Clevo W860CU User Manual

Table of Contents

Quick Links

V09.1.20

Table of Contents

Summary of Contents for Clevo W860CU

Page 1 V09.1.20...
Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4: Fcc Statement
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 5: Fcc Rf Radiation Exposure Statement
Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Page 6: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 7: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 9: Power Safety
Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, uninterrupted power supply. If you are unsure of your local power specifications, Power Safety Warning consult your service representative or local power company.
Page 10: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 11: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 12: Travel Considerations
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 13 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 14 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 15: Lcd Screen Care
Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 16 Preface...
Page 17: Table Of Contents
Preface Contents Notice .................I Hot Key Buttons & Keyboard ........1-10 FCC Statement ..............II Keyboard ..............1-11 FCC RF Radiation Exposure Statement: ......III Function/Hot Key Indicators ........1-12 Instructions for Care and Operation ........ V System Map: Left View ..........1-13 Power Safety ..............VII System Map: Right View ..........1-15 Battery Precautions ............
Page 18 Preface TouchPad and Buttons/Mouse ........2-8 Battery Life ..............3-12 Gesture Configuration ...........2-9 New Battery ..............3-12 Audio Features .............2-10 Recharging the Battery with the AC/DC Adapter ..3-12 Audio Setup for LCD Monitors/ Proper handling of the Battery Pack ......3-13 TVs with HDMI Input ..........2-11 Battery FAQ ..............3-14 Adding a Printer ............2-12 Drivers &...
Page 19 Preface Optional Drivers ............4-8 Advanced Menu .............5-8 PC Camera Module ............4-8 Advanced Chipset Control ..........5-8 Wireless LAN Module ...........4-8 SATA Mode Selection (Advanced Menu) .....5-9 Fingerprint Reader Module ..........4-8 Legacy USB Support (Advanced Menu) .......5-9 3.75G/HSPA Module (Model A Only) ......4-8 Boot-time Diagnostic Screen (Advanced Menu) ...5-9 TV Tuner Module (Model B Only) .......4-9 Legacy OS Boot (Advanced Menu) .......5-9...
Page 20 Preface Bluetooth Module ............7-2 Mobile Partner .............7-52 Bluetooth Configuration in Windows Vista ....7-3 Mobile Partner Application Installation ......7-52 PC Camera Module ............7-7 Mobile Partner Application .........7-53 PC Camera Driver Installation ........7-8 Profile Management .............7-53 Wireless LAN Module ..........7-16 TV Tuner Module ............7-57 Intel®...
Page 21 Preface Viruses ................8-4 Storage ................C-3 Upgrading and Adding New Hardware/Software ..8-5 Audio ................C-3 Problems and Possible Solutions ........8-7 Keyboard & Pointing Device ........C-3 Screen Resolution Error ..........8-13 Interface ................ C-3 Card Reader ..............C-3 Interface (Ports & Jacks) Slots ................
Page 22 Preface Attaching Other Displays ..........B-9 3rd Party 802.11b/g/n Driver Installation ....D-43 The Power Sources ............. D-11 Connecting to a Wireless Network ......D-44 AC/DC Adapter ............D-11 Windows Mobility Center ........... D-47 Battery................D-11 Fingerprint Reader Module (Win7) ......D-48 Turning On the Computer ...........
Page 23: Quick Start Guide
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 24: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Page 25: Not Included
Quick Start Guide Not Included Operating Systems (e.g. Windows Vista/Windows 7) and applications (e.g. word processing, spreadsheet and da- tabase programs) have their own manuals, so please consult the appropriate manuals. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...
Page 26: System Startup
Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Page 27: System Software
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, TV Tuner Module you will find the following operating systems are supported. Support Note that the TV Tuner Operating System &...
Page 28: Model Differences
Quick Start Guide Model Differences This notebook series includes two different model types that differ as indicated in the table below (see Appendix Feature Model A Model B 15.6" HD (1366 * 768) / HD+ (1600 * 900) / FHD 17.3 "...
Page 29: System Map: Front View - Model A
Quick Start Guide System Map: Front View - Model A Figure 1 - 2 Front View (Model A Computers) Wireless Device Built-In PC Camera Operation Aboard Aircraft (Optional) The use of any portable electronic trans- Power Button mission devices aboard aircraft is usually Speakers prohibited.
Page 30: System Map: Front View - Model B
Quick Start Guide System Map: Front View - Model B Figure 1 - 3 Front View (Model B Computers) Wireless Device Built-In PC Camera Operation Aboard Aircraft (Optional) The use of any portable electronic LED Status transmission devices aboard air- Indicators craft is usually prohibited.
Page 31: Led Indicators
Quick Start Guide LED Indicators A further two LED power indicators on the front right of the computer provide information on the comput- The LED indicators on the LED strip just below the er’s power status. LCD panel on the computer display helpful informa- tion about the current status of the computer when il- Icon Color...
Page 32: Hot Key Buttons & Keyboard
Quick Start Guide Hot Key Buttons & Keyboard The LED hot key buttons give instant access to the default Internet browser and e- Other Keyboards mail program, and allow you to toggle Silent Mode with one quick button press. If your keyboard is damaged or you just Hot Key Function...
Page 33: Keyboard
Quick Start Guide Keyboard The keyboard has a numerical keypad on the right for easy numeric data input, and features function keys to allow you to change operational features instantly. See Table 1 - 6, on page 1 - 12 for full function key combi- nation details.
Page 34: Function/Hot Key Indicators
Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators are available when the hot key utility is installed. Fn Keys Function Fn Keys...
Page 35: System Map: Left View
Quick Start Guide System Map: Left View Figure 1 - 5 Left View Model A RJ-11 Modem Jack USB 2.0 Port Mini-IEEE 1394 Port 7-in-1 Card Reader Optical Device Model B Drive Bay (for DVD Device) Cable (CATV) Antenna Jack *Enabled with Optional TV Tuner Only 7-in-1 Card Reader...
Page 36 Quick Start Guide Changing DVD Regional Codes Disk Eject Warning Go to the Control Panel and double-click Device Don’t try to eject a CD/DVD while the system is ac- Manager (Hardware and Sound), then click the + cessing it. This may cause the system to “crash”. Stop next to DVD/CD-ROM drives.
Page 37: System Map: Right View
Quick Start Guide System Map: Right View Figure 1 - 6 Right View Model A Headphone-Out Jack Microphone-In Jack Line-In Jack S/PDIF-Out Jack USB 2.0 Port Model B ExpressCard Slot (see page e-SATA Port DVI-Out Port Security Lock Slot (Model B Only) 10.
Page 38: System Map: Rear View
Quick Start Guide System Map: Rear View Figure 1 - 7 Rear View Model A Vent/Fan Intake/ Outlet Security Lock Slot (Model A Model B Only) HDMI-Out Port DC-In Jack 2 * USB Ports RJ-45 LAN Jack Rear Cover (Model B Only) HDMI-Out Port Overheating Note that the HDMI-Out Port supports video and audio signals to attached external dis-...
Page 39: System Map: Bottom View - Model A
Quick Start Guide System Map: Bottom View - Model A Figure 1 - 8 Bottom View (Model A Computers) Battery Information Battery Always completely dis- charge, then fully charge, a Component Bay new battery before using it. Cover Completely discharge and Vent/Fan Intake/ charge the battery at least Outlet...
Page 40: System Map: Bottom View - Model B
Quick Start Guide System Map: Bottom View - Model B Figure 1 - 9 Bottom View (Model B Computers) Battery Information Battery Always completely dis- Component Bay charge, then fully charge, a new battery before using it. Cover Completely discharge and Vent/Fan Intake/ charge the battery at least Outlet...
Page 41: Windows Vista Start Menu & Control Panel
Quick Start Guide Windows Vista Start Menu & Control Panel Most of the control panels, utilities and programs within Windows Vista (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 42: Video Features
Quick Start Guide Video Features You can configure display options, from the Display Settings control panel in Windows as long as the appro- priate video driver is installed. For more detailed video information see “NVIDIA Video Driver Controls” on page B - 1.To access Display Settings in Windows: 1.
Page 43: Display Devices & Options
Quick Start Guide Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display or TV (connected to the DVI-Out port/HDMI-Out port) as your display device. Figure 1 - 11 - Display Settings & NVIDIA Control Panel NVIDIA Display Mode Description Single...
Page 44: Power Options
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 18) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
Page 45: Features & Components
Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical (CD/DVD) Device • 7-in-1 Card Reader • ExpressCard Slot •...
Page 46: Hard Disk Drive
Features & Components Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives (see “Storage” on page C - 3) with a height of 9.5 mm.
