Page 1: Table Of Contents
Table of Contents Introduction Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo with CD AM/FM stereo cassette with CD Climate Controls Manual heating and air conditioning Electronic automatic temperature control Rear passenger climate control Lights Driver Controls Windshield wiper/washer control Steering wheel adjustment Power windows...
Page 2 Table of Contents Seating and Safety Restraints Seating Safety restraints Air bags Child restraints Driving Starting Brakes Traction control/AdvanceTrac Transmission operation Trailer towing Roadside Emergencies Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch Fuses and relays Changing tires Jump starting Wrecker towing Customer Assistance...
Page 4: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle the greater the safety and pleasure you will derive from driving it.
Page 5 Introduction SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury and prevent possible damage to others, your vehicle and its equipment? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol.
Page 6 This information may be stored during regular operation or in a crash or near crash event. This stored information may be read out and used by: • Ford Motor Company. • service and repair facilities. • law enforcement or government agencies.
Page 7 Using your vehicle as an ambulance Do not use this vehicle as an ambulance. Your vehicle is not equipped with the Ford Ambulance Preparation Package. Middle East/North Africa vehicle specific information For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner Guide;...
Page 8: Vehicle Symbol Glossary
Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Lower Warning Anchor Child Seat Tether Brake System Anchor Brake Fluid -...
Page 9 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
Page 10: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Standard instrument cluster Optional instrument cluster Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 11 Instrument Cluster On board diagnostics (OBD-II) in the Maintenance and Specifications chapter. If the light is blinking, engine misfire is occurring which could damage your catalytic converter. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced immediately.
Page 12 Instrument Cluster Air bag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains on, have the system serviced immediately. A chime will also sound when a malfunction in the supplemental restraint system has been detected.
Page 13 Instrument Cluster AdvanceTrac (if equipped): Illuminates when the AdvanceTrac system is active. If the light remains on, have the system serviced immediately. Four wheel drive low (if equipped): Illuminates when four-wheel drive low is engaged. Four wheel drive high (if equipped): Illuminates when HIGH four-wheel drive high is engaged.
Page 14: Gauges
Instrument Cluster GAUGES Standard instrument cluster gauges Optional instrument cluster gauges Speedometer: Indicates the current vehicle speed.
Page 15 Instrument Cluster Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
Page 16 Instrument Cluster Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine. Battery voltage gauge: Indicates the battery voltage when the ignition is in the ON position. If the pointer moves and stays outside the normal operating range (as indicated by arrows), have the...
Page 17: Entertainment Systems
Entertainment Systems PREMIUM IN-DASH SIX CD SOUND SYSTEM AUDIOPHILE IN-DASH SIX CD SOUND SYSTEM...
Page 18 Entertainment Systems 1. Seek: Works in radio ro CD mode. Press and release SEEK for previous/next strong station or track. 2. Rewind: In CD mode, press to reverse the CD Fast forward: In CD mode, press until desired selection is reached. 3.
Page 19 Entertainment Systems 6. Bass: Press BASS; then press to decrease/increase the bass output. Treble: Press TREB; then press to decrease/increase the treble output. 7. Select: Use with Bass, Treble, Balance and Fade controls to adjust levels. 8. Balance: Press BAL; then press to shift sound to the left/right speakers.
Page 20 Entertainment Systems 10. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. 11. CD: Press to select CD mode. 12. AM/FM: Press to select AM/FM frequency band. Autostore: Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2 .
Page 21 Entertainment Systems 17. Disc tune: Radio: Press to manually tune down or up the radio frequency band. CD: Press to select the previous track or to select the next track on the CD. • CD Door: Insert a CD label side up. PREMIUM AM/FM STEREO/CASSETTE/SINGLE CD 1.
Page 22 Entertainment Systems 3. CD Door: Insert a CD with the label side up. 4. Cassette door: Insert the cassette with the opening to the right. 5. Eject: Press to eject the cassette/CD. The radio will resume playing. 6. Tape: Press to start tape play. Press to stop tape during rewind/fast forward.
Page 23 Entertainment Systems 10. Balance: Press BAL; then press to shift sound to the left/right speakers. Fade: Press FADE; then press to shift sound to the rear/front speakers. 11. Memory preset buttons: To set a station: Select frequency band AM/FM, tune to a station, press and hold a preset button until sound returns.
Page 24 Entertainment Systems 18. Select (SEL): Use with Bass, Treble, Balance and Fade controls. 19. Bass: Press BASS; then press to decrease/increase the bass output. Treble: Press TREB; then press to decrease/increase the treble output. 20. Tune: Works in radio mode only. SEEK Press TUNE to change...
Page 25 Entertainment Systems RADIO RECEPTION FACTORS There are three factors that can affect radio reception: • Distance/strength: The further you travel from an FM station, the weaker the signal and the weaker the reception. • Terrain: Hills, mountains, tall buildings, power lines, electric fences, traffic lights and thunderstorms can interfere with your reception.
Page 26 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 27: Climate Controls
Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM 1. Temperature selection: Controls the temperature of the airflow in the vehicle. 2. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control. MAX A/C: Uses recirculated air through the instrument panel registers to cool the vehicle.
Page 28: Electronic Automatic Temperature Control
Climate Controls To aid in side window defogging/demisting in cold weather: 1. Select 2. Select A/C 3. Modulate the temperature control to maintain comfort. 4. Set the fan speed to HI 5. Direct the outer instrument panel vents towards the side windows To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel.
Page 29 Climate Controls 3. Passenger side temperature control: Controls the temperature on the passenger side of the vehicle when in dual zone mode. To enter dual zone, press the passenger temperature control or DUAL. The passenger temperature will appear in the display. 4.
Page 30 Climate Controls 13. Manual override controls: Allows you to manually determine where airflow is directed. To return to fully automatic control, press AUTO. 14. Driver’s side temperature control: Controls the temperature on the driver side of the vehicle. 15. Fan Speed: Used to manually enable or disable the fan speed.
Page 31 Climate Controls To aid in side window defogging/demisting in cold weather: 1. Select 2. Select A/C 3. Modulate the temperature control to maintain comfort. 4. Set the fan speed to HI 5. Direct the outer instrument panel vents towards the side windows To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel.
Page 32 Climate Controls 3. Fan control: Determines fan speed levels. Turn to REAR to give rear seat passengers control of the rear auxiliary controls. Otherwise, the front controls will determine the settings for the entire vehicle cabin. If set to OFF, the front and rear auxiliary controls will not function. Rear auxiliary controls (if equipped): Once the front auxiliary control is set to REAR, the rear seat passengers may use the rear auxiliary controls in the overhead console to make the...
Page 33 Climate Controls REAR WINDOW DEFROSTER The rear defroster control is located on the instrument panel. Press the rear defroster control to clear the rear window of thin ice and fog. • A small LED will illuminate when the rear defroster is activated. The ignition must be in the ON position to operate the rear window defroster.
Page 34: Lights
Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the headlamps on. Autolamp delay system The autolamp system sets the headlamps to turn on and off automatically. The autolamp control, located on the headlamp control, may be set to: •...
Page 35 Lights Always remember to turn on your headlamps at dusk or during inclement weather. The Daytime Running Light (DRL) System does not activate your tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision.
Page 36 Lights Move the control to the full down position (past detent) to prevent interior lamps from illuminating when the doors are opened. AIMING THE HEADLAMPS The headlamps on your vehicle are properly aimed before leaving the assembly plant. If your vehicle is involved in an accident or if you have problems fixing the alignment of your headlamps, have them checked by a qualified service technician.
Page 37 Lights 5. Locate the vertical adjuster for each headlamp. Adjust the aim by turning the adjuster control either clockwise (to adjust down) or counterclockwise (to adjust up). Note: Use a 4 mm socket or box wrench to turn the vertical adjuster control.
Page 38 Lights NOTE: If your vehicle is equipped with the Remote Keyless Entry feature, the courtesy lamp will remain on for 25 seconds after the door is shut or until the ignition is turned to the ON position. To use the reading lamps: •...
