Consumer: Retain This Manual For Future Reference.
In the Commonwealth of Massachusetts:
• Installation must be performed by a licensed plumber or gas fitter
• See Table of Contents for location of additional Commonwealth of
Massachusetts requirements
(Para Instrucciones en español, ver la página 15)
• Hot! Do not touch! This appliance will be hot during operation and will retain heat for a while after shutting
off the appliance. Severe burns may result.
• Carefully supervise children in the same room as appliance.
• Due to high temperatures, the appliance should be located out of traffic and away from furniture or draperies.
Do not place clothing or other materials on or near this appliance.
• Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to this
manual. For assistance or additional information consult a qualified installer, service agency or the gas supplier.
• Do not build a wood fire. Do not burn wood or other material in these appliances.
• This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed. Provisions for adequate
combustion and ventilation air must be provided. Refer to Combustion and Ventilation Air Section.
• This appliance may be installed in an aftermarket, permanently located, manufactured (mobile) home, where not prohibited
by local codes.
• The appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use
with other gases.
WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property
damage, personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• DO NOT light any appliance.
• DO NOT touch any electrical switches.
• Do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow your gas supplier's instructions.
• If your gas supplier cannot be reached, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
INSTALLATION AND OPERATION INSTRUCTIONS
Catalytic Vent - Free Wall-Mounted
Fireplace
Model: Scandium-NG
P/N 850,055M Rev. NC, 04/2007
Installer: Leave This Manual With The Appliance.
Report No. :
WARNINGS
Scandium
317-S-05-5
TM

Advertisement

Chapters

Table of Contents
loading

Related Manuals for Lennox Hearth Products Scandium-NG

Summary of Contents for Lennox Hearth Products Scandium-NG

  • Page 1 • If your gas supplier cannot be reached, call the fire department. Installation and service must be performed by a qualified installer, service agency or the gas supplier. INSTALLATION AND OPERATION INSTRUCTIONS Fireplace Model: Scandium-NG P/N 850,055M Rev. NC, 04/2007 WARNINGS Scandium Report No.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Section Contents General Information Packaging List Appliance Data Important Safety Information Codes Combustion and Ventilation Air Site Requirements Preparing the Appliance Mounting the Appliance 10.0 Checking the Burner 11.0 Connecting a Gas Line 12.0 Checking the Gas Connections 13.0 Gas Pressure Check 14.0...
  • Page 3 4.0 IMPORTANT SAFETY INFORMATION (continued) T H E F O L L O W I N G B O X E D I N F O R M AT I O N A P P L I E S T O REQUIREMENTS FOR THE COMMONWEALTH OF MASSACHUSETTS.

  • Page 4: Codes

    527 CMR 30 upon sale of the unit. Please refer to section 4.0 on page 2 of this manual. This Lennox Hearth Products unvented gas room heater is certified by OMNI-Test Laboratories, Inc to ANSI Z21.11.2-2007 standard. 6.0 COMBUSTION AND VENTILATION AIR...

  • Page 5: Preparing The Appliance

    7.0 SITE REQUIREMENTS (continued) Clearances to non-combustibles Non-combustible surfaces are defined as brick, metal, marble, concrete etc. and also a number of man-made materials impervious to flame. If in doubt refer to the material manufacturer for further information before proceeding with installation. Clearances to the sides of the appliance are 4”.

  • Page 6: Checking The Burner

    9.0 MOUNTING THE APPLIANCE (continued) WARNING THE WALL WHERE THE APPLIANCE IS TO BE INSTALLED MUST BE CAPABLE OF LONG-TERM SUPPORT OF THE TOTAL LOAD OF THE APPLIANCE. MEASURES SHOULD ALSO BE TAKEN TO ENSURE SUFFICIENT STRENGTH TO WITHSTAND THE FORCE OF EARTHQUAKES, VIBRATION AND OTHER EXTERNAL FORCES.

  • Page 7: Checking The Gas Connections

    12.0 CHECKING THE GAS CONNECTIONS Turn on gas supply and test for gas leaks using a gas leak test solution (also referred to as bubble leak solution). NOTE: using a soapy water solution (50% dish soap, 50% water) is an effective leak test solution, but it is not recommended, because the soap residue that is left on the pipes/fittings can result in corrosion over time.

