Page 1: Quick Start Guide
HD/SD-SDI TO VGA CONVERTER DAC-60 Quick Start Guide w w w . d a t a v i d e o . c o m... -
Page 2: Warranty
DVD Drives, Hard Drives are only covered for the first 10,000 hours, or 1 year (whichever comes first). Any second year warranty claims must be made to your local Datavideo office or one of its authorized Distributors before the extended warranty expires. -
Page 3: Packing List
Packing List DAC-60 Switching Adaptor 12V/500mA DAC-60 Quick Start Guide User Adjust Tool CD Front Panel HD/SD - SDI IN / OUT HD/SD - SDI input and pass-through output connectors. Power Switch Switches the power On / Off. DC In Socket Connects the supplied 12V PSU to this socket. -
Page 4: Rear Panel
Rear Panel VGA Output Connects your VGA equipment to this connector The LEDs indicate VGA output format Mode Select Selects VGA Output Format... -
Page 5: Dac-60 Installation
4. Connect optional SDI equipment to the BNC output connector. 5. Connect the +12V DC power adapter to the converter. LED Indication DAC-60 can work with six presets, which can be selected by pressing the menu button. LED Indication Resolution ●○○... - Page 6 Adjust Proc Amp Settings the Brightness, Contrast, Hue and Saturation port Please copy ‘’Adjust Proc Amp’’ tool from ‘’ User Adjust Tool ‘’ CD before you setting. Overview Application 1. Input format 2. Box firmware version 3. Brightness, Contrast, Hue and Saturation settings 4.
-
Page 7: Specifications
Specifications SD - 720 x 480 i / 720 x 576 i HD - 1280 x 720 50p/60p/59.94p Supported Input 1920 x 1080 50i/60i/59.94i Video Formats 1920 x 1080 24p/25p/30p 3G - 1920 x 1080 50p/60p/59.94p SD-SDI (SMPTE 259M) HD-SDI (SMPTE 292M) SDI Formats 3G-SDI (SMPTE 494M/495M) 800 x 600 60Hz...