Page 39 Lights Function Number of bulbs Trade number Park/turn lamps 3157 AK (amber) (front) Headlamp high beam 9005 Headlamp low beam 9006 Rear stop/turn/tail 3157K lamps Rear license plate lamps Backup lamp 3156K High-mount stop lamps Fog lamp 9145 Cargo lamp 211-2 Interior overhead lamp 912 (906)
Page 40 Lights Replacing headlamp bulbs Do not touch the glass of a halogen bulb. 1. Turn off the headlamps and open the hood. 2. Pry up the two retainer pins until they stop to release the headlamps assembly from the vehicle, then pull headlamp forward.
Page 41 Lights Replacing front parking lamp/turn signal/sidemarker bulbs 1. Turn off the headlamp switch to off. 2. Remove headlamp screw from the bulb assembly. 3. Disengage lamp assembly. 4. Rotate the bulb socket counterclockwise and remove it from the lamp assembly. 5.
Page 42 Lights Replacing foglamp bulbs 1. Make sure the headlamp switch is in the OFF position and then remove the plastic splash shield, by removing the two screws on the front of the fenderwell. 2. Remove the bulb socket from the foglamp by turning it counterclockwise.
Page 43: Driver Controls
Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the INT1 speed of the wipers. Speed dependent wipers: When the wiper control is on, the speed of the wipers will automatically adjust with the vehicle speed.
Page 44 Driver Controls Changing the wiper blades 1. Pull the wiper arm away from the vehicle. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the arm.
Page 45 Driver Controls CENTER CONSOLE Your vehicle may be equipped with a variety of console features. These include: • Utility compartment with cassette/compact disc storage • Auxiliary power point • Cupholders • Tissue box holder (located on underside of console lid) •...
Page 46 Driver Controls Rear console features The rear console may incorporate the following features: • air vents • cupholders (will pull up with break away feature) • rear power point OVERHEAD CONSOLE (IF EQUIPPED) The appearance of your vehicle’s overhead console will vary according to your option package.
Page 47 Driver Controls Installing a garage door opener (if equipped) The storage compartment can be converted to accommodate a variety of aftermarket garage door openers: • Place the Velcro hook onto the side of the aftermarket transmitter opposite of the button. •...
Page 48 Driver Controls Illuminated visor mirror (if equipped) Lift the mirror cover to turn on the visor mirror lamps. AUXILIARY POWER POINT Power outlets are designed for accessory plugs only. Do not hang any type of accessory or accessory bracket from the plug. Improper use of the power outlet can cause damage not covered by your warranty.
Page 49: Power Windows
Driver Controls POWER WINDOWS When closing the power windows, you should verify they are free of obstructions and ensure that children and/or pets are not in the proximity of the window openings. Press and hold the bottom part of the rocker switch to open the window. Press and hold the top part of the rocker switch to close the window.
Page 50: Mirrors
Driver Controls POWER SIDE VIEW MIRRORS The ignition must be in the ACC or ON position to adjust the power side view mirrors. To adjust your mirrors: 1. Rotate the control clockwise to adjust the right mirror and rotate the control counterclockwise to adjust the left mirror.
Page 51: Speed Control
Driver Controls POWER ADJUSTABLE FOOT PEDALS (IF EQUIPPED) The accelerator and brake pedal should only be adjusted when the vehicle is stopped and the gearshift lever is in the P(Park) position. Press and hold the rocker control to adjust accelerator and brake pedal toward you or away from you.
Page 52 Driver Controls 3. Press the SET + control and release it. 4. Take your foot off the accelerator pedal. 5. The indicator light on the instrument cluster will turn on. COAST Note: • Vehicle speed may vary momentarily when driving up and down a steep hill.
Page 53 Driver Controls Increasing speed while using speed control There are two ways to set a higher speed: • Press and hold the SET + control until you get to the desired speed, then release the control. You can also use the SET + control to operate the Tap-Up COAST function.
Page 54 Driver Controls Turning off speed control There are two ways to turn off the speed control: • Depress the brake pedal. This will not erase your vehicles previously set speed. • Press the speed control OFF control. Note: When you turn off the speed control or the ignition, your speed control set speed memory is erased.
Page 55 Driver Controls In AM, FM1, or FM2 mode: • Press MEM to select preset stations within the selected radio band. In Tape mode: • Press MEM to select the next selection on the tape. In CD mode: • Press MEM to select the next selection on the CD.
Page 56 Driver Controls Press + or - to adjust fan speed. MOON ROOF (IF EQUIPPED) You can move the glass panel of the moon roof back to open or tilt up to ventilate the vehicle. To open the moon roof: The moon roof is equipped with an automatic, one-touch, express opening feature.
Page 57 Driver Controls Do not let children play with the moon roof. They may seriously hurt themselves. HOMELINK UNIVERSAL TRANSCEIVER (IF EQUIPPED) The HomeLink Universal Transceiver, located on the overhead console, provides a convenient way to replace up to three hand-held transmitters with a single built-in device.
Page 58 Driver Controls 1. Press and hold the two outside buttons releasing only when the red light begins to flash after 20 seconds. Do not repeat step one to program additional hand-held transmitters to the remaining two HomeLink buttons. This will erase previously programmed hand-held transmitter signals into HomeLink .
Page 59 Driver Controls Note: There are 30 seconds in which to initiate step eight. 8. Return to the vehicle and firmly press, hold for two seconds and release the HomeLink button. Repeat the press/hold/release sequence again, and, depending on the brand of the garage door opener (or other rolling code equipped device), repeat this sequence a third time to complete the programming.
Page 60 Driver Controls Operating the HomeLink Universal Transceiver To operate, simply press and release the appropriate HomeLink button. Activation will now occur for the trained product (garage door, gate operator, security system, entry door lock, or home or office lighting etc.). For convenience, the hand-held transmitter of the device may also be used at any time.
Page 61 Driver Controls ELECTRONIC COMPASS/TEMPERATURE DISPLAY (IF EQUIPPED) OUTSIDE AIR TEMPERATURE The outside temperature display is contained in the instrument cluster and displays all the time. If equipped with the DEATC climate control system, the outside temperature will be displayed there. To turn the display off or change the display from English to metric see your dealer.
Page 62 Driver Controls 3. Locate compass sensor mounted at base of mirror. 4. Press the button on the top of the compass module until ZONE appears in the instrument cluster display. 5. Release pressure on the button and then slowly press it down again. 6.
Page 63: Message Center
Driver Controls MESSAGE CENTER (IF EQUIPPED) With the ignition in the ON position, the message center, located on your instrument cluster, displays important vehicle information through a constant monitor of vehicle systems. You may select display features on the message center for a display of status preceded by a brief indicator chime.
Page 64 Driver Controls Compass display The compass reading may be affected when you drive near large buildings, bridges, power lines and powerful broadcast antenna. Magnetic or metallic objects placed in, on or near the vehicle may also affect compass accuracy. Usually, when something affects the compass readings, the compass will correct itself after a few days of operating your vehicle in normal conditions.
Page 65 Driver Controls 6. Release the RESET AND SETUP control, then slowly press RESET down again. 7. Press the SETUP control repeatedly until the correct zone setting for your geographic location is displayed on the message center. To exit the zone setting mode press and release the RESET control. 8.
Page 66 Driver Controls Average fuel economy for FFV-equipped vehicles Upon refueling, your vehicle must determine the percentage of Ethanol in the fuel. For the first several minutes, or few miles of driving, the message CALCULATING FUEL will appear in the message center. The correct fuel economy will appear within approximately five miles of driving.
Page 67 Driver Controls Setup menu Press this control for the following displays: • Autolock • Easy Entry/Exit • Autolamp Delay • Language • Units (English/Metric) • System Check • Oil Change Autolocks 1. Select this function from the SETUP control for the current display mode.
Page 68 Driver Controls Language 1. Select this function from the SETUP menu for the current language to be displayed. 2. Pressing the RESET control cycles the message center through each of the language choices. 3. Press and hold the RESET control to set the language choice. Units (English/Metric) 1.
Page 69 Driver Controls The sequence of the system check report and how it appears in the message center is as follows: 1. FUEL LEVEL 2. WASHER FLUID LEVEL 3. OIL LIFE IN XX% 4. ENGINE TEMP 5. OIL PRESSURE 6. TIRE PRESSURE SYSTEM (if equipped) 7.