  • Page 8: Fitting The Glass Facia

    15.0 ASSEMBLY OF THE GLASS FACIA - (continued) 2. Slide on the side pieces ensuring that the grille fixing holes (shown) are aligned towards the top of the glass facia (as shown in figure 11). Grille fixing holes Figure 11 3.Ensure the sides are neatly aligned with the glass and secure the sides using two M6 screws for each side as shown in figure 12.

  • Page 9: Briefing The Customer

    17.0 FITTING THE SIDE PANELS (continued) Insert screwdriver through the holes in the right hand side panel to access the two M6 fixing screws (designated ‘a’ in figure 17) and tighten fully. Next insert two no.8 self tapping screws (designated ‘b’...

  • Page 10: Pilot Assembly

    21.0 PILOT ASSEMBLY WARNING NO ADJUSTMENTS ARE TO BE MADE TO THE ODS PILOT SYSTEM. TAMPERING WITH THIS SYSTEM CAN BE EXTREMELY HAZARDOUS. Remove the glass facia, glass panel and burner unit (as per servicing section), lint arrestor and pilot unit by using a screwdriver to remove the retaining screws.

  • Page 11: Lighting Instructions

    IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. This heater has a pilot which must be lit by hand. When lighting the pilot, follow these instructions exactly. BEFORE OPERATING smell all around the heater area for gas.

  • Page 12: Troubleshooting Guide

    If you encounter any problems, require spare parts, or have any H6055 questions concerning the installation of the heater please contact your H6059 distributor. For the name of your nearest distributor contact: H6060 H6061 LENNOX HEARTH PRODUCTS H6056 1110 West Taft Avenue H6062 Orange, CA 92865 H6063 Phone: 1-800-9-Lennox H6068 visit us at www.Lennox.com...

  • Page 13: Positioning Of Field Assembled Parts

    29.0 POSITIONING OF FIELD REMOVABLE PARTS 4 off burner installation positions Figure 21 FAILURE TO POSITION THE PARTS IN ACCORDANCE WITH THESE DIAGRAMS OR FAILURE TO USE ONLY APPROVED WITH THIS HEATER MAY RESULT IN DAMAGE OR PERSONAL INJURY. Figure 21: Removal and refitting of glass door assembly and burner assembly.

  • Page 14: Period

    THE WARRANTY Lennox Hearth Products ("LHP") warrants your gas fireplace, appliance, stove or insert ("Product") to be free from defects in materials and workmanship at the time of manufacture. After installation, if any of the components manufactured by LHP in the Product are found to be defective in materials or workmanship during the twenty year warranty period and while the Product remains at the site of the original installation, LHP will, at its option, replace or repair the defective components.
  • Page 15 • Si no puede contactar con su compañía de gas, llame a los bomberos. La instalación y el mantenimiento deben ser realizados por un instalador o empresa de mantenimiento autorizado, o por la compañía de gas. INSTRUCCIONES DE INSTALACIÓN Y OPERACIÓN Modelo : Scandium-NG P/N 850,055M Rev. NC, 04/2007 ADVERTENCIAS Scandium Informe N°:...

  • Page 16: Sit/Bray 9082

    CONTENIDO Sección Contenido Información general Lista de embalaje Especificaciones del aparato Información de seguridad importante Normativa Aire de combustión y ventilación Requisitos del lugar de ubicación Preparación del aparato Montaje del aparato 10.0 Comprobación del quemador 11.0 Conexión de un conducto de gas 12.0 Comprobación de las conexiones de gas 13.0...
  • Page 17 4.0 INFORMACIÓN DE SEGURIDAD IMPORTANTE (cont.) EN EL SIGUIENTE RECUADRO SE INDICAN LOS REQUISITOS ESPECÍFICOS DEL ESTADO DE MASSACHUSETTS. 5. El inspector de gas estatal o local no realizará la inspección final del calentador sin salida de humos hasta que se demuestre que el jefe de bomberos competente ha otorgado su permiso.

  • Page 18: Normativa

    527 CMR 30 en el momento de la venta de la unidad. Consulte la sección 4.0 en la página 2 de este manual. Este calentador de gas sin salida de humos de Lennox Hearth Products está certificado por OMNI-Test Laboratories, Inc con arreglo a la norma ANSI Z21.11.2-2007.

  • Page 19: Preparación Del Aparato

    7.0 REQUISITOS DEL LUGAR DE UBICACIÓN (cont.) Espacio libre hasta superficies no combustibles Las superficies no combustibles se definen como ladrillo, metal, mármol, hormigón etc., así como diversos materiales artificiales que son insensibles a las llamas. En caso de duda, solicite más información al fabricante del material antes de proceder con la instalación.

