Universal Security Instruments MP308 User Manual

Smoke & fire alarm
Hide thumbs
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual
SILENCE FEATURE AND ALARM ORIGINATION FEATURE
Smoke Alarm Limitations and Functions ................................. 2
Recommended Location of Alarms ......................................... 3
Avoid These Locations ........................................................... 4
Early Warning ......................................................................... 4
Installation Instructions ........................................................... 4
Locking/Tamper Feature ......................................................... 4
Operation, Testing & Maintenance .......................................... 5
RV Installation ........................................................................ 5
®
Alarm Originating Feature & Reset ..................... 5
Cautions/Warnings ................................................................. 6
Battery Replacement .............................................................. 6
Develop and Practice a Plan of Escape .................................. 7
Operational Summary ............................................................. 8
Warranty ................................................................. Back Cover
MODEL MP308, MP308L
MODEL MP508, MP508L
BATTERY POWERED
SMOKE & FIRE ALARM WITH
READ ALL INSTRUCTIONS

Table of Contents:

Page #

Advertisement

Table of Contents
loading

Related Manuals for Universal Security Instruments MP308

Summary of Contents for Universal Security Instruments MP308

  • Page 1: Table Of Contents

    MODEL MP308, MP308L MODEL MP508, MP508L BATTERY POWERED SMOKE & FIRE ALARM WITH SILENCE FEATURE AND ALARM ORIGINATION FEATURE READ ALL INSTRUCTIONS Table of Contents: Page # Smoke Alarm Limitations and Functions ......... 2 Recommended Location of Alarms ......... 3 Avoid These Locations ............

  • Page 2: Smoke Alarm Limitations And Functions

    SMOKE ALARM LIMITATIONS AND FUNCTIONS ® There are three basic smoke alarm types: IoPhic , Ionization and Photoelectric.  ® IoPhic is an ionization alarm containing a patent-pending Universal Smoke Sensing Technology. ® IoPhic alarms are very effective at detecting fast flaming fires and also respond very quickly to slow smoldering fires - up to 87% faster than the maximum allowable alarm limit (UL217 Smoldering Smoke Test on 5/26/2010, Underwriters Laboratories Project #09CA38078).

  • Page 3: Recommended Location Of Alarms

    RECOMMENDED LOCATION OF ALARMS • Locate the first smoke alarm in the immediate area of the bedrooms. Try to protect the escape route as the bedrooms are usually farthest from an exit. If more than one sleeping area exists, locate additional smoke alarms in each sleeping area. If a hall is more than 40 feet (12 meters) long, install a smoke alarm at each end.

  • Page 4: Avoid These Locations

    AVOID THESE LOCATIONS • the garage – products of combustion are produced when you start your vehicle. • near appliances or areas where normal combustion regularly occurs (kitchens, near furnaces, gas hot water heaters). Use smoke alarms with photoelectric sensors or smoke alarms with Silence Feature for these areas.

  • Page 5: Operation, Testing & Maintenance

    TO DEACTIVATE THE LOCKING FEATURES: To remove the smoke alarm for cleaning or servicing or to replace the battery, you must first remove the appropriate locking pin, if it has been installed. Use long nose pliers to pull the locking pin out of the hole. It is now possible to remove the smoke alarm or replace the battery.

  • Page 6: Cautions/Warnings

    NEVER use an open flame of any kind to test this smoke alarm. You might accidentally damage or set fire to the smoke alarm or to your home. The built-in test switch accurately tests the smoke alarm's operation as required by Underwriters Laboratories Inc. (UL). If you choose to use an aerosol smoke product to test the smoke alarm, be certain to use one that has been Listed to Underwriters Laboratories, Inc.
  • Page 7 WHAT TO DO WHEN THE ALARM SOUNDS o Leave immediately by your plan of escape. Every second counts, so don't waste time getting dressed or picking up valuables. o In leaving, don't open any inside door without first feeling its surface. If hot, or if you see smoke seeping through cracks, don't open that door! Instead, use your alternate exit.

  • Page 8: Operational Summary

    OPERATIONAL SUMMARY AUDIBLE & VISUAL SIGNALS CONDITION / RECOMMENDATION HORN RED LED Silent Blinks On once Condition: DC Power is present. approx every Recommendation: None, alarm is operating properly. 40-45 seconds Condition: Originating Smoke Alarm. 3 Beeps, Blinks On Recommendation: If hazard is identified, please take all precautions if an alarm sounds 2 second pause, approx every by calling an Emergency Service and getting out of the home.

  • Page 9: Warranty

    MODELS MP308, MP308L MODELS MP508, MP508L USI ELECTRIC, INC. / UNIVERSAL SECURITY INSTRUMENTS, INC. (“USI”) warrants your product to be free from defects in material and workmanship for a period of ten (10) years from the date of purchase. This warranty shall not apply to any batteries used in the product or to any damage which may be caused by such batteries.

This manual is also suitable for:

Mp308lMp508Mp508l