Page 47: Optical (Cd/Dvd) Device
Features & Components Optical (CD/DVD) Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the module you purchased (see “Storage” on page C - 3). The Adjustment optical device is usually labeled “Drive D:”...
Page 48: Handling Cds Or Dvds
Features & Components Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.
Page 49: Dvd Regional Codes
Features & Components DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...
Page 50: 7-In-1 Card Reader
Features & Components 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 51: Expresscard Slot
Features & Components ExpressCard Slot The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you install the Card Reader driver (see “CardReader”...
Page 52: Touchpad And Buttons/Mouse
Features & Components TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse. If you are using an ex- ternal mouse your op- Once you have installed the TouchPad driver (see...
Page 53: Gesture Configuration
Features & Components Gesture Configuration The Gesture Configuration control allows you to configure specific gesture func- tion settings on the surface of the TouchPad for various applications. You can configure Gestures from the Finger-sensing Pad tab in Mouse Properties: Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Mouse (Hardware and Sound).
Page 54: Audio Features
Features & Components Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ Adjustment control panel (right-click the taskbar icon bring up an audio menu).
Page 55: Audio Setup For Lcd Monitors/Tvs With Hdmi Input
Features & Components Audio Setup for LCD Monitors/TVs with HDMI Input Some LCD monitors/TVs support HDMI input, but DO NOT have built-in digital audio decoders. Where this is the case, when playing DVDs in Windows Media Player/CyberLink Power DVD etc., a background noise can occur. If this situation does arise then please follow the instructions below.
Page 56: Adding A Printer
Features & Components Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the print- er attach the parallel ca- ble to the printer.
Page 57: Power Management
Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
Page 58: The Power Sources
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. Silent Mode AC/DC Adapter Use the key to tog- gle Silent Mode to re- Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ duce fan noise and save DC adapter will damage the computer and its components.
Page 59: Turning On The Computer
Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shut Down er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Sleep/Hibernate hot- ways shut your comput- er down by choosing the key button when it is pressed for less than 4 seconds (pressing and holding the power...
Page 60: Power Plans
Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 61 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance for maximum performance when the computer is pow- ered from an AC power source.
Page 62: Power-Saving States
Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where Power Button you left off. Sleep is the default power-saving state in Windows Vista. The Power Button Earlier versions of Windows used Stand By and Hibernate as system power-saving in the Start Menu (in Classic View use the states.
Page 63: Hibernate
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a Hibernate Mode In power failure occurs the system can restore your work from the hard disk; if a power Windows Vista SP1 failure occurs when work is saved only to memory, then the work will be lost.
Page 64: Configuring The Power Buttons
Power Management Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Protection It is recommended that you enable a password on wake up in order to protect your data.
Page 65: Resuming Operation
Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status To Resume Icon Color send the computer to...
Page 66: Battery Information
Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power When the battery is criti- Your computer’s battery power is dependent upon many factors, including the pro- cally low, immediately grams you are running, and peripheral devices attached.
Page 67: Conserving Battery Power
Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 68: Battery Life
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.
Page 69: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.
Page 70: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 71 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 8 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 72 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 73: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some The Device Drivers & Utilities + User’s Manual disc of the computer’s subsystems. The system takes ad- contains the drivers and utilities necessary for the vantage of some newer hardware components for proper operation of the computer.
Page 74: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc and click Install Drivers/Option Drivers (button).
Page 75: Manual Driver Installation
Drivers & Utilities Driver - Windows Vista with Service Pack 2 Page Driver - Windows Vista with Service Pack 2 Page Chipset Page 4 - 6 PC Camera Module Page 7 - 8 Video Page 4 - 6 Wireless LAN Module Page 7 - 17 Modem Page 4 - 6...
Page 76: Updating/Reinstalling Individual Drivers
Drivers & Utilities Windows Update Updating/Reinstalling Individual Drivers After installing all the drivers make sure you enable If you wish to update/reinstall individual drivers it Windows Update in order to get all the latest security may be necessary to uninstall the original driver.To do updates etc.
Page 77: User Account Control (Win Vista)
Drivers & Utilities User Account Control (Win Vista) New Hardware Found If a User Account Control prompt appears as part of If you see the message “New Hardware Found” dur- the driver installation procedure, click Continue or ing the installation procedure (other than when out- Allow, and follow the installation procedure as direct- lined in the driver install procedure), click Cancel to close the window, and follow the installation proce-...
Page 78: Driver Installation Procedure
Drivers & Utilities Driver Installation Procedure Insert the Device Drivers & Utilities + User’s Manual 1. Click 4.Install LAN Driver > Yes. disc and click Install Drivers (button). 2. Click Next > Install. 3. Click Finish. Chipset 4. The network settings can now be configured. 1.
Page 79: Hot Key
Drivers & Utilities Hot Key 1. Click 8.Install Hotkey Utility > Yes. 2. Click Next > Install. Windows Update 3. Click Finish > Finish to restart the computer. After installing all the drivers make sure you enable Win- dows Update in order to get all the latest security up- Audio dates etc.
Page 80: Optional Drivers
Drivers & Utilities Optional Drivers Bluetooth Module Note: The operating system is the default setting for See the pages indicated for the driver installation pro- Bluetooth control in Windows Vista, and does not re- cedures for any modules included in your purchase op- quire a driver.
Page 81: Tv Tuner Module (Model B Only)
Drivers & Utilities TV Tuner Module (Model B Only) See the introduction in “TV Tuner Module” on page 7 57, and check the installation procedure for the Con- sumer Infrared (CIR) driver. RAID and AHCI Configuration (RAID for Model B Only) See the configuration instructions in “Setting Up SATA RAID or AHCI Modes”...
Page 82 Drivers & Utilities 4 - 10...
Page 83: Bios Utilities
BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Screens Note that BIOS This chapter gives a brief introduction to the computer’s built-in software: screens pictured on the following pages are in- Diagnostics: The POST (Power-On Self Test) tended for guidance in setting up your system’s BIOS.
Page 84: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a BIOS Settings POST, including a quick test of the on-board RAM (memory). Warning As the POST proceeds, the computer will tell you if there is anything wrong. If there Incorrect settings can is a problem that prevents the system from booting, it will display a system summary cause your system to...
Page 85: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
Page 86: The Setup Program
BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and manage ba- sic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen on page 5 - 2 is usually present for a few seconds...
Page 87: Setup Screens
BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with menu headings. When you select a Setup menus heading, a new screen appears. Scroll through the features listed on each screen to shown in this section are make changes to Setup.
Page 88: Main Menu
BIOS Utilities Main Menu Figure 5 - 1 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.
Page 89: Sata Port 1/2/3/4/5 (Main Menu)
BIOS Utilities SATA Port 1/2/3/4/5 (Main Menu) Pressing Enter opens the sub-menu to show the configuration of an HDD/optical de- vice on the computer’s SATA Port 1/2/3/4/5. Use the Auto (Type:) setting to have the items configured automatically for you. System/Extended Memory (Main Menu) This item contains information on the system memory, and is not user configurable.
Page 90: Advanced Menu
BIOS Utilities Advanced Menu Advanced Chipset Control The sub-menu here allows you to enable/disable Extreme Edition control, if appli- cable to your system. 5 - 8 Advanced Menu...
Page 91: Sata Mode Selection (Advanced Menu)
