Summary of Contents for TP-Link JETStream T2700G-28TQ
- Page 1 Business Networking Solution Installation Guide Stackable L2+ Managed Switch T2700G-28TQ Stackable L3 Managed Switch T3700G-28TQ...
-
Page 2: Fcc Statement
No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2015 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved. - Page 3 The User Guide and CLI Reference Guide of the product are provided on the resource To obtain the latest product information, please visit the Official Website: http://www.tp-link.com About this Installation Guide This Installation Guide describes the hardware characteristics, installation methods and the points that should be attended to during installation.
- Page 4 Network Engineer Network Administrator Conventions Due to the similarity in structure of TP-LINK Jetstream Stackable Managed Switch Series, in this Installation Guide we take T3700G-28TQ as an example to illustrate Chapter 2 Preparing for Installation, Chapter 3 Installation, Chapter 4 Lightening Protection and Chapter 5 Connection.
-
Page 5: Table Of Contents
Contents Chapter 1 Introduction ———————————— 01 Product Overview .........01 Appearance ..........01 Chapter 2 Preparing For Installation —————— 05 Package Contents .........05 Safety Precautions ........05 Installation Tools ..........07 Installation & Connection Flow ......07 Chapter 3 Installation ————————————— 09 Installing the Switch on a Desktop ....09 Installing the Switch Into a 19-inch Rack ...09 Installing &... -
Page 6: Chapter 1 Introduction
Obtain the T2700G-28TQ Layer 3 License T2700G-28TQ-L1000 via the following steps： 1. Buy a license key from a TP-LINK authorized distributor. 2. Go to T2700G-28TQ page on TP-LINK website, use the license key together with the switch S/N and the MAC address for authentication to download the license T2700G- 28TQ-L1000. - Page 7 Stackable L2+/L3 Managed Switch LEDs Status Indication The switch is powered on Power The switch is powered off or power supply is abnormal Flashing Power supply is abnormal Flashing The switch works properly System On/Off The switch works improperly Both the Power Supply Module and the redundant Green power supply work properly The Power Supply Module works improperly, but the...
- Page 8 Port 25-26, designed to install the 10Gbps SFP+ transceiver or SFP+ cables. T3700G-28TQ also provides an interface card slot on the rear panel to install the expansion card (TX432 of TP-LINK for example). If TX432 is installed, you get another two 10Gbps SFP+ ports.
- Page 9 RPS Input Connector Designed to connect the RPS (Redundant Power Supply). You can selected an RPS of TP-LINK (RPS150 for example) for your switch if needed. For how to install an RPS, please refer to 5.6 Power on via Redundant Power Supply.
-
Page 10: Chapter 2 Preparing For Installation
Stackable L2+/L3 Managed Switch Chapter 2 Preparing For Installation 2.1 Package Contents Make sure that the package contains the following items. If any of the listed items is damaged or missing, please contact your distributor. One Switch (One PSM150-AC O n e Po w e r C o rd a n d o n e This Installation Guide included) Console Cable... - Page 11 Stackable L2+/L3 Managed Switch Please keep a proper temperature and humidity in the equipment room. Too high/low humidity may lead to bad insulation, electricity leakage, mechanical property changes and corrosions. Too high temperature may accelerate aging of the insulation materials and can thus significantly shorten the service life of the device.
-
Page 12: Installation Tools
Stackable L2+/L3 Managed Switch instant current is strong enough to damage electronic devices, more effective lightning protection measures should be taken. Ensure the rack and device are well earthed. ■ Make sure the power socket has a good contact with the ground. ■... - Page 13 Stackable L2+/L3 Managed Switch The Installation & Connection flow is shown as the following figure. Start Install the switch to the specified position Connect to the ground Install Interface Card? Install the Interface Card Verify installation Power on via Power Supply Module Connect to SFP/SFP+ transceivers and cables...
-
Page 14: Chapter 3 Installation
Stackable L2+/L3 Managed Switch Chapter 3 Installation 3.1 Installing the Switch on a Desktop To install the switch on the desktop, please follow the steps below: 1. Set the switch on a flat surface strong enough to support the entire weight of the device with all fittings. -
Page 15: Installing & Removing The Power Supply Module
Stackable L2+/L3 Managed Switch 3. After the brackets are attached to the switch, use suitable screws (not provided) to secure the brackets to the rack, as illustrated in the following figure. Rack Figure 3-3 Rack Installation Caution: Please set 5~10cm gaps around the device for air circulation. ■... -
Page 16: Installing & Removing The Interface Card
Stackable L2+/L3 Managed Switch 2. If the protective cover has been installed on the power supply module slot of the switch, use a Phillips screwdriver to loosen the mounting screws of the protective cover and remove the protective cover, as shown in the following figure. Figure 3-4 Removing the Protective Cover 3. -
Page 17: Stacking Using Interface Card On Rear Panel
Stackable L2+/L3 Managed Switch 3. Hold the captive screws on the front panel of the interface card, and gently push the interface card in along the slot guide rail until the interface card is flush with the switch, as shown in the following figure. Switch Figure 3-6 Installing the Interface Card 4. - Page 18 5. You can access to any member of the stack via Web/SSH/Telnet/Console connection, thus to manage all the switches in the stack. Caution: In the process of using TP-LINK SFP+ Cables, please never bend them into a radius of 45mm (1.77 inch) or less, because it may permanently damage the SFP+ Cables.
