UNDER HOOD OVERVIEW - 2.0L DURATORQ-TDCI (DW) DIESEL

A
I
E152530
A Engine coolant reservoir
B Brake fluid reservoir (right-hand drive)
C Brake fluid reservoir (left-hand drive)
D Battery: See Changing the 12V Battery (page 195).
E Engine compartment fuse box: See Fuses (page 176).
F Air cleaner: No maintenance necessary.
G Engine oil dipstick
H Engine oil filler cap
I Windshield and rear window washer fluid reservoir: See Washer Fluid Check
(page 195).
*
The filler caps and the engine oil dipstick are colored for easy identification.
Kuga (CBS) Vehicles Built From: 08-09-2014 Vehicles Built Up To: 31-05-2015, CG3585en enGBR, Edition date: 08/2014, First Printing
Maintenance
B
H G
*
: See Engine Coolant Check (page 194).
*
: See Engine Oil Check (page 193).
*
: See Engine Oil Check (page 193).
C D
*
: See Brake Fluid Check (page 194).
*
: See Brake Fluid Check (page 194).
191
E
F