BIOS Utilities SATA Mode Selection (Advanced Menu) You may enable/disable SATA RAID or AHCI mode for your hard disks, however you should only enable/disable RAID or AHCI BEFORE installing an operat- SATA Mode ing system, and after you have backed up all necessary files and data (see sidebar). Selection Legacy USB Support (Advanced Menu) If you have installed the...
Page 92: Security Menu
BIOS Utilities Security Menu Security Menu changes make here affect the access to the Setup utility itself, and also access to your ma- chine as it boots up af- ter you turn it on. These settings do not affect your machine or network passwords which will be set in...
Page 93: Password On Boot (Security Menu)
BIOS Utilities choose to set a Password on Boot (see below). Many menu items in the Phoenix- BIOS Setup Utility cannot be modified in user mode. You can only set the user password after you have set the supervisor password. Password Warning Password on boot (Security Menu) If you set a boot pass-...
Page 94: Boot Menu
BIOS Utilities Boot Menu Figure 5 - 4 Boot Menu When you turn the computer on it will look for an operating system (e.g. Windows Vista) from the devices listed in this menu, and in this priority order. If it cannot find the operating system on that device, it will try to load it from the next device in the order specified in the Boot priority order.
Page 95: Exit Menu
BIOS Utilities Exit Menu Figure 5 - 5 Exit Menu Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Set- up defaults that will return the Setup to its original state, and erase any previous changes you have made in a previous session.
Page 96 BIOS Utilities 5 - 14...
Page 97: Upgrading The Computer
Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- lined to make the desired upgrades. If you have any trouble or problems you can con- Warranty Warning tact your service representative for further help. Before you begin you will need: Please check with your service representative...
Page 98: When Not To Upgrade
Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...
Page 99: Removing The Battery
Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Turn the computer off, and turn it over. Please check with your Slide the latch in the direction of the arrow.
Page 100: Upgrading The Hard Disk Drive(S)
Upgrading The Computer Upgrading the Hard Disk Drive(s) The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard HDD System disk drives with a height of 9.5mm (h) (see “Storage” on page C - 3). Follow your Warning operating system’s installation instructions, and install all necessary drivers and util- ities (see...
Page 101 Upgrading The Computer Lift the hard disk assembly out of the computer in the direction of arrow Remove the screws and the cover bracket Reverse the process to install a new hard disk drive (do not forget to replace all the screws and covers) Figure 6 - 3 HDD Assembly...
Page 102 Upgrading The Computer Removing the Hard Disk in the Secondary HDD Bay (Model B Computers Only) If you want to configure your hard disks in a RAID configuration then install iden- tical drives in the primary (see page 4) and secondary hard disk bays as per the RAID Hard Disks instructions here.
Page 103 Upgrading The Computer Slide the hard disk assembly in the direction of the arrow Lift the hard disk out of the compartment. Remove screws to separate the hard disk from the brackets. RAID Hard Disks Reverse the process to install a new hard disk drive (do not forget to replace all the screws and covers).
Page 104: Upgrading The Optical (Cd/Dvd) Device
Upgrading The Computer Upgrading the Optical (CD/DVD) Device Turn off the computer, and turn it over and remove the battery. Locate the component bay cover and remove screws (Model A) or (Model B). Carefully remove the cover Figure 6 - 6 Component Bay Model A Model B...
Page 105 Upgrading The Computer Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Reverse the process to install the new device. Figure 6 - 7 Removing the Optical Device Upgrading the Optical (CD/DVD) Device 6 - 9...
Page 106: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 204 pin Small Outline Dual In-line (SO- DIMM) DDRIII (DDR3) type memory modules (see “Memory” on page C - 2 details of supported module types). Turn off the computer, and turn it over and remove the battery.
Page 107 Upgrading The Computer Carefully remove the cover The RAM is located at point Contact Warning Be careful not to touch the metal pins on the Model A Model B RAM module’s connect- edge. Even cleanest hands have oils which can attract particles, and degrade module’s perfor-...
Page 108 Upgrading The Computer Gently pull the two release latches on the sides of the memory socket in the direction indicated by the arrows ( & Figure 6 - The RAM module will pop-up, and you can remove it. Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30°...
Page 109: Modules & Options
Modules & Options Chapter 7: Modules & Options Overview Wireless Device Operation Aboard This chapter contains information on the following modules, which may come with Aircraft your computer, depending on the configuration purchased. If you are unsure please The use of any portable contact your service representative.
Page 110: Bluetooth Module
Modules & Options Bluetooth Module The operating system’s Bluetooth Devices control panel is used to configure the Wireless Device Bluetooth settings in Windows Vista, and therefore does not require a driver. Use Operation Aboard the Fn + F12 key combination (see “Function/Hot Key Indicators”...
Page 111: Bluetooth Configuration In Windows Vista
Modules & Options Bluetooth Configuration in Windows Vista Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Taskbar Make the device discoverable (to do this check your device documentation). Icon To Turn the Bluetooth Module On If you cannot see the...
Page 112 Modules & Options To Add a Bluetooth Device Access the Bluetooth Devices control panel and click Bluetooth Settings. Click Options (tab), and make sure that Allow Bluetooth devices to connect to Pairing Options this computer check box (Connections) has a tick inside it, and click OK. Click Add Wireless Device in the Bluetooth Devices control panel.
Page 113 Modules & Options Enter the code into your Bluetooth enabled device and follow any on-screen instructions to complete the pairing. Figure 7 - 3 Pairing Codes Pairing Code Example The example outlined here shows a connection to a mobile device. Other devices e.g. computers, may have a slightly different connection proce- dure, and may require you to confirm a pairing code is correct on both devices.
Page 114 Modules & Options To Change Settings for the Bluetooth Device Access the Bluetooth Devices control panel. Click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click General, type a new name and click OK). •...
Page 115: Table
Modules & Options PC Camera Module If you have included a PC Camera module in your purchase option, make sure that Latest PC Camera the PC Camera module is on before installing the driver. Use the Fn + F10 key com- Driver Information bination (see “Function/Hot Key Indicators”...
Page 116 Modules & Options PC Camera Driver Installation 1. Make sure the module is powered on, then insert the Device Drivers & Util- ities + User’s Manual disc into the CD/DVD drive. PC Camera Screen 2. Click Option Drivers (button). Refresh 3.
Page 117: Pc Camera Module
Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Double-click Sound (Hardware and Sound).
Page 118 Modules & Options Figure 7 - 6 Audio Setup for PC Camera Right-click 7 - 10 PC Camera Module...
Page 119 Modules & Options Camera Application The WebCam application is a video viewer for general purpose video viewing and testing, and for capturing video files to .avi format. Pre-Allocating File Size/Space Run the camera application from the desktop shortcut (it is recommended that you set the capture file before the capture process - see “Set Capture File”...
Page 120 Modules & Options Set Capture File Prior to capturing video files you may select the Set Capture File... option in the File menu, and set the file name and location before capture (this will help avoid ac- cidentally overwriting files). Set the name and location then click Open, then set the "Capture file size:"...
Page 121 Modules & Options Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
Page 122 Modules & Options Eliminating Screen Flicker If you find that the video screen in the camera program is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the camera program from the desktop shortcut. Go to Options and scroll down to select Video Capture Filter..
Page 123 Modules & Options Zoom The WebCam program allows you to zoom the camera in and out (note the zoom function is not available in all camera model applications). Run the camera application from the desktop shortcut. Go to Zoom and select Zoom Out/Zoom In. Figure 7 - 8 Zoom/Setting Snapshot Folder...
Page 124: 7 - 16 Wireless Lan Module
Modules & Options Wireless LAN Module If you have included an Intel® Wi-Fi Link 5300 Series or 3rd Party 802.11b/g/n Wireless Device WLAN module in your purchase option, make sure that the Wireless LAN module is Operation Aboard on before installing the driver. Aircraft Use the Fn + F11 key combination (see “Function/Hot Key Indicators”...
Page 125: Intel® Wi-Fi Link Series Driver Installation
Modules & Options Intel® Wi-Fi Link Series Driver Installation If you see the message “Found New Hardware” click Cancel to close the window. 1. Make sure the module is powered on, then insert the Device Drivers & Util- Intel(R) PROSet/ ities + User’s Manual disc into the CD/DVD drive.
Page 126: Connecting To A Wireless Network