Page 70 Driver Controls Warning display Status Warning-tire very low (if Warning returns every minute equipped) Check engine temperature Warning returns after 10 minutes Transmission overheated Check transmission Low fuel level Check fuel cap Check charging system Low brake fluid level Low oil pressure Check tire pressure (if Warning returns after the ignition key equipped)
Page 71 Driver Controls cool. Refer to Transmission fluid in the Maintenance and specifications chapter. If the warning stays on or continues to come on, contact your dealer for transmission service as soon as possible. CHECK TRANSMISSION. Indicates the transmission is not operating properly.
Page 72 Driver Controls LOW WASHER FLUID LEVEL. Indicates the washer fluid reservoir is less than one quarter full. Check the washer fluid level. Refer to Windshield washer fluid in the Maintenance and specifications chapter. CHECK ADVANCETRAC (if equipped). Displayed when the AdvanceTrac system is not operating properly.
Page 73 Driver Controls 3. Press and hold the RESET control for 2 seconds to display “IF NEW OIL HOLD RESET”. 4. Press and hold the RESET control to display OIL LIFE SET TO 100%. Your oil life is now reset. To reset the oil monitoring system to your personalized oil life %: 1.
Page 74 Driver Controls • Door sensor • Washer fluid • Brake fluid • Compass • Outside temperature • Engine sensor Contact your dealer as soon as possible if these messages occur on a regular basis. POSITIVE RETENTION FLOOR MAT Position the driver floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to lock in.
Page 75 Driver Controls To lock the liftgate and the liftgate window, use the power door locks or press the door lock switch on the left side of the cargo area. To manually lock or unlock the liftgate, move the button located below the window down or up.
Page 76 Driver Controls Cargo management system The cargo management system consists of storage compartments located in the floor of the rear cargo area. 7 passenger stowage: 1. To open, lift the release handle and the lid. 2. To close, lower the lid, lift the release handle and press down on the lid.
Page 77 Driver Controls To adjust cross-bar position (if equipped): 1. Loosen the thumbwheel at both ends of the cross-bar (both cross-bars are adjustable). 2. Slide the cross-bar to the desired location. 3. Tighten the thumbwheel at both ends of the cross-bar. Vehicles with a higher center of gravity such as utility and four-wheel drive vehicles handle differently than vehicles with a lower center of gravity.
Page 78: Locks And Security
Locks and Security KEYS One key operates all the locks and starts the vehicle. Always carry a spare key with you in case of an emergency. Your keys are programmed to your vehicle; using a non-programmed key will not permit your vehicle to start. If you lose your dealer supplied keys, replacement keys are available through your authorized dealer.
Page 79: Locks
Locks and Security Childproof door locks • When these locks are set, the rear doors cannot be opened from the inside. • The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 80 Locks and Security If there is any potential remote keyless entry problem with your vehicle, ensure ALL remote entry transmitters are brought to the dealership, to aid in troubleshooting. Unlocking the doors 1. Press and release to unlock the driver’s door. Note: The interior lamps will illuminate.
Page 81 Locks and Security Memory seat feature (if equipped) The remote entry system can also control the memory seat feature. Press to automatically move the seat to the desired memory position (the seat position corresponds to the transmitter being used). Activating the memory seat feature To activate this feature: 1.
Page 82 Locks and Security To replace the battery: 1. Twist a thin coin between the two halves of the remote entry transmitter near the key ring. DO NOT TAKE THE FRONT PART OF THE REMOTE ENTRY TRANSMITTER APART. 2. Remove the old battery. 3.
Page 83 Locks and Security 4. Cycle, eight times, rapidly (within 10 seconds) between the 1 (LOCK) position and 3 (ON). Note: The eighth turn must end in the 3 (ON) position. 5. The doors will lock, then unlock, to confirm that the programming mode has been activated.
Page 84 Locks and Security KEYLESS ENTRY SYSTEM (IF EQUIPPED) You can use the keyless entry keypad to: • lock or unlock the doors without using a key. • open the liftgate window. • activate or deactivate the autolock feature. • arm or disarm the perimeter alarm system (if equipped).
Page 85 Locks and Security 2. Press and hold the 1 • 2 for two seconds. This must be done within five seconds of completing step 1. 3. Press the 7 • 8 and the 9 • 0 at the same time. This must be done within five seconds of completing step 2.
Page 86: Anti-Theft System
Note: The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Large metallic objects, electronic devices that are used to purchase gasoline or similar items, or a second coded key on the same key chain may cause vehicle starting issues.
Page 87 Locks and Security engine. If a problem occurs, turn the ignition off, remove all objects on the key chain away from the coded key and restart the engine. Theft indicator The theft indicator is located on top of the instrument panel. •...
Page 88 Locks and Security Programming spare keys You can program your own coded keys to your vehicle. Please read and understand the entire procedure before you begin. Tips: • A maximum of eight keys can be coded to your vehicle. • Only use Securilock keys.
Page 89 Locks and Security 9. Remove the newly programmed coded key from the ignition. If the key has been successfully programmed it will start the vehicle’s engine and the theft indicator light will illuminate for three seconds and then go out. If the key was not successfully programmed, it will not start your vehicle’s engine and the theft indicator light will flash on and off, or stay on for more than three seconds.
Page 90 Locks and Security The parking lamps will flash once when all doors/hood/liftgate and liftgate window are closed indicating the vehicle is locked and entering the 20 second countdown. DISARMING THE SYSTEM You can disarm the system by any of the following actions: •...
Page 91 Locks and Security Deactivating/activating power door lock disable feature Before beginning the activation/deactivation procedure, verify that: • the perimeter alarm is not armed, • the ignition is in the OFF position, and • all doors, the liftgate and all windows are closed. 1.
Page 92: Seating And Safety Restraints
Seating and Safety Restraints SEATING Notes: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 93 Seating and Safety Restraints Push control to lower head restraint. Adjusting the front manual seat Never adjust the driver’s seat or seatback when the vehicle is moving. Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Lift handle to move seat forward or backward.
Page 94 Seating and Safety Restraints Adjusting the front power seat (if equipped) The control is located on the outboard side of the seat cushion. Press front to raise or lower the front portion of the seat cushion. Press rear to raise or lower the rear portion of the seat cushion.
Page 95 Seating and Safety Restraints Memory seat/easy entry/exit feature (if equipped) This system allows automatic positioning of the driver seat to two programmable positions. The memory seat control is located on the driver door. • To program position one, move the driver seat to the desired position using the seat controls.
Page 96 Seating and Safety Restraints Using the manual lumbar support For more lumbar support, turn the lumbar support control toward the front of vehicle. For less lumbar support, turn the lumbar support control toward the rear of vehicle. Heated seats (if equipped) To operate the heated seats: •...
Page 97 Seating and Safety Restraints REAR SEATS Folding down the 60/40 rear seats (if equipped) If the rear seat is equipped with adjustable head restraints, they should be placed in the full down position before folding the seat back down. 1. Press the lower release control downward to unlatch the seatback.
Page 98 Seating and Safety Restraints For assistance, refer to the label located on the lower position of the opening. 1. Locate handle on the side of the seat cushion by the door. 2. Push the handle up and push the seatback toward the front of the vehicle.
Page 99 Seating and Safety Restraints 3. To return the seat to a seating position, flip the seat into the upright position. 4. Make sure the seat is latched to the floor. To exit the 3rd row seat, pull the red access control lever up releasing the seat from the floor and rotate the seat up towards the front seat.
Page 100 Seating and Safety Restraints Folding the middle 2nd row seat (If equipped) 1. Locate the lever on the side of the seatback. 2. Pull the lever up and push the seatback toward the front of the vehicle. 3. Press down on the top outboard area of the seatback until a click is heard.
Page 101 Seating and Safety Restraints To put seat in stowed position: 1. Pull the seat release lever located on top of the seatback while pushing the seatback down onto the seat cushion. 2. The seatback will latch into place. 3. Push the closeout panel forward over the space between the seats.
Page 102: Safety Restraints
Seating and Safety Restraints 2. Pull the seat release lever located on top of the seatback while lifting the seatback into the upright position. 3. The seatback will latch into place. The third row seat is equipped with combination lap and shoulder belts in both seating positions.
Page 103 Seating and Safety Restraints information to the Restraints Control Module (RCM). During a crash, the RCM activates the safety belt pretensioners and/or either one or both stages of the dual-stage air bag supplemental restraints based on crash severity and occupant conditions. The fact that the pretensioners or air bags did not activate for both front seat occupants in a collision does not mean that something is wrong with the system.
