Page 1: Gigabit Ethernet Switches
24-Port Gigabit Ethernet Switches ’ ’ DOC.100505... - Page 2 2. Features 24-Port 10/100/1000Mbps Auto-Negotiation and Auto-MDI/MDI-X Gigabit Ethernet Switch Complies with the IEEE 802.3 10Base-T Ethernet, IEEE 802.3u 100Base-TX Fast Ethernet and IEEE 802.3ab 1000Base-T Gigabit Ethernet standards IEEE 802.3x Flow Control for Full-duplex and Back Pressure for Half-duplex...
-
Page 3: Package Contents
Rackmount Kit. User guide CD Power cord. Gigabit Ethernet Switch 4. Hardware Introduction 4.1 Front Panel The unit front panel provides a simple interface monitoring the Switch. See the chart in section 4.2 for the status of each LED denotes.. - Page 4 4.2 LED Displays 4.3 Rear Panel The rear panel of the Gigabit Ethernet Switch indicates an AC inlet, which accepts 100-240VAC 50-60Hz power input.
-
Page 5: Specifications
Temperature Humidity Power Input Registrations IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, IEEE 802.3x Flow control - Ethernet : 10Mbps(half-duplex), 20Mbps(full-duplex) - Fast Ethernet : 100Mbps(half-duplex), 200Mbps(full-duplex) - Gigabit Ethernet : 2000Mbps(full-duplex) Power, Link/Act, 10/100Mbps – Green 1000Mbps – Orange 24 10/100/1000Mbps RJ-45 Auto-MDI / MDI-X Ports -10Base-T : Cat.3, 4, 5 or higer... -
Page 6: Fcc Warning
5. FCC Warning This equipment has been tested and found to comply with the regulations for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with this user’s guide, may cause harmful interference to radio communications.
