Sharp LC-60E77UN Service Manual page 117

NO. PARTS CODE
[12] PACKING PARTS (NOT REPLACEMENT ITEM)
S1
SPAKCF070WJZZ
S1
SPAKCF071WJZZ
S1
SPAKCF294WJZZ
S1
SPAKCF290WJZZ
S3
SPAKCF063WJZZ
S3
SPAKCF065WJZZ
S4
SPAKPB427WJZZ
S4
SPAKPA962WJZZ
S5
SPAKPB428WJZZ
S6
SPAKXC634WJZZ
S6
SPAKXC635WJZZ
S7
SSAKA0101GJZZ
S8
SSAKAA032WJZZ
S9
TLABKA009WJZZ
S10
SPAKSA017WJZZ
[13] SERVICE JIGS (USE FOR SERVICING)
N
QCNW-C222WJQZ
N
N
QCNW-F676WJQZ
N
N
QCNW-H184WJQZ
N
N
QCNW-G401WJQZ
N
N
QCNW-H762WJQZ
N
N
QCNW-H649WJPZ
N
N
QCNW-J279WJQZ
N
N
QCNW-K277WJQZ
N
N
QCNW-G405WJQZ
N
N
QCNW-K077WJQZ
N
N
QCNW-H017WJQZ
N
N
QCNW-H018WJQZ
N
N
QCNW-K276WJQZ
LC-60E77UN/LC-65E77UM/LC-C6077UN/LC-C6577UM
PRICE NEW PART
RANK MARK
DELIVERY
Packing Case (LC-60E77UN)
- N -
Packing Case (LC-65E77UM)
- N -
Packing Case (LC-C6077UN)
- N -
Packing Case (LC-C6577UM)
- N -
Packing Case Bottom (LC-60E77UN/C6077UN)
- N -
Packing Case Bottom (LC-65E77UM/C6577UM)
- N -
Wrapping Paper (LC-60E77UN/C6077UN)
- N -
Wrapping Paper (LC-65E77UM/C6577UM)
- -
Wrapping Paper
- N -
- N - packing ADD (LC-60E77UN/C6077UN)
- N - packing ADD (LC-65E77UM/C6577UM)
- - Polyethylene Bag
Polyethylene Bag
- -
Case No. Label
- -
C-PAD (LC-60E77UN/C6077UN)
- -
AW J Connecting Cord (L=1000mm 80Pins), x2
LCD Control - LCD Panel
Connecting Cord (L=1000mm 41Pins)
BH J
MAIN - LCD Control (LW)
Connecting Cord (L=1000mm 12Pins)
AX J
MAIN - POWER (PD)
Connecting Cord (L=1000mm 4-5Pins)
AP J
MAIN - KEY (KM)
Connecting Cord (L=1000mm 10Pins)
AV J
MAIN - R/C, LED (RA)
Connecting Cord (L=1000mm 4Pins)
AP J
MAIN - SPEAKER (SP)
Connecting Cord (L=1000mm 15Pins) (LC-60E77UN/C6077UN)
AY J
MAIN - LCD Control (LP)
Connecting Cord (L=1000mm 9-10-14Pins) (LC-60E77UN/C6077UN)
N J
MAIN (LB) - POWER (LA1) - INVERTER (LA)
Connecting Cord (L=1000mm 4Pins) (LC-60E77UN/C6077UN)
AP J
MAIN - LCD Control (PL)
Connecting Cord (L=1370mm 9Pins) (LC-65E77UM/C6577UN)
N J
MAIN - INVERTER (LB)
Connecting Cord (L=1000mm 3Pins) (LC-65E77UM/C6577UN)
AM J
MAIN POWER - SUB POWER (PP1) (PP2)
Connecting Cord (L=1000mm 2Pins) (LC-65E77UM/C6577UN)
AK J
MAIN POWER - SUB POWER (PP3)
Connecting Cord (L=1000mm 12Pin-MAIN 15Pins/SUB POWER 4Pin (FR)) (LC-
N J
65E77UM/C6577UM)
25
DESCRIPTION