-
Page 19: Chapter 4 Lightning Protection
Stackable L2+/L3 Managed Switch Chapter 4 Lightning Protection 4.1 Cabling Reasonably In the actual network environment, you may need cable outdoors and indoors, and the requirements for cabling outdoors and indoors are different. A reasonable cabling system can decrease the damage of induced lightning to devices. Note: It’s not recommended using Ethernet cables outdoors. - Page 20 Stackable L2+/L3 Managed Switch Requirements for the distance between Ethernet cable and other pipelines are shown ■ in the table. Ethernet Cable Other Pipelines Min Parallel Net Length Min Parallel-overlapping Net Height L (mm) H (mm) Down-conductor 1000 Service pipe Compressed air pipe Thermal pipe (not wrapped) 500 Thermal pipe (wrapped)
-
Page 21: Connect To Ground
Stackable L2+/L3 Managed Switch 4.2 Connect to Ground Connecting the device to ground is to quickly release the lightning over-voltage and over-current of the device, which is also a necessary measure to protect the body from electric shock. In different environments, the device may be grounded differently. The following will instruct you to connect the device to the ground in two ways, connecting to the grounding bar or connecting to the ground via the power cord. -
Page 22: Equipotential Bonding
Stackable L2+/L3 Managed Switch Note: The figure is to illustrate the application and principle. The power cord you get from ■ the package and the socket in your situation will comply with the regulation in your country, so they may differ from the figure above. If you intend to connect the device to the ground via the PE (Protecting Earth) cable ■... -
Page 23: Use Lightning Arrester
Stackable L2+/L3 Managed Switch 4.4 Use Lightning Arrester Power lightning arrester and signal lightning arrester are used for lighting protection. Power lightning arrester is used for limiting the voltage surge due to a lightning. If an outdoor AC power cord should be directly connected to the device, please use a power lightning arrester. -
Page 24: Chapter 5 Connection
Stackable L2+/L3 Managed Switch Chapter 5 Connection 5.1 Ethernet Port Connect the Ethernet ports of the switch to the network devices by RJ45 cable as the following figure shown. RJ45 Port RJ45 Cable Figure 5-1 Connecting the RJ45 Port 5.2 SFP/SFP+ Port Connect an SFP transceiver to the SFP port, or connect an SFP+ transceiver/cable to the SFP+ port. -
Page 25: Verify Installation
Stackable L2+/L3 Managed Switch Connect the console port of the device with your computer by the console cable as the following figure shown. Figure 5-3 Connecting the Console Port You can also manage the device through the console port, for details please refer to the CLI Reference Guide on the resource CD. -
Page 26: Power On Via Redundant Power Supply
Stackable L2+/L3 Managed Switch Figure 5-4 Power on via PSM150-AC Note: The figure is to illustrate the application and principle. The power cord you get from the package and the socket in your situation will comply with the regulation in your country, so they may differ from the figure above. -
Page 27: Initialization
Stackable L2+/L3 Managed Switch Figure 5-6 Power on RPS150 Caution: Make sure the power supply of RPS150 is cut off when connecting or disconnecting RPS150 and the switch, otherwise both RPS150 and the switch may work abnormally or even be damaged. 5.7 Initialization After the device is powered on, it begins the Power-On Self-Test. -
Page 28: Chapter 6 Configuration
Stackable L2+/L3 Managed Switch Chapter 6 Configuration 6.1 Configure the Switch via GUI Note: To log on to the GUI of the switch, the IP address of your PC should be set in the same subnet addresses of the switch. The IP address is 192.168.0.x ("x" is any number from 2 to 254), Subnet Mask is 255.255.255.0. -
Page 29: Configure The Switch Using Cli
Stackable L2+/L3 Managed Switch Figure 6-3 Main Page of the Switch 6.2 Configure the Switch Using CLI You can log on to the switch and access the CLI by the following two methods: Log on to the switch by the console port on the switch. ■... - Page 30 Stackable L2+/L3 Managed Switch 3. The Connection Description Window will prompt as Figure 6-5. Enter a name into the Name field and click OK. Figure 6-5 Connection Description 4. Select the port to connect in Figure 6-6, and click OK. Figure 6-6 Select the port to connect 5.
- Page 31 Stackable L2+/L3 Managed Switch Figure 6-7 Port Settings 6. Type in the User name and Password in the Hyper Terminal window, the factory default value for both of them is admin. The DOS prompt ”T3700G-28TQ>” will appear after pressing the Enter button as Figure 6-8 shown. It indicates that you can use the CLI now.
- Page 32 Stackable L2+/L3 Managed Switch 3. Click Start→Run to open the Run window. Figure 6-9 Open the Run window 4. Type in cmd in the prompt Run window as Figure 6-10 and click OK. Figure 6-10 Run Window 5. Type in telnet 192.168.0.1 in the command prompt shown as Figure 6-11, and press the Enter button.
- Page 33 Stackable L2+/L3 Managed Switch 6. Type in the User name and Password (the factory default value for both of them is admin) and press the Enter button, then you can use the CLI now, which is shown as Figure 6-12. Figure 6-12 Log in the switch For detailed CLI configuration instructions, please refer to the CLI Reference Guide on the resource CD.
-
Page 34: Appendix A Troubleshooting
Stackable L2+/L3 Managed Switch Appendix A Troubleshooting What could I do if I forgot the username and password of the switch? 1. Connect the console port of the PC to the console port of the switch and open hyper terminal. 2. -
Page 35: Appendix B Hardware Specifications
