CHAPTER 3 – SPECIFICATIONS

Additional Information for the MTSMC-H5 Serial Device

Mode
IDLE mode (WCDMA)
AT+CFUN=5
IDLE mode (GSM/EDGE)
AT+CFUN=1
AT+CFUN=5
Reset hold
AT+CFUN=7
Operative mode (WCDMA)
WCDMA HSPA+ (0dBm)
WCDMA HSPA+ (22dBm)
Operative mode (EDGE)
EDGE 4TX+2RX
GSM900 PL5
DCS1800 PL0
Operative mode (GSM)
GPRS 4TX+2RX
GSM900 PL5
DCS1800 PL0

Set Phone and Registration Functionality +CFUN

AT+CFUN=[<fun>[,<rst>]] Sets the functionality level in the ME.
<fun>
0
1
4
5
7
<rst>
0
1
21
Average (mA) Mode description
17ma Full Function with power save
30ma Normal mode: full functionality of the module
17ma Full function with power save.
13ma Deep sleep mode. Need to hold unit in reset event until
wake up. Disabled TX and RX and AT commands.
17-30 Full Function w/periodic power save.
286 WCDMA data call (Cat 14, TX = 0dBm)
610 WCDMA data call (Cat 14, TX = 22dBm)
EDGE Sending data mode
495
484
GPRS Sending data mode
580
438
Power saving function mode.
+CFUN=0 is not operational. The board wakes it.
Mobile full functions with power saving disabled. Default: 1.
Disable both TX and RX.
Mobile full functions with power saving enabled.
CYCLIC SLEEP mode. In this mode, the serial interface is periodically
enabled while CTS is active. If characters are recognized on the serial
interface, the ME stays active for 2 seconds after the last character was
sent or received. ME exits SLEEP mode only, if AT+CFUN=1 is entered.
Reset flag.
Do not reset the ME before setting it to <fun> function level.
Reset the device. The device is fully functional after the reset. This value is
available only for <fun> = 1
SocketModem Cell HSPA and SocketModem iCell HSPA MTSMC-H5 Device Guide