Modules & Options Connecting to a Wireless Network Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then click Connect to a network (or right- click the icon , and then click Connect to a network). Figure 7 - 9 Taskbar Menus Click icon...
Page 127 Modules & Options Click a network, and then click Connect. If you do not see a network you want to connect to, click Set up a connection or network (a list of options will appear allowing manual searching, and creating a new network).
Page 128 Modules & Options To disconnect from the wireless network you can click the taskbar wireless icon and then select Connect or disconnect to access the network menu, and click Disconnect (or right-click the icon , and then click Disconnect from). Security Enabled Networks You should try to make...
Page 129: Intel My Wifi Installation & Configuration
Modules & Options Intel My WiFi Installation & Configuration ® Intel® My WiFi Technology uses your WLAN module to allow you to connect up to eight other WiFi enabled devices (e.g. digital cameras, other computers, cell Intel® My WiFi Help phones, handheld devices etc.) to your computer (similar to Bluetooth), while still To get help on Intel®...
Page 130: Intel® Wi-Fi Link Series My Wifi Driver Installation
Modules & Options Intel® Wi-Fi Link Series My WiFi Driver Installation If you see the message “Found New Hardware” click Cancel to close the window. 1. Make sure the module is powered on, then insert the Device Drivers & Util- Intel(R) PROSet/ ities + User’s Manual disc into the CD/DVD drive.
Page 131 Modules & Options Intel® My WiFi Configuration You can configure the My WiFi settings as follows. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by clicking the taskbar icon Click Enable (on the first run of the program there will be no connected...
Page 132 Modules & Options Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Network and Sharing Center (Network and Internet). Click Manage Network Connections. Click Manage Network Connections Figure 7 - 16 Network and Sharing Center Right-click Intel My WiFi STA (Station) in Network Connections and select Properties.
Page 133 Modules & Options Click Sharing (tab) and select “Allow other network users to connect through this computer’s Internet connection”. Select Intel My WiFi PAN under Home Networking Connection. Click OK. Click “Allow other network users to connect through this computer’s Internet connection”.
Page 134 Modules & Options 10. A message will appear to inform you that the LAN adapter will be set to use the IP address 192.168.0.1. Figure 7 - 19 11. Click Yes to enable Internet Connection Sharing. IP Address Warning IP Addresses The Intel®...
Page 135 Modules & Options 14. Click Profiles, click Intel Wireless PAN and click Edit. Figure 7 - 21 IP Address Warning 15. You can change the Profile Name and Network Name to your personal preferences in General (tab). Profile and Network Names The Profile Name is the name as Figure 7 - 22 displayed on your computer in the...
Page 136 Modules & Options 16. Click Security (tab). 17. Change the Security Type to WEP and the Encryption Type to 64bit. 18. Enter a password (5 characters long) in the Passphrase box. 19. Click OK. Figure 7 - 23 Intel® My WiFi Profile Settings - Security 7 - 28 Wireless LAN Module...
Page 137 Modules & Options 20. Click Sharing (tab). 21. Make sure Filter Network Traffic and DHCP and DNS Server are Disabled. 22. Click OK. Set Filter Network Traffic & DHCP and DNS Servers Figure 7 - 24 to Disabled. Intel® My WiFi Profile Settings - Sharing Wireless LAN Module 7 - 29...
Page 138 Modules & Options 23. Click Advanced (tab). 24. Make sure the Default Channel is set to Channel 1, 6 or 11. 25. Click OK. Figure 7 - 25 Intel® My WiFi Profile Settings - Advanced 7 - 30 Wireless LAN Module...
Page 139 Modules & Options 26. Double-click Intel My WiFi PAN (Personal Area Network) in Network Connections. 27. Click Details to display the Network Connection Details. Figure 7 - 26 Intel My WiFi PAN Network Connection Details (Network Connections) Wireless LAN Module 7 - 31...
Page 140 Modules & Options 28. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by clicking the taskbar icon 29. To add a new device follow the instructions in the devices’ user guide for connecting to a WiFi network.
Page 141: Windows Mobility Center
Modules & Options Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 142: Fingerprint Reader Module
Modules & Options Fingerprint Reader Module The optional fingerprint reader provides a high level of security for your comput- Password Warning Help & Manual er. A further level of security and control is provided in the BIOS (see “Security Menu” on page 5 - 11).
Page 143: User Enrollment
Modules & Options User Enrollment Click Start > Programs/All Programs > Protector Suite > Control Center, or double click the taskbar icon (click Initialize). Fingerprint On the first run of the program you will be asked to click the Accept button to Enrollment accept the license.
Page 144 Modules & Options Click the button above any of the fingers to begin the enrollment process for that finger. Swipe the finger until the progress bar reaches 100% to enroll that finger. Fingerprint Repeat the process for all the fingers you wish to enroll (see sidebar), and then Enrollment click Save and Continue.
Page 145 Modules & Options 11. Right-click the taskbar icon and select Start Control Center (and then swipe a finger) to allow you to Edit Fingerprints, register Applications, edit Settings and access the Help menu etc. You can also run the Control Center etc. from the Protector Suite item in the Programs/All Programs menu 12.
Page 146: Fingerprint Control Center Features
Modules & Options Fingerprint Control Center Features Application Launcher Help The Application Launcher allows you to register applications to be launched when assigned to a particular finger. Simply copy the application icon on to one of the reg- For more information on these and other features istered fingers and ten click OK to close the application window.
Page 147: 3.75G/Hspa Module
Modules & Options 3.75G/HSPA Module (Optional for Model A Computers Only) If you have included an optional 3.75G/HSPA (High Speed Packet Access) module 3.75G/HSPA Module Options (see “Communication” on page C - 4 for specification details) in your purchase op- tion, you will have the appropriate application (HSPA Modem Interface or Mobile There are two optional Partner) provided for your module.
Page 148 Modules & Options Before installing the application, make sure that the 3.75G/HSPA module is ON (installing the driver with the module off will not allow the software to detect the module hardware correctly). Use the Fn + key combination (see “Function/Hot 3.75G/HSPA Key Indicators”...
Page 149: Usim Card Installation
Modules & Options USIM Card Installation Turn off the computer, and turn it over and remove the battery (see “Removing the Battery” on page 6 - Power Safety The SIMLOCK is located in the compartment under the battery. Warning Remove screw from the SIMLOCK cover, and remove the cover.
Page 150 Modules & Options Slide the SIMLOCK towards the hinge (in the direction of the arrow illustrated in Figure 7 - 33) in order to release the lock and lift it up. Insert the USIM card as illustrated in (Figure 7 - 34) and close the SIMLOCK.
Page 151: Hspa Modem Interface
Modules & Options HSPA Modem Interface With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the HSPA Modem Interface. The HSPA Modem In- Wireless Device terface allows you to directly access your HSPA internet service from the computer. Operation Aboard Aircraft HSPA Modem Interface Installation...
Page 152: Hspa Modem Interface
Modules & Options HSPA Modem Interface The connection information is stored on the USIM card supplied by the service pro- vider. HSPA Modem Help Power on the 3.75G/HSPA module using the Fn + key combination. To get help on 3.75G/ Access the HSPA Modem Interface from the Start menu (Start >...
Page 153 Modules & Options Click Connect to connect to your service provider. Figure 7 - 36 Connecting to Network The message “Network is connected” will be displayed when the network connection is successful. Figure 7 - 37 Network is Connected You can then access the internet, download e-mail etc. as per any internet connection.
Page 154: Adding A Profile
Modules & Options While you are connected the upper right corner of the HSPA Modem interface will display the upload and download rates, and the taskbar icon will display the Figure 7 - 38 connection speed. Uploading/ Downloading Rates and Speed 10.
Page 155 Modules & Options Click Add (button) and input any Network Settings required by your service provider. Click OK to save the profile. Figure 7 - 40 Network Settings & Profiles You can Edit or Delete profiles from the Profiles tab. To use a profile click to select it, and then click Apply (button) and the settings will be transferred to Connection Manager.
Page 156: Contacts
Modules & Options Contacts Access the HSPA Modem Interface from the Start menu (Start > Programs/All Programs > HSPA Modem > HSPA Modem), or by clicking the desktop icon. Click Contacts (button). Figure 7 - 41 Network Settings & Profiles Click Refresh (button) to download the contacts from the USIM card to the computer.
Page 157: Messages
Modules & Options Messages Access the HSPA Modem Interface from the Start menu (Start > Programs/All Programs > HSPA Modem > HSPA Modem), or by clicking the desktop icon. SMS Service Click Messages (button). In addition to standard in- ternet services you may also send and receive SMS text messages us- ing the HSPA Modem In-...
Page 158: Settings