Page 104 Seating and Safety Restraints effectiveness of the safety belts and helps properly position the occupant relative to the air bag to improve protection. The safety belt pretensioners can be either activated alone or, if the collision is of sufficient severity, together with the air bags. Front safety belt energy management retractors The front safety belt energy management retractors allow webbing to be pulled out of the retractor in a gradual and controlled manner in...
Page 105 Seating and Safety Restraints Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision. All occupants of the vehicle, including the driver, should always properly wear their safety belts, even when an air bag (SRS) is provided.
Page 106 Seating and Safety Restraints • This safety belt system has a retractor assembly that is designed to extend the seat belt webbing in a controlled manner. This helps reduce the belt force acting on the user’s chest. BELT AND RETRACTOR ASSEMBLY MUST BE REPLACED if the safety belt assembly automatic locking retractor feature or any other safety belt function is not operating properly when checked according to the procedures in Workshop Manual.
Page 107 Seating and Safety Restraints All safety restraints in the vehicle are combination lap and shoulder belts. All of the passenger combination lap and shoulder belts have two types of locking modes described below: Vehicle sensitive mode This is the normal retractor mode, which allows free shoulder belt length adjustment to your movements and locking in response to vehicle movement.
Page 108 Seating and Safety Restraints • Grasp the shoulder portion and pull downward until the entire belt is pulled out. • Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode.
Page 109 Seating and Safety Restraints When the Safety Canopy system or the front airbags are activated, the safety belt pretensioners for the driver and right front passenger seating positions will be activated when the respective seatbelt is properly buckled. The driver and the right front passenger seat belt system (including retractors, buckles and height adjusters) must be replaced if the vehicle is involved in a collision that results in deployment of front air bags and/or Safety Canopy...
Page 110 Seating and Safety Restraints Do not use extensions to change the fit of the shoulder belt across the torso. Safety belt warning light and indicator chime The safety belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten their safety belts. Conditions of operation If...
Page 111 Seating and Safety Restraints If... Then... The driver’s safety belt is not The BeltMinder feature is activated - buckled before the vehicle has the safety belt warning light reached at least 5 km/h (3 illuminates and the warning chime mph) and 1-2 minutes have sounds for 6 seconds every 30 elapsed since the ignition seconds, repeating for approximately...
Page 112 Seating and Safety Restraints Reasons given... Consider... “I was in a hurry” Prime time for an accident. BeltMinder reminds us to take a few seconds to buckle up. “Safety belts don’t work” Safety belts, when used properly, reduce risk of death to front seat occupants by 45% in cars, and by 60% in light trucks.
Page 113 Seating and Safety Restraints One time disable Any time the safety belt is buckled and then unbuckled during an ignition ON cycle, the BeltMinder will be disabled for that ignition cycle only. Deactivating/activating the BeltMinder feature Before following the procedure, make sure that: •...
Page 114 (if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies used in vehicles involved in a collision be replaced.
Page 115: Air Bags
Seating and Safety Restraints AIR BAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Air bags DO NOT inflate slowly; there is a risk of injury from a deploying air bag.
Page 116 Do not attempt to service, repair, or modify the air bag supplemental restraint systems or its fuses. See your Ford or Lincoln Mercury dealer. Modifications to the front end of the vehicle, including frame,...
Page 117 Seating and Safety Restraints Children and air bags Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position. Failure to follow these instructions may increase the risk of injury in a collision.
Page 118 Seating and Safety Restraints The air bags inflate and deflate rapidly upon activation. After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
Page 119 Seating and Safety Restraints The SRS consists of: • driver and passenger air bag modules (which include the inflators and air bags). • Safety canopy system (if equipped). Refer to Safety canopy system later in this chapter. • one or more impact and safing sensors. •...
Page 120 Do not attempt to service, repair, or modify the Safety Canopy system, its fuses, the A, B, or C pillar trim, or the headliner on a vehicle containing a Safety Canopy . See your Ford or Lincoln Mercury dealer. All occupants of the vehicle including the driver should always...
Page 121 Seating and Safety Restraints How does the Safety Canopy system work? The design and development of the Safety Canopy system included recommended testing procedures that were developed by a group of automotive safety experts known as the Side Airbag Technical Working Group.
Page 122 Seating and Safety Restraints The Safety Canopy is mounted to the roof side-rail sheet metal, behind the headliner, above the first and second row seats. In certain lateral collisions or rollover events, the Safety Canopy system will be activated, regardless of which seats are occupied. The Safety Canopy designed to inflate between the side window area and occupants to further enhance protection provided in side impact collisions and rollover events.
Page 123: Child Restraints
Seating and Safety Restraints • A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and light are repaired. If any of these things happen, even intermittently, have the SRS serviced at your dealership or by a qualified technician immediately. Unless serviced, the system may not function properly in the event of a collision or rollover event.
Page 124 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
Page 125 Seating and Safety Restraints Types of booster seats There are two types of belt-positioning booster seats: • Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder belt. If a seating position has a low seat back and no head restraint, a backless booster seat may place your child’s head (top...
Page 126 Seating and Safety Restraints Follow all instructions provided by the manufacturer of the booster seat. Never put the shoulder belt under a child’s arm or behind the back because it eliminates the protection for the upper part of the body and may increase the risk of injury or death in a collision. Never use pillows, books, or towels to boost a child.
Page 127 (passenger side front and outboard rear seating positions) (if equipped) section in this chapter. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with a tether anchor.
Page 128 Seating and Safety Restraints Installing child safety seats with combination lap and shoulder belts Air bags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active air bag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
Page 129 Seating and Safety Restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
Page 130 Seating and Safety Restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
Page 131 Seating and Safety Restraints Attaching child safety seats with tether straps Most new forward-facing child safety seats include a tether strap which goes over the back of the seat and hooks to an anchoring point. Tether straps are available as an accessory for many older safety seats. Contact the manufacturer of your child seat for information about ordering a tether strap.
Page 132 Seating and Safety Restraints 3. Locate the correct anchor for the selected rear seating position. When placing a child safety seat in the 2nd row center seating position of the 5 passenger vehicle, the tether straps may be attached to either of the tether anchors located at the rear of the cargo area.
Page 133 Seating and Safety Restraints 4. Clip the tether strap to the anchor. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 5. Refer to the Installing child safety seats in combination lap and shoulder belt seating positions section of this chapter for further instructions to secure the child safety seat.
Page 134 Seating and Safety Restraints Your vehicle has LATCH anchors for child seat installation at the seating positions marked with the child seat symbol: Never attach two LATCH child safety seats to the same anchor. In a crash, one anchor may not be strong enough to hold two child safety seat attachments and may break, causing serious injury or death.
Page 135 Follow the child seat manufacturer’s instructions to properly install a child seat with LATCH attachments. Two plastic LATCH guides can be obtained at no charge from any Ford or Lincoln-Mercury dealer. They snap onto the LATCH lower anchors in the seat to help attach a child seat with rigid attachments.
Page 136 Seating and Safety Restraints Each time you use the safety seat, check that the seat is properly attached to the lower anchors and tether anchor. Try to move the child seat from side to side. Also try to tug the seat forward. Check to see if the anchors hold the seat in place.
Page 137: Driving
Driving STARTING Positions of the ignition 1. OFF/LOCK, shuts off the engine and all accessories/locks the steering wheel, gearshift lever and allows key removal. 2. ACC, allows the electrical accessories such as the radio to operate while the engine is not running.
Page 138 Driving • Make sure the gearshift is in P (Park). 3. Turn the key to 3 (ON) without turning the key to 4 (START). HI TEMP LOW OIL SERVICE ENGINE SOON HIGH BRAKE...
Page 139 Driving Make sure the corresponding lights illuminate or illuminate briefly. If a light fails to illuminate, have the vehicle serviced. • If the driver’s safety belt is fastened, the light may not illuminate. Starting the engine 1. Turn the key to 3 (ON) without turning the key to 4 (START).
Page 140: Brakes
Driving If the engine fails to start using the preceding instructions (flexible fuel vehicles only) 1. Press and hold down the accelerator 1/3 to 1/2 way to floor, then crank the engine. 2. When the engine starts, release the key, then gradually release the accelerator pedal as the engine speeds up.
