Page 1: Mobile Printer
Mobile Printer SM-S200 SERIES Models: SM-S201 SM-S202 Hardware Manual... -
Page 2: Trademark Acknowledgments
This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. Hereby, Star Micronics Co., Ltd. declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. -
Page 3: Operating Precautions
Operating Precautions Please follow the precautions below to enjoy and maintain the full performance of the printer. Using the Printer ■ ● Some semiconductor devices are easily damaged by static electricity. You should turn the printer “OFF”, before you connect or removed the cable on the rear side, in order to guard the printer against the static electricity. -
Page 4: Choosing A Place For The Printer
Choosing a Place for the Printer Before actually unpacking the printer, you should take a few minutes to think about where you plan to use it. Remember the following points when doing this. P Choose a firm, level surface where the printer will not be exposed to vibration. P The power outlet you plan to connect to for power should be nearby and unobstructed. P Make sure that the printer is close enough to your host computer for you to connect the two. -
Page 5: Table Of Contents
Table of Contents 1. Introduction ..................5 2. Setting up the printer ..............6 2.1. Printer & Accessories ................6 2.2. Printer Features ..................7 2.3. Replacing Paper Roll ................8 2.4. Power Supply ..................10 2.4.1. Specified Power Supply ..................10 2.4.2. -
Page 6: Introduction
1. Introduction This printer is the ideal solution for Mobile banking system , Retail, point of sales, Credit card Transaction, other traveling and mobile computing etc. The general features of this printer are as follows: ● Pocket size (80 × 112 × 46 mm) ● Light weight (232 g) for true mobility ● Very silent printing thru direct thermal printing method ● High speed (80 mm/sec, MAX) -
Page 7: Setting Up The Printer
2. Setting Up the Printer 2.1. Printer & Accessories Your printer box should include these items. If any items are damaged or missing, please contact your dealer for assistance. Battery Charger Printer Paper Safety Instruction Sheet Communication Cable Battery Pack ( SERIAL CABLE SM-S ) ▼... -
Page 8: Printer Features
2.2. Printer Features ■ Part Name Cover Open Lever Paper Cover Protection Film Error Lamp Magnetic Stripe Reader ( Inside ) Power Lamp Feed Button Feed Button ※ Remove the Protection Film, if it’s not necessary. Platen Platen Gear Thermal Head Mechanism Ass’y Charge Connector Power Switch... -
Page 9: Replacing Paper Roll
2.3. Replacing Paper Roll Cautions : Be sure to use paper rolls that meet the specifications. Do not use paper rolls that have the paper glued to the core because the printer cannot detect the paper end correctly. 1. Make sure that the printer is not receiving data; otherwise, data may be lost. 2. - Page 10 3. Insert a new paper roll as shown. 4. Tear the excess paper off using the tear bar. - 9 -...
-
Page 11: Power Supply
2.4. Power Supply 2.4.1. Specified Battery Charger OUTPUT : DC 8.4 V/0.8 A (CC-CV) 2.4.2. Installing the Battery Cautions : 1) Before installing or removing the battery pack, ensure the printer is OFF. 2) If the printer is not used for long period of time, remove the battery pack from the printer. -
Page 12: Recharging The Battery Pack
● To extend battery life, it is recommended to use a smart energy management solution such as the Auto Power Down Mode available on all Star Micronics Portable Printers. ● When used at low temperatures, battery performance will temporarily decline. Be sure to have a fully-charged spare battery standing by if the printer will operate in a cold environment. -
Page 13: Memory Switch Settings
2.5. Memory Switch Settings 1. Change the Memory switch by this operation. (Refer to Table 1). MODE button : changing Printer MODE status FEED button : changing OPTION status. 2. [Example] The defaults of the printer are : Bluetooth/57600 bps/8 Data bit/No Parity/1 Stop bit/Density Medium If a user wants to change the defaults with RS-232C/9600 bps/7 Data bit/Even Parity/2 Stop bit/Density High u After pressing the MODE button simultaneously, if the ERROR lamp 5 turn... - Page 14 u Press FEED button one time. g You will see present STOP BIT mode in the LCD. Parity Bit g Stop Bit g Press the MODE button one time. (The stop bit has set to 2 stop bit.) 1 Stop Bit g 2 Stop Bit u Press FEED button one time.
- Page 15 Memory Switch Setting Table Printer Mode Setting RS-232C Communication Port Bluetooth * 9600 bps 19200 bps Baud Rate 38400 bps 57600 bps * 115200 bps 7 Data bit Data Bit 8 Data bit * No Parity * Parity Bit Odd Parity Even Parity 1 Stop bit * Stop Bit...
-
Page 16: Interface
3. Interface 3.1. RS-232C This printer has a RS-232C interface and is connected by means of a 4 pin mini USB socket. In the following table, the signals present on the Mini- USB socket are listed: Pin No. Name Direction Function Output Transmit Data... -
Page 17: Bluetooth
SPP (Serial Port Profile) PIN code: 1234 as default Device Name: Star Micronics Caution 1) If the quantity of data which is printed at once is more than 1M byte on Bluetooth communication, it would cause the buffer to overflow and the data to get damaged. -
Page 18: Using The Printer
4. Using the Printer 4.1. Control Panel Battery Capacity Status Mode Status Bluetooth Mode ERROR FEED MODE POWER Bluetooth Connection Status Display Data Transmission u Button FEED Button : When the printer is on, paper can be feed manually by pressing and holding the FEED button for more than one second. -
Page 19: The Self Test
4.2. The Self Test The self test procedure will check most of the printer functions. For self test, turn on the power while holding down the FEED button. The Self-Test checks the following : 1) Make sure paper roll has been installed properly. 2) The Self-Test prints the current printer status, which provides the control ROM version and the communication method setting. -
Page 20: Consumable Parts
5. Consumable Parts 5.1. Paper Roll Specifications Type : Thermal Paper Paper width : 57.5±0.5 mm 65±5 µm Paper thickness : Outer diameter : Ø39 mm or less Recording side : Outside of roll Cautions : 1) Do not paste the paper to the core. And the roll paper which has Near end mark printing on its near end is recommended. -
Page 21: Specifications
H/W Spec. MCU : 32bits RISC, FLASH : 4Mbytes, RAM : 8Mbytes Receive buffer size 1M bytes SM-S201 ISO 7810 / 7811 / 7812 1st and 2nd Track Reading SM-S202 ISO 7810 / 7811 / 7812 2nd and 3rd Track Reading 128×32 Dots FSTN (Blue LED Backlight) - Page 22 ■ Dimensions External Dimensions : 80 mm (width) × 112 mm (depth) × 46 mm (height) Weight : 232 g (Including Battery Pack) Body Color : Piano Black - 21 -...
- Page 23 - 22 -...
- Page 24 1150 King Georges Post Road, Edison, NJ 08837-3729 U.S.A. Tel: (int+1)-732-623-5555, Fax: (int+1)-732-623-5590 SPECIAL PRODUCTS DIVISION STAR MICRONICS EUROPE LTD. STAR MICRONICS CO., LTD. Star House, Peregrine Business Park, Gomm Road, 536 Nanatsushinya, Shimizu-ku, Shizuoka, High Wycombe, Bucks, HP13 7DL, U.K. 424-0066 Japan Tel: (int+44)-1494-471111, Fax: (int+44)-1494-473333...