Modules & Options Click to select a contact from the list and then click Add (button) and the phone number will automatically be added to the recipient field. Type the message information into the message body and click Send (button) to send it, or Save to draft (button) to save the message.
Page 159 Modules & Options Click OK alongside any of the options to configure the settings. The Network can be configured for an Automatic (usually from the USIM card) or Manual connection. The Network Mode can be configured for any appropriate mode required. Figure 7 - 44 Settings - Network/ Network Mode...
Page 160: Mobile Partner
Modules & Options Mobile Partner With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the Mobile Partner application. The Mobile Partner Wireless Device application allows you to directly access your HSPA internet service from the com- Operation Aboard Aircraft puter.
Page 161: Mobile Partner Application
Modules & Options Mobile Partner Application You will need to contact your service provider to obtain the exact details of how ex- actly to configure the settings on this page. Mobile Partner Help Profile Management To get help on Mobile Partner configuration Power on the 3.75G/HSPA module using the Fn +...
Page 162 Modules & Options Connecting to the Service Provider Power on the 3.75G/HSPA module using the Fn + key combination. Access the Mobile Partner application from the Start menu (Start > Programs/ All Programs > Mobile Partner), or by double-clicking the Mobile Partner icon on the desktop The software will run and you can select the Profile Name from the menu.
Page 163 Modules & Options When the connection is successful you can move the cursor over the network icon in the taskbar to display the connection information. Figure 7 - 48 Connected Taskbar Notification You can then access the internet, download e-mail etc. as per any internet connection.
Page 164 Modules & Options 11. The module will still be on, and you will need to press the Fn + key combination to turn it off. 12. If you click the Mobile Partner close icon a message will be displayed asking you to click OK to confirm the program exit and to terminate the connection.
Page 165: Tv Tuner Module
Modules & Options TV Tuner Module (Optional for Model B Computers Only) TV Antenna If your purchase configuration includes the optional Hybrid (Analog & Digital) The TV antenna sup- USB Mini-Card TV Tuner module, you will be supplied with a remote control unit plied with any TV Tuner and appropriate antenna and fittings for the module.
Page 166: Consumer Infrared Driver
Modules & Options Consumer Infrared Driver 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ TV Tuner Module DVD drive. Support 2. Click Option Drivers (button). 3. Click 5.Install CIR Driver > Yes. Note that the TV Tuner module (factory) option in 4.
Page 167: Digital Tv Broadcast Signal
Modules & Options Digital TV Broadcast Signal The antenna is the most crucial factor in receiving a clear digital terrestrial TV broadcast signal. The passive antenna provided should provide a clear signal when CATV Cable Safety placed beside a window. If the signal is not clear then you can purchase an active Make sure that your antenna (it should also be placed beside a window) to improve the signal.
Page 168: Setting Up Sata Raid Or Ahci Modes
Modules & Options Setting Up SATA RAID or AHCI Modes (RAID Mode is Optional for Model B Computers Only) RAID Hard Disks AHCI Mode All hard disks in a RAID Advanced Host Controller Interface (AHCI) is an interface specification that allows should be identical (the the storage driver to enable advanced serial ATA features such as Native Command same size and brand) in...
Page 169 Modules & Options RAID Level Description Table 7 - 1 RAID Levels Identical drives reading and writing data in parallel to increase performance. RAID 0 RAID 0 implements a striped disk array and the data is broken into blocks and each block is written to a separate disk drive.
Page 170: Sata Raid Setup Procedure (Bios)
Modules & Options SATA RAID Setup Procedure (BIOS) Start-up your notebook computer and press <F2> to enter the BIOS. Go to the Advanced menu, select "SATA Mode Selection" and press Enter (see RAID and Ready- page Drive Compatibility • Select “RAID”. On a system configured in RAID mode, a condi- Press Esc and go to the Boot menu.
Page 171: Raid Setup (Intel Matrix)
Modules & Options RAID Setup (Intel Matrix) Press Ctrl + i to enter RAID configuration menu. Intel(R) Rapid Storage Technology - Option ROM - 9.5.0.1021 Figure 7 - 52 Copyright (C) 2003-09 Intel Corporation. All Rights Reserved. [ MAIN MENU ] Intel(R) Matrix Create RAID Volume Recovery Volume Options...
Page 172 Modules & Options 10. This will now return to the main menu. Intel(R) Rapid Storage Technology - Option ROM - 9.5.0.1021 Copyright (C) 2003-09 Intel Corporation. All Rights Reserved. [ MAIN MENU ] Create RAID Volume Recovery Volume Options Figure 7 - 53 Delete RAID Volume Acceleration Options Reset Disks to Non-RAID...
Page 173: Intel Matrix Driver Installation
Modules & Options Intel Matrix Driver Installation Make sure you have installed all the necessary drivers from the Drivers Installer menu (see Figure 4 - 2 on page 4 - e-SATA Port Insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive of the operable computer and click Browse CD/DVD.
Page 174 Modules & Options If a hard drive member of a RAID volume is reported as “Degraded” or “Failed” it may be possible to recover the volume. If the volume cannot be restored then you will need to recreate the RAID volume and restore the data from a back up. The Help menu (press F1 or select Contents and Index from the Help menu) provides in- structions on how to recover or recreate RAID Volumes.
Page 175: Raid Volume Data Verification And Repair
Modules & Options RAID Volume Data Verification and Repair The RAID volume data verification process identifies any inconsistencies or bad data on a RAID 0, RAID 1 or Recovery volume. The table outlines what occurs for each RAID level: RAID Verify Verify &...
Page 176 Modules & Options Verifying and Repairing RAID Volume Data Run the Intel® Matrix Storage Console from the Intel® Matrix Storage Man- ager in the Programs/All Programs menu. Click View > Advanced Mode. Right-click on the RAID volume and select either Verify Volume Data or Verify and Repair Volume Data.
Page 177: Troubleshooting
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 178: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 179: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 180: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 181: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 182 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...
Page 183: Problems And Possible Solutions
Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power but it doesn’t Battery missing / incorrectly installed. Check the battery bay, make sure the work. battery is present and seated properly (the design of the battery only allows it to go in one way).
Page 184 Troubleshooting Problem Possible Cause - Solution The computer feels too hot. Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 185 Troubleshooting Problem Possible Cause - Solution You forget the boot password. If you forget the password, you may have to discharge the battery of the CMOS. Contact your service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Page 186 Troubleshooting Problem Possible Cause - Solution Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically. However special functions/hot keys unique to the system’s regular keyboard may not work.
Page 187 Troubleshooting Problem Possible Cause - Solution The PC Camera module cannot be The module is off. Press the Fn + F10 key combination in order to enable the detected. module (see “Function/Hot Key Indicators” on page 1 - 12). Run the camera program from the desktop shortcut to view the camera picture.
Page 188 Troubleshooting Problem Possible Cause - Solution The Hibernate function has disappeared. You have a computer with 4GB of RAM and have installed Windows Vista Serv- ice Pack 1. This is a known issue if your computer has 4GB of RAM and is run- ning Windows Vista Service Pack 1.
Page 189: Screen Resolution Error
Troubleshooting Screen Resolution Error If you are experiencing either screen resolution reduction, or screen flickering after resuming from Sleep in Windows Vista only then follow the instructions below to fix this problem. This error arises in compliance with Windows Vista policy, which triggers TMM (Transient Multi-Monitor Manager) when the notebook lid (S3) is closed.
Page 190 Troubleshooting Double-click Task Scheduler Library > Microsoft > Windows. Click MobilePC to open the control panel. Right-click TMM and select Disable. Figure 8 - 2 - TMM Disable Close all the control panels. 8 - 14 Screen Resolution Error...
Page 191: Interface (Ports & Jacks)
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Item Description Cable (CATV) Use this jack to connect a CATV cable if you have included the optional TV Tuner in your...
Page 192 Interface (Ports & Jacks) Item Description DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer. DVI-Out Port The DVI-Out (Digital Visual Interface) Port (at the rear of the computer) allows you to connect an external monitor, or Flat Panel Display, to allow dual video or simultaneous display on the LCD and external monitor/FPD (see “Display Devices”...
Page 193 Interface (Ports & Jacks) Item Description Microphone-In Jack Plug an external microphone in to this jack to record on your computer. Mini-IEEE 1394 Port This allows high-speed connection to various peripheral devices, e.g. external disk drives and digital cameras (see note below). IEEE 1394 The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices.