Page 141 Driving Four-wheel anti-lock brake system (ABS) Your vehicle is equipped with an Anti-lock Braking System (ABS). This system helps you maintain steering control during emergency stops by keeping the brakes from locking. Noise from the ABS pump motor and brake pedal pulsation may be observed during ABS braking; any pulsations or mechanical noise you may feel or hear is normal.
Page 142: Traction Control/Advancetrac
Driving The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the ignition is turned ON) until the parking brake is released. Always set the parking brake fully and make sure that the gearshift is securely latched in P (Park). The parking brake is not recommended to stop a moving vehicle.
Page 143 Driving to cool down. A limited AdvanceTrac function using only engine power reduction will still help control the wheels from over-spinning. When the brakes have cooled down, the system will again function normally. Anti-lock braking is not affected by this condition and will function normally during the cool-down period.
Page 144 Driving light with a “sliding car” icon in the instrument cluster that will flash when the system is active and an indicator light in the control button that will illuminate when the system is turned off. In vehicles with a message center, the message “ADVANCETRAC OFF”...
Page 145 Driving Aggressive driving in any road conditions can cause you to lose control of your vehicle increasing the risk of severe personal injury or property damage. The occurrence of an AdvanceTrac event is an indication that at least some of the tires have exceeded their ability to grip the road;...
Page 146: Transmission Operation
Driving Vehicles with a higher center of gravity such as utility and four-wheel drive vehicles handle differently than vehicles with a lower center of gravity. Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions.
Page 147 Driving 2. Locate the access cover plate to the brake-shift interlock override. It is located on the underside of the steering column. 3. Rotate the access panel (counterclockwise) with a flat head screw driver until it is lined up to the access hole in the open position.
Page 148 Driving 5. Return the cover plate (rotate clockwise) to the closed position. Start the vehicle. If it is necessary to use the above procedure to move the gearshift lever, it is possible that a fuse has blown or the vehicle’s brakelamps are not operating properly.
Page 149 Driving P (Park) This position locks the transmission and prevents the rear wheels from turning. To put your vehicle in gear: • Start the engine • Depress the brake pedal • Move the gearshift lever into the desired gear To put your vehicle in P (Park): •...
Page 150 Driving • To return to O/D (overdrive mode), press the transmission control switch. The O/D OFF lamp will not be illuminated. • O/D (Overdrive) is automatically returned each time the key is turned off. 3 (Third) Transmission operates in third gear only. Used for improved traction on slippery roads.
Page 151 Driving • the vehicle is in R (Reverse) but not moving backward (the brake pedal is depressed or the parking brake is applied), and a moving object is approaching the rear of the vehicle at a speed of 5 km/h (3 mph) or less.
Page 152 Driving The RSS detects obstacles up to 2 meters (6 ft.) from the rear bumper with a decreased coverage area at the outer corners of the bumper, (refer to the figures for approximate zone coverage areas). As you move closer to the obstacle, the rate of the tone increases.
Page 153 Driving LIMITED-SLIP AXLE (IF EQUIPPED) This axle provides added traction on slippery surfaces, particularly when one wheel is on a poor traction surface. Under normal conditions, the limited slip axle functions like a standard rear axle. Extended use of other than the manufacturer’s specified size tires on a limited slip rear axle could result in a permanent reduction in effectiveness.
Page 154 Driving Using the Control Trac 4WD system 4X4 AUTO - Power to all four wheels; used for normal street and highway driving. 4X4 HIGH (4WD High) - Used for extra traction such as in snow or icy roads or in off-road situations. Not intended for use on dry pavement. 4X4 LOW (4WD Low) - Uses extra gearing to provide maximum power to all four wheels.
Page 155 Driving 4. Press the desired 4WD position. • If shifting into 4X4 LOW (4WD Low), wait for the 4X4 LOW light in the instrument cluster to turn on indicating the shift is complete. • If shifting out of 4X4 LOW (4WD Low), wait for the 4X4 LOW light in the instrument cluster to turn off indicating the shift is complete.
Page 156 Driving pavement only after reducing your speed. Do not turn the steering wheel too sharply while returning to the road surface. • It may be safer to stay on the apron or shoulder of the road and slow down gradually before returning to the pavement. You may lose control if you do not slow down or if you turn the steering wheel too sharply or abruptly.
Page 157 Driving Do not spin the wheels at over 56 km/h (35 mph). The tires may fail and injure a passenger or bystander. Emergency maneuvers • In an unavoidable emergency situation where a sudden sharp turn must be made, remember to avoid “over-driving” your vehicle, i.e., turn the steering wheel only as rapidly and as far as required to avoid the emergency.
Page 158 Driving 4WD Systems 4WD (when you select a 4WD mode) uses all four wheels to power the vehicle. This increases traction, enabling you to drive over terrain and road conditions that a conventional two-wheel drive vehicle cannot. Power is supplied to all four wheels through a transfer case.
Page 159 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 160 Driving possibly rolling over. Whenever driving on a hill, determine beforehand the route you will use. Do not drive over the crest of a hill without seeing what conditions are on the other side. Do not drive in reverse over a hill without the aid of an observer. When climbing a steep slope or hill, start in a lower gear rather than downshifting to a lower gear from a...
Page 161 If you nevertheless decide to equip your 4WD for off-road use with tires larger than what Ford Motor Company recommends, you should not use these tires for highway driving. If you use any tire/wheel combination not recommended by Ford Motor...
Page 162 Failure to follow tire pressure recommendations can adversely affect the way your vehicle handles. Do not exceed the Ford Motor Company recommended pressure even if it is less than the maximum pressure allowed for the tire.
Page 163 Driving Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover). Failure to maintain your vehicle properly may void the warranty, increase your repair cost, reduce vehicle performance and operational capabilities and adversely affect driver and passenger safety.
Page 164 Driving Maintain steering wheel control at all times, especially in rough terrain. Since sudden changes in terrain can result in abrupt steering wheel motion, make sure you grip the steering wheel from the outside. Do not grip the spokes. Drive cautiously to avoid vehicle damage from concealed objects such as rocks and stumps.
Page 165 Driving If your vehicle gets stuck If your vehicle gets stuck in mud or snow it may be rocked out by shifting between forward and reverse gears, stopping between shifts, in a steady pattern. Press lightly on the accelerator in each gear. Do not rock the vehicle if the engine is not at normal operating temperature or damage to the transmission may occur.
Page 166 Driving Vehicles with a higher center of gravity such as utility and four-wheel drive vehicles handle differently than vehicles with a lower center of gravity. Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions.
Page 167 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 168 Driving possibly rolling over. Whenever driving on a hill, determine beforehand the route you will use. Do not drive over the crest of a hill without seeing what conditions are on the other side. Do not drive in reverse over a hill without the aid of an observer. When climbing a steep slope or hill, start in a lower gear rather than downshifting to a lower gear from a...
Page 169 Do not use a size and type of tire and wheel other than that originally provided by Ford Motor Company because it can affect the safety and performance of your vehicle, which could lead to loss of vehicle control or rollover and serious injury.
Page 170 Driving If you use any tire/wheel combination not recommended by Ford Motor Company, it may adversely affect vehicle handling and could cause steering, suspension, axle or transfer case failure as well as the increased risk of loss of vehicle control.
Page 171 Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover).
Page 172 Driving • GAWR (Gross Axle Weight Rating): Carrying capacity for each axle system. The GAWR is specific to each vehicle and is listed on the Safety Certification Label on the driver’s door pillar. • GCW (Gross Combined Weight): The combined weight of the towing vehicle (including occupants and cargo) and the loaded trailer.
Page 173: Trailer Towing
Driving SPECIAL LOADING INSTRUCTIONS FOR OWNERS OF PICKUP TRUCKS AND UTILITY-TYPE VEHICLES For important information regarding safe operation of this type of vehicle, see the Preparing to drive your vehicle section in this chapter. Loaded vehicles may handle differently than unloaded vehicles. Extra precautions, such as slower speeds and increased stopping distance, should be taken when driving a heavily loaded vehicle.
Page 174 Driving • Do not tow a trailer until your vehicle has been driven at least 800 km (500 miles). • Refer to the instructions included with towing accessories for the proper installation and adjustment specifications. Do not exceed the maximum loads listed on the Safety Compliance Certification label.
