SPLIT TYPE
ROOM AIR CONDITIONER
WALL MOUNTED
Models
Indoor unit
ASH9USCCW
ASH9USCCW
ASH12USCCW
CONTENTS
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OUTLINE AND DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . .
REFRIGERANT SYSTEM DIAGRAM . . . . . . . . . . . . . . . . . . . .
CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INDOOR PRINTED CIRCUIT BOARD CIRCUIT DIAGRAM . . .
ERROR CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DISASSEMBLY ILLUSTRATION . . . . . . . . . . . . . . . . . . . . . . . .
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
STANDARD ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . 16
type
Outdoor unit
AOH9USCC
AOH9UFCC
AOH12USCC
1
2
4
5
7
8
9
14
Advertisement
Table of Contents
Related Manuals for Fujitsu ASH9USCCW
Summary of Contents for Fujitsu ASH9USCCW
-
Page 1: Room Air Conditioner
SPLIT TYPE ROOM AIR CONDITIONER WALL MOUNTED type Models Indoor unit Outdoor unit ASH9USCCW AOH9USCC ASH9USCCW AOH9UFCC ASH12USCCW AOH12USCC CONTENTS SPECIFICATIONS ........ -
Page 2: Specifications
SPECIFICATIONS TYPE COOLING & HEATING ASH9USCCW ASH12USCCW INDOOR UNIT AOH9USCC AOH9UFCC AOH12USCC OUTDOOR UNIT COOLING CAPACITY ( kW ) 2.60 2.60 3.25 HEATING CAPACITY ( kW ) 2.95 2.95 3.95 ELECTRICAL DATA POWER SOURCE 230V 50Hz 230V 50Hz 230V 50Hz... - Page 3 DIMENSIONS INDOOR UNIT Unit : mm Models : ASH9USCCW ASH12USCCW 2005.02.18...
- Page 4 OUTDOOR UNIT Unit : mm Model : AOY9USCC AOY9UFCC Model : AOY12USCC Drain pipe hold 20 2004.11.30...
-
Page 5: Refrigerant System Diagram
REFRIGERANT SYSTEM DIAGRAM Models : ASY9USCCW / AOY9USCC ASY9USCCW / AOY9UFCC OUTDOOR UNIT INDOOR UNIT Capillary tube for heating and cooling Dryer or Strainer Refrigerant pipe 6.35mm(1/4") 2-Way Check valve valve Compressor Evaporator Condenser 4-Way valve Refrigerant pipe 9.52mm(3/8") 3-Way Charging valve valve Models : ASY12USCCW / AOY12USCC... -
Page 6: Circuit Diagram
CIRCUIT DIAGRAM Models : ASY9USCCW ASY12USCCW Thermistor (Room Temp.) Thermistor (Pipe Temp.) 2 3 4 5 Stepping Motor Display PCB Controller PCB 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 Fan Motor 1 2 3 4 5 6 7 8 Relay Fan Motor... - Page 7 Models : AOY9USCC AOY12USCC FAN MOTOR WHITE TERMINAL CAPACITOR DARK GRAY WHITE WHITE COMPRESSOR COMPRESSOR CAPACITOR FAN MOTOR OVERLOAD FOUR WAY RELAY BLUE VALVE COIL DARK GRAY BLACK Model : AOY9UFCC FAN MOTOR WHITE TERMINAL CAPACITOR DARK GRAY WHITE WHITE COMPRESSOR COMPRESSOR CAPACITOR...
-
Page 8: Indoor Pcb Circuit Diagram
Jumper wire configurations INDOOR PCB CIRCUIT DIAGRAM Switch Function ON/Linked OFF/Open Heating compensation POWER TRANSFORMER Cooling compensation Auto restart enable disable Custom code CONTROLLER PCB ASSEMBLY (MAIN PCB) EZ-002YHSE-C (F) POWER SUPPLY PCB I C 1 R29 10K uPD780024-X06-8ET <1/10W> MANUAL AUTO SWITH FAN MOTOR... -
Page 9: Error Contents
ERROR DISPLAY Large division indication Small division indication LED flashing LED flashing Error contents Error contents timer operation timer operation 0.5 second thermistor 0.1 second room temp. thermistor error 2 times 0.1 second 0.5 second 2 times 0.5 second 0.1 second heat exchanger thermistor error 3 times 0.5 second... - Page 10 D I S A S S E M B L Y I L L U S T R A T I O N Models : ASH9USCCW ASH12USCCW 2005.02.18...
- Page 11 Models : ASY9USCCW ASY12USCCW 2004.11.30...
- Page 12 Model : AOY9USCC 2005.01.07...
- Page 13 Model : AOY9UFCC 2005.01.07...
- Page 14 Model : AOY12USCC 2004.11.30...
-
Page 15: Parts List
PARTS LIST INDOOR UNIT Part No. Ref. Ord. Description Q'ty ASH9USCCW ASH12USCCW Capacitor (Fan Motor) 9900089061 9900089061 Panel (Front) Total Assy 9312172085 9312172115 Flow Control Panel-Z 9306058012 9306058012 Louver-A 9306055028 9306055028 Filter 9305444014 9305444014 Base 9309755062 9309755062 Casing 9306052027 9306052027... -
Page 16: Outdoor Unit
OUTDOOR UNIT Part No. Part No. Ref. Ord. Ref. Ord. Description Description Q'ty Q'ty AOH9USCC AOH9UFCC AOH12USCC Emblem-Rear 9308474018 9308474018 Emblem-Rear 9308474018 Cabinet Front Panel, Plastic 9306016012 9306016012 Cabinet Front Panel, Plastic 9306386016 Connector Cover 9306018016 9306018016 Connector Cover 9306119010 Cabinet Rear Panel, Plastic 9306017019 9306017019... -
Page 17: Standard Accessories
STANDARD ACCESSORIES Name and Shape Part No. Wall hook bracket 9304358008 Remote control unit 9312058020 Battery (penlight) 0600185534 Tapping screw ( 4 x 25 ) 0700076046 Cloth tape 9308117007 Drain pipe (Including drain packing) 9303029015 2004.12.01... - Page 18 0309G2373...