Page 194 Interface (Ports & Jacks) Item Description S/PDIF-Out Jack This S/PDIF (Sony/Philips Digital Interface Format) Out Jack allows you to connect your DVD- capable PC to a Dolby AC-3 compatible receiver for “5.1” or ‘dts’ surround sound. USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc.
Page 195: Nvidia Video Driver Controls
NVIDIA Video Driver Controls Appendix B: NVIDIA Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Resolution Error NVIDIA Video Driver Installation If you are experiencing Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - screen resolution...
Page 196: Nvidia Control Panel
NVIDIA Video Driver Controls NVIDIA Control Panel More advanced video configuration options are provided in the NVIDIA Control NVIDIA Control Panel tab. Panel Open the Display Settings (see page 21) control panel. To access the Ge- Click Advanced Settings (button). Force..
Page 197 NVIDIA Video Driver Controls The NVIDIA Control Panel provides additional video configuration controls and tools which allow quick access to features such as display configuration, 3D Settings and Help menus etc. Navigating the Control Panel Navigate through the control panels in much the same way as you would a web page.
Page 198 NVIDIA Video Driver Controls The Help menus provide index and search features, and direct links to the NVIDIA website etc. Figure B - 3 Help Menus B - 4 NVIDIA Control Panel...
Page 199: Display Devices
NVIDIA Video Driver Controls Display Devices Note that you can use a DVI cable connected to the DVI-Out port, or an HDMI Display Devices (High-Definition Multimedia Interface) cable connected to the HDMI-Out port to connect an external display (if you are using an older type of monitor you can use a Besides built-in converter to convert the signal from DVI to VGA).
Page 200: Attaching Other Displays
NVIDIA Video Driver Controls Attaching Other Displays Configuring an External Display in Windows Vista Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Windows Mobility Center control panel (Mobile PC >...
Page 201 NVIDIA Video Driver Controls Configuring an External Display using the NVIDIA Control Panel Alternatively you can use the NVIDIA control panel to configure any attached dis- plays. Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Go to NVIDIA Control Panel (see “NVIDIA Control Panel”...
Page 202 NVIDIA Video Driver Controls Click the tickbox alongside any display you wish to use. Click Apply > Yes to save the changes. The default display mode will be in Extended mode (i.e the desktop will be Display Not Shown extended on to the external display - see “Display Devices”...
Page 203 NVIDIA Video Driver Controls Enabling Clone Mode Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Go to NVIDIA Control Panel (see “NVIDIA Control Panel” on page B - Double-click Display (if the sub-menus are not visible), and then click Set up multiple displays.
Page 204 NVIDIA Video Driver Controls To switch back to Extended Mode right-click one of the display icons and click “Clone Laptop Display and..” (to remove the tick) option from the pop-up menu and click Apply. Figure B - 8 Switch to Extended Mode B - 10 Attaching Other Displays...
Page 205: Hdmi Audio Configuration
NVIDIA Video Driver Controls HDMI Audio Configuration As HDMI (High-Definition Multimedia Interface) carries both audio and video sig- nals you will need to configure the audio output as per the instructions below. The settings will depend upon the video card you have installed in your purchase option. Windows Audio Setup for HDMI Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 206 NVIDIA Video Driver Controls Adjust the HDMI settings from the control panel tabs. Click OK to close the Sound control panel. Figure B - 10 HDMI Device Properties B - 12 Attaching Other Displays...
Page 207 NVIDIA Video Driver Controls HDMI Notes • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • If you disconnect the HDMI cable the default audio playback device will not If you are using a third revert to speakers until the computer is restarted (if you do not wish to restart the party application to play...
Page 208: Display Modes
NVIDIA Video Driver Controls Display Modes Single Display Mode SLI Configuration & Only one of your displays is used. Multiple Displays Note that if SLI configu- Clone Mode ration is enabled only a Clone Mode simply shows an exact copy of the Primary display desktop on the other Single display may be display(s).
Page 209 NVIDIA Video Driver Controls Using New Display Detected to Enable Extended Mode Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Windows Mobility Center control panel (Mobile PC >...
Page 210 NVIDIA Video Driver Controls Using Display Settings to Enable Extended Mode Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Click Start, and click Control Panel (or point to Settings and click Control Display Settings Panel).
Page 211: Enabling Tv Display
NVIDIA Video Driver Controls Enabling TV Display To display desktop images on a TV, connect the TV to your computer by using an Detect Displays HDMI cable/DVI cable from the TV to the HDMI-Out port/DVI-Out port (if sup- ported by your TV). To get a full range of dis- “My play options click...
Page 212: Changing The Tv Signal Or Hd Format
NVIDIA Video Driver Controls Changing the TV Signal or HD Format When the TV is enabled as a display device click the sub-menus under Video & Television. Click “Select the format you would like to use.”. Select the TV signal format you would like to use. Apply the settings, and then click Yes to save the changes.
Page 213: Specifications
Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Page 214: Processor
Specifications Processor Core Logic Video Adapter Intel® Core i7-820QM Processor: Intel® PM55 Chipset For Model A & B Computers: 1.73GHz nVIDIA® GeForce GTX 280M PCIe * 16 Display Video Card 45nm (45 Nanometer) Process Technology, 8M L3 Cache & 1GB GDDR3 Video RAM on board For Model A Computers: FSB 1333MHz - TDP 45W Supports Microsoft DirectX...
Page 215: Storage
Specifications Storage Keyboard & Pointing Device Card Reader One Changeable 12.7mm(h) Optical Full Size WinKey Keyboard Embedded 7-in-1 Card Reader (MS/ MS Device (CD/DVD) Type Drive (see Pro/ SD/ Mini SD/ MMC/ RS MMC/ MS Built-in TouchPad with Multi Gesture “Factory Options for All Models”...
Page 216: Communication
Specifications Communication Power Management Environmental Spec Built-In 56K Fax Modem V.90 & V.92 Supports Wake on LAN Temperature Compliant ° ° Supports Wake on USB Operating: C - 35 Supports Resume From Modem Ring Non-Operating: -20°C - 60°C Built-In 10/100/1000Mb Base-TX Ethernet LAN Relative Humidity Intel®...
Page 217: Factory Options For All Models
Specifications Factory Options for All Models Super Multi Drive ODD Module Blu-Ray ODD Module Intel® WiFi Link Wireless LAN Module 5300 3*3 802.11 a/g/n Half Mini-Card with PCIe Interface 3rd Party 802.11b/g/n Half Mini-Card Wireless LAN Module with PCIe Interface Bluetooth 2.1 + EDR (Enhanced Data Rate) Module Fingerprint Reader Module...
Page 218 Specifications C - 6...
Page 219: Windows 7 Information
Windows 7 Information Appendix D: Windows 7 Information This Appendix contains information (including control panel information, driver installation etc.) for users of the Windows 7 OS where there are significant differences from Windows Vista, or where is it helpful to have essential information or features repeated.
Page 220: Dvd Regional Codes
Windows 7 Information DVD Regional Codes Changing DVD Regional Codes Go to the Control Panel and double-click Device Manager (System and Security > System), then click the + next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties dialogue box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code.
Page 221: Windows 7 Start Menu & Control Panel
Windows 7 Information Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are ac- cessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 222: Function/Hot Key Indicators
Windows 7 Information Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators are available when the hot key utility is installed. Fn Keys Function Fn Keys...
Page 223: Hot Key Buttons & Keyboard
Windows 7 Information Hot Key Buttons & Keyboard The LED hot key buttons give instant access to the default Internet browser and e- Other Keyboards mail program, and allow you to toggle Silent Mode with one quick button press. If your keyboard is Hot Key Function damaged or you just...
Page 224: Video Features
Windows 7 Information Video Features You can configure display options from the Display control panel in Windows, and from the NVIDIA Control Panel as long as the appropriate video driver is installed. For more detailed video information see “NVIDIA Video Driver Controls” on page B - To access Display (Control Panel) and Screen Resolution in Windows: Click Start and click Control Panel.
Page 225: Screen Resolution
Windows 7 Information Screen Resolution Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display as your display device. Video Options Note that card types, specifications and drivers are subject to continual updates and changes. Check with your service center for the latest de- tails on video cards supported.
Page 226: Nvidia Control Panel
Windows 7 Information NVIDIA Control Panel Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display as your display device. Figure D - 3 - NVIDIA Control Panel D - 8 Video Features...
