883 WEIGHT HORN ATTACHMENT
CLASS H
PART # 7082001
REV. A
USER'S GUIDE
1
WARNING:
Read and follow all directions
for each step to insure proper
assembly of this product.
Version: 883107
Revision: 03/20/01

Advertisement

Table of Contents
loading

Related Manuals for ParaBody 883

Summary of Contents for ParaBody 883

  • Page 1 883 WEIGHT HORN ATTACHMENT CLASS H PART # 7082001 REV. A USER’S GUIDE WARNING: Read and follow all directions for each step to insure proper assembly of this product. Version: 883107 Revision: 03/20/01...

  • Page 2: Important Safety Information

    Use only the pin provided by the manufacturer. If unsure, call your authorized ParaBody dealer. NOTE: In a continual effort to improve our products, specifications are subject to change 2001 Life Fitness, a division of Brunswick Corporation. All rights reserved. © ParaBody is a trademark of Brunswick Corporation www.parabody.com...

  • Page 3: Important Notes

    Please note: * Thank you for purchasing the ParaBody 883 Weight Horn Attachment. Please read these instructions thoroughly and keep them for future reference. This product must be assembled on a flat, level surface to assure its proper function. * This product must be assembled on a flat, level surface to assure its proper function. DO NOT securely tighten any frame connections until the entire frame has been assembled, unless otherwise stated.

  • Page 4: Parts List

    FIGURE 1 STEP 1: INSTALLATION SHOWN FOR 888 SMITH MACHINE. 838 SQUAT RACK INSTALLATION SHOWN ON PAGE 6 &7. • Remove and discard the eight 9/16” CAP PLUGS from the UPRIGHT FRAMES as shown in FIGURE 1. PARTS LIST PART # DESCRIPTION 6799601 PLATE HOLDER...
  • Page 5 UPRIGHT FRAME 2 1/2 X 3” FIGURE 2 STEP 2: • Insert four 1-3/4” ROUND END CAPS (5) into the end of the four PLATE HOLDERS (1) as shown in FIGURE 2. • SECURELY assemble the four PLATE HOLDERS (1) to the UPRIGHT FRAMES as shown in FIGURE 2, using eight 1/2 X 3” BOLTS (2), eight 1/2”...
  • Page 6 FIGURE 1 STEP 1: INSTALLATION SHOWN FOR 838 SQUAT MACHINE. 888 SMITH MACHINE INSTALLATION SHOWN ON PAGE 4 & 5. • Remove and discard the four 1/2 X 3” BOLTS, four 1/2” WASHERS, and four 1/2” LOCK NUTS from the CROSS BRACE as shown in FIGURE 1.
  • Page 7 FIGURE 2 STEP 2: • Insert four 1-3/4” ROUND END CAPS (5) into the end of the four PLATE HOLDERS (1) as shown in FIGURE 2. • SECURELY assemble two PLATE HOLDERS (1) and the CROSS BRACE to the UPRIGHT FRAMES as shown in FIGURE 2, using four 1/2 X 3”...

  • Page 8: Maintenance

    YOU MAY NEED SERVICE YOU WILL BE ASKED FOR THIS INFORMATION. REMEMBER TO FILL OUT YOUR WARRANTY REGISTRATION CARD AND MAIL BACK. MODEL #________________________ SERIAL #_________________________ DATE OF PURCHASE: _____________ DEALERS NAME: _________________ DEALERS PHONE #_______________ Thank you for purchasing the ParaBody 883 Weight Horn Attachment. MAINTENANCE...

  • Page 9: Limited Warranty

    ParaBody extends the following LIMITED WARRANTY to the original owner of the ParaBody products. The Warranty terms apply to IN HOME USE ONLY. 1. LIMITED WARRANTY ON FRAME AND WELDS. If the frame of the ParaBody product or a weld should crack or break, it will be repaired or replaced by ParaBody.
  • Page 10 Life Fitness Italia S.R.L. Via Elvas 92 39042 Bressanone Italy Phone: 39 (472) 835-470 Fax: 39 (472) 833-150 Life Fitness Asia Pacific Limited Room 2610, Miramar Tower 132 Nathan Road, Tsimshatsui Kowloon, Hong Kong Phone: (852) 2891-6677 Fax: (852) 2575-6001 LIFE FITNESS www.parabody.com...