  • Page 20: Comprobación Del Quemador

    Para garantizar la seguridad del usuario, diseñe la instalación de manera tal que la resistencia de la pared y de los accesorios utilizados sea suficiente. Lennox Hearth Products no asume ninguna responsabilidad por lesiones y daños que puedan producirse a consecuencia de una instalación o un manejo inadecuados.

  • Page 21: Comprobación De Las Conexiones De Gas

    12.0 COMPROBACIÓN DE LAS CONEXIONES DE GAS Abra el suministro de gas y verifique que no hay fugas usando una solución para detectar fugas de gas (también conocida como detector de burbujas). NOTA: El uso de una solución de agua jabonosa (50% jabón de mano, 50% agua) es una solución eficaz para buscar fugas, pero no se recomienda porque el residuo de jabón que queda en las tuberías y los acoplamientos puede producir corrosión con el tiempo.

  • Page 22: Montaje Del Panel Decorativo De Vidrio

    15.0 ARMADO DEL PANEL DECORATIVO DE VIDRIO (cont.) 2. Deslícelo por las piezas laterales y asegúrese de que los orificios de fijación de la rejilla (que se ilustran) queden alineados hacia la parte superior del panel decorativo de vidrio (según se muestra en la figura 11). Orificios de sujeción de la rejilla Figura 11...

  • Page 23: Información Al Cliente

    17.0 COLOCACIÓN DE LOS PANELES LATERALES (cont.) Introduzca un destornillador a través de los orificios del panel de la derecha y apriete los dos tornillos de fijación M6 (tornillos ‘a’ en la figura 17). Luego introduzca dos tornillos autorroscantes Nº 8 (tornillos ‘b’...

  • Page 24: Montaje Del Piloto

    21.0 CONJUNTO DEL PILOTO ADVERTENCIA NO DEBEN EFECTUARSE AJUSTES EN EL SISTEMA DE PILOTO ODS. LA MANIPULACIÓN DE ESTE SISTEMA PUEDE SER EXTREMADAMENTE PELIGROSA. Retire el panel decorativo de vidrio, la puerta de vidrio y el conjunto del quemador (según lo indicado en la sección de mantenimiento), el filtro de malla y el conjunto del piloto usando un destornillador para retirar los tornillos de fijación.

  • Page 25: Instrucciones De Encendido

    PARA SU SEGURIDAD, LEA ANTES DE ENCENDER EL APARATO SI USTED NO OBSERVA ESTRICTAMENTE ESTAS INSTRUCCIONES, PUEDE PRODUCIRSE UN INCENDIO O UNA EXPLOSIÓN, CON RESULTADO DE DAÑOS MATERIALES, LESIONES PERSONALES O PÉRDIDA DE LA VIDA. El calentador tiene un piloto que debe ser encendido manualmente. Para encender el piloto, siga estas instrucciones exactamente.

  • Page 26: Guía De Solución De Problemas

    H6059 distribuidor. Para saber cuál es el distribuidor más cercano a su domicilio, H6060 diríjase a: H6061 H6056 LENNOX HEARTH PRODUCTS H6062 1110 West Taft Avenue H6063 Orange, CA 92865 H6068 Teléfono: 1-800-9-Lennox...

  • Page 27: Ubicación De Piezas Ensambladas In Situ

    29.0 UBICACIÓN DE PIEZAS SUSTITUIBLES IN SITU 4 posiciones de instalación del quemador Figura 21 EL NO UBICAR LAS PIEZAS EN LOS LUGARES SEÑALADOS EN ESTOS DIAGRAMAS, O LA UTILIZACIÓN DE PIEZAS OFICIALMENTE PARA EL USO CON ESTE CAUSAR DAÑOS MATERIALES O LESIONES PERSONALES.

  • Page 28: Period

    GARANTÍA Lennox Hearth Products ("LHP") garantiza que su calentador de gas, aparato, estufa o accesorio ("el Producto") está libre de defectos de materiales y mano de obra en el momento de su fabricación. Después de la instalación, si alguno de los componentes del Producto fabricado por LHP presenta defectos de materiales o mano de obra durante el periodo de cobertura de la garantía de 20 años y mientras el Producto se conserve en el lugar de instalación original, LHP, a su opción, sustituirá...
