Icom IC-M1V Service Manual page 20

[RF UNIT]
REF ORDER
NO. NO.
D1 1720000670 S.VARICAP
D2 1790000620 S.DIODE
D4 1790001650 S.DIODE
D5 1720000370 S.VARICAP
D6 1720000370 S.VARICAP
D7 1790000620 S.DIODE
D8 1790000620 S.DIODE
D9 1790000620 S.DIODE
D10 1790000490 S.DIODE
D11 1790000620 S.DIODE
D12 1790000620 S.DIODE
D13 1720000370 S.VARICAP
D14 1720000370 S.VARICAP
D15 1720000370 S.VARICAP
D16 1720000370 S.VARICAP
D17 1720000370 S.VARICAP
D18 1720000370 S.VARICAP
D19 1730002300 S.ZENER
FI1 2010002420 MONOLITH
FI2 2010002420 MONOLITH
X1 6050010800 S.XTAL
L1 6200007000 S.COIL
L2 6200008070 S.COIL
L3 6200003090 S.COIL
L5 6200006980 S.COIL
L6 6200006980 S.COIL
L7 6200006980 S.COIL
L8 6200006980 S.COIL
L9 6200006670 S.COIL
L10 6200002320 S.COIL
L11 6200009240 S.COIL
L12 6200008460 S.COIL
L13 6200002370 S.COIL
L14 6200003090 S.COIL
L15 6200008450 S.COIL
L16 6200008450 S.COIL
L17 6200008400 S.COIL
L18 6200002820 S.COIL
L19 6200002820 S.COIL
L20 6200007160 S.COIL
L21 6200007160 S.COIL
L22 6200002360 S.COIL
L23 6200002360 S.COIL
L24 6200005740 S.COIL
L25 6200006980 S.COIL
L26 6200004790 S.COIL
L27 6200003590 S.COIL
L28 6200003590 S.COIL
L29 6200008190 S.COIL
R1 7030003760 S.RESISTOR
R2 7030003640 S.RESISTOR
R3 7030003380 S.RESISTOR
R4 7510001160 S.THERMISTOR NTCCM1608 4LH 473KC
R5 7030005870 S.RESISTOR
R6 7030003440 S.RESISTOR
R7 7030003560 S.RESISTOR
R8 7030003640 S.RESISTOR
R9 7030003320 S.RESISTOR
R10 7030003440 S.RESISTOR
R11 7030003200 S.RESISTOR
R12 7030003510 S.RESISTOR
R13 7030003410 S.RESISTOR
R14 7030003660 S.RESISTOR
R15 7030003580 S.RESISTOR
R16 7030003680 S.RESISTOR
R17 7030003680 S.RESISTOR
R19 7030003440 S.RESISTOR
R20 7030003640 S.RESISTOR
R22 7030003440 S.RESISTOR
R23 7030003550 S.RESISTOR
R24 7030003550 S.RESISTOR
R26 7030003390 S.RESISTOR
R27 7030003350 S.RESISTOR
R28 7030003660 S.RESISTOR
DESCRIPTION
HVU17TRF
MA77 (TX)
MA77 (TX) -AB
HVU350TRF
HVU350TRF
MA77 (TX)
MA77 (TX)
MA77 (TX)
HSM88AS-TR
MA77 (TX)
MA77 (TX)
HVU350TRF
HVU350TRF
HVU350TRF
HVU350TRF
HVU350TRF
HVU350TRF
MA8082-M (TX)
21R15AB (FL-310)
21R15AB (FL-310)
CR-659 (21.25 MHz)
ELJRE 82NG-F
MLF1608E 6R8K 6.8U
NL 322522T-2R7J-3
ELJRE R10G-F
ELJRE R10G-F
ELJRE R10G-F
ELJRE R10G-F
ELJRE 68NG-F
LQN 1A 8N8J04
0.20-1.0-7TL 31N
0.26-0.9-5TR 15N
LQN 1A 39NJ04
NL 322522T-2R7J-3
0.35-1.6-5TL 28N
0.35-1.6-5TL 28N
0.35-1.6-6TL 36N
LQN 1A 47NJ04
LQN 1A 47NJ04
LQN 1H 54NK04
LQN 1H 54NK04
LQN 1A 33NJ04
LQN 1A 33NJ04
ELJRE 47NG-F
ELJRE R10G-F
MLF1608D R47K-T
EXCCL3225U1
EXCCL3225U1
0.25-1.9-8TL 80N
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 331 V (330 Ω)
RR0816R-104-D (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 392 V (3.9 kΩ)
ERJ3GEYJ 561 V (560 Ω)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 181 V (180 Ω)
ERJ3GEYJ 683 V (68 kΩ)
[RF UNIT]
REF ORDER
NO. NO.