Page 227: Attaching Other Displays
Windows 7 Information Attaching Other Displays Configuring an External Display in Windows 7 Attach your external display to the external monitor port/HDMI-Out port and turn it on. Go to the Screen resolution control panel. Click the Detect button. The computer will then detect any attached displays. Figure D - 4 - Screen Resolution - Multiple Displays Video Features D - 9...
Page 228 Windows 7 Information You can configure the displays from the Multiple Displays menu. Figure D - 5 - Screen Resolution - Multiple Display Options • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) •...
Page 229: The Power Sources
Windows 7 Information The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. Silent Mode AC/DC Adapter Use the key to tog- gle Silent Mode to re- Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ duce fan noise and save DC adapter will damage the computer and its components.
Page 230: Turning On The Computer
Windows 7 Information Turning On the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Forced Off er button on the front panel. If the system “hangs”, When the computer is on, you can use the power button as a Stand by/Hibernate/ and the Ctrl + Alt + Del Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and key combination doesn’t...
Page 231: Power Plans
Windows 7 Information Power Plans The computer can be configured to conserve power by means of power plans. You can use (or modify) an existing power plan, or create a new one. Resuming The settings may be adjusted to set the display to turn off after a specified time, and Operation to send the computer into Sleep after a period of inactivity.
Page 232 Windows 7 Information Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.
Page 233: Power-Saving States
Windows 7 Information Power-Saving States You can use power-saving states to stop the computer’s operation and restart where you left off. Sleep is the default power-saving state in Windows 7. Earlier versions of Windows used Stand By and Hibernate as system power-saving states. Windows 7 combines the features of Stand By and Hibernate into the default Sleep power-saving state.
Page 234 Windows 7 Information Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.
Page 235: Configuring The Power Buttons
Windows 7 Information Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the computer in to a power- saving state. Click Choose what the power buttons do on the left menu in Power Options to bring up the menu. Password Protection It is recommended that you enable a password on wake...
Page 236 Windows 7 Information Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Power Status To Resume Icon Color Power Off Press the Power Button Press the Power Button Sleep Blinking Green...
Page 237: Battery Information
Windows 7 Information Battery Information Follow these simple guidelines to get the best use out of your battery. Low Battery Battery Power Warning Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- grams you are running, and peripheral devices attached.
Page 238: Conserving Battery Power
Windows 7 Information Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 239: Battery Life
Windows 7 Information Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its perfor- mance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason (e.g.
Page 240 Windows 7 Information Proper handling of the Battery Pack •DO NOT disassemble the battery pack under any circumstances •DO NOT expose the battery to fire or high temperatures, it may explode Caution •DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.
Page 241: Battery Faq
Windows 7 Information Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 242 Windows 7 Information Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Battery Charging & Maintenance How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green.
Page 243: Driver Installation
Windows 7 Information Driver Installation 1. Check the driver installation order from Table D - 5 (the drivers must be installed in this order) which is the same as that listed in the Drivers Installer menu Insert the Device Drivers & Utilities + User’s Manual below.
Page 244 Windows 7 Information Windows 7 Drivers Page # Windows 7 Drivers Page # Chipset Page D - 28 PC Camera Module (Win7) Page D - 36 Video Page D - 28 Wireless LAN Module (Win 7) Page D - 30 Audio Page D - 29 Fingerprint Reader Module (Win7)
Page 245: Updating/Reinstalling Individual Drivers
Windows 7 Information Updating/Reinstalling Individual Drivers If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do this go Driver Installation General Guidelines to the Control Panel in the Windows OS and double- click the Programs and Features item (Programs > The driver installation procedure outlined in this Uninstall a program).
Page 246: Driver Installation Procedure
Windows 7 Information Driver Installation Procedure Insert the Device Drivers & Utilities + User’s Manual 1. Click 4.Install LAN Driver > Yes. disc and click Install Drivers (button). 2. Click Next > Install. 3. Click Finish. Chipset 4. The network settings can now be configured. 1.
Page 247: Optional Drivers
Windows 7 Information Hot Key Optional Drivers 1. Click 8.Install Hotkey Utility > Yes. See the pages indicated for the driver installation pro- cedures for any modules included in your purchase op- 2. Click Next > Next. tion. Where Windows 7 information differs from 3.
Page 248: G/Hspa Module (Win 7 - Model A Only
Windows 7 Information Bluetooth Module (Win 7) 3.75G/HSPA Module (Win 7 - Model A Note: The operating system is the default setting for Only) Bluetooth control in Windows 7, and does not require See the introduction in “3.75G/HSPA Module (Win a driver.
Page 249 Windows 7 Information Bluetooth Module (Win 7) The operating system’s Bluetooth Devices control panel is used to configure the Wireless Device Bluetooth settings in Windows Vista, and therefore does not require a driver. Use the Operation Aboard Fn + F12 key combination (see “Function/Hot Key Indicators”...
Page 250: Bluetooth Configuration In Windows Vista
Windows 7 Information Bluetooth Configuration in Windows Vista Setup your Bluetooth Device so the Computer Can Find it 1. Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Add a Device 2. Make the device discoverable (to do this check your device documentation). Click Start, and click To Turn the Bluetooth Module On Control Panel and then...
Page 251 Windows 7 Information To Add a Bluetooth Device Access the Bluetooth Devices control panel and click Add a device. Double-click the device you want to pair with the computer. Pairing Options If a device has been pre- viously connected then the pairing option menu will appear when you at- tempt subsequent con-...
Page 252 Windows 7 Information 4. Enter the code into your Bluetooth enabled device and follow any on-screen instructions to complete the pairing. Figure D - 4 Pairing Codes Pairing Code Example The example outlined here shows a connection to a mobile device. Other devices e.g. computers, may have a slightly different connection proce- dure, and may require you to confirm a pairing code is correct on both devices.
Page 253 Windows 7 Information To Change Settings for the Bluetooth Device Click the taskbar icon and select Show Bluetooth Devices. Right-click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click Bluetooth, type a new name and click OK). •...
Page 254 Windows 7 Information PC Camera Module (Win7) If you have included a PC Camera module in your purchase option, make sure that Latest PC Camera the PC Camera module is on before installing the driver. Use the Fn + F10 key com- Driver Information bination (see “Function/Hot Key Indicators”...
Page 255 Windows 7 Information PC Camera Driver Installation 1. Make sure the module is powered on, then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. 2. Click Option Drivers (button). 3. Click 1.PC Camera, Web cam > Yes. 4.
Page 256 Windows 7 Information Camera Application The WebCam application is a video viewer for general purpose video viewing and testing, and for capturing video files to .avi format. Pre-Allocating File Size/Space 1. Run the camera application from the desktop shortcut (it is recommended that you set the capture file before the capture process - see “Set Capture File”...
Page 257 Windows 7 Information Set Capture File Prior to capturing video files you may select the Set Capture File... option in the File menu, and set the file name and location before capture (this will help avoid accidentally overwriting files). Set the name and location then click Open, then set the "Capture file size:"...
Page 258 Windows 7 Information Eliminating Screen Flicker If you find that the video screen in the camera program is flickering, you can try to adjust the setting in the Video Capture Filter options. 1. Run the camera program from the desktop shortcut. 2.
Page 259 Windows 7 Information Zoom The WebCam program allows you to zoom the camera in and out (note the zoom function is not available in all camera model applications). Run the camera application from the desktop shortcut. Go to Zoom and select Zoom Out/Zoom In. Figure D - 8 Zoom/Setting Taking Still Pictures...
Page 260 Windows 7 Information Wireless LAN Module (Win 7) If you have included an Intel® Wi-Fi Link 5300 Series or 3rd Party 802.11b/g/n Wireless Device WLAN module in your purchase option, make sure that the Wireless LAN module is Operation Aboard on before installing the driver.
Page 261: Intel® Wi-Fi Link Series Driver Installation