Page 175 Driving 4x4 w/automatic transmission GCWR (Gross Combined Weight Rating)/Trailer Weight Engine Rear axle ratio Maximum Trailer weight GCWR-kg (lbs.) range-kg (lbs.) (0-Maximum) 4.0L SOHC/4.6L* 3.55 3629 (8000) 0-1542 (0-3400) 4.0L SOHC 3.73 LS 4536 (10000) 0-2440 (0-5380) 4.6L* 3.73/3.73 LS 5262 (11600) 0-3166 (0-6980) Notes: - For high altitude operation, reduce GCW by 2% per 300 meters...
Page 176 Never connect any trailer lighting to the vehicle’s taillamp circuits, because it may damage the electrical system resulting in fire. Contact your local Ford dealership for assistance in proper trailer tow wiring installation. Additional electrical equipment may be required.
Page 177 Driving • Anticipate stops and brake gradually. • Do not exceed the GCWR rating or transmission damage may occur. Servicing after towing If you tow a trailer for long distances, your vehicle will require more frequent service intervals. Refer to your scheduled maintenance guide for more information.
Page 178 • Maximum distance is 80 km (50 miles). If a distance of 80 km (50 miles) or a speed of 56 km/h (35 mph) must be exceeded, you must disconnect the driveshaft. Ford recommends the driveshaft be removed/installed only by a qualified technician. See your local dealer for driveshaft removal/installation.
Page 179: Roadside Emergencies
Roadside Emergencies GETTING ROADSIDE ASSISTANCE To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: • 24–hours, seven days a week •...
Page 180: Hazard Flasher Switch
Roadside Emergencies Canadian customers who require roadside assistance, call 1–800–665–2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673; Lincoln vehicle customers call 1–800–521–4140.
Page 181: Fuses And Relays
Roadside Emergencies The fuel pump shut-off switch is located in the passenger’s foot well, by the kick panel. Use the following procedure to reset the fuel pump shut-off switch. 1. Turn the ignition to the OFF position. 2. Check the fuel system for leaks. 3.
Page 182 Roadside Emergencies Note: Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. Standard fuse amperage rating and color COLOR Cartridge Fuse Mini...
Page 183 Roadside Emergencies Passenger compartment fuse panel The fuse panel is located below the instrument panel on the driver’s side. To remove a fuse use the fuse puller tool provided on the fuse panel box.
Page 184 Roadside Emergencies The fuses are coded as follows: Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Memory seat module, Driver power seat Heated seats, Moonroof Radio, Amplifier, DVD Front wiper module Flasher relay (Turn, hazards) Right horn Heated mirrors –...
Page 185 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description ABS, IVD Controller Brake pedal position switch, Driver brake applied relay, Redundant cruise deactivate switch Cigar lighter, OBD II Mode-Temperature actuator for auxiliary climate control, Trailer tow battery charge coil 7.5A Park aid, Brake shift interlock, Approach lamp relay coil, IVD...
Page 186 Roadside Emergencies Passenger compartment fuse panel (top side) These relays are located on the reverse side of the passenger compartment fuse panel. See your dealer or a certified technician for service of this relay box. Fuse/Relay Location Description Relay 1 Flasher relay Relay 2 Rear defrost...
Page 187 Roadside Emergencies Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses. To reduce risk of electrical shock, always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs.
Page 188 Roadside Emergencies The high-current fuses are coded as follows: Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 60A** 30A** — Not used 30A** Rear defrost 40A** Anti-lock Brake System (ABS) pump 60A** Delayed accessory 20A** Power point #2 — Not used 20A** Power point #1...
Page 189 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 20A* Horn relay 60A** 20A** Rear wiper motor — Not used — Not used 30A** Auxiliary blower motor 30A** Passenger power seat, Adjustable pedals — Not used 40A** Blower motor 15A* A/C clutch relay, Transmission 15A*...
Page 190 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description — Starter relay — PTEC relay — Ignition relay — Driver brake applied relay (vehicles equipped with AdvanceTrac only) — PCM diode — A/C clutch diode 30A CB Power windows circuit breaker * Mini Fuses ** Maxi Cartridge Fuses Rear Relay Box The relay box is located on the rear passenger side quarter trim panel.
Page 191 Roadside Emergencies Fuse/Relay Location Description Relay 17 Not used Relay 18 Not used Relay 19 Trailer tow park lamps Relay 20 Trailer tow battery charge Relay 21 Not used Relay 22 Approach lamps Relay 23 Not used Diode 3 Not used Diode 4 Not used Auxiliary relay box (Canadian vehicles equipped with...
Page 192: Changing Tires
Roadside Emergencies CHANGING THE TIRES If you get a flat tire while driving: • do not brake heavily. • gradually decrease the vehicle’s speed. • hold the steering wheel firmly. • slowly move to a safe place on the side of the road. The use of tire sealants is not recommended and may compromise the integrity of your tires.
Page 193 Roadside Emergencies When one of the rear wheels is off the ground, the transmission alone will not prevent the vehicle from moving or slipping off the jack, even if the transmission is in P (Park). Note: Passengers should not remain in the vehicle when the vehicle is being jacked.
Page 194 Roadside Emergencies Removing the jack and tools 1. Open liftgate and remove the carpeted floor lid and jack cover. 2. Turn jack screw eyelet counterclockwise and remove the jack from the bracket. 3. Remove the tools from the provided bag. Rotate the wrench socket out from the handle.
Page 195 Roadside Emergencies Removing the spare tire Do not use an impact wrench on the winch drive nut. This will damage the spare tire winch. 1. Open the cover from the carpeting on cargo floor to expose the winch drive nut. 2.
Page 196 Roadside Emergencies 3. Turn the wrench counterclockwise until the tire is lowered to the ground and the cable has slack. When turning the wrench, make sure that it does not scuff the kick plate. 4. Slide the tire rearward, lift one side and remove the retainer from the spare tire.
Page 197 Roadside Emergencies 3. Assemble the jack handle extension on the lug nut wrench by sliding the square end of the jack handle through the plastic grommet on the lug nut wrench and into the square hole on the other side. If equipped with a two-piece extension, assemble the two-piece extension by sliding the two halves...
Page 198 Roadside Emergencies To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is only meant for changing the tire. •...
Page 199: Jump Starting
Roadside Emergencies ability, to the point where the ratchet/slip occurs, if possible. The spare tire carrier will not allow you to overtighten. If the spare tire carrier ratchets or slips with little effort, take the vehicle to your dealer for assistance at your earliest convenience.
Page 200 Roadside Emergencies Preparing your vehicle When the battery is disconnected or a new battery is installed, the transmission must relearn its shift strategy. As a result, the transmission may have firm and/or soft shifts. This operation is considered normal and will not affect function or durability of the transmission.
Page 201 Roadside Emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to the provided jumpstarting bolt.
Page 202 Roadside Emergencies 4.0L Engine 4.6L Engine...
Page 203 Roadside Emergencies 5. Ensure that the cables are clear of fan blades, belts, moving parts of both engines, or any fuel delivery system parts. Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2.
Page 204 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 205: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. If the vehicle’s battery is discharged, refer to Automatic transmission operation in the Driving chapter for directions on how to move the gearshift lever out of the P (Park) position, for proper towing.
Page 206: Customer Assistance
Ford Customer Relationship Center. Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 207 P.O. Box 2000 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) www.ford.ca In order to help you service your Ford or Lincoln Mercury vehicle, please have the following information available when contacting a Customer Relationship Center: • Your telephone number (home and business).
Page 208 5,000 participating Ford or Lincoln Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Please contact your dealer for further information. Since this information is subject to...
Page 209: The Dispute Settlement Board
THE DISPUTE SETTLEMENT BOARD (U.S. ONLY) The Dispute Settlement Board is: • an independent, third-party arbitration program for warranty disputes • available free to owners and lessees of qualifying Ford Motor Company vehicles The Dispute Settlement Board may not be available in all states. Ford...
Page 210 • The name of the dealer(s) who sold or serviced the vehicle. • A brief description of your unresolved concern. • A brief summary of the action taken by the dealer(s) and Ford Motor Company. • The names (if known) of all the people you contacted at the dealership(s).
Page 211 After a case is reviewed, the Board mails you a decision letter and a form on which to accept or reject the Board’s decision. The decisions of the Board are binding on Ford (and, in some cases, on the dealer) but not on consumers who are free to pursue other remedies available to them under state or federal law.
