Radio Shack Keychain-Remote Control System Owner's Manual

Keychain-Remote Control System
Your RadioShack Keychain-Remote Control
System is a valuable accessory for your Wire-
less Remote Control System. With this switch
and transceiver, you can individually turn on
or off lights or appliances from any location in
your home. Using the remote, you can turn
on and off a lamp or appliance connected to
the transceiver. You can also turn on and off
other lamps or appliances attached to your
optional Plug 'n Power receivers.
®
This remote control system is compatible
with other Plug 'n Power systems and con-
trollers, all of which are available from your
local RadioShack store.
PREPARATION
1. Using a small screwdriver, set the house
code dial of the transceiver and the dial
of the remote (located inside the
remote's battery compartment) to the
same letter.
Remote
I
E M
A
2. Set the slide switch inside the remote's
battery compartment to the unit code of
the lamps or appliances you want to
control (1 and 2, or 5 and 6). Set the unit
code on each optional lamp/appliance
module to correspond to the same num-
ber setting on the slide switch.
1, 2 5, 6
OWNER'S MANUAL — Please read before using this equipment.
Transceiver
A
O C
M E
K
G
I
©
1999, 2000 RadioShack Corporation. All Rights Reserved.
RadioShack and RadioShack.com are trademarks
Note: Regardless of the switch setting,
the transceiver always turns on a con-
nected lamp or appliance using Button 1.
Your appliance switch requires two AAA bat-
teries (not supplied) for power. For the best
performance and longest life, we recom-
mend RadioShack alkaline batteries.
Cautions:
• Use only fresh batteries of the required
size and recommended type.
• Do not mix old and new batteries or dif-
ferent types of batteries.
Follow these steps to install batteries.
1. Slide the battery compartment cover in
the direction of the arrow to remove it.
2. Place the batteries in the compartment
as indicated by the polarity symbols (+
and –) marked inside. Then replace the
cover.
3. Plug the transceiver into a standard AC
outlet, then fully extend the transceiver's
antenna. Plug the lamp or appliance into
the transceiver. If you plug the trans-
ceiver into a switched outlet, turn the
switch on.
When a lamp or appliance does not reliably
respond to the remote's command, replace
the batteries.
Warning: Dispose of old batteries promptly
and properly. Do not burn or bury them.
Caution: If you do not plan to use the remote
switch for several weeks, remove the batter-
ies. Batteries can leak chemicals that can
destroy electronic parts.
used by RadioShack Corporation.
