Lenovo THINKPAD R60 Setup Poster

R60 models Setup Poster
P/N 42T7974
8/18/2006
Unpack
ThinkPad(R) computer Battery pack
2 TrackPoint(R) caps Manuals
See reverse for notes about unlist ed, missing, or damaged it
Initial Setup Instructions
Read the safety notices and important tips in the included manuals
before using your computer.
Install battery pack:
Your battery is ready to use. 2
Connect to power:
1
1
Turn on the power: 6
Point and click with UltraNav(R) Multi-pointing Navigation System:
Press the TrackPoint cap or move across the touch pad in the direction you want to move
the pointer. The left and right buttons below the space bar and touch pad function like
mouse buttons. Some models may have only a TrackPoint.
Configure the Operating System following on-screen instructions:
This process takes several minut es, and your computer may restart mul
For more detailed information, press the ThinkVantage(R) button:
Power cord AC adapter
- Setup Instructions (this sheet)
- Safety and Warranty Guide
- Service and Troubleshooting Guide
- Other supplements or flyers
ems and recovery CD.
1
2
2 3
tiple times.
7
Size : 11x14 inches
Color : 2 color job = Process Black (This plate must be printed in PMS Process Black C)
Process Magenta (This plate must be printed in PMS 032cvc)
Font : IBM Fonts and Helvetica Neue Family
Material : 100 gsm gloss art paper (Us
Blue line shows die-cut. DO NOT PRINT .
Please change the barcode No.
Please change the country name if the poster is printed in other than China.
1
UltraConnect(TM) wireless
LAN antennas
2 ThinkLight(R) keyboard light
3
One - handed latch
4 Wireless WAN antenna*
*Specific models only.
5
Volume and mute buttons
6
Power button
7
ThinkVantage button
8
Web browser back and forward
9 Fingerprint reader*
*Specific models only.
12
10
TrackPoint center button
11 Wireless radio switch*
*Specific models only.
Fn key
12
Use in combination with other keys to a ccess special ThinkPad featu
Lock your computer
Manage battery & power
Enter standby
Manage wireless connections
Change display settings
Change input device settings
Manage external devices
e 100% recycled paper in only J apan. )
1 3
2
5 7 6
8
10
9
11
res
Enter hibernation
ThinkLight on/off
Multimedia controls
Change display brightness
Magnify screen contents
1
4
P/N: 42T7974