R29 7030003420 S.RESISTOR
R30 7030003660 S.RESISTOR
R31 7030003400 S.RESISTOR
R32 7030003630 S.RESISTOR
R33 7030003390 S.RESISTOR
R34 7030003520 S.RESISTOR
R35 7030004050 S.RESISTOR
R36 7030003320 S.RESISTOR
R37 7030003520 S.RESISTOR
R38 7030003500 S.RESISTOR
R39 7030003450 S.RESISTOR
R40 7030003310 S.RESISTOR
R41 7030003260 S.RESISTOR
R42 7030003560 S.RESISTOR
R43 7030003580 S.RESISTOR
R44 7030003320 S.RESISTOR
R46 7030003280 S.RESISTOR
R47 7030003440 S.RESISTOR
R48 7030003320 S.RESISTOR
R49 7030003560 S.RESISTOR
R51 7030000280 S.RESISTOR
R52 7030003670 S.RESISTOR
R53 7030003600 S.RESISTOR
R54 7030003460 S.RESISTOR
R56 7030003310 S.RESISTOR
R57 7030003800 S.RESISTOR
R58 7030003680 S.RESISTOR
R59 7030003800 S.RESISTOR
R60 7030003680 S.RESISTOR
R61 7030003780 S.RESISTOR
R62 7030003720 S.RESISTOR
R63 7030003770 S.RESISTOR
R64 7030003780 S.RESISTOR
R65 7030003360 S.RESISTOR
R67 7030003200 S.RESISTOR
R68 7030003680 S.RESISTOR
R69 7030003800 S.RESISTOR
R70 7030003680 S.RESISTOR
R71 7030003800 S.RESISTOR
R72 7030003680 S.RESISTOR
R73 7030003320 S.RESISTOR
R74 7030003520 S.RESISTOR
R78 7030003680 S.RESISTOR
R80 7030003340 S.RESISTOR
R82 7030003200 S.RESISTOR
R83 7030003460 S.RESISTOR
R86 7030003460 S.RESISTOR
R87 7030003440 S.RESISTOR
R88 7030003680 S.RESISTOR
R89 7030003400 S.RESISTOR
R90 7030005320 S.RESISTOR
R91 7030008120 S.RESISTOR
R92 7030003440 S.RESISTOR
R95 7030003440 S.RESISTOR
R96 7030003580 S.RESISTOR
R97 7030003440 S.RESISTOR
R98 7030007330 S.RESISTOR
R99 7030003560 S.RESISTOR
R100 7030003680 S.RESISTOR
R101 7030003560 S.RESISTOR
R102 7030003680 S.RESISTOR
R103 7030003320 S.RESISTOR
R104 7030003620 S.RESISTOR
R105 7030003560 S.RESISTOR
C1 4030006900 S.CERAMIC
C2 4030007170 S.CERAMIC
C3 4030007010 S.CERAMIC
C4 4030007020 S.CERAMIC
C5 4030008630 S.CERAMIC
C6 4030006860 S.CERAMIC
C7 4030006860 S.CERAMIC
C8 4030007000 S.CERAMIC
C9 4030007000 S.CERAMIC
C10 4030006860 S.CERAMIC
C11 4030006900 S.CERAMIC
C13 4030009520 S.CERAMIC
C15 4030009520 S.CERAMIC
C16 4550000510 S.TANTALUM
C17 4550006140 S.TANTALUM
6 - 3
DESCRIPTION
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 1R0 V (1 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 820 V (82 Ω)
ERJ3GEYJ 330 V (33 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 103 V (10 kΩ)
MCR10EZHJ 150 Ω (151)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 820 V (82 Ω)
[M1EURO V] only
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 684 V (680 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 564 V (560 kΩ)
ERJ3GEYJ 684 V (680 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 471 V (470 Ω)
RR0816P-103-D (10 kΩ)
RR0816P-682-D (6.8 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ1WRSJR15U (0.15 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
C1608 JB 1E 103K-T-A
C1608 CH 1H 221J-T-A
C1608 CH 1H 100D-T-A
C1608 CH 1H 120J-T-A
C1608 JF 1C 104Z-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 090D-T-A
C1608 CH 1H 090D-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1E 103K-T-A
C1608 CH 1H 020B-T-A
C1608 CH 1H 020B-T-A
TESVA 1V 473M1-8L
ECST1EY474R
S.=Surface mount