Page 212: Utilizing The Mediation/Arbitration
UTILIZING THE MEDIATION/ARBITRATION PROGRAM (CANADA ONLY) In those cases where you continue to feel that the efforts by Ford and the dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 213: Ordering Additional Owner's Literature
U.S.A. Telephone: (313) 594-4857 FAX: (313) 390-0804 If you are in another foreign country, contact the nearest Ford dealership. If the dealership employees cannot help you, they can direct you to the nearest Ford affiliate office. If you buy your vehicle in North America and then relocate outside of the U.S.
Page 214: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1–800–424–9393 (or 366–0123 in the Washington D.C.
Page 215: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral Ph shampoo, such as Motorcraft Detail Wash (ZC-3–A), which is available from your dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 216 • Do not use hydrofluoric acid-based or high caustic-based wheel cleaners, steel wool, fuels or strong household detergent. • To remove tar and grease, use Ford Extra Strength Tar and Road Oil Removal (B7A-19520–AA), available from your dealer. ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal.
Page 217 Cleaning • Cover the highlighted areas to prevent water damage when cleaning the engine. 4.6L V8 Engine 4.0L SOHC V6 Engine • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage.
Page 218 Use only approved products to clean plastic parts. These products are available from your dealer. • For routine cleaning, use Motorcraft Detail Wash (ZC-3–A). • If tar or grease spots are present, use Ford Extra Strength Tar and Road Oil Removal (B7A-19520–AA). WINDOWS AND WIPER BLADES The windshield, rear window and wiper blades should be cleaned regularly.
Page 219 For fabric, carpets, cloth seats and safety belts: • Remove dust and loose dirt with a vacuum cleaner. • Remove light stains and soil with Ford Extra Strength Upholstery Cleaner (E8AZ-19523–AA). • If grease or tar is present on the material, spot-clean the area first with Motorcraft Spot and Stain Remover (ZC-14).
Page 220 Cleaning FORD, LINCOLN AND MERCURY CAR CARE PRODUCTS Your Ford, Lincoln or Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 221: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS • Use the Scheduled Maintenance Guide to track routine service. • Use only recommended fuels, lubricants, fluids and service parts conforming to specifications. • Your dealership can provide parts and service. PRECAUTIONS WHEN SERVICING YOUR VEHICLE •...
Page 222 Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom left corner of the instrument panel.
Page 223 Maintenance and Specifications 2. Go to the front of the vehicle and release the auxiliary latch that is located under the front center of the hood. 3. Lift the hood.
Page 224: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.0L SOHC V6 engine 1. Engine coolant reservoir 2. Engine oil filler cap 3. Engine oil dipstick 4. Brake fluid reservoir 5. Power distribution box 6. Battery 7. Power steering fluid reservoir 8.
Page 225 Maintenance and Specifications 4.6L V8 engine 1. Engine coolant reservoir 2. Engine oil dipstick 3. Brake fluid reservoir 4. Power distribution box 5. Battery 6. Power steering fluid reservoir 7. Engine oil filler cap 8. Air filter assembly 9. Windshield washer fluid reservoir...
Page 226 Add fluid to fill the reservoir if the level is low. In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16–A2. Refer to Lubricant specifications in the Capacities and specifications chapter.
Page 227: Engine Oil
Maintenance and Specifications ENGINE OIL Checking the engine oil Refer to the scheduled maintenance guide for the appropriate intervals for checking the engine oil. 1. Make sure the vehicle is on level ground. 2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan.
Page 228 Maintenance and Specifications • 4.6L V8 engine 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. • If the oil level is between the MIN and MAX marks, the oil level is acceptable, DO NOT ADD OIL. •...
Page 229 Maintenance and Specifications • 4.0L SOHC V6 engine • 4.6L V8 engine • Oil levels above the MAX mark may cause engine damage. Some oil must be removed from the engine by a service technician. 7. Put the indicator back in and ensure it is fully seated. Adding engine oil 1.
Page 230 Only use oils “Certified For Gasoline Engines” by the American Petroleum Institute (API). Use Motorcraft or an equivalent oil meeting Ford Specification WSS-M2C153–H. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 231 Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford Material and design specifications, start-up engine noises or knock may be experienced.
Page 232: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the scheduled maintenance guide for the service interval schedules.
Page 233 Maintenance and Specifications When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
Page 234 Maintenance and Specifications If the battery has been disconnected or a new battery has been installed, the clock and the preset radio stations must be reset once the battery is reconnected. • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal.
Page 235 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “cold fill level” or within the “cold fill range” as listed on the engine coolant reservoir (depending upon application).
Page 236 The cooling system in your vehicle is filled with either green-colored Motorcraft Premium Engine Coolant meeting Ford specification ESE-M97B44–A or yellow-colored Motorcraft Premium Gold Engine Coolant meeting Ford Specification WSS-M97B51–A1. To determine your vehicle’s coolant type (color), check your coolant reservoir. • Add Motorcraft Premium Engine Coolant (green-colored), VC-4–A (U.S.) or CXC-10 (Canada) or Motorcraft Premium...
Page 237 Maintenance and Specifications • Do not mix with recycled coolant unless from a Ford-approved recycling process (see Use of Recycled engine coolant section). For vehicles with overflow coolant systems with a non-pressurized cap on the coolant recovery system, add coolant to the coolant recovery reservoir when the engine is cool.
Page 238 Operating an engine with a low level of coolant can result in engine overheating and possible engine damage. Recycled engine coolant Ford Motor Company recommends the use of a recycled engine coolant produced by Ford-approved processes in vehicles originally equipped with Motorcraft Premium Engine Coolant (green-colored). However, not all coolant recycling processes produce coolant that meets Ford specification ESE-M97B44–A.
Page 239 Maintenance and Specifications What you should know about fail-safe cooling (4.6L V8 engine only) If the engine coolant supply is depleted, this feature allows the vehicle to be driven temporarily before incremental component damage is incurred. The “fail-safe” distance depends on ambient temperatures, vehicle load and terrain.
Page 240: Fuel Information
Maintenance and Specifications 3. If this is not possible, wait a short period for the engine to cool. 4. Check the coolant level and replenish if low. Never remove the coolant reservoir cap while the engine is running or hot. 5.
Page 241 Maintenance and Specifications Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before fueling your vehicle. • Always turn off the vehicle before fueling. • Automotive fuels can be harmful or fatal if swallowed. Fuels such as gasoline and ethanol are highly toxic and if swallowed can cause death or permanent injury.
Page 242 Maintenance and Specifications and sugar cane. When ethanol is used in the making of motor fuels, a small amount of a bad tasting chemical is added to discourage beverage use. The resulting fuel is called E 100 meaning 100% pure ethanol diluted by 2% to 5% gasoline as the “denaturant.”...
Page 243 Maintenance and Specifications • DO NOT use a device that would hold the fuel pump handle in the fill position. Choosing the right fuel Use only UNLEADED FUEL. The use of leaded fuel is prohibited by law and could damage your vehicle. If your vehicle is a flexible fuel vehicle (FFV), use only UNLEADED FUEL and (E85) ETHANOL.
Page 244 Maintenance and Specifications Fuel quality Many of the world’s automakers issued the World-wide Fuel Charter that recommends gasoline specifications to provide improved performance and emission control system protection for your vehicle. Gasolines that meet the World-wide Fuel Charter should be used when available.
Page 245 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 246 Maintenance and Specifications If you do not use the proper fuel filler cap, excessive pressure or vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in possible personal injury.
Page 247 Maintenance and Specifications For consistent results when filling the fuel tank: • Turn the engine/ignition switch to the off position prior to refueling, an error in the reading will result if the engine is left running. • Use the same filling rate setting (low — medium — high) each time the tank is filled.
Page 248 Maintenance and Specifications during summer and winter will show how temperature impacts fuel economy. In general, lower temperatures give lower fuel economy. Driving style — good driving and fuel economy habits Give consideration to the lists that follow and you may be able to change a number of variables and improve your fuel economy.
Page 249 Maintenance and Specifications Conditions • Heavily loading a vehicle or towing a trailer may reduce fuel economy at any speed. • Carrying unnecessary weight may reduce fuel economy (approximately 0.4 km/L [1 mpg] is lost for every 180 kg [400 lb] of weight carried). •...