Windows 7 Information Intel® Wi-Fi Link Series Driver Installation If you see the message “Found New Hardware” click Cancel to close the window. 1. Make sure the module is powered on, then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive.
Page 262: Connecting To A Wireless Network
Windows 7 Information Connecting to a Wireless Network Make sure the Wireless LAN module is turned on. Network and 1. Click the taskbar wireless icon , and then double-click an access point to connect Sharing Center to or click to Open Network and Sharing Center if you do not see a network you want to connect to in the taskbar menu (a list of options will appear allowing setting You can also use the Net- changes, and creating a new network).
Page 263 Windows 7 Information You may need to enter a security key for any access point to which you are trying to connect. Click to select a network location (e.g. Home, Work or Public). Click “View or change settings in Network and Sharing Center” to access further options for the connection.
Page 264 Windows 7 Information 5. Click the taskbar icon to see any currently connected networks. 6. To disconnect from the wireless network you can click the taskbar wireless icon click the active connection and then click Disconnect (button). Security Enabled Networks You should try to make sure that any network you are connecting to is a se-...
Page 265: Windows Mobility Center
Windows 7 Information Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel). Double-click Windows Mobility Center (Mobile PC).
Page 266: Fingerprint Reader Module (Win7
Windows 7 Information Fingerprint Reader Module (Win7) The fingerprint reader module provides a high level of security for your computer. Help & Manual Make sure you have administrator’s rights to your computer, and have a Windows password enabled for full security protection. Right-click the taskbar icon to bring up the menu to Before beginning the enrollment process it is recommended that you go through the...
Page 267 Windows 7 Information User Enrollment Click Start > Control Center (Start > All Programs > Protector Suite > Control Center), or double click the taskbar icon On the first run of the program you will be asked to click the Accept button to accept the license.
Page 268 Windows 7 Information 6. Click the button above any of the fingers to begin the enrollment process for that finger. 7. Swipe the finger until the progress bar reaches 100% to enroll that finger. Fingerprint 8. Repeat the process for all the fingers you wish to enroll (see sidebar), and then click Enrollment the close button to close the window.
Page 269 Windows 7 Information Click the taskbar icon and select Start Control Center (and then swipe a finger) to allow you to Edit Fingerprints, register Applications, edit Settings and access the Help menu etc. You can also run the Control Center from the Start menu or Protector Suite >...
Page 270: G/Hspa Module (Win 7
Windows 7 Information 3.75G/HSPA Module (Win 7) (Optional for Model A Computers Only) 3.75G/HSPA Module If you have included an optional 3.75G/HSPA (High Speed Packet Access) module Options (see “Communication” on page C - 4 for specification details) in your purchase op- tion, you will have the appropriate application (HSPA Modem Interface or Mobile There are two optional Partner) provided for your module.
Page 271 Windows 7 Information Before installing the application, make sure that the 3.75G/HSPA module is ON (installing the driver with the module off will not allow the software to detect the module hardware correctly). Use the Fn + key combination (see “Function/Hot 3.75G/HSPA Key Indicators”...
Page 272: Usim Card Installation
Windows 7 Information USIM Card Installation 1. Turn off the computer, and turn it over and remove the battery (see “Removing the Battery” on page 6 - Power Safety 2. The SIMLOCK is located in the compartment under the battery. Warning 3.
Page 273 Windows 7 Information Slide the SIMLOCK towards the hinge (in the direction of the arrow illustrated in Figure D - 17) in order to release the lock and lift it up. Insert the USIM card as illustrated in (Figure D - 18) and close the SIMLOCK.
Page 274 Windows 7 Information HSPA Modem Interface With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the HSPA Modem Interface. The HSPA Modem In- Wireless Device terface allows you to directly access your HSPA internet service from the computer. Operation Aboard Aircraft HSPA Modem Interface Installation...
Page 275: Hspa Modem Interface
Windows 7 Information HSPA Modem Interface The connection information is stored on the USIM card supplied by the service pro- vider. HSPA Modem Help Power on the 3.75G/HSPA module using the Fn + key combination. To get help on 3.75G/ Access the HSPA Modem Interface from the Start menu (Start >...
Page 276 Windows 7 Information 6. Click Connect to connect to your service provider. Figure D - 20 Connecting to Network 7. The message “Network is connected” will be displayed when the network connection is successful. Figure D - 21 Network is Connected 8.
Page 277 Windows 7 Information While you are connected the upper right corner of the HSPA Modem interface will display the upload and download rates, and the taskbar icon will display the Figure D - 22 connection icon Uploading/ Downloading Rates and Speed 10.
Page 278 Windows 7 Information 3. Click Add (button) and input any Network Settings required by your service provider. 4. Click OK to save the profile. Figure D - 24 Network Settings & Profiles 5. You can Edit or Delete profiles from the Profiles tab. 6.
Page 279 Windows 7 Information Contacts Access the HSPA Modem Interface from the Start menu (Start > Programs/All Programs > HSPA Modem > HSPA Modem), or by clicking the desktop icon. Click Contacts (button). Figure D - 25 Network Settings & Profiles Click Refresh (button) to download the contacts from the USIM card to the computer.
Page 280 Windows 7 Information Messages 1. Access the HSPA Modem Interface from the Start menu (Start > Programs/All Programs > HSPA Modem > HSPA Modem), or by clicking the desktop icon. SMS Service 2. Click Messages (button). In addition to standard in- ternet services you may also send and receive SMS text messages us-...
Page 281 Windows 7 Information Click to select a contact from the list and then click Add (button) and the phone number will automatically be added to the recipient field. Type the message information into the message body and click Send (button) to send it, or Save to draft (button) to save the message.
Page 282 Windows 7 Information Settings 1. Access the HSPA Modem Interface from the Start menu (Start > Programs/All Programs > HSPA Modem > HSPA Modem), or by clicking the desktop icon. 2. Click Settings (button). Figure D - 27 Settings D - 64 3.75G/HSPA Module (Win 7)
Page 283 Windows 7 Information Click OK alongside any of the options to configure the settings. The Network can be configured for an Automatic (usually from the USIM card) or Manual connection. The Network Mode can be configured for any appropriate mode required. Figure D - 28 Settings - Network/ Network Mode...
Page 284: Mobile Partner
Windows 7 Information Mobile Partner With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the Mobile Partner application. The Mobile Partner Wireless Device application allows you to directly access your HSPA internet service from the com- Operation Aboard Aircraft puter.
Page 285 Windows 7 Information Mobile Partner Application You will need to contact your service provider to obtain the exact details of how ex- actly to configure the settings on this page. Mobile Partner Help Profile Management To get help on Mobile Partner configuration Power on the 3.75G/HSPA module using the Fn +...
Page 286 Windows 7 Information Connecting to the Service Provider 1. Power on the 3.75G/HSPA module using the Fn + key combination. 2. Access the Mobile Partner application from the Start menu (Start > Programs/All Programs > Mobile Partner), or by double-clicking the Mobile Partner icon on the desktop 3.
Page 287 Windows 7 Information When the connection is successful you can click the network icon in the taskbar to display the connection information. Figure D - 32 Connected Taskbar Notification You can then access the internet, download e-mail etc. as per any internet connection.
Page 288 Windows 7 Information 9. To disconnect click the Disconnect icon, or right click the taskbar icon, click the connected icon and select Disconnect. Figure D - 33 Disconnect 10. The program will disconnect from the service provider. 11. The module will still be on, and you will need to press the Fn + key combination to turn it off.
Page 289 Windows 7 Information 12. The module will still be on, and you will need to press the Fn + key combination to turn it off. 13. If you click the Mobile Partner close icon a message will be displayed asking you to click OK to confirm the program exit and to terminate the connection.
Page 290: D - 72 Audio Setup For Lcd Monitors/Tvs With Hdmi Input
Windows 7 Information Audio Setup for LCD Monitors/TVs with HDMI Input Some LCD monitors/TVs support HDMI input, but DO NOT have built-in digital audio decoders. Where this is the case, when playing DVDs in Windows Media Player/CyberLink Power DVD etc., a background noise can occur.

Clevo W860CU User Manual

Quick Start Guide

Features & Components

Power Management

Drivers & Utilities

BIOS Utilities

Upgrading the Computer

Modules & Options

Troubleshooting

Interface (Ports & Jacks)

NVIDIA Video Driver Controls

Specifications

Windows 7 Information

Quick Links

Related Manuals for Clevo W860CU

Summary of Contents for Clevo W860CU
