suggested checks. If this does not resolve the problem contact your dealer or service company. They will tell you what warranty condition is applied.
Page 42 TECHNICAL TECHNICAL SIGNAL CONNECTOR PIN ASSIGNMENT RGB IN [1]/[2] S-VIDEO RGB OUT D-sub 15-pin Shrink Mini Din 4-pin Mini Din 4-pin Pin No Signal Pin No Signal Pin No Signal Video input Red Color: Video input Green Ground 0.286Vp-p (NTSC, burst signal), Video input Blue 75Ω...
Page 43: Example Of Computer Signal
EXAMPLE OF COMPUTER SIGNAL Display mode Resolution fH (kHz) fV (Hz) Rating Signal mode H × × V ED-S3170A ED-X3270A 720 × 400 37.9 85.0 VESA TEXT Zoom in Zoom in 640 × 480 31.5 59.9 VESA VGA (60Hz) Zoom in Zoom in 640 ×...
Page 44 INITIAL SET SIGNALS The following signals are used for the initial settings. The signal timing of some computer models may be different. In such case, refer to adjust the V.POSIT and H.POSIT of the menu. Back porch b Front porch d Back porch b Front porch d Display interval c...
Page 45: Serial Mouse
CONNECTION TO THE MOUSE CONTROL Projector Computer ADB Mouse ( POWER ON ) DATA Mouse jack CONTROL Terminal Mini DIN 4-pin D-sub 15-pin shrink jack ! " # % & ' ! " # Serial Mouse Projector Computer CONTROL Terminal Mouse jack...
Page 46 RS-232C COMMUNICATION (1) Turn off the projector and computer power supplies and connect with the RS-232C cable. (2) Turn on the computer power supply and after the computer has started up, turn on the projector power supply. Projector Computer RS-232C jack D-sub 9-pin Control jack D-sub 15-pin shrink jack...
Page 47 RS-232C COMMUNICATION (continued) Requesting projector status (Get command) (1) Send the request code Header + Command data (‘02H’+‘00H’+ type (2 bytes) +‘00H’+‘00H’) from the computer to the projector. (2) The projector returns the response code ‘1DH’+ data (2 bytes) to the computer. Changing the projector settings (Set command) (1) Send the setting code Header + Command data (‘01H’+‘00H’+ type (2 bytes) + setting code (2 bytes)) from the computer to the projector.
Page 48: Command Data Chart
Command data chart Command data Names Operation type Header Action Type Setting code Blue BE EF 06 00 CB D3 01 00 00 30 03 00 White BE EF 06 00 6B D0 01 00 00 30 05 00 Black BE EF 06 00 9B D0...
Page 49 Command data chart (continued) Command data Names Operation type Header Action Type Setting code H.Position Reset Execute BE EF 06 00 IC D3 06 00 03 70 00 00 H.Size Reset Execute BE EF 06 00 68 D2 06 00 04 70 00 00 Color Balance...
Page 50 Command data Names Operation type Header Action Type Setting code BE EF 06 00 FD D3 02 00 04 20 00 00 Contrast Increment BE EF 06 00 9B D3 04 00 04 20 00 00 Decrement BE EF 06 00 4A D2 05 00 04 20...
Page 51 Command data chart (continued) Command data Names Operation type Header Action Type Setting code BE EF 06 00 49 73 02 00 03 22 00 00 Tint Increment BE EF 06 00 2F 73 04 00 03 22 00 00 Decrement BE EF 06 00...
Page 52: Regulatory Notices
REGULATORY NOTICES REGULATORY NOTICES FCC Statement Warning WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 53 6740 Campobello Road, Mississauga, Ontario Spain L5N2L8, Canada Tel: +34-3-330-8652 Fax: +34-3-339-7839 Tel: +1-905-821-4545 Fax: +1-905-821-1101 Hitachi Home Electronics Asia, (S) Pte Ltd. Hitachi Home Electronics (Europe), Ltd. 16 Collyer Quay #20-00 Hitachi Tower Singapore Dukes Meadow, Millboard Road, Bourne End , 049318, Singapore...