Page 250 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 251 Maintenance and Specifications On board diagnostics (OBD-II) Your vehicle is equipped with a computer that monitors the engine’s emission control system. This system is commonly known as the On Board Diagnostics System (OBD-II). This OBD-II system protects the environment by ensuring that your vehicle continues to meet government emission standards.
Page 252 Maintenance and Specifications CHECKING AND ADDING POWER STEERING FLUID Check the power steering fluid. Refer to the scheduled maintenance guide for the service interval schedules. If adding fluid is necessary, use only MERCON ATF. • 4.0L SOHC V6 engine • 4.6L V8 engine 1.
Page 253 Maintenance and Specifications BRAKE FLUID RESERVOIR The fluid level will drop slowly as the brakes wear, and will rise when the brake components are replaced. Fluid levels below the “MAX” line that do not trigger the brake system warning lamp are within the normal operating range, there is no need to add fluid.
Page 254 Use only fluid that meets Ford specifications. Refer to Lubricant Specifications in this chapter. DRIVELINE UNIVERSAL JOINT AND SLIP YOKE Your vehicle may be equipped with universal joints that require lubrication.
Page 255 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it. Treadwear...
Page 256 Maintenance and Specifications The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 257 Make sure that all replacement tires are of the same size, type, load-carrying capacity and tread design as originally offered by Ford. Do not replace your tires with “high performance” tires or larger size tires. Failure to follow these precautions, your vehicle handling may be adversely effected which can lead to loss of vehicle control, vehicle rollover and/or personal injury.
Page 258: Low Tire Warning System
Maintenance and Specifications Tire pressure monitoring system (TPMS) (if equipped) The tire pressure monitoring system provides the driver with a warning message indicating when tire pressure is severely low or high. This system is a supplement to normal tire maintenance including regular manual inspections.
Page 259 The tires on your vehicle have all-weather treads to provide traction in rain and snow. However, in some climates, using snow tires or traction devices may be necessary. Ford offers tire cables as a Ford approved accessory and recommends use of these or SAE class “S” tire cables. See your dealer or qualified service technician for more information on tire cables for your vehicle.
Page 260: Part Numbers
** If a spark plug is removed for inspection, it must be reinstalled in the same cylinder. If a spark plug needs to be replaced, use only spark plugs with the service number suffix letter as shown on the engine decal. REFILL CAPACITIES Fluid Ford Part Application Capacity Name Brake fluid...
Page 261 Maintenance and Specifications Fluid Ford Part Application Capacity Name Power steering Motorcraft Fill between the fluid MERCON ATF MIN and MAX lines on reservoir Transmission Motorcraft Automatic 12.0L (12.7 fluid MERCON V transmissions quarts) Transfer case Motorcraft 1.4L (1.5 MERCON ATF...
Page 262 Synthetic Rear Axle Lubricant, part number XY—75W140–QL or equivalent meeting Ford Specification WSL-M2C192–A. Limited Slip differentials must add 118ml (4 oz) of Additive Friction Modifier XL—3 or equivalent meeting Ford Specification EST-M2C118–A to the rear axle whenever the axle has been serviced.
Page 263: Lubricant Specifications
Maintenance and Specifications LUBRICANT SPECIFICATIONS Ford Part Ford Part Ford Item Name or Number Specification equivalent Body hinges, latches, door striker plates and rotors, seat Multi-Purpose ESR-M1C159-A tracks, fuel filler Grease or XG–4 or XL–5 door hinge and Multi-Purpose ESB-M1C93–B...
Page 264 MERCON V. Refer to your scheduled maintenance guide to determine the correct service interval. Limited slip differentials must add 118 ml (4 oz) of Additive Friction Modifier XL—3 or equivalent meeting Ford specification EST-M2C118–A to the rear axle whenever the axle has been serviced.
Page 265 Maintenance and Specifications ENGINE DATA Engine 4.0L SOHC V6 4.6L V8 engine engine Cubic inches Required fuel 87 octane 87 octane Firing order 1-4-2-5-3-6 1-3-7-2-6-5-4-8 Spark plug gap 1.3-1.4 mm 1.3-1.4 mm (0.052-0.056 (0.052-0.056 inch) inch) Ignition system EDIS EDIS Compression ratio 9.7:1 9.4:1...
Page 266 Maintenance and Specifications * Height includes roof rack and P255/70R16 tire...
Page 267 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification label be affixed to a vehicle and prescribe where the Certification label may be located. The Certification label is located on the front door latch pillar on the driver’s side.
Page 268 Maintenance and Specifications 6. Model year 7. Assembly plant 8. Production sequence number Engine number The engine number (the last eight numbers of the vehicle identification number) is stamped on the engine block, transmission, frame and transfer case (if equipped).
Page 269: Accessories
Accessories FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of genuine Ford accessories are available for your vehicle through your local authorized Ford, Lincoln Mercury or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 270 Accessories Travel equipment Ash cup Automatic headlamps with daytime running lights (DRL) Cargo Organizer Cellular phone holder Chrome wheels Daytime running lights (DRL) Dog guard DVD — Rear entertainment system Factory luggage rack adaptors (bike and ski) First aid kit Fog lamps Full vehicle cover Highway safety kit...
Page 271 Accessories Trailer hitch (Class IV) Trailer hitch bars and balls Trailer hitch mount bike carrier Trailer hitch receiver cover Trailer hitch wiring adaptor Protection and appearance equipment Air bag anti-theft locks All-weather floor mats B-pillar trim kit Cargo liners, interior Carpet floor mats Door edge guards Front end covers (full and sport)
Page 272 (Citizens band [CB] transceivers, garage door openers and other transmitters with outputs of five watts or less will not ordinarily affect your vehicle’s operation.) • Ford cannot assume responsibility for any adverse effects or damage that may result from the use of such equipment.
Page 273: Index
Index acid, treating emergencies ..232 jumping a disabled battery ..199 maintenance-free ....232 Accessory delay ......49 replacement, specifications ...260 Air bag supplemental restraint servicing ........232 system ........115, 120 BeltMinder .........110 and child safety seats ....117 description ......115, 120 Brakes ........140 disposal ........123 anti-lock ........141 driver air bag ....117, 121 anti-lock brake system (ABS)
Page 274 Dual automatic temperature specifications ....263, 265 control (DATC) ......28 Cruise control (see Speed control) ....51 Customer Assistance ....179 Electronic message center ..63 Ford accessories for your Emergencies, roadside vehicle ......220, 269 jump-starting ......199 Ford Extended Service Plan ..........208 Emission control system ..250 Getting assistance outside the Engine ........265...
Page 275 Index Engine oil ........227 Fuel - flex fuel vehicle checking and adding ....227 (FFV) .........240, 243 dipstick ........227 Fuses ........181, 183 filter, specifications ..230, 260 recommendations ....230 refill capacities ......260 specifications ....263, 265 Garage door opener ....47, 57 Exhaust fumes ......140 Gas cap (see Fuel cap) ....245 Gas mileage (see Fuel economy) ........246...
Page 276 Index Hood ..........222 GAWR ........171 GVWR ........171 trailer towing ......171 Loading instructions ....173 Ignition .......137, 265 Locks Infant seats (see Safety seats) 126 childproof ........79 Inspection/maintenance (I/M) doors ..........78 testing ........251 Lubricant specifications ...263, 265 Instrument panel cleaning ........218 Lumbar support, seats ....96 cluster ........10 Manual transmission Jack ........192, 194...
Page 277 Index Pedals (see Power adjustable belt minder ......110 foot pedals) .........51 extension assembly ....109 for adults ......105–108 Power adjustable foot pedals ..51 for children ......123 Power distribution box safety belt maintenance ..114 (see Fuses) .......187 warning light and chime ..110 Power door locks ......78 Safety seats for children ..126 Power point ......46, 48...
Page 278 Index treadwear ........255 Vehicle Identification Number (VIN) ..........267 Towing ........173 Vehicle loading ......171 recreational towing ....178 trailer towing ......173 Ventilating your vehicle ...140 wrecker ........205 Traction control ......142 Transfer case Warning lights (see Lights) ..10 fluid checking ......254 Washer fluid ......226 Transmission ......146 Water, Driving through .....171 fluid, checking and adding...
