Page 1: Photo Frame
DIGITAL PHOTO FRAME ENERGY Photo Frame 730 Series Manual de usuario/User manual/Manuel de l’utilisateur... - Page 2 User manual...
-
Page 3: Care And Maintenance
INTRODUCTION ≥ Energy Sistem® thanks you for buying your new digital photo frame Energy™ Photo Frame 730. We wish you enjoy using it. This digital photo frame is a perfect gift to remember the most special moments, you can enjoy or share your photos and video by exceptional picture quality. SlideShow with music background, all simply from a USB pen drive or memory cards. -
Page 4: Main Features
MAIN FEATURES ≥ 7” TFT LED backlight screen. ≥ 16:9 Widescreen format. ≥ 800x480 pixels resolution. ≥ Compatible with the JPG pictures of the majority of the digital cameras with maximum resolution 8000 x 8000 pixels. ≥ Plays audio with MP3, WMA and WAV files. ≥... - Page 5 Brightness, contrast, color and tone adjustments. ≥ Allows picture rotation and 5 levels of zoom. ≥ Built-in memory available for storing your favorite photos. ≥ File browser function and data indication. ≥ Auto On / Off function for energy saving.
-
Page 6: Product Content
Allows deleting files from memory card or USB pendrive. ≥ Slim remote control. ≥ AC/DC power adapter (Europlug). Input 100-240V; Output 5V/1.5A. PRODUCT CONTENT ≥ Energy Sistem® digital photo frame Energy™ Photo Frame 730. ≥ User manual. ≥ Slim remote control. ≥ AC/DC power adapter (Europlug). -
Page 7: General Overview
GENERAL OVERVIEW ON/OFF: Turn on-off the digital photo frame. BACKWARD/UP: Go up one position in the current menu / rotate the current image / move the current view up when applying zoom to an image / BACKWARD function. - Page 8 NEXT/VOL+: Show next image / move the current view to the right when applying zoom to an image / add value in the setting options menu / volume up. PLAY/PAUSE: Show the selected image in full screen / execute the option currently selected in the menu / start or pause the slideshow / reproduce, pause or resume the files of audio and video / enter or exit from the current folder.
-
Page 9: Remote Control
REMOTE CONTROL MODE MUTE MENU EXIT 12 11 SETUP 15 14 VOL- VOL+ ZOOM 18 17 ROTATE ON/OFF: Turn on/off the digital photo frame. MODE: Adjust the image mode from the full screen image. - Page 10 MUTE: Sound Off / On. MENU: Return to the memory menu / appear the option of “Delete file” from picture miniature, selected folder or selected file / appear the options of “Save picture”, “Rotate” and “Zoom” from the full screen picture / appear the options of “Set as alarm”...
-
Page 11: Main Menu
DOWN: Go down one position in the current menu / rotate the current image / move the current view down when applying zoom to an image. BGM: Activate background music. VOL-: Volume up. VOL+: Volume down. ZOOM: Perform a zoom to the current image (up to 5 zoom levels are available). BACKWARD. -
Page 12: Power Source
CALENDAR SETTINGS POWER SOURCE Your Energy™ Photo Frame 730 is powered through the AC/DC 5V adapter provided with the product. Please firstly connect the photo frame with the power adapter then connect the power adapter with electrical outlet. The remote control is powered by a CR2025 3V lithium battery that you can easily replace when depleted by releasing the battery compartment in the back of the remote control. -
Page 13: Switching On/Off
SWITCHING ON / OFF To power on your Energy™ Photo Frame 730 just plug in the provided power adapter to a 100-240V AC source and press the ON/OFF button located on the back side of the frame or press the ON/OFF button from remote control. -
Page 14: Slide Show
you can use the UP and DOWN buttons to select and use the PLAY/PAUSE button to confirm the operation. IMAGE DISPLAY IN FULL SCREEN From picture miniatures, you can view the currently selected image in full screen by pressing PLAY/PAUSE button. When in full screen view mode, you can manually move to the next pictures, using the PREVIOUS and NEXT buttons. - Page 15 PAUSE button again. Note: Only when slideshow mode is deactivated, it is possible to change the pictures displayed manually by using the PREVIOUS / NEXT buttons. You can access other functions too, such as zoom or rotate image. Important: Do not leave the same image still for more than one day because you risk damaging the TFT screen.
- Page 16 VIDEO You can access to this function from the main menu of your Energy™Photo Frame 730, by selecting the “VIDEO” option with the UP / DOWN and PLAY/PAUSE buttons.
- Page 17 MUSIC SELECT AND PLAY MUSIC You can access to this function from the main menu of your Energy™Photo Frame 730, by selecting the “MUSIC” option with the UP / DOWN and PLAY/PAUSE buttons. After that, you will see a list of audio files stored in the memory device (e.g. pendrive or memory cards), with the indication of title, duration, size and order of each file.
-
Page 18: File Explorer
EBOOK You can access to this function from the main menu of your Energy™Photo Frame 730, by selecting the “EBOOK” option with the UP / DOWN and PLAY/PAUSE buttons. After that, you will see a list of files by TXT format stored in the memory device (e.g. - Page 19 “Delete file” option with the UP / DOWN buttons and the PLAY/PAUSE buttons. CALENDAR You can access this function from the main menu of your Energy™Photo Frame 730, selecting the option “CALENDAR” by pressing the UP / DOWN and PLAY/PAUSE buttons.
- Page 20 LANGUAGE: Shows the available languages for the different menus and information, and allows choosing the one we prefer. PHOTO SEQUENCE: From this option it is possible to select the display order between “Sequence” and “Random”. BOOT MODE: From this option it is possible to select the boot mode once turn on the digital frame, the available options are “Slideshow”, “Music”, “Video”, “Calendar”...
-
Page 21: Image Mode
“random” option. ≥ IMAGE MODE: Allows choosing between the following 3 automatic image adjustments modes: ≥ Auto Fit: The image is adjusted to display in the screen, respecting the original proportions. ≥ Optimal: The image expands vertically and horizontally to fit the (full) screen, respecting the original proportions and the screen resolution. - Page 22 Allows resetting the digital photo frame to the default values. USB HOST / M-EX Your Energy™ Photo Frame 730, as well as showing your favorite pictures stored in SDHC/ SD/MMC/MS memory cards, can also load and display pictures from USB devices such as...
-
Page 23: Troubleshootings
pen drives. Just plug in the pen drive to the USB HOST input located on the back side of the digital photo frame, the system will detect the compatible image files stored. TROUBLE SHOOTINGS ≥ Why can’t the digital photo frame display my .JPG files? Many digital cameras and image edition software add hidden data to the .JPG files. - Page 24 Over a period of 36 months from the date of first purchase by the consumer, in accordance with the RDL 1 / 2007, Energy Sistem Soyntec SA will be held liable for any lack of conformity that exists at the time of delivery of goods in the terms and under the conditions of the rule.
- Page 25 the RD 1 / 2007. The 36-months warranty is valid for the European Union. For other countries, please refer to your specific legislation or your local distributor. GUARANTY PROCEEDINGS Entering http://support.energysistem.com and after selecting your product you can find FAQ’s (answers to Frequently Asked Questions), manuals, user guides, drivers and updates.
-
Page 26: Declaration Of Conformity
Energy Sistem help desk team will not perform any backup of the memory contents, so it is advisable to deliver the player with blank memory or with the original factory content. - Page 27 We declare under our own exclusive responsibility that the product: Energy Sistem® Digital Frame Energy™ Photo Frame 730 Series Manufactured in: China This symbol on the product or the instructions means that your electrical and electronic equipment should be disposed at the end of life separately from your household waste.
